Snapper 1696000 User manual

Not for
Reproduction
Parts Manual fo
r
24" 9TP TWO STAG
E
2011
INTERMEDIATE SNOWTHROWER
Revision: - 6/14/2011
Briggs & Stratton Yard Power Products Group
Manual No. 7105282
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
169600
0
M924E

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5491---IS-N
24" 9TP TWO STAGE
2011 3
Manual No. 7105282
PAGE GROUP
4Handles & Controls Group
8Auger Housing Group
10 Auger Drive Group
12 Gear Case Assembly
14 Chute & Rotation Group - Dash Mount Crank
16 Engine & Frame Group
20 Traction Drive Group - Standard
22 Decals Group
24 Wheel & Tire Group

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
4
Handles & Controls Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 5
Handles & Controls Group
Part No Descri
p
tionItem Qty
0010 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2, G5
0050 724361 1 SPRING, 3/4
0060 1918266 1 WASHER, 3/8
0070 1919439 1 NUT, Hex Lock, ESNA Light, 3/8-16
0080 1739782A 1 LEVER, Clutch, LH
0090 1667588 1 BUSHING
0100 1736836 1 LEVER, Speed
0120 1921962 4 CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G5
0130 1737684 1 BRACKET, Controls
0140 1751543 1 ROD, Speed Control
0150 1931277 3 NUT, Hex Flange, Whiz Lock, 5/16-18
0170 2820263 1 NUT, Hex, 5/16-24
0180 1739487 2 BRACKET, Mounting
0190 724360 1 BALLJOINT
0200 1917356 1 LOCKWASHER, Spring, 5/16
0230 1738286 1 WIRING HARNESS, Headlights
0270 722323 1 BUSHING, Chute Crank
0290 1931323 1 BOLT, Carriage, Short Neck, 1/4-20 x 2, G5
0300 1920397 5 NUT, Hex Lock, ESNA Light, 1/4-20
0330 1738324 1 DASH
0340 1960001 2 SCREW, Hex Washer Head, Plastite, 10-14 x 5/8
0360 1750554 2 BOLT, Shoulder, 10-24
0370 723873 3 BOLT, Carriage, Short Neck, 5/16-18 x 3/4
0390 1739500BZ 1 SUPPORT, Dash
0400 1737544 1 CABLE, Auger Drive
0410 1739783A 1 LEVER, Clutch, RH
0420 1933896 2 NUT, Hex Lock, Nylon Insert, 10-24
0430 1726317 2 GRIP
0440 1736542 2 SPACER, Stepped
0450 1678392 2 SPACER, 1/4 ID x 3/8 OD x 5/16"
0460 1735589 1 BRACKET, Rod Support
0470 1734587A 1 HANDLE, Upper, RH
0480 1734586A 1 HANDLE, Upper, LH
0490 1750299 2 BOLT, Carriage, Curved Head, 5/16-18 x 2-1/4
0500 1737274A 1 HANDLE, Lower
0510 7035744 4 KNOB, Wing, 5/16-18
0515 7090391 4 WASHER, Internal Tooth, 5/16
0520 1736176 1 HEADLIGHT ASSEMBLY
0520-10 ----- 1 LENS, Twin Light (Included in Ref. No 0520)
0520-20 ----- 1 DEFLECTOR, Twin Light (Included in Ref. No 0520)
0520-30 1736180 2 SOCKET & GASKET ASSEMBLY, Headlight (Included in Ref. No 0520)
0520-50 ----- 2 * BULB, 12V - 20W Halogen (Included in Ref. No 0520)
0540 723259 1 BRACKET, Cable Adjusting
0550 723154 1 BOOT, Spring End Cover
Note* See your local hardware store for replacement bulbs.

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
6
Handles & Controls Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 7
Handles & Controls Group
Part No Descri
p
tionItem Qty
0560 727331 1 CABLE, Forward Drive
0590 1733505A 1 BRACKET, Pivot, Free Hand
0600 1733095 1 SPACER, 1/4 ID x 3/8 OD x 1/8"
0610 1733509 1 ROD & SPRING ASSEMBLY
0630 2108360 1 SPRING, Compression, 2-1/4"
0640 1960353 1 WASHER, 1/4
0650 1736360 1 ROD, Hold Down
0680 1733192 1 KNOB, Slot Speed
0700 1921319 2 WASHER, 1/4
0740 7091105 4 SCREW, Hex Washer Head, #10-16 x 1/2
0750 1960589 1 SCREW, Phillips Head, #10-24 x 3/4
0760 1933896 1 NUT, Hex Lock, Nylon Insert, 10-24
0790 7091189 2 BOLT, Carriage, Curved Head, 5/16-18 x 2
0880 7091081 2 SCREW, Hex Washer, Tap, 1/4-15 x 3/4
0900 1960684 4 NUT, Hex KEPS, 5/16-18
0910 723873 4 BOLT, Carriage, Short Neck, 5/16-18 x 3/4
Note* See your local hardware store for replacement bulbs.

