SnowWolf AlphaBlower 36-106-P Manual

!
Operation & Maintenance Manual
REMEMBER: Register your product! No claims for warranty shall be considered unless your product
registration card is completed online within 30 days of purchase. Go to: snowwolfplows.com/registration.
AlphaBlower
Model 36-106-P
12-2021

MANUFACTURER'S WARRANTY
One-Year Limited Warranty
SNOWWOLF International, hereinafter referred to as SNOWWOLF, warrants new SNOWWOLF SNOW
BLOWERS at the time of delivery to the original purchaser, to be free from defects in material and
workmanship when properly set up and operated in accordance with the recommendations set forth by
SNOWWOLF.
SNOWWOLF'S liability for any defect with respect to accepted goods shall be limited to repairing the
goods at a SNOWWOLF designated location or at an authorized dealer location, or replacing them as
SNOWWOLF shall elect. The above shall be in accordance with SNOWWOLF warranty adjustment
policies. SNOWWOLF'S obligation shall terminate twelve (12) months after the delivery of the goods to
original purchaser including cutting edge breakage or wear. This warranty shall not apply to any machine
or attachment which shall have been repaired or altered outside the SNOWWOLF factory or authorized
SNOWWOLF dealership or in any way so as in SNOWWOLF'S judgment, to affect its stability or reliability,
nor which has been subject to misuse, negligence or accident beyond the Company recommended
machine rated capacity.
Warranty Claim
To submit a warranty claim, a return authorization from SNOWWOLF must be obtained. The failed part
may then be returned. Tampering with the failed part may void the warranty. This warranty does not
include freight or delivery charges incurred when returning machinery for servicing. Dealer mileage,
service calls, and pickup/delivery charges are the customers' responsibility.
Exclusions of Warranty
Except as otherwise expressly stated herein, SNOWWOLF makes no representation or warranty of any
kind, expressed or implied, AND MAKES NO WARRANTY OF MERCHANTABILITY IN RESPECT TO
ITS MACHINERY AND/OR ATTACHMENTS ARE FIT FOR ANY PARTICULAR PURPOSE. SNOWWOLF
shall not be liable for incidental or consequential damages for any breach of warranty, including but not
limited to inconvenience, rental of replacement equipment, loss of profits or other commercial loss. Upon
purchase, the buyer assumes all liability for all personal injury and property resulting from the handling,
possession, or use of the goods by the buyer.
No agent, employee, or representative of SNOWWOLF has any authority to bind SNOWWOLF to any
affirmation, representation or warranty concerning its machinery and/or attachments except as specifically
set forth herein.
This warranty policy supersedes any previous documents.
No claims for warranty shall be considered unless warranty registration is sent to SNOWWOLF
within 30 days of purchase!
Manufactured By:
14311 Ewing Avenue
Burnsville, MN 55306
www.snowwolfintl.com

1
AlphaBlower Operation and Maintenance Manual
Introduction..........................................................................................................................................3
Owner Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
AlphaBlower Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Standard Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Telescopic Loading Chute (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Hydraulic Tip Down (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Safety.....................................................................................................................................................9
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Safe Operation Needs A Qualified Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Importance of Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Operation.............................................................................................................................................15
General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Pre-Operation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Snow Blower Operating Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
AlphaBlower Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Daily Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Monthly Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Tractor Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PTO Revolutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Entering and Exiting the Tractor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Entering The Operator’s Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Exiting The Operator’s Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
AlphaBlower Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Connecting The Snow Blower To The Tractor’s Three-Point Hitch . . . . . . . . . . . . . . . . . .20
PTO Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
PTO Shaft Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
AlphaBlower Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Hydraulic Couplers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Checking AlphaBlower Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Operating The AlphaBlower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Clearing a Plugged AlphaBlower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
AlphaBlower Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Maintenance.......................................................................................................................................31
Maintenance Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
General Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

