SnoMaster VT-19R Installation instructions

VT-19R WINE COOLER
USER MANUAL
AND PRODUCT
SPECIFICATIONS

CONTENTS
Before Using Your Appliance
Critical Safety Information For Your Safety
IMPORTANT SAFETY INFORMATION 01
03
04
05
07
08
STRUCTURE AND INSTALLATION
Accessory Installation Before Operating
UNPACKING AND CLEANING THE WINE COOLER
Working Climate
Storage
Recommended Temperatures
WINE STORAGE AND CONTROL PANEL
Power On/O Control
Temperature Setting
Temperature Display Window
Interior Lighting Control
CLEANING THE WINE COOLER
Cleaning Your SnoMaster Wine Cooler
Power Failure
Moving the Wine Cooler
Energy Saving Tips
Warranty, Service And Support
Warranty Registration
Service and Support
TROUBLESHOOTING

This manual contains important information including safety and
installation instructions of the SnoMaster Wine Cooler. Please read this
manual carefully before use and follow all safety information and
instructions. It is recommended to keep this manual for easy reference
so that you are familiar with the operation of your appliance.
BEFORE USING YOUR APPLIANCE
• Ensure all packaging materials, stickers, and films are removed from
the product. Clean the product's surfaces with a mild detergent
and a damp cloth before the initial use.
• Before connecting the appliance to a power source, let it stand
upright for approximately 24 hours. This measure helps minimise
the risk of cooling-system malfunctions that might occur due to
handling during transportation.
• Clean the interior surface using a soft cloth and lukewarm water.
CRITICAL SAFETY INFORMATION FOR YOUR SAFETY
Before using this appliance, ensure it is correctly positioned and
installed as outlined in this manual. Follow these basic precautions to
prevent the risk of fire, electrical shock, or injury:
• This appliance is designed for domestic use only. It is intended
exclusively for storing sealed bottled wines or beverages.
• Ensure the plug is easily accessible after positioning the appliance.
• Avoid connecting or disconnecting the electric plug with wet hands.
• To disconnect the appliance, hold the plug and pull it from the wall
outlet. Never pull out by the cord.
• It's advisable to use a dedicated power source and avoid using
extension cords.
• Unplug the appliance or disconnect power before performing any
cleaning, maintenance, or servicing. Failure to do so can result in
electrical shock or even death.
IMPORTANT SAFETY INFORMATION
SNOMASTER VT-19R RETRO WINE COOLER
01

• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or a similarly qualified person
to prevent any hazard.
• The fuse (or circuit breaker) size should be 10 amps or higher.
• This appliance can be used by children aged 8 years and older and
persons with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, provided they have been given
supervision or instruction concerning the safe use of the appliance,
and understand the associated hazards. The appliance should not be
used as a toy. Cleaning and user maintenance should not be carried
out by children unless they are supervised.
• To ensure proper ventilation for the appliance, the front of the unit
must be completely unobstructed. Place the unit away from direct
sunlight and heat sources (stove, heater, radiator, etc.).
• Unless specifically recommended in this manual, do not attempt to
repair or replace any part of the appliance. All other servicing should
be referred to a qualified technician.
• Ensure sucient personnel are available to move and install the
appliance to prevent any damage or injuries.
• The appliance needs to be level for optimal operation.
You can adjust the appliance’s feet to level it.
• Never clean appliance parts with flammable fluids as they may
create a fire hazard or explosion. Also, avoid storing or using
gasoline or other flammable vapours and liquids near this appliance.
• Avoid solvent-based cleaning agents or abrasives on the interior as
they may damage or discolour it.
• This appliance should only be used for its intended purpose.
• Avoid using electrical appliances inside the wine cooler.
• The use of attachments not recommended by the manufacturer
may be hazardous.
• Before disposing of the appliance, keep it away from fire or similar
glowing substances.
• GWP (Global Warming Potential): R600a.
• When disposing of the appliance, remove the door and leave
the shelves in place to prevent children from climbing inside easily.
• Ensure the coolant circuit, especially the heat exchanger at the
back/bottom of the unit, is not damaged.
02

