Snapper 7800849 User manual

Not for
Reproduction
Parts Manual fo
r
22" STEEL DECK WALK BEHIND
SERIES 20
COMMERCIAL MOWER
Revision: - 9/30/2013
Briggs & Stratton Yard Power Products Group
Manual No. 7106167
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
7800849 CP215520HV

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5566---CW-N
22" STEEL DECK WALK BEHIND
SERIES 20 3
Manual No. 7106167
PAGE GROUP
4Handle Group
8Wheels, Brackets & Latches
10 Deck, Engine & Blade Group
12 Drive System, Self Propelled
16 Transmission - Differential Group
18 Grass Bag & Adapter Group
20 Decal Group

Not for
Reproduction
Manual No. 7106167 22" STEEL DECK WALK BEHIND
SERIES 20
4
Handle Group

Not for
Reproduction
Footnotes:
Manual No. 710616722" STEEL DECK WALK BEHIND
SERIES 20 5
Handle Group
Part No Descri
p
tionItem Qty
1 7074411AYP 1 HANDLE, Upper
2 7023810YP 1 FOAM GRIP, 18.75
3 7074418AYP 1 BAIL, OPC Control (16.6” Wide)
4 7034872YP 1 CLIP, Zone Control
5 7074156AYP 1 HANDLE, Middle
6 7033985AYP 1 HANDLE, Lower, ADJ, LH
7 7033986AYP 1 HANDLE, Lower, ADJ, RH
8 7074140YP 1 PANEL, Control, No Electric Switch
9 703961 4 SCREW, 1/4-20 X .550, Self-Tapping, Zinc/Clear (Was 7900067 or 80005286)
10 7074473AYP 1 HANDLE, Clutch
11 7028407YP 1 GRIP, International Symbol, 4.6” Black
12 704031 1 PIN, 1/4 X 1.5”, Clevis, ZC/CL (Was 7011886, 7023792 or 80005708)
13 7014343YP 2 BUSHING, Flanged, .27 ID, Nylon, Black
14 704005 1 NUT, 1/4”, Push, Zinc/Clear (Was 7091020 or 80005599)
15 703234 1 SCREW, 1/4-20 X 1.5, Hex Head Cap, GR5, ZC/CL (Was 7090909, 7079577 or 80002713)
16 7102235YP 1 CABLE, Zone Control (60.3 Long)
17 703462 3 WASHER, 1/4 Internal Tooth Lock, YZ (Was 7090053 or 80004414)
18 703127 3 NUT, 1/4-20, G5 Zinc/Clear (Was 7090063, 7091576 or 80003586)
19 7023813SM 3 CLIP, Wiring Harness
20 7078026YP 1 CONTROL, Throttle, Honda, 50.81” L
21 7075308YP 1 KNOB, Throttle, Red
22 703163 2 SCREW, 1/4-20 X 2.0, Hex Head Cap, GR5, Zinc/Clear (Was 1921963, 90505 or 80003674)
23 7028488MA 1 GUIDE, 1/4-20, Rope, CL/ZC
24 15X145MA 1 NUT, 1/4-20, Nylock, GR A, Zinc/Clear (Was 703232, 7076978 or 80002730)
25 7034604YP 1 CABLE, Clutch Control, 41.25” L
26 7012121YP 1 COVER, Vinyl
27 7012122YP 1 SPRING, Clutch
28 7026219YP 1 CLAMP, 7/8” Double Cable
29 704063 6 BOLT, 5/16-18 X 1.50, Carriage Head, Short Neck, ZC/CL (Was 7091190 or 80005975)
31 7090391SM 6 WASHER, 5/16, Internal Lock, Zinc/Clear (Was 703587 or 80003683)
32 703465 6 NUT, 5/16-18, Hex, GR5, Zinc/Clear (Was 7091069, 7091511 or 80002725)
33 7074003YP 1 BRACKET, Shift
34 703589 1 SCREW, 3/8-16 x 2, Hex Head Cap, GR5, Zinc/Clear (Was 1923701, 7091305 or 80003522)
35 703964 2 WASHER, 7/16” ID, 1” OD, .060 Thk, Flat, ZC/CL (Was 7031961 or 80005597)
36 704004 2 WASHER, .406 ID X 1.0 OD X .063 Thk, Flat Nylon (Was 7028465 or 80005596)
37 7074113BMYP 1 LEVER, Shift
38 7075182YP 1 KNOB, Shift, Red
39 703351 1 SCREW, #8-32 X 0.50, Machine Fillister Head, Zinc/Clear (Was 7091167 or 80004404)
40 703460 1 NUT, #8-32, Hex, Zinc/Clear (Was 7091018 or 80004411)
41 704006 1 WASHER, 3/8” ID x 3/4” OD, Belleville, Zinc/Clear (Was 7028568 or 80005600)
42 703347 1 NUT, 3/8-16, Hex Center-Lock, GR B, Zinc/Clear (Was 7091585 or 80004408)
43 7074133YP 1 ROD, Speed Control (1/4-28 thread)
44 703350 1 WASHER, 5/16, Flat SAE, Zinc/Clear (Was 80004405)
45 704030 1 PIN, 5/16 X 1.044, Self-Locking Cotter, Zinc/Clear (Was 7034162 or 80005707)

