Snell Premier Basis 300 User manual

Design:
Bass Reflex Powered
Subwoofer
Frequency Response
26Hz-150Hz ± 3dB
-6dB at 23Hz
Maximum Output
107 dB
Amplifier Power
300 Watts
Internal Power Amplifier
Woofer
10 - inch long excursion
treated paper cone and
cast aluminum basket.
Controls
Back-Lighted Top-Mounted
Level Control,Variable Low-
Pass Phase Switch, 0
Degrees/180 Degrees On/Off,
Auto On-Off Switch with Instant
On, and Turn-Off Delay.
Crossover
Variable 50-150Hz
Line Level Inputs
Low-level inputs allow
adjustment of crossover
frequency and subwoofer level.
Speaker Level Inputs
High-level inputs allow
adjustment of crossover
frequency &subwoofer level.
Universal speaker connector,
accepts bare wire to 12 gauge.
Cabinet Construction
Hardwood veneer over
3/4 - inch MDF Panels. Full
length brace with integrated
port flare. Radiused 2.25- inch
stain black MDF baffle.
End Caps
1/4"inch Aluminum,
Anodized Black
Grille
Perforated steel with black
powder-coat paint.
Finishes
Hand-sanded natural Cherry.
Black-painted Walnut. Can be
ordered in most wood and
paint finishes.
Weight
75 lbs.
Manufactured in the USA by Snell Acoustics, Peabody MA 01960 • www.snellacoustics.com • 978-538-6262 • © Snell Acoustics, Inc • All specifications subject to change without notice.
Like all Snell loudspeakers, each Basis 300 is hand tuned for natural imaging and sonic depth.
Basis 300
Premier Series
Application Alternatives: System Suggestions:
LCR7 Front
IC-Basis 300 In Cabinet SR7 Surround
IW-Basis 300 In Wall
Is bigger always better?...Can speakers be beautiful?
Snell Series 7 loudspeakers reveal the depth, impact and nuance
in every music and movie soundtrack without the obtrusive look
and placement conflicts of typical speakers. Handcrafted in
Massachusetts from real wood and solid aluminum, the elegant
Series 7, with its soft lines and superb finish, plays perfect host to
the technology inside.
B300 The basis for any good music or cinema system is the
bottom end. A subwoofer allows the main speakers to be more
compact, and can be fine-tuned to individual needs. Why then,
do so many subwoofers sound boomy? Most “sell-off” quality for
a big woofer and more watts. They use cheaply made vinyl
boxes, losing texture and detail for shake and quake. The Snell
Basis 300 features an extremely tight, long throw 10-inch woofer,
with a neo magnet and cast frame. Its total excursion is nearly an
inch! Coupled with a 300-Watt amplifier and a very sophisticated
cabinet, the B300 is deep, tight, and blends seamlessly to
the front speakers.
Dimensions:
17”High
15.25”Wide
15.25”Deep
CR70 Center