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
8
Auger Housing Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 9
Auger Housing Group
Part No Descri
p
tionItem Qty
0010 1687511 1 AUGER HOUSING ASSEMBLY, 24"
0020 1736620 2 CLIP, Retainer
0030 1960569 2 SCREW, Truss Head Torx, #10-24 x 3/8
0040 722401 2 NUT, Nylock, 10 x 26
0060 1736094 1 BRUSH, Cleanout
0070 724427 2 BEARING, Auger Shaft
0080 722839 4 CAPSCREW, Hex Head, 5/16-18 x 3/4
0090 7091547 4 BOLT, Carriage, 3/8-16 x 3/4, GR5
0100 7091619 4 NUT, Hex Flange, 3/8-16
0110 725273 7 NUT, Hex Flange, Serrated Lock, 5/16-18
0150 1727854A 2 SHOE, Skid, Reversible
0160 1738301A 1 BLADE, Scraper, 24"
0170 724712 1 RETAINER, Ball Bearing
0180 1705897 1 BEARING, Ball
0190 720018 3 BOLT, Hex, 5/16-18 x 5/8
0200 725521 2 PLUG, Panel
0210 7090799 4 BOLT, Carriage, 3/8-16 x 5/8, GR5

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
10
Auger Drive Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 11
Auger Drive Group
Part No Descri
p
tionItem Qty
0070 1753072 1 GEAR CASE ASSEMBLY
0080 722726 1 KEY, Square, 3/16 x 3/4
0090 1739094A 1 IMPELLER
0100 1739073 1 HUB, Impeller
0110 1930601 3 SCREW, Hex Washer Head, 5/16-18 x 5/8
0130 7090848 3 SET SCREW, Socket Head, 5/16-18 x 1/2
0150 722128 1 PULLEY
0160 726061 2 CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G2
0170 725429 2 NUT, Hex Centerlock, 1/4-20
0190 723913 2 SPACER, Sleeve, 1/4 x 1/2
0220 1738299A 1 AUGER, LH, 24"
0230 1738300A 1 AUGER, RH, 24"
0220-40 721620 2 FITTING, Grease
-- 722130 1 KIT, Shear Bolt (Includes Ref. Nos. 0160, 0170 & 0190)

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
12
Gear Case Assembly

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 13
Gear Case Assembl
y
Part No Descri
p
tionItem Qty
0300 725982 1 CASE, Gear, RH
0301 725981 1 CASE, Gear, LH
0303 725996 7 CAPSCREW, Hex, 5/16-24 X 1
0304 725338 8 NUT, Hex Flange, Serrated, 5/16-24
0305 723575 1 CAPSCREW, Hex Head, 5/16-24 x 1-1/2
0306 724426 1 PLUG, Pipe, 1/4-18
0310 725874 2 SEAL, Oil
0311 724424 2 BEARING, Sleeve, 1 x 1-1/4 x 1
0312 724425 2 WASHER, Flat, 1
0313 1739058 1 SHAFT, Auger Out
0314 725983 1 GASKET
0315 1752500 1 GEAR, Worm
0316 725433 1 KEY, Woodruf
0320 724423 1 RING, Quad
0321 724729 1 BEARING, Flange, 3/4ID x 1-1/8 OD
0322 724079 1 WASHER, Thrust
0323 724352 1 BEARING, Roll Thrust, 3/4 ID x 1-1/4 OD
0324 724079 1 WASHER, Thrust
0326 724366 1 KEY, Hi-Pro
0327 724421 1 WORMGEAR
0330 724420 1 BEARING, Sleeve, 3/4 ID x 7/8 OD
0340 1751535 1 SHAFT, Impeller
0380 1752515 1 RING, Retaining, 3/4"

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
14
Chute & Rotation Group - Dash Mount Crank

