Snom PA1+ User manual

© 2023 Snom Technology GmbH
Snom Technology AG
Aroser Allee 66
13407 Berlin, Deutschland
Tel. [phone]
Fax [phone]
offi [email protected]
Snom Technology GmbH.
130 Avenue Joseph Kessel
78960 Voisins-le-Bretonneux, France
Tel. [phone]
Fax [phone]
o [email protected]
Snom Technology GmbH
The Courtyard, High Street
Ascot
Berkshire SL5 7HP, UK
Tel. [phone]
Fax [phone]
o [email protected]
Snom Technology GmbH
Via Milano 2
20045 Lainate (Milano area), Italia
Tel. [phone]
Fax [phone]
o [email protected]
VTech Commuinications Inc.
Snom Americas
9020 Washington Square Road, Suite 555
Tigard, OR 97223, U.S.A.
Phone support: [phone]
VTech Technologies Canada Ltd.
Suite 222
13888 Wireless Way
Richmond, B.C., V6V 0A3, Canada
Phone support: [phone]
Manufacturer:
VTech Telecommunications Ltd.
23/F, Tai Ping Industrial Centre, Block 1
57 Ting Kok Road, Tai Po
Hong Kong
Your specialist retailer - Ihr Fachhändler -
Votre distributeur - Su distribuidor - Il tuo rivenditore:
v1.01
PA1+
User Manual
Public Address System

2
TABLE OF CONTENTS
Copyright, Trademarks, GPL, Legal Disclaimers ...........................................................4
Important information ......................................................................................................5
Safety instructions ................................................................................................................. 5
Standards conformance ........................................................................................................ 6
Disposal of the device ............................................................................................................ 6
Cleaning .................................................................................................................................... 6
Product specications ........................................................................................................... 7
Setting up ..........................................................................................................................8
Delivery Content ...................................................................................................................... 8
Wallmounting .......................................................................................................................... 8
Connecting the PA1+ .............................................................................................................. 9
Low impedance connection (ex. 4–32 Ohm) ................................................................ 9
600 Ohm load connection ..............................................................................................10
Initializing and conguring ........................................................................................... 11
Initializing.................................................................................................................................12
Initializing with DHCP .......................................................................................................12
Initializing without DHCP .................................................................................................12
Security settings ...................................................................................................................14
Conguring accounts ...........................................................................................................15
Conguring identities automatically ...........................................................................15
Conguring identities manually ...................................................................................15
Settings ...................................................................................................................................16
Time zone .........................................................................................................................16
Tone scheme ....................................................................................................................16
Automatic termination of calls .....................................................................................17
Adjusting the volume ......................................................................................................17
Using the PA1+ ............................................................................................................... 18
Making announcements ......................................................................................................18
Turning the loudspeaker on or o .....................................................................................18
Software update ............................................................................................................. 19
Provisioning software updates ..........................................................................................19
Manual software update .....................................................................................................20
Settings .............................................................................................................................20
Updating manually ..........................................................................................................21

3
Troubleshooting ............................................................................................................. 23
Reboot .....................................................................................................................................23
Hard reboot ............................................................................................................................23
Reset to factory values ........................................................................................................23
Contacting Snom Support ...................................................................................................24
Traces .....................................................................................................................................24
Appendix 1 — Drilling template for wallmounting ..................................................... 26
Appendix 2 —GNU General Public License ................................................................. 27

4
snom PA1+ User Manual Copyright, Trademarks, GPL, Disclaimers
Copyright, Trademarks, GPL, Legal Disclaimers
© 2023 Snom Technology GmbH
All Rights Reserved.
Snom , the names of Snom products, and Snom logos are trademarks owned by Snom Technology
GmbH. All other product names and names of enterprises are the property of their respective
owners.
Product specications are subject to change without notice.
Snom Technology GmbH reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.
Texts, images, and illustrations and their arrangement in this document are subject to the protection
of copyrights and other legal rights worldwide. Their use, reproduction, and transmittal to third
parties without express written permission may result in legal proceedings in the criminal courts as
well as civil courts.
When this document is made available on Snom ’s web page, Snom Technology GmbH gives its
permission to download and print copies of its content for the intended purpose of using it as a
manual. No parts of this document may be altered, modied or used for commercial purposes without
the express written consent of Snom Technology GmbH.
Although due care has been taken in the compilation and presentation of the information in this
document, the data upon which it is based may have changed in the meantime. Snom therefore
disclaims all warranties and liability for the accurateness, completeness, and currentness of the
information published, except in the case of intention or gross negligence on the part of Snom or
where liability arises due to binding legal provisions.
Our rmware includes some source code that may be used and modied by anyone and everyone
under the GNU Public License (GPL) (see "Appendix 2 — GNU General Public License" on page 27),
provided they, in turn, make it available to everyone else with the same licensing agreement. Please
go to https://www.snom.com/en/footer/discover-snom/gtc/source-code-gpl-open-source/ for
the original GPL license and the source code of components licensed under GPL and used in Snom
products.

