Snapper S50X Series User manual

Parts
Rev. Date: 12/2007
S50X Series
Zero-Turn Riding Mower
Manual
5101101
5375 North Main Street
Munnsville, NY 13409 USA
800-933-6175
Briggs and Stratton Yard Power Products Group
TP 400-7345-IR-M5-SP
Models: Descri
p
tion:
5900683 S50XKAV1936, 36" 19HP Kawasaki Mid Mount Zero-Turn Rider
5900734 S50XBS1948, 48" 19HP Kawasaki Mid Mount Zero-Turn Rider
5900709 S50XBS2648, 48" 26HP Briggs & Stratton Mid Mount Zero-Turn Rider
IRRevision

Table Of Content
s
Tor
q
ue S
p
ecification Chart ............................................................................................. Inside Back Cover
MODEL COMPONENTS PAGE
Main Frame & Front Caster Group ..................................................................................................................................... 4
Rear Bumper Group ........................................................................................................................................................... 6
Seat Mount & Floor Group ................................................................................................................................................. 8
Fuel Tank Mount & Suppl
y
Group ...................................................................................................................................... 10
Instrument Control Panel Group ........................................................................................................................................
.
12
Engine & PTO Group - 26 HP Briggs & Stratton ................................................................................................................ 14
Engine & PTO Group - 19 HP Kawasaki ............................................................................................................................ 16
Pump Drive Group .............................................................................................................................................................
.
18
Motion Control Group ......................................................................................................................................................... 20
Hydraulic Group ................................................................................................................................................................. 22
Parkin
g
Brake Group .........................................................................................................................................................
.
24
Deck Lift Group .................................................................................................................................................................. 26
Transmission SERVICE PARTS ........................................................................................................................................ 28
Wheel & Tire Group ...........................................................................................................................................................
.
30
Decal Group - Brand & Model ............................................................................................................................................ 32
Decal Group - Safet
y
& Operation .....................................................................................................................................
.
34
36" & 48" Mower Deck - Hanger Chains ............................................................................................................................
.
36
48" Mower Deck - Housing, Covers, Spindles & Blades .................................................................................................... 38
48" Mower Deck - Pulle
y
s, Belts & Idler Arm Group ..........................................................................................................
.
40
36" Mower Deck - Housin
g
, Covers, Spindles & Blades ....................................................................................................42
36" Mower Deck - Pulleys, Belt & Idler Arm ....................................................................................................................... 44
48" Mower Deck - Rollers ..................................................................................................................................................
.
46

Main Frame & Front Caster Group
NOTE: Unless noted otherwise, use
the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2007 4 © Copyright Briggs and Stratton. All Rights Reserved.
5900683
5900709
5900734
TP 400-7345-IR-M5-SP

PART NO. DESCRIPTIONREF NO. QTY.
Main Frame & Front Caster Group
Footnotes
1 5025457 2 BOLT, 1/4-28 X 1/2, GD5 YZ
2 5402539D 2 WELD, CASTER YOKE, IS500Z
3 5020884 4 BEARING, TAPERED ROLLER, 1"
4 5021072 2 SEAL, GREASE
5 5025449 4 WASHER, BELLEVILLE - 1.500 X .755
6 5025448 2 NUT, 3/4-16, HEX JAM NYLON LOCK
7 5100882 2 CAP, CASTER SPINDLE, LOW PROFILE
8 5402841D 1 WELD, MAINFRAME, SNAPPER PRO 38-44 - RED
9 5100716 1 GROMMET, 2" ID
10 5021379 1 GROMMET, 7/8
11 5020883 1 CUP, BEARING (SV)
12 5020095 2 GREASE FITTING, 1/4-28 STRAIGHT
The above parts group applies to the following Mfg. Nos.:
2007 5 © Copyright Briggs and Stratton. All Rights Reserved.
5900683
5900709
5900734
TP 400-7345-IR-M5-SP

