DVTEL ioimage CT-5320F User manual

CT-5320F/CT-5640F
Fixed Thermal Camera
Quick Installation
Guide
Rev H December 18, 2014
Document P/N 1018266
The contents of this guide
may not be reproduced or
reprinted in whole or in part
without the express written
permission of DVTEL, INC.
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660

CT-5320F/CT-5640F Fixed Thermal Camera QIG
ii

Document Information
iii
Table of Contents
1. Document Information ........................................................v
2. Introduction........................................................................1
2.1. Package Contents .......................................................... 1
3. Installation and Mounting ...................................................3
3.1. Preparation.................................................................... 4
3.2. Items Required for Installation That Are Not Supplied . 4
3.3. Preparing the Cables...................................................... 5
3.4. Inserting Ethernet and Video Cables into the Camera .. 6
3.5. Preparing the IP66 Enclosure ........................................ 8
3.6. Attaching the Camera to an Analog Device................. 11
3.7. Assembling the Camera Components ......................... 11
3.8. Mounting the Camera.................................................. 13
4. Accessing the Camera........................................................15
4.1. Device Discovery.......................................................... 15
4.2. Viewing Live Video....................................................... 16
Contacting DVTEL ....................................................................19

CT-5320F/CT-5640F Fixed Thermal Camera QIG
iv
List of Figures
Figure 1: Package Contents............................................................ 1
Figure 2: Recommended Tools....................................................... 5
Figure 3: Installation Step 1 Illustration........................................... 6
Figure 4: Installation Step 2 Illustration........................................... 7
Figure 5: Installation Step 4 Illustration........................................... 7
Figure 6: Installation Step 5 Illustration........................................... 7
Figure 7: Installation Step 6 Illustration........................................... 8
Figure 8: Installation Step 7 Illustration........................................... 8
Figure 9: IP66 Enclosure with PoE Connection.............................. 9
Figure 10: AC Power Installation................................................... 10
Figure 11: DC Power Installation .................................................. 10
Figure 12: AC Power Cable Connections ..................................... 10
Figure 13: DC Power Cable Connections..................................... 10
Figure 14: Ground Loop Isolator Installation................................. 11
Figure 15: Back Cover and White Desiccant ................................ 12
Figure 16: Back Cover Screws and Sealing Washer.................... 13
Figure 17: Solar Shroud and Stem Bumpers................................ 13
Figure 18: ActiveX Plug-in Information Bar................................... 16
Figure 19: View Screen................................................................. 16

Document Information
v
1. Document Information
Document Scope and Purpose
The purpose of this document is to provide instructions and installation
procedures for physically connecting the ioimage Thermal CT-5320F/CT-5640F
fixed cameras. After completing the physical installation, additional setup and
configurations are required before video analysis and detection can commence.
Note:
This document is intended for use by technical users who have a basic
understanding of CCTV camera/video equipment and LAN/WAN
network connections.
Remarque:
Ce document est destiné aux utilisateurs techniciens qui possèdent des
connaissances de base des équipements vidéo/caméras de
télésurveillance et des connexions aux réseaux LAN/WAN.
Warning:
Installation must follow safety, standards, and electrical codes as well
as the laws that apply where the units are being installed.
Avertissement:
L'installation doit respecter les consignes de sécurité, les normes et les
codes électriques, ainsi que la législation en vigueur sur le lieu
d'implantation des unités.

CT-5320F/CT-5640F Fixed Thermal Camera QIG
vi
Proprietary Rights and Non-Disclosure
This guide is delivered subject to the following restrictions and conditions:
This document contains proprietary information belonging to DVTEL,
Inc. This information is supplied solely for the purpose of assisting
explicitly the licensee of the DVTEL units.
No part of this document contents may be used for any other
purpose, disclosed to any third party or reproduced by any means,
electronic or mechanical, without the express prior written
permission of DVTEL, Inc.
DVTEL, Inc. makes no representations whatsoever about any other products or
trademarks mentioned in the manual. © DVTEL, Inc. 2014. All rights reserved.
Legal and Environmental Information
This product contains technology controlled under the U.S. Export Administration
Regulations (EAR). Diversion contrary to U.S. law is prohibited. This product has
been tested and found to comply with the limits of FCC (47 CFR) Part 15, Subpart
B, Class A and CES-003. This product complies with the European RoHS directive.
Disclaimer
Users of DVTEL products accept full responsibility for ensuring the suitability and
considering the role of the product detection capabilities and their limitation as
they apply to their unique site requirements. DVTEL, Inc. and its agents make no
guarantees or warranties to the suitability for the users’ intended use. DVTEL,
Inc. accepts no responsibility for improper use or incomplete security and safety
measures.
Failure in part or in whole of the installer, owner, or user in any way to follow the
prescribed procedures or to heed WARNINGS and CAUTIONS shall absolve
DVTEL, Inc. and its agents from any resulting liability. Specifications and
information in this guide are subject to change without notice.
Electrical Safety Notice and Warnings
SAVE ALL SAFETY AND OPERATING INSTRUCTIONS FOR FUTURE USE.
Although the unit is designed and manufactured in compliance with all applicable
safety standards, certain hazards are present during the installation of this
equipment.