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 15
Chute & Rotation Group - Dash Mount Cran
k
Part No Descri
p
tionItem Qty
0100 1736379D 1 CHUTE ASSEMBLY, Red
0120 1736038 1 GEAR, Chute Support
0130 1960715 3 SCREW, Truss-Head, Torx, 1/4-20 x 3/4
0150 1738340 2 DECAL, Hinge
0160 720064 1 BOLT, Carriage, 5/16-18 x 1-1/2
0170 1735767 1 GUARD, Chute Ring
0180 2860210 2 WASHER, Nylon, 3/8
0200 1733026 1 WASHER, 1/2 x 1-1/8 OD
0210 1732412 1 BOLT, Shoulder, 5/16-18 X 5/8, G5
0220 1960684 4 NUT, Hex, Conical Washer, 5/16-18
0230 1734423A 1 SUPPORT, Gear Crank
0240 1922127 2 CAPSCREW, Hex-Head, 5/16-18 x 1-3/4, G5
0250 1738020 1 SUPPORT, Worm, Clear
0260 1734439 1 GEAR, Worm, Chute, L.H.
0280 722139 2 PIN, Hair, Chute Gear
0290 1960762 1 NUT, Locking, 3/8-24
0300 1734542 1 WASHER, Cup, 3/8
0310 1736195A 1 CHUTE SUPPORT ASSEMBLY
0320 1734442 1 COVER, Gear
0330 1935048 1 NUT, Hex-Flange, Locking, 5/16-18
0360 1931335 1 BOLT, Carriage, 5/16-18 X 1, G5
0370 722136 1 KNOB, Wing 5/16-18
0380 95118 4 SCREW, Shoulder, Hex-Washer, 11/16
0390 5025391 8 NUT, Nylock, 1/4-20
0400 720386 1 BOLT, Carriage, 1/4-20 X 3/4
0410 7012080 2 TIE, Self-Locking
0420 1960093 1 PUSHNUT, 3/8 Dia.
0430 1714084 1 KNOB, Spinner, 3/8 ID, 2-3/16 OD, 2-1/2 Lg
0440 1735661 1 CRANK, Chute Hande
0450 1735660 1 ROD & YOKE ASSEMBLY
0460 724564 1 PIN, Universal Joint, 3/8 X 1
0470 724565 1 BLOCK, Universal Pivot
0480 724605 1 PIN, Cotter, 5/8 X 1/2
0490 1733611 1 YOKE TUBE ASSEMBLY, Chute
0510 724579 1 PIN, Clevis, 1/4 X 1-3/16

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
16
Engine & Frame Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 17
Engine & Frame Group
Part No Descri
p
tionItem Qty
0010 12D114-0149-E8 1 * ENGINE, 9TP Briggs & Stratton (Engine Model: 12D114-0149-E8)
0010-10 797003 1 * GUARD, Muffler
0010-20 699854 2 * SCREW, Muffler Guard
0010-30 795027 1 * CAP, Fuel
0020 724865 1 CORD, Electric
0050 75246 4 SCREW, Hex Head, Trilobular, 3/8-16 x 1-1/4
0090 1739514 1 PULLEY
0100 1919381 1 WASHER, 5/16
0110 722041 1 CAPSCREW, Hex Head, 5/16-24, 1-3/4, G5
0120 1733324 1 V-BELT, Traction Drive, 3L, 33.13
0130 724801 1 BELT, Auger Drive, V4L 38.10
0135 1750314 1 SEAL, Strip
0140 1737377 1 STOP, Belt
0150 1917356 4 LOCKWASHER, Spring, 5/16 (Qty 3 used on 14.5TP models)
0160 1921515 2 CAPSCREW, Hex Head, 5/16-24 x 3/4, G5
0170 1739846 1 BRACKET, Idler
0171 1931335 1 BOLT, Carriage, Short Neck, 5/16-18 x 1, G5
0172 1960684 1 NUT, Hex KEPS, 5/16-18
0180 722072 1 BUSHING, Idler Bracket
0190 722457 1 SPRING, Extension, Idler
0200 722378 2 IDLER
0205 7091299 1 NUT, Hex Nylock, 3/8-16
0210 1960251 2 NUT, Hex Centerlock Jam, 3/8-16
0220 724823 1 BOLT, Carriage, Short Neck, 3/8-16 x 1-1/2, G5
0230 1739574 1 IDLER, Auger
0240 1739964 1 SPACER, Auger Bracket
0250 1960027 1 WASHER, 1/2
0260 1733451 1 ARM, Control
0270 725367 1 PIN, Hair
0280 1736381 1 PIN, Clevis
0290 1737221A 1 PANEL, Bottom
0300 1927429 6 SCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8
0310 722455 1 SPRING, Extension, Auger
0320 1739107D 1 FRAME
0325 1739093A 1 ANGLE, Auger & Traction Rod Mounting
0330 1739450D 1 PLATE, Engine
0350 1664847 15 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
0360 1750551 1 COVER, Belt
0370 1751355 2 SCREW, Hex Washer Head, Tap, SEMS, 1/4-20 x 3/4
0390 1733868A 1 PLATE, Seal (Used on 11.5TP Models)
Note* See your local Briggs & Strattion Distributor for Parts & Service.

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
18
Engine & Frame Group

Not for
Reproduction
Footnotes:
Manual No. 710528224" 9TP TWO STAGE
2011 19
Engine & Frame Group
Part No Descri
p
tionItem Qty
0390-10 1733898 1 SEAL, Foam (Used on 11.5TP Models)
0410 725996 1 BOLT, Hex, 5/16-24 x 1
0420 7023590 1 PIN, Cotter, Self Locking, 1/4"
Note* See your local Briggs & Strattion Distributor for Parts & Service.

Not for
Reproduction
Manual No. 7105282 24" 9TP TWO STAGE
2011
20
Traction Drive Group - Standard