2AlphaBlower Operation and Maintenance Manual
AlphaBlower Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Auger Axle Couplings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cutout Clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Hydraulic Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cutting Edge Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
AlphaBlower Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
AlphaBlower Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Auger Axle Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Storage And Return To Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Return to Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Parts......................................................................................................................................................43
AlphaBlower Model 36-106-P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Impeller and Augers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
PTO Shaft Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Hydraulic Swivel Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Chute, 4-Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Chute, Hydraulic Tilt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Drawbar Ball Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Swivel Stopper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Drift Cutters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Decal Identification (AlphaBlower) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Chute, Telescopic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Adjustable Gauge Wheels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications....................................................................................................................................69
AlphaBlower Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Torque Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

3
AlphaBlower Operation and Maintenance Manual
Introduction
Owner Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
AlphaBlower Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Standard Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Telescopic Loading Chute (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Hydraulic Tip Down (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4AlphaBlower Operation and Maintenance Manual

5
AlphaBlower Operation and Maintenance Manual
Introduction
Owner Information
Thank you for your decision to purchase a
SnowWolf AlphaBlower. To ensure maximum
performance of your equipment, it is mandatory
that you thoroughly study the Operator’s Manual
and follow the recommendations. Proper
operation and maintenance are essential to
maximize equipment life and prevent personal
injury.
Operate and maintain this equipment in a safe
manner and in accordance with all applicable
local, state, and federal codes, regulations and /
or laws. Follow all on-product labeling and
instructions.
Make sure that all personnel have read this
Operator’s Manual and thoroughly understand
safe and correct operating, installation and
maintenance procedures.
SnowWolf is continually working to improve its
products. SnowWolf reserves the right to make
any improvements or changes as deemed
practical and possible without incurring any
responsibility or obligation to make any changes
or additions to equipment sold previously.
Although great care has been taken to ensure the
accuracy of this publication, SnowWolf makes no
warranty or guarantee of any kind, written or
expressed, implied or otherwise with regard to the
information contained within this manual.
SnowWolf assumes no responsibility for any
errors that may appear in this manual and shall
not be liable under any circumstances for
incidental, consequential or punitive damages in
connection with, or arising from the use of this
manual.
Keep this manual available for frequent reference.
All new operators or owners must review the
manual before using the equipment and annually
thereafter. Contact your SnowWolf Attachments
Dealer for assistance, information, or additional
copies of the manual. Contact
www.snowwolfplows.com or call 1-800-905-2265
for a complete list of dealers in your area.
Serial Number Location
Please record the snow blower information in the
space provided for future reference.
Always use the serial number of the snow blower
when requesting service information or when
ordering parts. Early or later models (identification
made by serial number) may use different parts,
or may require a different procedure in doing a
specific service operation.
NOTE: This document and the information
provided are the property of SnowWolf
and may only be used as authorized
by SnowWolf.
The snow blower serial number plate is located on
the left side of the frame, below the discharge
chute.
Model Number:
Serial Number:
Dealer Name:
Dealer Number:
Date of Purchase:

6AlphaBlower Operation and Maintenance Manual
Introduction
AlphaBlower Identification
AUGERS
GEARBOX
IMPELLER
GAUGE WHEEL
CHUTE
4-STAGE
CHUTE
TELESCOPIC
CUTTING
EDGE
BLOWER HOUSING
RUBBER
FLAP
CUTTING EDGE
LEFT SIDE
DEFLIECTOR
CHUTE
SWIVEL
MOTOR
DRIFT CUTTER
RIGHT SIDE
HYDRAULIC
CYLINDER
PTO
STUB

