Parts Manual fo
r
21" VARIABLE SPEED
REAR DISCHARGE EUROPEAN MOWERS
Revision IR, TP 400-5403-IR-WB-N7/1/2008
Briggs & Stratton Yard Power Products Group
Manual No. 7006158
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
MODEL
ESPV21675 (7800253)

Table Of Content
s
TP 400-5403-IR-WB-N
21" VARIABLE SPEED
3
Manual No. 7006158
PAGE GROUP
4Handles and Controls
6Front and Rear Wheels
8Deck Assembly
12 Engine and Blade Assembly
14 Transmission
16 Decals

TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
4

Handles and Controls
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
5
Part No Descri
p
tionItem Qt
y
Note
1 7100225 4 SCREW, #8-16 Torxplus Recessed Pan Head, Twin Helix
2 7300670A 1 PLATE, Control Panel - Plastic Handle
3 2860694 2 NUT, 1/4-20, Hex Flange Nyloc
4 7101410 1 ROPE GUIDE (1/4-20 thread)
5 7101312 1 HANDLE, Plastic Upper, WBM
6 7101321BH 1 BAIL, Plastic Handle, WBM
7 7101416 1 ASSY, Control Head, 21” WBM, RD, Snapper (includes cable &
lever)
8 7090015 1 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2
9 7024649 3 WIRE TIE, 11 Inch Standard Black Nylon
10 7091508 6 BOLT, 5/16-18 x 3/4” Round Head Short Square Neck, GR5 YZ
11 7300567BH 1 BRACKET, Lower Handle, LH 21” WBM
12 7300566BH 1 BRACKET, Lower Handle RH 21” WBM
13 7090951 2 NUT, 5/16-18 Large Head Center Lock, Black
14 7300649BH 2 HANDLE, Connecting 21”/22” WBM
15 7101399 1 CABLE, Bail, 21” WBM, RD, Snapper 44.20” length
16 7300639BH 1 HANDLE, Lower, 21” WBM, RD
17 7101198 2 PIN, Handle Adjust
18 7101200 2 SPRING, Compression
19 7101199 2 BUSHING, Handle Pin
20 7101202 2 KNOB, Quick Release
21 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
22 7090391 2 WASHER, 5/16” Internal Tooth Lock
23 7035744 2 KNOB, 5/16-18 Wing (Black)
24 7091601 4 NUT, 5/16-18 Flange Lock, YZ

Front and Rear Wheels
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
6

Front and Rear Wheels
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
7
Part No Descri
p
tionItem Qt
y
Note
1 7100861 2 PIN, Axle
2 727782 1 SHIELD, Axle
3 7400275 1 WELDMENT, Rear Crossbar 21” WBM, RD also shown on Deck Assembly
page
4 7101367 2 DUST SHIELD, 21” WBM, RD
5 7100820 2 GEAR, Pinion
6 7014341 2 RETAINING RING Waldes #5133-50 or equiv.
7 7500540 2 ASSY, Wheel, 8 x 2 Idle, Snapper Tread, Charcoal Gray
8 7500647 1 ASSY, Wheel, 9” Snapper Tread w/Bearing Charcoal Gray incl 2 ball bearings, p/n 7101380
9 7100914 1 GEAR, External Wheel
10 7091196 6 SCREW, #8 x 1-1/4 Hi-Lo, Hex Washer Self-Tap
11 722604 4 WASHER, 1” OD x .387 ID, FLAT
12 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ
13 7101350 4 HUBCAP, 8” & 9” Wheel Spoked- Snapper Cool Gray
14 7400276 1 WELDMENT, Front Crossbar, 21” WBM, RD also shown on Deck Assembly
page