Document Information
vii
Camera Warnings
Warning:
1. Only qualified trained personnel should service and repair this
equipment.
2. Observe local codes and laws and ensure that installation and
operation are in accordance with fire, security and safety
standards.
3. The unit’s cover is an essential part of the product. Do not
open or remove it. Operating the unit without the cover poses
a risk of fire and shock hazards.
4. Do not disassemble the unit or remove screws. There are no
user serviceable parts inside the unit.
5. Operating the camera at voltage levels outside the specified
range may result in permanent damage to the unit and void the
product warranty.
6. The camera electronics and electronic interfaces are sensitive
to electrostatic discharge. Follow appropriate ESD procedures
when handling the camera and during installation.
7. Be sure not to expose the camera head to strong sunlight,
which could cause the camera to overheat.
8. This product must be connected to a Power over Ethernet IEEE
802.af-compliant power source or a UL listed Class 2 power
supply rated 12-24 VDC or 24 VAC, minimum 13W or 0.54A.
9. For PoE installations, we strongly recommend using STP cabling
and an earth grounded end point to ensure proper ESD
immunity. For installations powered by AC or DC, a properly
earth grounded power source is strongly recommended. Any
other installation method may leave the camera at risk and
void the warranty.
10. If you use a power supply, make sure that the connection
matches the positive and negative polarity on the unit, and
protect against static electricity, ground faults and power
surges.

CT-5320F/CT-5640F Fixed Thermal Camera QIG
viii
Avertissements relatifs à la Caméra
Avertissement:
1. Seul un technicien formé et qualifié est autorisé à entretenir et
à réparer cet équipement.
2. Respectez les codes et réglementations locaux, et assurez-vous
que l'installation et l'utilisation sont conformes aux normes
contre l'incendie et de sécurité.
3. Le cache de l'unité est une partie essentielle du produit. Ne les
ouvrez et ne les retirez pas. L'utilisation de l'unité sans cache
présente un risque d'incendie et de choc électrique.
4. Ne démontez pas l'unité et ne retirez pas ses vis. Aucune pièce
se trouvant à l'intérieur de l'unité ne nécessite un entretien par
l'utilisateur.
5. Toute utilisation de la caméra à des niveaux de tension n'étant
pas compris dans la fourchette indiquée peut endommager
l'unité de façon permanente et peut annuler la validité de la
garantie du produit.
6. L'électronique et les interfaces électroniques de la caméra sont
sensibles aux décharges électrostatiques. Suivez les
procédures ESD adéquates lors de toute manipulation de la
caméra et au cours de son installation.
7. Assurez-vous de ne pas exposer la tête de la caméra aux rayons
de soleil intenses qui pourraient surchauffer la caméra.
8. Ce produit doit être connecté à une source d'alimentation par
Ethernet conforme à la norme IEEE 802.af ou à une
alimentation UL de Classe 2 de 12-24 V CC ou 24 V AC, 13W ou
0,54A minimum.
9. Pour les installations PoE, nous recommandons fortement d'utiliser
des câbles STP et une liaison à la terre pour assurer l'immunité face
aux décharges électrostatiques. Pour les installations alimentées
par AC ou CC, une source d'alimentation reliée à la terre est
fortement recommandée. Toute autre méthode d'installation peut
comporter des risques pour la caméra et annuler la garantie.
10. Si vous utilisez une alimentation, assurez-vous que le branchement
à l'alimentation corresponde aux polarités positive et négative sur
l'unité, et protéger l'unité contre l'électricité statique, les défauts de
mise à la terre et les surtensions.

Introduction
1
2. Introduction
This document provides information about the ioimage Thermal CT-5320F/
CT-5640F fixed-mount, fixed-focal length thermal camera. The NTSC/PAL camera
system is a hybrid analog/Internet Protocol (IP) networked solution that
conforms to the Open Network Video Interface Forum (ONVIF™) Profile S
standard.
2.1.Package Contents
The unit package contains the following items:
Figure 1: Package Contents