7
AlphaBlower Operation and Maintenance Manual
Introduction
The AlphaBlower can be mounted at the front by
using the specially designed gearbox.
Standard Items
• Front Mounting
• Gearbox for Front Mounting
• Reversing
• Hydraulic Rotating Deluxe Chute
• Hydraulic Adjustable Deflector
• Swivel Stopper for Chute
• Replaceable / Reversible Bolt-On Cutting
Edge
• Drift Cutters
• 1-3/4” PTO Stub on Blower Side
• Clearing Rod
• PTO Shaft and Mounting Kit
• Adjustable Gauge Wheels
Adjustable Gauge Wheels
The gauge wheels help avoid the snow from
becoming compacted and icy in the tracks. This
also makes snow blowing on gravel roads easier.
The gauge wheels float on top of gravel roads
instead of digging down into the gravel. The
gauge wheel is a 6 x 9” truck wheel and has
stepless height adjustment.
Options
Telescopic Loading Chute (Optional)
• Telescopic Loading Chute
A optional hydraulic controlled telescopic loading
chute is available. The telescopic loading chute is
useful for blowing snow into a dump trailer or
dump truck. And it is also useful when it is
required to throw the snow over tall snowbanks.
The telescopic loading chute is supplied with
hydraulic cylinders for height adjustment and
hydraulic cylinders for deflector adjustment.
Hydraulic Tip Down (Optional)
• Hydraulic Tip Down (for Deluxe Chute)

8AlphaBlower Operation and Maintenance Manual

9
AlphaBlower Operation and Maintenance Manual
Safety
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Safe Operation Needs A Qualified Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Importance of Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

10 AlphaBlower Operation and Maintenance Manual

11
Safety
AlphaBlower Operation and Maintenance Manual
Safety Information
Safety Alert Symbol
This SAFETY ALERT SYMBOL identifies
important safety messages on the
equipment and in the owner’s manual. When
you see this symbol, be alert to the
possibility of personal injury and carefully
read the message that follows.
The signal word DANGER on the machine
and in the manuals indicates a hazardous
situation which, if not avoided, will result in
death or serious injury.
The signal word WARNING on the machine
and in the manuals indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
The signal word CAUTION on the machine
and in the manuals indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate injury. It
may also be used to alert against unsafe
practices.
The signal word IMPORTANT identifies
procedures which must be followed to avoid
damage to the machine.
Safe Operation Needs A Qualified
Operator
AVOID SERIOUS INJURY OR DEATH
Operators must receive instructions before
operating the machine. Untrained operators
can cause serious injury or death.
For an operator to be qualified, he or she
must not use drugs or alcoholic drinks
which impair alertness or coordination while
working. An operator who is taking
prescription drugs must get medical advice
to determine if he or she can safely operate
a machine and the equipment.
Owner’s Responsibility
Operate and maintain this machine in a safe
manner and in accordance with all applicable
local, state, and federal codes, regulations and/or
laws; and in compliance with on-product labeling
and this owner’s manual instructions.
Make sure that all personnel have read this
owner’s manual, and thoroughly understand safe
and correct installation, operation and
maintenance procedures.
Give operating instructions to the operators before
allowing them to operate the equipment, and at
least annually there after.

12
Safety
AlphaBlower Operation and Maintenance Manual
Importance of Safety
Operating Safety
• Read and follow instructions in this manual and
the tractor’s Operators Manual before
operating.
• Operator must have instructions before
operating the equipment. Untrained operators
can cause injury or death.
• Be certain all equipment operators are aware
of the dangers indicated by safety decals
applied to the snow blower, and be certain they
follow all safety decal instructions. Contact
your authorized Distributor, Dealer Parts
Department or SnowWolf for safety decal
replacement.
• Operate the snow blower according to the
Operator’s Manual.
• The snow blower is intended for use in snow
removal. Us in any other manner is considered
to be contrary to the intended use of the snow
blower.
• In addition to the design and configuration of
equipment, hazard control and accident
prevention are dependent upon the
awareness, concern, prudence and proper
training of personnel involved in the operation,
transport, maintenance and storage of
equipment.
• Under no circumstances should young children
be allowed to work with this equipment.
• The snow blower is dangerous to persons
unfamiliar with its operation.
• Check for overhead power lines before
operating snow blower (if applicable).
• Check that the snow blower is securely
fastened to the tractor.
• Make sure all the tractor controls are in the
NEUTRAL before starting the snow blower.
• When learning to operate the equipment, do it
at a slow rate in an area clear of bystanders.
• DO NOT permit personnel to be in the work
area when operating the snow blower. Snow,
ice rocks or debri can be thrown from the
blower, causing injury to persons, cars,
buildings or other objects.
• Rotating PTO shaft, augers, impeller can
cause serious personal injury or death, make
sure no-one is in the work area when operating
the blower.
• The snow blower must be used ONLY on
approved machines.
• Always stop the snow blower if any persons
enter the work area.
• DO NOT modify the snow blower in any way.
Unauthorized modification may impair the
function and / or safety and could affect the life
of the snow blower.
• DO NOT make any adjustments or repairs on
the snow blower while the tractor is running.
• Keep shields and guards in place. Replace if
damaged.
• Prior to maintenance, repairs or clearing a
plugged blower the tractor engine must be
turned off or the snow blower must be
disconnected from the tractor.
• DO NOT operate the snow blower in poor
visibility conditions such as fog, darkness, or
any conditions that limit clear visibility.
• DO NOT operate in a work area that has not
been inspected for foreign debris and
obstacles.
• Remove any foreign objects and clearly mark
any objects that cannot be removed.
• Wear safety glasses, gloves, hard hat, hearing
protection and other protective clothing when
operating or maintaining this equipment.
• Have a first-aid kit available for use should the
need arise and train personnel on proper use
of the kit.
• SnowWolf cannot anticipate every
possible circumstance that may involve a
potential hazard. The warnings in this owner’s
manual are not all inclusive.