Not for
Reproduction
Manual No. 7106167 22" STEEL DECK WALK BEHIND
SERIES 20
6
Handle Group

Not for
Reproduction
Footnotes:
Manual No. 710616722" STEEL DECK WALK BEHIND
SERIES 20 7
Handle Group
Part No Descri
p
tionItem Qty
46 703798 2 BOLT, 5/16-18 X .50, Carriage, Zinc/Clear (Was 7090731, 725993, 908156MA or 80004563)
47 690272MA 3 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)
48 7046707BMYP 2 BRACE, Handle
49 703301 1 SCREW, 5/16-24 x 1 Hex Head Cap, GR 5, BZ (Was MT910828MA or 80003532)
50 9357MA 3 SCREW, 5/16-18 X .750, Flanged Whiz-Lock, GR5 (Was 1930591, 1960738, 7090595 or
80003531)
51 703118 2 WASHER, 7/8, Flat, GR5, Zinc/Clear (Was 7091130, 7900022 or 80003517)
52 703947 1 NUT, 5/16-18 X .625, Weld, ZC/CL (Was 7090733, 7090895 or 80005534)
53 7012114SM 1 BUSHING, Differential
54 7034179BMYP 1 LINK, Differential, Commercial
55 703896 1 NUT, 5/16-24, Hex Center Lock, GR B, Zinc/Clear (Was 7091606, 7090174, 7090222 or
80004848)
56 7073913YP 1 BELL CRANK, Black Zinc
57 7015753YP 2 BALL JOINT, 1/4-28
58 703461 3 NUT, 1/4-28 Hex, GR5, Zinc/Clear (Was 7090095 or 80004412)
59 703408 1 SCREW, 5/16-18 x 7/8 Hex Head Cap, GR 5, Zinc/Clear (Was 80004421)
60 7073822BMYP 1 BRACKET, Bell Crank
61 690272MA 5 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)
62 703970 1 SPACER, .623 OD x .328 ID x .151 L (Was 7013849 or 80005375)
63 703167 1 SCREW, 5/16-18 x 1-1/4 Hex Washer Head Self-Tap (Was 1931202, 7091151, 7091524 or
80003681)

Not for
Reproduction
Manual No. 7106167 22" STEEL DECK WALK BEHIND
SERIES 20
8
Wheels, Brackets & Latches

Not for
Reproduction
Footnotes:
Manual No. 710616722" STEEL DECK WALK BEHIND
SERIES 20 9
Wheels, Brackets & Latches
Part No Descri
p
tionItem Qty
0010 703964 6 WASHER, 7/16” ID, 1” OD, .060 Thk, Flat, ZC/CL (Was 7031961 or 80005597)
0020 7600180YP 1 KIT, Front Wheel Arm Assembly, RH (Was 7051886)
0020-20 7012325YP 2 LATCH, Height
0020-30 703839 2 BOLT, 5/16-18 X .750, Hex Washer Head Shoulder, Zinc/Clear (Was 7015761 or 80004422)
0020-50 7031017YP 1 WHEEL ARM, Front, Round Hole, RH, Clear
0030 7054246YP 1 ASSEMBLY, Wheel Arm, Long, RR (Was 7054230YP)
0030-10 703840 2 BOLT, 5/16-18 X 1.0, Hex Washer Head .435 Dia. Shoulder, ZC/CL (Was 7011078 or
80004423)
0030-20 703297 4 RETAINER, 5/16 X .625, Push Nut, GR 5, Zinc/Clear (Was 1921982, 3031796 or 80003523)
0030-30 7012312YP 2 BEARING, 9/16” ID
0030-50 7032722YP 1 ARM, Wheel, Right Rear, Zinc/Clear
0030-60 7035717YP 2 LATCH, Height Adjusting, (long)
0030-70 703967 6 SCREW, #10-32 x 3/8, Torx Hex Washer Head Self-Tap, ZC/CL (Was 7091012 or 80005604)
0030-90 7103793YP 4 GRIP, Height Latch, Black (Was 7100633)
0040 7054247YP 1 ASSEMBLY, Wheel Arm, Left Rear, Long (Was 7054231YP)
0040-50 7032723YP 1 ARM, Wheel, Left Rear, Zinc/Clear
0050 703348 4 NUT, 7/16-20, Hex Jam Center Lock, GR B, Zinc/Clear (Was 7090377 or 80004407)
0060 690272MA 4 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)
0070 7021119YP 1 AXLE, V21
0080 7031960YP 2 HUBCAP, Rear
0090 7031121YP 4 HUBCAP, Front
0100 7600179YP 1 ASSEMBLY, Front Wheel Arm, LH (Was 7051885)
0100-50 7031016YP 1 WHEEL ARM, L.H. Front (Square Hole)
0110 7035727YP 2 WHEEL, 8 x 1.75 - Steel - D - Gray
---- 7011125YP 4 BEARING, 7/16” ID, Ball, Front Wheel (Not Shown)
0120 7035726YP 2 WHEEL, 10 x 1.75, Steel-D, (Self Propelled) - Gray

Not for
Reproduction
Manual No. 7106167 22" STEEL DECK WALK BEHIND
SERIES 20
10
Deck, Engine & Blade Group
