LED Group ROBUS R18230DL-01 User manual

Technical specification:
Issue 3 151213
Please read instruction before commencing installation and retain
for future reference.
Safety instructions:
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.led.ie
Page 1
Product code: R18230DL-01 R25230DL-01
Power supply: 100V - 240V~50/60Hz 100V - 240V~50/60Hz
Total power 18W 25W
Lumen output: 1450lm 2000lm
Color temperature: 4000K 4000K
Power factor: 0.95 0.95
CRI: 80 80
Beam angle: 110O 110O
Operating Temp range: -5OC ~ 35OC -5OC ~ 35OC
IP rating: IP54 IP54
Safety Classification: Class II Class II
Diameter : 230mm 230mm
Height: 58mm 58mm
Weight: 0.9Kg 0.9Kg
Cut out: 205mm 205mm
Warranty: 5 years 5 years
Installation: Recessed mounting
Suitable for mounting on normally flammable surface
Driver must never be “hot-plugged” or connected to the fitting when live.
Doing this may damage the fitting and will void the warranty.
Complete with driver with female connector and male connector
Complies with EN55015/A2:2009,EN61547:2009,EN61000-3-2/A2:2009,
EN61000-3-3:2008,EN60598-2-2:2012,EN60598-1/A11:2009,
EN62031:2008,EN62471:2008,EN62493:2010
Dimensions:
ISO 9001:2008
Q UAL IT Y ASSU RE DCO MPAN Y
Caution;
Recessed Luminaires may pose an increased risk of fire or property damage if not installed according to the instructions provided.
Luminaires not suitable for
covering with thermally
insulating material.
d
c
a
b
Thermal
insulation
Auxiliary
equipment
combustible building element above tting
combustible
building element
Dimension Clearance
a
b
c
d
200mm
200mm
50mm
100mm
R18230DL-01,
R25230DL-01
IP20 18W & 25W 230MM
4000K LED DOWNLIGHT, WHITE
Ø230mm
58mm

LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.led.ie
Page 2
Installation:
Information for the Product user
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre for
waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is important
that it is separated from normal household waste and recycled in the WEEE chain
4. The “crossed out wheelie bin symbol” on a product indicates this equipment must not be disposed of in normal household waste ,
but should be disposed of according to local WEEE regulations
!Electrical products can cause death or injury, or damage to property. This
product must be installed only by a competent electrician.
1. Ensure mains supply is switched off before commencing work
2. Before cutting, ensure that the hole does not impinge on joists, pipe work,
cables or other building services
Fig 3. Connect the lamp cable to the drive
by terminal connector, offer the luminaire
up to cut out
Fig 2.
Connect mains supply to the female
connector Brown to L and Blue to N and
connect male with female connector
,
place the driver on insulation.
Fig 4. The luminaire is retained in position by
the spring tension against the ceiling.
Fig 1. This luminaire requires a round hole
Ø205mm to be cut into the ceiling for
correct installation.
cut out
Ø205mm
The Installation must be carried out by an electrician
ISO 9001:2008
Q UAL IT Y ASSU RE DCO MPAN Y
L
Brown Blue
N