13
Safety
AlphaBlower Operation and Maintenance Manual
Importance of Safety Cont’d
Fire Prevention Safety
• All fuels, most lubricants and some coolant
mixtures are flammable. Flammable fluids that
are leaking or spilled onto hot surfaces or onto
electrical components can cause a fire.
• Know where fire extinguishers are located and
how to use them.
Transporting Safety
• Comply with state and local laws governing
highway safety and movement of machinery
on public roads.
• Check local laws for all highway lighting and
marking requirements.
• Always yield to oncoming traffic and move to
the side of the road so any following traffic may
pass.
• Never allow riders on either tractor or snow
blower.
• If transporting the snow blower on a truck or
trailer, make sure it is properly secured to the
transport vehicle.
Hydraulic Safety
• Always disconnect hydraulic connections
between the tractor and the snow blower
before performing maintenance to the snow
blower.
• Always clean fluid spills. Do not use gasoline or
diesel fuel for cleaning parts. Use commercial
nonflammable solvents.
• Check hydraulic tubes, hoses and fittings for
damage and leakage. Never use open flame or
bare skin to check for leaks. Hydraulic tubes
and hoses must be properly routed and have
adequate support and secure clamps. Tighten
or replace any parts that show leakage.
Leaking fluids under pressure can enter the
skin and cause serious injury or death.
Immediate medical attention is required.
Wear goggles. Use cardboard to check for
leaks.
First Aid Safety
Know where first aid kits are located and how to
use them.

14 AlphaBlower Operation and Maintenance Manual

15
AlphaBlower Operation and Maintenance Manual
Operation
General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Pre-Operation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Snow Blower Operating Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
AlphaBlower Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Daily Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Monthly Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Tractor Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PTO Revolutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Entering and Exiting the Tractor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Entering The Operator’s Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Exiting The Operator’s Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
AlphaBlower Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Connecting The Snow Blower To The Tractor’s Three-Point Hitch . . . . . . . . . . . . . . . . . . . . .20
PTO Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
PTO Shaft Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
AlphaBlower Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Hydraulic Couplers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Checking AlphaBlower Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Operating The AlphaBlower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Clearing a Plugged AlphaBlower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
AlphaBlower Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