Deck Assembly
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
8

Deck Assembly
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
9
Part No Descri
p
tionItem Qt
y
Note
1 7101490 1 CHUTE, 21” Side Discharge
2 7091020 4 PUSHNUT, 1/4”
3 7101471 1 ROD, Pivot, Mulch Cover
4 722507 1 SPRING, Torsion, Chute
5 722848 17 SCREW, 1/4-20 x 11/16” Pan Head Torx, Self-Tap
6 7101437 1 COVER, 21” Mulching
7 7300590D 1 BRACKET, Chute Deflector
8 7091286 5 SCREW, #10-24 x 1/2” Hex Washer Self-Tap, SEMS
9 722503 1 SPRING, Torsion
10 720735 1 SPACER, Rear Door, 21”
11 7101314 1 ROD, Pivot, Rear Door, 21” RD
12 727785 1 DOOR, 21” Black
13 7400275 1 WELDMENT, Rear Crossbar 21” WBM, RD
14 7101774 2 BOLT, Shoulder (#10-24 thread)
15 7101430 1 ROD, Lifter Link
16 7101241 4 BUSHING, Front, 21”
17 7091892 2 PUSHNUT, 1/4 Black
18 7400276 1 WELDMENT, Front Crossbar 21” WBM, RD
19 7101304 1 GRASSBAG, 21” Rear Discharge
20 7101303A 1 BAG FRAME, 21” RD WBM
21 7026421 1 GRIP, Rectangular (Black)
22 7300723D 1 TRANSMISSION COVER, Rear 21”
23 7101434 1 SPRING, Extension, Height-of-Cut Assist
24 7101553 1 DEFLECTOR, Rear, 21” WBM, RD
25 720723 1 PLUG, Mulching
26 7101418 1 BEARING HOLDER, 21” WBM,RD
27 7078243 1 BALL BEARING, Axle
28 7091318 4 SCREW, 5/16-18 x 3/4” Hex Head Cap, GR 5 YZ
29 7091601 6 NUT, 5/16-18 Hex Flange Lock, GR 5, YZ
30 7091508 2 BOLT, 5/16-18 x 3/4” Round Head Short Square Neck, GR 5, YZ
31 7300587D 1 INDEX PLATE, Height-of-Cut, 21” WBM, RD
32 7300591D 1 BAFFLE, Right Rear, 21” WBM, RD
33 7300584D 1 DECK, 21” Rear Discharge
34 7091290 5 NUT, #10-24 Hex Nyloc
35 7300589D 1 BAFFLE, Left Rear, 21” RD, WBM
36 7091711 3 BOLT, #10-24 x 5/8” Flat Head Square Neck, YZ
37 7101502 1 BAFFLE, Extension, 21” RD WBM

Deck Assembly
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
10

Deck Assembly
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
11
Part No Descri
p
tionItem Qt
y
Note
38 7300585D 1 BAFFLE, Front 21” WBM, RD
39 724970 1 LEVER, Spring Height-of-Cut
40 724887 1 GRIP, Height-of-Cut

Engine and Blade Assembly
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
12

Engine and Blade Assembly
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
13
Part No Descri
p
tionItem Qt
y
Note
1 -- 1 * ENGINE, B&S, 675 Series Euro Mod. 126T02-0180-B1
2 7090324 3 SCREW, 3/8-16 x 1” Hex Washer Self-Tap
3 7300725D 1 BELT GUARD
4 7300724D 1 COVER, Belt
5 7091200 4 SCREW, 1/4-20 x 1/2” Pan Head Self-Tap, Torx
6 7100437 1 PULLEY, Engine
7 7092086 1 SET SCREW, 5/16-18 x 1/2” Hex Recess
8 7091214 1 KEY, #HP-506 Hi-Pro
9 7100883 1 BELT, 3L, Traction Drive, 21” Pivot Handle 3L Sect., 32.86” Effective Length
10 7101313 2 BELT GUIDE, Engine, 21” RD (1/4-20 thread)
11 7300596D 1 COVER, Belt Guard
12 722864 6 SCREW, #10 x 1/2”, AB, w/Washer
13 7091584 2 NUT, 1/4-20 Hex Flange Lock, GR 5, YZ
14 7101414 1 HUB, Blade, 21” WBM, RD, 2 Position
15 7100242 1 BLADE, Wave, 21” Steel Deck
16 7012063 1 WASHER, Cone
17 7090167 1 SCREW, 3/8-24 x 2” Hex Head Cap, GR 5
18 7101271 1 COVER, Front, 21” WBM, RD
NOTE: * Purchase engine parts from engine manufacturer dealer.

Transmission
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
14

Transmission
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
15
Part No Descri
p
tionItem Qt
y
Note
1 -- 1 ASSY, TRANSMISSION, 21 (not sold as an assembly)
2 7091195 2 SCREW, #10-16 x 3/4” Pan Head Self-Tap, Combo
3 7100863 1 BELT GUIDE, Transmission
4 7100883 1 BELT, Traction Drive, 21” Pivot Handle Section 3L, 32.86 effective length
5 1960251 1 NUT, 3/8-16 Hex Center Lock Jam, Black
6 7100240 1 PULLEY, Trans Var Speed, LC WBM
7 7101245 1 TRANSMISSION, 21” WBM, RD, Snapper
8 7900032 8 SCREW, 7mm x 1 x .550 AB Point

Decals
TP 400-5403-IR-WB-N
Manual No. 7006158 21" VARIABLE SPEED
16

Decals
Footnotes:
TP 400-5403-IR-WB-N
Manual No. 700615821" VARIABLE SPEED
17
Part No Descri
p
tionItem Qt
y
Note
1 7101540 1 DECAL, Front Cover, 21” RD, Snapper
2 7102153 1 DECAL, Briggs Engine, Snapper
3 7101536 1 DECAL, Control Head, VS, Snapper
4 7102381 1 DECAL, Engine, TP, 675 Snapper euro
5 7101084 1 DECAL, Warning, Euro, Multi-Panel