Rear Bumper Group
NOTE: Unless noted otherwise, use
the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2007 6 © Copyright Briggs and Stratton. All Rights Reserved.
5900683
5900709
5900734
TP 400-7345-IR-M5-SP

PART NO. DESCRIPTIONREF NO. QTY.
Rear Bumper Group
Footnotes
1 5025158 4 WASHER, 1/2 SAE
2 5025017X12 4 BOLT, 1/2-13 X 1-1/2 GD5 YZ
3 5025396 4 NUT, 1/2-13 HEX NYLOCK FLANGE
4 5025155 4 WASHER, 5/16 SAE
5 5025011X6 4 BOLT, 5/16-18 X 3/4 GD5
6 5025392 4 NUT, 5/16-18 HEX NYLOCK FLANGE
7 5403018D 1 PLATE, CARB GUARD - RED
8 5403573D 1 WELD, PLATE, BUMPER - RED
9 5403593D 1 SHIELD, MUFFLER - RED
The above parts group applies to the following Mfg. Nos.:
2007 7 © Copyright Briggs and Stratton. All Rights Reserved.
5900683
5900709
5900734
TP 400-7345-IR-M5-SP

Seat Mount & Floor Group
NOTE: Unless noted otherwise, use
the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
2007 8 © Copyright Briggs and Stratton. All Rights Reserved.
5900683
5900709
5900734
TP 400-7345-IR-M5-SP

PART NO. DESCRIPTIONREF NO. QTY.
Seat Mount & Floor Group
Footnotes
1 5025155 3 WASHER, 5/16 SAE
2 5025011X8 4 BOLT, 5/16-18 X 1 GD5 YZ
3 5025392 10 NUT, 5/16-18 HEX NYLOCK FLANGE
4 5025127 1 NUT, 5/16-18 HEX SERRATED FLANGE (SMALL)
5 5025011X10 1 BOLT, 5/16-18 X 1-1/4 GD5 YZ
6 5021878 1 SPACER, .25 X .37 X .25
7 5025144X6 1 BOLT, 1/4-20 X 3/4", CARRIAGE
8 5025391 1 NUT, 1/4-20 HEX NYLOCK FLANGE
9 5044617 2 WASHER, .34 X 1.25 X 10 GA
10 5025394 10 NUT, 3/8-16 HEX NYLOCK FLANGE
11 5403706D 1 PLATE, SIO FLOOR MOUNT - RED
12 5100909 1 SEAT, NO ARM REST
13 5403015D 1 SEAT PLATE, STOP - RED
14 7078299 2 SPRING, SEAT SUPPORT
15 5402859D 1 MOUNT, SEAT STOP - RED
16 5403555D 1 PLATE, FOOT REST - RED
17 5403574D 1 WELD, PLATE, SEAT MOUNT - RED
18 5023263 1 VINYL CLAMP
19 5101374 1 SAFETY WALK, FLOOR REST, 16.00 X 6.00
20 5101333 1 SAFETY WALK, FLOOR PLATE, S50X, 10X17.13
21 5101004 1 SAFETY WALK, 4.00 X 7.50
22 5025013X8 6 BOLT, 3/8-16 X 1 GD5 YZ
23 5025156 6 WASHER, 3/8 SAE
24 1686907 1 ARM REST (SET OF TWO) (SV)
25 5100636 1 SPRING, SEAT ADJUSTMENT (SV)
26 5061599X1 1 KIT, SEAT RAILS (COMPLETE)(SV)
27 197546 4 MOUNT, VIBRATION, RUBBER
28 5100383 2 BUMPER, ROPS
29 5025481 4 BOLT, 3/8-16 X 5/8, SERRATED UNDER HEAD
30 5025480 4 WASHER, 3/8" ID, INTERNAL TOOTH
31 5025011X6 1 BOLT, 5/16-18 X 3/4 GD5
32 5041930 2 SPACER, .38 X .50 X .27
The above parts group applies to the following Mfg. Nos.:
