ARTRAY ARTCAM-384P2-THERMO User manual

- 1 -
June 18, 2021
Ver1.00
Thermal Infrared Camera
ARTCAM-384P2-THERMO
INSTRUCTION BOOKLET
ARTRAY CO., LTD.

- 2 -
Contents
1. Attention............................................................................................................................- 3 -
2. Introduction.......................................................................................................................- 6 -
3. Main Features...................................................................................................................- 6 -
4. The Product ......................................................................................................................- 7 -
5. Connections ......................................................................................................................- 7 -
5.1. How to Connect a Camera.......................................................................................- 7 -
6. Specifications ...................................................................................................................- 8 -
6.1. Detailed specifications.............................................................................................- 8 -
6.2. Dimensional outline ..................................................................................................- 9 -
7. Systems Requirements .................................................................................................- 10 -
7.1. Recommended Specifications...............................................................................- 10 -

- 3 -
1. Attention
■About this manual
1．Before using the camera, please read this manual thoroughly.
2．Please keep this manual reachable and always refer to the contents when needed.
3．Please contact us if the manual is lost or damaged. We will provide a replacement.
4．We cannot guarantee the safety of improper uses of the camera.
5．For your safety, please follow the directions of this manual.
6．All contents are subject to change.
7．Images in this manual may have been simplified to be easier comprehended.
8．Please contact us if you find any unclear points or mistakes in this manual.
9．Quoting, copying or altering some or all parts of the manual without our permission is prohibited.
10．We are not responsible for any lost or damages on your profits due to the use of our products.
11．Please understand that our oversea branches do not provide maintenance or repair services.
■About the Icons
To keep the safety of the user, other people and their properties, please pay attention to the following
icons.
Warning
If the user fails to follow the instruction, serious injury or death may occur.
Caution
If the user fails to follow the instruction, physical injury on human or damages on hardware may occur.

- 4 -
■For Safe Use
Warning
●In following circumstances, please stop using the product and turn off the power immediately to
prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or
exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
Please stop using the product and turn off the power immediately when:
・The product becomes smoky or gets extremely hot on the surface, or makes unusual smells or sounds.
・Foreign material or water gets into the product.
・The product falls and becomes damaged.
●Do not place the product on unstable surfaces. The product may be fallen and people may get hurt.
Caution
●Do not expose the product to steam or fumes to avoid electric shocks and fires.
●Do not leave the product in high temperature places such as inside of vehicles or under direct
sunlight. High temperature may cause damages to the camera, or even cause fires.
●Do not cover the product with cloth or other materials. The product may get extremely hot and the
heat may cause deformations on the parts or even cause fires.
●Please avoid dropping or shocking the product as the product may be damaged.
●Do not touch the cable with a wet hand. Such action may cause electric shocks.
●Please avoid continuously contacting the surface of the camera to your skin when the camera is
being used. The surface temperature of the camera may cause burns.
■Other Notices
●Please do not use the camera under strong lights such as sun light for a long period. Also please do
not expose the camera under strong lights even when the product is not being used because the
sensor might be damaged.
Maintenance
●Wipe the dirt on surface with soft cloth or tissue paper. Do not use alcohol, thinner or benzene to
avoid damaging the surface paints.

- 5 -
Electro Magnetic Interference
●The camera may interference with electronic devices such as TV and radio. Please do not place the
camera next to such equipment.
■Export Control
This product is a List Control item subject to the Foreign Exchange and Foreign Trade Act and its
relevant legislations No.1 10 (2) and (4). To export this product from Japan, obtaining export licenses
from the Ministry of Economy, Trade and Industry is required. It is also necessary for our company to
manage the information of users and the purposes of use. If the end users or purposes of use change
after the purchase and thus cause the need to apply export licenses from Ministry of Economy, Trade
and Industry, please contact the sales representative in advance.
About the Japanese Security Export Controls, please refer to the webpage for Security Export Control
Policy, the Ministry of Economy, Trade and Industry:
www.meti.go.jp/policy/anpo/englishpage.html
The above is based on the enforcement laws and regulations at the time of issuance of this document.
Please be sure to check the latest laws and regulations before actually exporting this product.
■Guarantee
To save the environment, we do not issue warranty in printed format. Instead, all records of the
warranty periods, delivery dates and the customer information are well kept in our system.
For more details, please refer to the sites below:
Hardware Warranty: www.artray.us/download/artray_warranty.pdf
■Dispose
To dispose this product, please return the camera to us. If you decide to dispose the camera without
returning it us, please follow related regulations and have the camera disposed as an industrial waste.
Please always keep records of the dispose, and make sure the disposed camera cannot be accessed or
used by any 3rd party.
■Limited Responsibility
We do not guarantee the functions of this product or the descriptions on this manual to be completely
adapted to the users’end applications or marketing purposes. We are also not held responsible for any
direct or indirect damages caused by our products under any circumstances.
Please do not use this product on applications that require high reliability. This product is not
manufactured to be used as medical, nuclear, aerospace, transportation equipment or equipment that
is highly related to human safety. We are not held responsible for any damages on the users’property,
equipment or personal safety caused by this product.