CT-5320F/CT-5640F Fixed Thermal Camera QIG
2
Item
QTY
Description
1
1
CT-5320F/CT-5640F Fixed Thermal Camera (with 90°
BNC adapter attached to the camera’s back panel)
2
1
Base mount
3
1
Back cover
4
1
Solar shroud
5
1
Cable sealing gland with electrical nut
6
16
#6 32 x 3/8” screws (including spares)
7
3
Stem bumpers ( including one spare)
8
1
White silica gel desiccant for installation
9
1
O-ring
10
3
Sealing washers with gasket (including one spare)
In addition, the following items are supplied:
QTY
Description
1
Male 5-pin AC power terminal block connector
for use with AC power cables
1
Male 5-pin DC power terminal block connector
for use with DC power cables
1
Video Ground Loop Isolator
1
Quick Installation Guide (this document)
Note:
A 24 VAC power source should supply 13W. Be sure that a 12VDC
supply is rated at 2 amps and that a 24VDC supply is rated at 1 amp.
Related information:
ioimage Thermal CT-5320F/CT-5640F User and Installation Guide
ioimage HTML Edition Units User’s Guide
ioimage trk-101 Installation Manual

Installation and Mounting
3
3. Installation and Mounting
The physical installation of the unit is the first phase of making the unit
operational in a security plan. The goal is to physically place the unit, connect it
to other devices in the system, and to establish IP network connectivity.
When finished with the physical installation, refer to the ioimage Thermal
CT-5320F/CT-5640F User and Installation Guide to complete the second phase of
installation, which is the setup and configuration of the unit.
Caution:
To avoid damage from overheating or unit failure, assure that there is
sufficient temperature regulation to support the unit’s
cooling/heating requirements. Operating temperature should be kept
in the range -40° to 60°C (-40° to 140°F), with no more than 95%
non-condensing humidity.
Attention:
Afin d'éviter tout dommage dû à une surchauffe ou toute panne de
l'unité, assurez-vous que la régulation de température est suffisante
pour répondre aux exigences de l'unité (refroidissement/chauffage).
La température de fonctionnement doit être maintenue dans la plage
de température spécifiée pour le produit (-40° à 60°C/-40° à 140°F,
sans condensation d'humidité supérieur à 95%).

CT-5320F/CT-5640F Fixed Thermal Camera QIG
4
3.1.Preparation
Read the instructions in this chapter thoroughly before installing the camera.
Following are additional considerations for outdoor installation:
Always use weatherproof equipment, such as boxes, receptacles,
connectors, etc.
For electrical wiring, use the properly rated sheathed cables for
conditions to which the cable will be exposed (for example,
moisture, heat, UV, physical requirements, etc.).
Plan ahead to determine where to install infrastructure
weatherproof equipment. Whenever possible, ground components
to an outdoor ground.
Use best security practices to design and maintain secured camera
access, communications infrastructure, tamper-proof outdoor
boxes, etc.
To minimize the effects of EMI (electromagnetic interference) and RFI
(radio frequency interference), consult your reseller.
3.2.Items Required for Installation That Are Not
Supplied
The following items are required for installation, but are not included in the
package:
Power source (PoE switch, 12-24VDC or 24VAC power supply)
Shielded Twisted Pair (STP) cable if using a PoE switch
Cat 5 Ethernet cable for network connection without a PoE switch
Tripod or mounting bracket for mounting the camera
One #2 Phillips head screwdriver
Two open-end, 1-inch (25.4mm) wrenches or adjustable wrenches
One 6-inch (152mm) scale or ruler
Electric or manual torque screwdriver set to 10 inch-pounds
(1.23 Newton meters)

Installation and Mounting
5
Torx T10 pin-in security bit, 3-1/2” (90mm) in length
Hex wrench
RJ45 connector
RJ45 crimping tool
Coax cable
Coax cable cutter/stripper
BNC connector
BNC crimping tool
Figure 2: Recommended Tools
3.3.Preparing the Cables
To prepare the camera cabling
Disconnect power from any previously installed cables.
Use a #2 Phillips head screwdriver to pierce a hole in the center of the
cable gland.
If needed, pierce the smaller holes on the outer perimeter of the cable
gland membrane for AC/DC power.
Remove the electric nut from the sealing gland.
Place the O-ring on the threaded end of the cable gland to insure a
good seal.
If using existing cable, cut off the RJ45 or BNC connector.
Feed the cables through the components in the following order:

CT-5320F/CT-5640F Fixed Thermal Camera QIG
6
Four-hole mount adapter, with its flat surface facing the mating
standard four-hole bracket, if required
Base mount (flat side first for base-mounting bracket)
Electrical nut (convex side) of the supplied cable sealing gland
Bottom of the camera body through the back hole below the
connectors
3.4.Inserting Ethernet and Video Cables into the
Camera
The following procedure explains how to insert the Cat 5 Ethernet cable and
analog video coax cable with the sealing gland into the thermal camera.
Recommended video cable components:
RG179BU video coax cable assembly
RJ179 male BNC crimp connector
To insert the cables
Place the nut onto the cables.
Figure 3: Installation Step 1 Illustration

