Snell IC-LCR7 User manual

A HI PERFORMANCE LCR THAT CAN STAND WITH
THE BEST TWO CHANNEL
The left and right speaker in an audiophile two-channel
system can uncannily recreate all the complexity, detail
and space of a live performance, while the center
channel speaker is regarded as the most important
speaker in any multi-channel, surround system.
LCR’s, are a multipurpose design for both of these
critical applications. The IC LCR7 is a D’Appolito Array,
designed by Snell chief engineer, Joe D’Appolito. As a
Left & Right it can haunt you with precision and
soundstage, while as a Center it captures every whisper, every nuance. Together they set the tonal balance, called
timbre, for the rest of the system. The IC LCR7 takes its drivers and crossover design of the acclaimed Snell LCR7 and
integrates them into a utility, in-cabinet LCR. As such, it is designed to fit into furniture or millwork, and is tuned to
compensate for the sonic problems that these cabinet boundaries cause. The result is a speaker that perfectly matches
the LCR7, and its two cousins the IW LCR7 In-Wall and OH LCR7 In-Ceiling Monitor. Any combination of these four
models can be mixed and matched to make a fully integrated system that will work with any room décor.
Design:
Acoustic Suspension
D’Appolito array
Frequency Response
75Hz-20kHz ± 3dB
Sensitivity
[1Watt (2.83v) @ tm]
90 dB
Impedance
Nominal 4 Ohms
Maximum Output
110 dB
Recommended Power
50 Watts minimum
250 Watts maximum
Tweeter
1-inch SEAS silk dome
Woofer
Two 5.25-inch SEAS Treated Paper,
5mm Excursion
Video Shielding
Yes
Crossover Frequency
2.0 kHz
Crossover
Discrete tweeter, and woofer
circuit boards. Time alignment
and coherency are achieved
through the transition region from
driver to driver. Each crossover is
individually tuned by our
technicians to ± 0.5db of the
Master Reference.
Boundary compensation
"Normal" – When placed on
stands away from wall.
"Boundary"– When placed on
shelf or near wall.
Wiring
Bi-amp, bi-wire ready
Connections
5-way satin, nickel-plated, brass
terminals, accepts 5/16 - inch
spades, pins, banana plugs and
bare wire to 12 gauge.
Cabinet Construction
Hardwood veneer over 3/4-inch
MDF Panels. Textured painted
MDF baffle.
Grille
Black cloth over MDF frame.
Finishes
Textured black paint. Can
be ordered in most wood
and paint finishes.
Weight
20 lbs.
Manufactured in the USA by Snell Acoustics, Peabody MA 01960 • www.snellacoustics.com • 978-538-6262 • © Snell Acoustics, Inc • All specifications subject to change without notice.
IC-LCR7
Premier Series
Like all Snell loudspeakers, each IC-LCR7 is hand tuned for natural imaging and sonic depth.
Application Alternatives: System Suggestions:
LCR7 In Room
IW-LCR7 In Wall SR7 Surround
Basis 150 Sub
Dimensions:
• 19”Wide • 7”High • 8.75”Deep
OH-LCR7 In Ceiling