- 6 -
2. Introduction
ARTCAM-384P2-THERMO is a thermal infrared camera, which adopts microbolometer and sensitive to
FIR wavelength between 8～14μm.
The resolution of this camera is 384 x 288 pixels.
Adopting USB2.0 interface, thus enables direct data transfer to PC without a capture board or a host
adapter card.
Specially designed Viewer software ART-THERMO included, which makes it easier to acquire thermal
images.
3. Main Features
●FIR (Far infrared) sensitivity
Adopting uncooled microbolometer as an infrared detector, sensitive to standard FIR wavelength (8
～14μm).
●High Resolution
Possible to output images with a resolution up to 384 x 288 pixels. The data (14 bits) obtained from
the infrared detector can be transfer to a PC without compressing.
●USB2.0 Interface
Adopting USB2.0 interface, thus enables direct data transfer to PC without a capture board or a host
adapter card.
●NTSC Output (Option)
Adopting analog output terminal NTSC, so the image can be delivered to analog monitors directly.
●Viewer software ART-THERMO is attached
Viewer Software ART-THERMO, which is designed especially for Thermal Infrared Cameras and
compatible with Windows 7/8/10, is attached as standard.
Functions such as previewing, various settings, still/ moving image savings, graph creating and
alarming are included.

- 7 -
4. The Product
1) Camera
2) 3m USB2.0 cable
3) Viewer Software (including temperature calibration data)
< Option >
1) Germanium lens (Focal length : 6.2mm / 8mm / 13mm / 19mm)
5. Connections
5.1. How to Connect a Camera
・USB Output
・NTSC Output (Option)

- 8 -
6. Specifications
6.1. Detailed specifications
Items
Sensor Type
Uncooled Micro bolometer
Detected Wavelength
8~14µm
Interface
USB2.0, NTSC (Option)
Resolution
384(H) X 288(V)
Pixel Pitch
17μm
Output Bits
14bit
Frame Rate
50fps
Electronic shutter
56.88µs
Operability
> 99.8 %
Temperature
Measurement Range
0°C~120°C
Temperature Resolution
< 60mK
Thermal Time Constant
12msec typ.
Synchronization Method
Internal Synchronization
Lens Mount
M25 X P0.5
Compatible lenses
and
FOV
Focal length : 6.2mm FOV : 62.7°(H) X 46.1°(V)
Focal length : 8mm FOV : 47.2°(H) X 35.5°(V)
Focal length : 13mm FOV : 28.8°(H) X 21.7°(V)
Focal length : 19mm FOV : 19.6°(H) X 14.7°(V)
* Lenses are optional. Please choose the lens when you purchase.
Power Supply
5.0V (±0.5V) USB BUS Power
Power Consumption
< Approx. 2.5 W (ambient temperature 25°C)
Startup Time
≤10s
Operation Temperature /
Humidity
0 ~ 35°C / 10 ~ 80%
（Non-water vapor condensation state）
Recommended temperature
for measurement
TBD
Dimension
46.6(W) X 51(H) X 51.5(D)mm
※Lens and Tripod mount not included
Weight
Approx.140g
※Lens and tripod mount not included

- 9 -
6.2. Dimensional outline

- 10 -
7. Systems Requirements
7.1. Recommended Specifications
●Host Controller
This camera is applicable to USB 2.0.
●CPU
The driver of this camera is applicable to computer architecture “x86”or “amd64”.
The specification of CPU effects directly the imaging process speed, therefore it is highly
recommended to utilize a high-end CPU if possible.
●Memory
In the viewer software, there is a data buffer which can store 4 to 8 frames.
Therefore, it is necessary to keep spare space at least for 8 frames in the memory.
(For example, when using 1.3MP color camera, 1280 x 1024 x 3 x 8 [byte] = 30[MB] is necessary.)
It is highly recommended to keep enough memory space especially when using high resolution
camera.
●OS
This camera is applicable only to the architecture of Windows NT (32bit/64bit).
Standard functions are confirmed with OS after Windows 7.
In addition, it is recommended to use Windows 10.
Caution
■Please refer the restrictions below when you use ARTCAM series.
(1) Recommended System Requirements
If the system specifications do not meet the requirements recommended above, it may be difficult
to run at the maximum frame rate.
(2) Connection of Multiple USB Devices
When connecting multiple USB devices to one USB host controller, some USB device may fail to
function stably depending on the specifications of the host controller.
(Problem of power supply, data transfer bandwidth, etc.)
To avoid power supply problem, it is recommended to use powered USB hub.
(3) USB2.0 Cable Extension
We cannot guarantee the functionality of the USB2.0 camera if the user adopts USB2.0 extension
cables or repeaters which are not confirmed by us. With the extension cables or repeaters, the
bandwidth of transfer may differ, and thus caused malfunctions such as a low frame rate or
recognition failure on the camera.
What may cause the problem is that the regulation of the power lines becomes not enough, and so
causes impudence mismatch on data signals.
*For the recommended extension cable, please contact our sales department.
(TEL: [phone])
ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17
1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan
Tel: [phone] Fax: [phone]
Email: [e-mail] URL: www.artray. us