Installation and Mounting
7
Feed the Cat 5 Ethernet cable and video coax cable through the gland
housing. The Ethernet cable goes through the center of the gland
housing. The analog video cable goes through one of the five outer
holes of the gland housing.
Figure 4: Installation Step 2 Illustration
Push the gland housing over the cables.
Push the gland rubber into the gland housing.
Figure 5: Installation Step 4 Illustration
Tighten the gland nut onto the gland housing. Leave about 3.15” (8cm)
of cable sticking out of the gland housing.
Figure 6: Installation Step 5 Illustration

CT-5320F/CT-5640F Fixed Thermal Camera QIG
8
Insert the cables and gland housing into the camera and attach them to
the connectors.
Figure 7: Installation Step 6 Illustration
Slide the gland housing chassis nut over the cables. Tighten the gland
housing chassis nut into the camera.
Figure 8: Installation Step 7 Illustration
Crimp the other end of the cables in place (not shown).
3.5.Preparing the IP66 Enclosure
To prepare the camera for PoE power connection
Slide the Ethernet cable through the threaded end of the cable sealing
gland with the O-ring installed.
Use a scale to measure approximately 4-1/2” (114mm) of cable slack
from the end of the cable to the rubber grommet of the sealing gland.
Attach one open-end wrench onto the flange of the cable gland.
Using the second open wrench, tighten the compression nut to
approximately 8 in-lbs. (0.9 newton meters) of torque.

Installation and Mounting
9
Attach an RJ45 connector to the Ethernet cable.
Pull the cables tightly back through the camera, exposing the thread of
the cable sealing gland out of the base of the camera.
Attach the electrical nut back onto the gland.
Tighten the nut securely until it is finger-tight.
Use the hex wrench to tighten the electrical nut to approximately
8 in-lbs. (0.9 newton meters) of torque.
Figure 9: IP66 Enclosure with PoE Connection
Note:
To ensure a proper earth ground between the camera and a PoE
switch, we strongly recommend using Shielded Twisted Pair (STP)
cabling. Installations of ioimage Thermal cameras with STP cabling
and a properly earth grounded PoE switch are tested to comply with
industry immunity standards for Electro Static Discharge. Any other
installation method may leave the camera at risk and void the
warranty.

CT-5320F/CT-5640F Fixed Thermal Camera QIG
10
To prepare the camera for AC/DC power connections
Attach the male AC or DC five-pin terminal block connector to the AC
or DC power cables.
Figure 10: AC Power Installation
Figure 11: DC Power Installation
Insert the male connector into the female connector on the back of the
camera housing.
Figure 12: AC Power Cable Connections
Figure 13: DC Power Cable Connections
Pull the cables tightly back through the camera, exposing the thread of
the cable sealing gland out of the base of the camera.
Attach the electrical nut back onto the gland.
Tighten the nut securely until it is finger-tight.
Use the hex wrench to tighten the electrical nut to approximately
8 in-lbs. (0.9 newton meters) of torque.

Installation and Mounting
11
3.6.Attaching the Camera to an Analog Device
In order to prevent video signal distortion, the supplied ground loop isolator must
be installed between the analog out connector on each camera and an attached
analog device if:
You are connecting the camera to an analog device and
You are connecting more than one camera on the network segment
Figure 14: Ground Loop Isolator Installation
3.7.Assembling the Camera Components
Refer to Package Contents (page 1) for illustrations and a description of the
components mentioned in this section.
To assemble the camera components
Attach the base mount to the camera using 8 of the #6 screws.
Using the electric screwdriver and the Torx T10 security bit, tighten the
8 fasteners to about 10 in-lbs. (0.9 newton meters) of torque.
Using the electric screwdriver and the Torx T10 security bit, tighten the
fasteners to about 10 in-lbs. (1.23 newton meters) of torque.
Connect the cables to the respective connector:
Ethernet port
Analog video out

CT-5320F/CT-5640F Fixed Thermal Camera QIG
12
AC/DC power: Connect the AC or DC male terminal block
connectors to the camera according to the wiring in section 3.5.
If you are powering the camera with an AC supply, insert the
green AC terminal block connector and connect AC+ to the
24VAC input and AC- to the 12VDC input
If you are powering the camera with a DC supply, insert the
white DC terminal block connector and connect DC+ to the
12VDC input and DC- (or ground) to the GND input
Caution:
DO NOT connect an AC supply to a DC connector. This
could damage the unit.
Attention:
Ne branchez pas une alimentation AC à un connecteur CC.
Ceci pourrait endommager la caméra.
Reconnect power to the existing cables.
Check for a steady LED indication on the Ethernet connector to confirm
connection to the IP network. The status LED indicators are:
LED 1: Steady green for 10MB connection or flashing green for
activity.
LED 2: Steady amber for 100MB connection or flashing amber for
activity.
Place the supplied white desiccant into the back cover.
Figure 15: Back Cover and White Desiccant
