Snapper 19E01 User manual

Parts Manual fo
r
Revision 1,
19" 120 VOLT ELECTRIC
SERIES 1
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5108-1-WB-N
9/27/2005 Manual No. 7015175
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
WALK BEHIND MOWER
MODEL
19E01
19E01D

Table Of Content
s
TP 400-5108-1-WB-N
Manual No. 701517519" 120 VOLT ELECTRIC
SERIES 1 3
PAGE GROUP
4HANDLES, DECK, MOTOR, & WHEELS
8CHUTE, BAG, & DECALS

HANDLES, DECK, MOTOR, & WHEELS
TP 400-5108-1-WB-N
Manual No. 7015175 19" 120 VOLT ELECTRIC
SERIES 1
4

HANDLES, DECK, MOTOR, & WHEELS
Footnotes:
TP 400-5108-1-WB-N
Manual No. 701517519" 120 VOLT ELECTRIC
SERIES 1 5
Part No Descri
p
tionItem Qt
y
Note
1 7019712 1 BLADE, Cutting
2 7014262 1 HUB, Blade
3 -- 1 *FAN, Cooling (B&S #280478) (Includes item 35)
4 40525 1 DECK (Weldment)
5 7032406 1 CLIP, Strain Relief
6 -- 1 *PLATE, Adapter (B&S #223184)
7 -- 1 *MOTOR, Electric Model #748001-0126-01
8 -- 1 *FILTER (B&S #271711)
9 -- 1 *SHROUD, Motor (B&S #280413) Includes 10 & 11
10 7014937 1 DECAL, Grass Bag Warning
11 7014898 1 DECAL, Discharge Warning
12 7051487 1 UPPER Handle Assembly
13 -- 1 *CONTROL, Electric (B&S #399192)
14 7014879 1 *N/A 04 DECAL, Starting
15 7014907 1 *N/A 2001 DECAL, Circuit
16 7014894 1 STRAIN-RELIEF, Harness
17 7012080 1 CABLE TIE, 7.0
18 7039746 1 HANDLE, Lower
19 7090015 2 RHSNB, 1/4C X1-3/4 GR2 YZ
20 7015693 2 WN, 1/4C ZP Was 14207
21 7091303 2 RHSSNB, 5/16C X1 GR5 YZ Was 90383
22 7090189 2 IETLW, 5/16 ZP
23 7032118 2 CLIP, Guard Retaining
24 7018444 1 GUARD, Rear Foot
25 7013320 4 BUSHING, Height Adjusting
26 7013027 2 SPRING, Rear Axle
27 7034357 2 AXLE, Front & Rear Was 37946
28 7013307 1 Spring, Front Axle
29 7013024 4 HUB-CAP 3/8 I.D.
30 7029399 2 WHEEL, Rear 8 x 1.75 Was 18485
31 7026160 2 WHEEL, Front 7 x 1.50 Was 18484
33 7090871 1 SCREW, 5/16-24 x 1-1/4” Hex Cap Gr. 5
34 7014263 2 WASHER, Cone
35 7014897 1 WASHER, 5/8 Spring
36 7090122 2 WASHER, 3/8” Flat
37 7090799 3 BOLT, 5/16-18 x 5/8” Short Neck Carriage Was 90388
38 7090388 2 T-NUT, 5/16C
*NOTE: Purchase engine components directly from engine manufacturer dealer.
Available through Briggs & Stratton

HANDLES, DECK, MOTOR, & WHEELS
TP 400-5108-1-WB-N
Manual No. 7015175 19" 120 VOLT ELECTRIC
SERIES 1
6

HANDLES, DECK, MOTOR, & WHEELS
Footnotes:
TP 400-5108-1-WB-N
Manual No. 701517519" 120 VOLT ELECTRIC
SERIES 1 7
Part No Descri
p
tionItem Qt
y
Note
39 7090799 3 BOLT, 5/16-18 x 5/8” Short Neck Carriage
40 7011791 3 RETAINER, 5/16 Bolt
41 7090188 3 WASHER, 5/16 Flat
42 7090851 3 HTLN, NYLON, 5/16C ZP
43 7090187 2 SLW, .318X.583X.078 ZP
44 7091511 2 HN, 5/16C GR5 YZ Was 90196
45 7090541 3 SCREW, 1/4-28 x 3/4” Hex Cap
46 7090053 3 WASHER, 1/4 Internal Tooth
47 7090095 3 NUT, 1/4-28 Hex
48 7090233 3 SCREW, 5/16-24 x 3/4” Hex Cap
49 7090480 3 NUT, 5/16-24 Hex Flange Lock
50 -- 2 NUT, #10-24 Hex Not available from Snapper,
check B&S engine manual.
51 7090894 2 SCREW, #10-24 x 1-3/8” Slotted Cap
52 7015114 2 INSULATOR, Handle
*NOTE: Purchase engine components directly from engine manufacturer dealer.
Available through Briggs & Stratton

CHUTE, BAG, & DECALS
TP 400-5108-1-WB-N
Manual No. 7015175 19" 120 VOLT ELECTRIC
SERIES 1
8

CHUTE, BAG, & DECALS
Footnotes:
TP 400-5108-1-WB-N
Manual No. 701517519" 120 VOLT ELECTRIC
SERIES 1 9
Part No Descri
p
tionItem Qt
y
Note
1 7053681 1 ADAPTER, Bag Was 19920
2 7047876 1 CONNECTOR, Bag Was 47736
3 7018413 1 BAG, Grass
4 7050711 1 ASSEMBLY, Rope & Slider
5 7018412 1 WIRE, Rear Bag
6 7035771 1 CHUTE, Side 19” Was 51224
7 7014808 1 DECAL, Warning
8 7013010 1 DECAL, Danger (Keep Hands & Feet Away)

Parts Manual fo
r
19" 120 VOLT ELECTRIC
SERIES 1
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
Revision 1,
COPYRIGHT
©
2005
TP 400-5108-1-WB-N
9/27/2005 Manual No. 7015175
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
McDonough, GA, 30253 U.S.A.
WALK BEHIND MOWER