The recycle symbol on the product or its
packaging indicates that this product must
not be disposed of as regular household
waste. It should be taken to a designated
collection point for recycling electrical and
electronic goods.
STRUCTURE AND INSTALLATION
The images provided below only describe the appliance.
The dimensions and shelf quantity may dier among the
models in the same series.
Let the appliance stand upright for approximately 24
hours before connecting it to the power source, which
helps to reduce the possibility of a cooling-system
malfunction from handling during transportation.
Foot
Glass
Shelf
Glass
Door Shelf
Control
Panel
Inner Fan
Running
Box
Body
DO NOT TURN ON FOR AT LEAST
24 HOURS AFTER DELIVERY
03

• Remove all exterior and interior packing materials.
• Before connecting the appliance to a power source, let it stand
upright for approximately 24 hours. This helps to reduce the
possibility of a cooling-system malfunction due to handling
during transportation.
• Use a soft cloth and lukewarm water to clean the interior surface.
OPERATING THE WINE COOLER
OPERATING CONDITIONS
This appliance is designed for operation in SN to T climates (refer to the
climate class chart below). We recommend maintaining an ambient
temperature of 22-25°C. This temperature range optimises the
appliance's performance and lowers power consumption.
If the ambient temperature falls outside the specified climate range, the
performance of the unit may be compromised. Operating the appliance
in extremely cold or hot conditions could cause internal temperatures
to fluctuate. Consequently, the set temperature of 5-20°C may not
always be achieved.
UNPACKING AND CLEANING
THE WINE COOLER
Climate Class Ambient
Temperature
SN = Subnormal 10°C -32°C
(50°F-90°F)
N = Normal16°C -32°C
(61°F-90°F)
Climate Class Ambient
Temperature
ST =Subtropical18°C -38°C
(64°F-100°F)
T = Tropical18°C -43°C
(64°F-109°F)
04

The standard shelves are optimally designed for Bordeaux-style
bottle storage. The maximum bottle capacity may vary depending
on the sizes or dimensions of the wine bottles you intend to store.
• To prevent damage to the door gasket, ensure the door is fully
opened before pulling out the shelves.
• Do not cover the shelves with aluminium foil or any other material
as it could hinder proper air circulation.
• Wine should be stored in sealed bottles. If the wine cooler is to
remain empty for an extended period, we recommend unplugging
the appliance. After thoroughly cleaning the interior, leave the door
slightly open. This allows air to circulate within the cabinet,
preventing potential condensation, mold, or odours.
WINE STORAGE
BELOW ARE THE RECOMMENDED TEMPERATURES FOR CHILLING/
STORING YOUR WINES.
Wine TypeRecommended Temperature
Red14-18°C (59°F-64°F)
White6-14°C (48°F-57°F)
Rose6-12°C (50°F-52°F)
Sparkling4-10°C (41°F-46°F)
CONTROL PANEL
88˚F
Control
Area
Display
Area
Control
Button
POWER ON/OFF CONTROL
When the appliance is plugged in to a
power outlet, it powers on automatically.
05

• The temperature setting range for this appliance is between 5°C - 20°C.
• Touch the control button to cycle through and set the
desired temperature.
• If untouched for 5 seconds, the digital display will revert
to show the set temperature.
Note: If you are using the appliance for the first time or restarting it
after a long period of shutdown, you may notice a slight discrepancy
between the set temperature and the displayed temperature.
This is normal and will resolve after a few hours of operation.
• The temperature is shown in a digital format for easy readability.
When you are setting the temperature, the display shows the set
temperature.
• If the temperature probe malfunctions, the display window will show
"HH" or "LL" instead of a numerical figure, and a continuous buzzing
sound will be heard. In such instances, the appliance is thoughtfully
designed to maintain periodic operation of the compressor and fans.
This functionality helps to preserve the coldness within the cabinet,
protecting your stored wines.
• To turn the interior LED lighting on or off, touch
and hold the control button for 3 seconds.
• If not manually turned off, the interior lighting
will remain continuously on.
To avoid stressing the compressor, please
do not turn on the appliance again within
5 minutes after you turn it o.
WARNING
TEMPERATURE SETTING
INTERIOR
LIGHTING
CONTROL
06
TEMPERATURE DISPLAY WINDOW

