Snell FLIR C5 User manual

© 2022 The Snell Group / 322 N. Main St. / Suite 8 / Barre, VT 05641 / 800.636.9820 / www.thesnellgroup.com
QuickStart FLIR C5
1. MEMORY:
• Memory is internal only. Can be accessed vis USC-C cable for download into computer, or WI-FI / Bluetooth to
Flir Ignite (cloud)
• Gallery can be accessed by the Gallery / Replay button to the right of screen.
2. POWER:
• Battery is internal and not removable. Battery is charged at the USB-C connection.
3. START:
 •Turnpoweron/o󰀨atthepowerbuttononthetopoftheunit.
4. FOCUS:
 •Isxed,thereisnoadjustment.
5. AUTO ADJUST (Level and Span):
 •Thisfeatureisturnedon/o󰀨intheMenuAccess(threedotslowerrightofscreen).Iconappearsasathermometer,
selectbytappingAuto.
6. MANUAL ADJUST (Level & Span):
 •Thisfeatureisturnedon/o󰀨intheMenuAccess(threedotslowerrightofscreen).Iconappearsasathermometer,
select by tapping Manual (looks like a hand).
• The span values will highlight, highlighted values will be changed by swiping up or down on the scale.
Taponvaluetolockorunlock.Ifbotharehighlighted,levelisadjusted.
Ifonlyoneishighlighted,spanisadjusted.
ACPower
USB-C
Touch screen
Save Button
Menu access
(touch screen)
Camera
Gallery
Device
settings
Setting
buttons
PowerButton

© 2022 The Snell Group / 322 N. Main St. / Suite 8 / Barre, VT 05641 / 800.636.9820 / www.thesnellgroup.com
7. PAUSE IMAGE:
• Setting is not available.
8. SAVE IMAGE:
 •Pressbuttonontopofunittosaveimage.
9. RECALL IMAGE:
 •Pressbuttontotherightofscreentoopengallery.Pressimagethumbnailtoopenimage.
• Menu icon in upper right (three dots) will open an edit submenu.
 •Imagecanbeeditedwithinavailableparameters.ManualSpan/LevelisactivewhileinEditmode.Alongwith
Image Mode, Measurement tools, and Color palette. Back arrow (upper right) will return to previous screen.
10. PALETTE:
• On main live screen the menu access (three dots lower right) will bring up submenu color that can be
accessedfromthere.7palettesareavailabledragngerupordowntoviewpalettes,taptoselect.
11. RANGE:
• This unit has two thermal ranges -20°C to 150°C (-4°F to 302°F) and 0°C to 400°C (32°F to 752°F)
 •Pressthesettingsbuttontotherightofthescreen.Accessingthesubmenu,selectCameratemperaturerange.
Select the needed range. Once selected, back arrow at the top of screen will return to previous screen. To return
to live image tap the Camera Icon at the top of the right side of screen.
12. EMISSIVITY:
 •Pressthesettingsbuttontotherightofthescreen.Accessingthesubmenu,selectMeasurementParameters
then select, Emissivity, custom value set as needed.
13. BACKGROUND:
 •Pressthesettingsbuttontotherightofthescreen.Accessingthesubmenu,selectMeasurementParameters,
thenReectedtemperature,setvalueasneeded.
IFOV =5.9 mRad (Theoretical with 160 x 120 Detector and standard 54˚x42˚ lens) Detect 1in. target @ 14ft.
Flir C5
QuickStart FLIR C5