16 AlphaBlower Operation and Maintenance Manual

17
AlphaBlower Operation and Maintenance Manual
Operation
General Information
Pre-Operation Inspection
Before operating the snow blower for the first time
and each time thereafter, use the following list as
a guideline during equipment inspection.
1. Use only a tractor of adequate power and
weight to operate the snow blower. (See
“Tractor Requirements” on page 19).
2. Check the snow blower and tractor’s three-
point mounts for damage, loose or missing
parts. Repair as needed before operation.
3. Lubricate the snow blower, see Lubrication on
page 37.
4. Check that the PTO driveline telescopes easily
and turns freely.
5. Check that the snow blower is properly
attached to the tractor. Be sure retainers are
used on the mounting pins.
6. Check that the adjustable gauge wheels are
set at the same working depth.
7. Make sure that all guards and shields are in
place, secured and functioning as designed.
8. Check oil level in tractor’s hydraulic reservoir.
9. Check that the hydraulic hoses and couplers
are securely attached to the snow blower and
to the tractor. Make sure hoses are routed and
secured to avoid pinch points or strain during
movement of the tractor / snow blower.
10. Check cutting blade for wear or damage.
11. Check hydraulic lines, connections and fittings
for hydraulic oil leaks.
Leaking fluids under pressure can enter the
skin and cause serious injury or death.
Immediate medical attention is required.
Wear goggles. Use cardboard to check for
leaks.
Snow Blower Operating Tips
• Make sure the snow blower is adjusted
properly. (See “AlphaBlower Adjustment” on
page 23.)
NOTE: Improper snow blower adjustment will
cause increased wear to the gauge
wheels.
• Driving speed and gear selection are
dependent on the snow conditions and the
tractor type. Do not choose too high a gear but
make a selection so speed can be kept steady.
• Before disengaging the PTO it is important to
wait until the blower has emptied out the snow.
If the PTO is disengaged while the blower is full
of snow, the chute will likely clog up when the
PTO is re-engaged.
• If the blower is frequently used on gravel roads
or asphalt, in conditions with little snow, it is
recommended to use gauge wheels.
• Adjust throwing distance and the direction of
the snow being removed, away from buildings,
cars, or other objects to avoid causing
damage.
• The chute can be tilted down to remove snow
from the impeller housing. Always stop the
tractor’s engine before the chute is tilted down.
• Always stop the snow blower before exiting the
tractor.

18 AlphaBlower Operation and Maintenance Manual
Operation
AlphaBlower Inspection
Daily Inspection
NOTE: Inspect the snow blower by performing
a walk around daily before and after
use. Use the following inspection
checklist as a guideline.
Check the following items every 10 hours of
operation:
• Verify that the snow blower is properly
connected to the tractor.
• Check that all shields and guards are in place.
• Check for damaged or leaking hydraulic hoses
or fittings. Replace if necessary.
• Check the cutting edge for wear or damage.
Replace if necessary.
• Check that all cotter pins that retain pivot/
anchor pins are in place and not damaged or
missing.
• Check the snow blower to ensure that all
components are secure and that all bolts and
nuts are thoroughly tightened.
• Check the snow blower mounting hardware for
wear or damage. Inspect the pins and mounts
for wear or damage. Repair or replace
damaged parts if necessary.
• Check that all bearings turn freely. Replace
any that are rough or seized.
• Check that the PTO driveline is securely fasten
to the snow blower and to the tractor.
• Check the oil level in the gearbox.
Monthly Inspection
• Inspect the snow blower for cracks, bends, or
excessive wear.
• Check gauge wheels for wear and PSI if not
foam filled.
• Check that all bolts are tight.
• Check the cutting edge and mounting plate for
cracks or damage. Replace if necessary.
• Check the drift cutters for cracks or damage.
Replace if necessary.
• Check hydraulic lines, connections and fittings
for hydraulic oil leaks. Repair or replace
damaged parts if necessary.
• Check for damaged or missing decals.
Replace if necessary.
• Lubricate as required.
AVOID SERIOUS INJURY OR DEATH
Before servicing the snow blower:
• Always park on a flat level surface.
• Lower the tractor’s three-point hitch and
place snow blower flat on the ground.
• Place all controls in NEUTRAL.
• Engage the park brake.
• Stop the engine and remove the key.
• Wait for all moving parts to stop.
• Exit the tractor.
SEE TRACTOR’S OPERATOR’S MANUAL
FOR ADDITIONAL INFORMATION.