• Turn off the power, unplug the appliance, and remove all contents
including shelves.
• Use a sponge to clean the inside surfaces with a solution of baking
soda and warm water. The solution should consist of approximately
2 tablespoons of baking soda to 1 litre of warm water.
• Wash the shelves with a mild detergent solution. Allow the shelves to
dry thoroughly before reinstalling them in the wine cooler.
• When cleaning the controls or any other electrical display areas,
ensure your sponge or cloth is not overly saturated.
• Clean the external cabinet with warm water and a mild liquid
detergent. Wipe dry with a clean, soft cloth.
• Avoid using steel wool or steel brushes on the stainless steel parts
of the appliance. These materials can contaminate the stainless steel
with particles, leading to possible rust.
Most power failures are resolved within a few hours and should not
affect your appliance's temperature if you limit the frequency of
door openings. If you anticipate a prolonged power outage, take
appropriate measures to safeguard your stored items.
• Empty all items from the wine cooler.
• Secure all loose items (like shelves) inside your appliance using tape.
• Retract the adjustable legs to the base to prevent any damage.
• Securely tape the door shut.
CLEANING THE WINE COOLER
POWER FAILURE
MOVING THE WINE COOLER
During transportation, ensure the appliance remains upright.
Use a blanket or similar protective covering to safeguard
the appliance's exterior.
07

If you feel the appliance is out of order, follow these instructions to try to see if you can solve
the problem simply by yourself before calling forservice.
The wine cooler does
not operate
The wine cooler is not
cold enough
Automatically turn-on
and turn-o frequently
• Not plugged in.
• The appliance is turned o.
• The circuit breaker tripped or a blown fuse.
• Check the temperature control setting.
• External environment may require a higher setting.
• The door is opened too frequently.
• The door is not closed completely.
• The door gasket does not seal properly.
• The room temperature is hotter than normal.
• A large amount of contents has been added
to the wine cooler.
• The door is opened too frequently.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
• Not plugged in.
• The circuit breaker tripped or a blown fuse.
• The lighting is turned o.
• Position the appliance away from heat
-generating appliances and direct sunlight.
• Maintain adequate ventilation around the
unit. Never obstruct the air vents.
• Only open the door when necessary.
Limit extended periods of the door being
open or frequent opening and closing.
ENERGY SAVING TIPS
TROUBLESHOOTING
PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE
The lighting does not work
08

Too much vibration • Check to assure that the appliance is level.
• Check to assure no parts inside the cabinet
or in the compressor chamber are loose.
The wine cooler seems
to make too much noise
• The rattling noise may come from the ow of the
refrigerant, which is normal. As each cycle ends,
you may hear gurgling sounds caused by the ow
of refrigerant.
• Contraction and expansion of the inside walls
may cause popping and crackling noises.
• The appliance is not level.
• The wine cooler is not level.
• The gasket is dirty.
• The shelves are out of position.
• The temperature probe is out of order.
TROUBLESHOOTING
PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE
The door will not
close properly
The display window is shown
with “HH” or “LL”instead of a
digital gure, and/or with
continuous buzz sound.
09

THANK YOU FOR PURCHASING THE
SNOMASTER VT-19R WINE COOLER
This product is warranted for 5 years on the compressor, 3 years
on the unit and 1 year on all parts not listed from the date of
purchase. Warranty does not cover products that have not been
used in accordance with the user guide or are outside the warranty
terms and conditions, which can be found at the following url:
https://snomaster.co.za/warranty/
WARRANTY, SERVICE AND SUPPORT
WARRANTY REGISTRATION
Register your SnoMaster Wine
Cooler now for warranty, and
allow us to provide you with the
best possible after sales service:
• Please log onto our website at
www.snomaster.co.za
• Click on the ‘Warranty’ tab.
• Enter warranty information and
upload proof of purchase at the
bottom of the page.
SERVICE AND SUPPORT
Should an instance arrive where
you require assistance, contact
our service team:
• Please log onto our website at
www.snomaster.co.za
• Click on the ‘Support’ tab.
• Click ‘Find a Repair Agent Near You’
and enter your region.
• Alternatively contact us via email:
[e-mail] or contact us
on [phone].
ON THE UNIT
WARRANTY
ON COMPRESSOR
WARRANTY
10