5
snom PA1+ User Manual Important information
Important information
Please read the instructions on safety and disposal and on how to set up and use the device before
using it and also give them to other users to read or inform those users of their contents. Save this
manual and do not give the device to third parties without it.
The nameplate is located at the bottom or rear of the product.
Safety instructions
Follow the instructions in this manual and other applicable documentation of the device.
• Warning: The product included (ITE) in this manual is to be connected only to PoE networks
without routing to the outside plant.
• The socket outlet for the power adaptor must be near the equipment and easily accessible.
• Mount the device only at heights not exceeding 2m.
• If the device is not supplied with power via an Ethernet cable, use only a power adapter expressly
recommended by Snom technology. Other power supplies may damage or destroy the device,
aect its behavior, or induce noise.
• Avoid placing the cables where people may trip over them or where they may be exposed to
mechanical pressure as this may damage them.
• This device is for indoor use only! NOT FOR OUTDOOR USE!
• Do not install the device in rooms with high humidity (for example, in bathrooms, laundry rooms,
damp basements). Do not immerse the device in water and do not spill or pour liquids of any kind
onto or into the device.
• Do not install the device in surroundings at risk for explosions (paint shops, for example). Do not
use the device if you smell gas or other potentially explosive fumes.
• Do not use the device during thunderstorms. Lightning striking the power grid may cause electric
shocks.
• Do NOT remove the device's power supply (Ethernet cable when using PoE, power adapter when
not using PoE) when the red light is on or blinking; a rmware update is ongoing. Cutting o the
device's power during a rmware update (red LED on, green LED o) will damage the rmware
and render the PA1+ inoperational. In such cases, it will need to be returned to the vendor for
resetting.
• SELV (Safety Extra Low Voltage) Compliance. Safety status of input/output connections comply
with SELV requirements.
Warning: To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to
teledevice-network voltage (TNV) circuits. LAN ports contain SELV circuits, and PSTN ports
contain TNV circuits. Some LAN and PSTN ports both use RJ-45 (8P8C) connectors. Use caution
when connecting cables.

6
snom PA1+ User Manual Important information
Standards conformance
This device complies with the essential health, safety, and environmental requirements of
all relevant European directives and UK legislation.
The declaration of conformity can be downloaded at https://www.Snom .com/conformity.
Important additional information for the USA
FCC part 15
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at the user’s expense.
WARNING: Changes or modications to this equipment not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Unauthorized opening, changing, or modifying the device will cause the warranty to lapse and
may also result in the loss of CE conformity and FCC compliance. In case of malfunction contact
authorized service personnel, your seller, or Snom .
Disposal of the device
This device is subject to European Directive 2012/19/EU and may not be disposed of with
general household garbage. If you do not know where to dispose the device at the end of its
lifespan, contact your municipality, local waste management provider, or vendor.
For countries outside the European Union
Disposal of electrical and electronic products in countries outside the European Union should be done
in line with local regulations. Please contact local authorities for further information.
Cleaning
To clean the device, use an anti-static cloth. Please avoid cleaning liquids as they might damage the
surface or internal electronics of the device.

7
snom PA1+ User Manual Important information
Product specications
• Safety: IEC 62368-1
• Connectors:
◦2 x RJ45 (Ethernet): 1 x LAN/PoE, 1 x PC, camera, etc.
◦1 x 5V DC coaxial power connector
◦2 push-on speaker connectors
◦2 x 3.5 mm headset connectors (mic in/line out) for installation and maintenance purposes
only
◦4 I/O pin ports for controlling connected devices via web interface or DTMF
• Amplier: Class D, 6.5W (loudspeaker not included)
• Ethernet: 2 x IEEE 802.3, 1 Gigabit switch
• Power over Ethernet (PoE): IEEE 802.3af, Class 3. If PoE is not available, use the separately
available power adapter (not included in delivery):
◦EU, UK: Mass Power, model NBS12E050200UV, Snom PN 00004570
◦U.S.A., Canada: VTPL, model VT07EUS05200
Feature list
• SIP or multicast support
• Remote SW update
• Network/web management
• Remotely settable speaker volume adjustment
• IP address/reset button
• Call/network activity indicator
• One "Mic-In" and one "Line Out" 3.5 mm connector for headset connection (SPK impedance =
32 Ohm, MIC power supply 3.3V, RL = 2 KOhm, S= -42 dB (+-2dB)). Microphone input must be
dierential and without grounding.
◦Low impedance connections. The "Line Out" port is for installation and maintainance
purposes only, not for the connection of other devices. See "Low impedance connection (ex.
4–32 Ohm)" on page 9 for more information.
◦600 Ohm connection. The 600 Ohm loudspeaker is connected to the "Line Out" port. See "600
Ohm load connection" on page 10 for more information.
• 4 I/O pins remotely settable
◦via web interface (in administrator mode only) or
◦with DTMF tones (with programmable timer)
• Robust casing design for wall mounting

8
snom PA1+ User Manual Setting Up
Setting up
Delivery Content
GNU
General Public License
Quick Installation
Guide
PA1+
◦Base unit
◦2 brackets for wall mounting (pre-assembled)
◦4 screws (Ø 8 mm, length 16 mm) + 4 expansion anchors for wall mounting
◦Cable set (5 proprietary Snom cables for connecting periphery devices)
◦1 audio adapter 3-pin screw terminal < - > 3.5 mm jack plug
◦Quick Start Guide
Wallmounting
Note: The Ethernet cable must not be bent to avoid damage and loss of the network
connection. We recommend that you place the PA1+ so that the PoE connector is facing
toward the LAN port in your network. We also recommend that you place the PA1+ in a
location where you can see the LEDs from your desk or work station.
121 mm
(4.764")
121 mm
(4.764")
110 mm (4.331")
110 mm (4.331")
Fig. 1
1. Use the measurements in Fig. 1 to mark the positions of the four holes to be drilled in the wall, or
use the template at "Appendix 1 — Drilling template for wallmounting" on page 26.

9
snom PA1+ User Manual Setting Up
2. Drill the holes and insert the expansion anchors in the holes.
3. Place the Snom PA1+ on the wall with the cut-outs above the anchors as shown in Fig. 2.
Fig. 2
4. Place the screws in the anchors and tighten them evenly..
Connecting the PA1+
Low impedance connection (ex. 4–32 Ohm)
Fig. 1 Fig 2
1. Plug the Ethernet cable into the RJ45 connector labelled "Port 1PoE", as shown in Fig. 1. The
second RJ45 connector labelled "Port 2" is for daisy-chaining further Ethernet devices without the
need for another Ethernet cable.
If no PoE available: Connect a Snom-approved 5V 10W power supply to the power
connector labelled "5V DC".
2. Connect the loudspeaker wires to the speaker terminals labelled "Speaker", as shown in Fig. 2.
Connect the "+" wire with the red terminal, connect the "-" wire with the black terminal.
Note: If you want to use a headset during the setup:
Connect the headset's microphone plug to the jack labelled "Mic-In".
Connect the headset's speaker plug to the jack labelled "Line Out".

10
snom PA1+ User Manual Initializing and Conguring the PA1
600 Ohm load connection
+
Fig. 1 Fig 2
1. Plug the Ethernet cable into the RJ45 connector labelled "Port 1PoE", as shown in Fig. 1. The
second RJ45 connector labelled "Port 2" is for daisy-chaining further Ethernet devices without the
need for another Ethernet cable.
If no PoE available: Connect a Snom-approved 5V 10W power supply to the power
connector labelled "5V DC".
2. Connect the Snom cable to the "I/O 1" port, as shown in Fig. 1
3. Connect the loudspeaker wires to the 3-pin screw terminal/3.5 mm jack plug adapter and plug
the adapter into the "Line Out 600 Ohm O/P" port, as shown in Fig. 2.
Note: If you want to use a headset during the setup:
Connect the headset's microphone plug to the jack labelled "Mic-In".
Connect the headset's speaker plug to the jack labelled "Line Out".
