SOCO CP1 User manual

Do not operate the electric vehicle until you have read the user manual carefully and
understand the performance of the electric vehicle, and please keep the user manual in a safe place.
E-Scooter User Manua

To ensure your safety, please read this manual carefully before riding and make sure you
are always following the requirements below:
USER INSTRUCTION
1
To ensure your safety, please read this manual carefully before riding and make sure you
are always following the requirements below:
Fully understand the information in this manual, including but not limited to the relevant instructions, precautions
and warnings.
Fully understand the operation and contingency measures of CP1 Smart Electric Scooter.
Be fully aware of warning labels of CP1 Smart Electric Scooter.
Do not disassemble the vehicle or any parts without permission. Please contact customer service department
and dealers if you need any replacement or make further purchase.
Please keep the user manual in a safe place.
1
2
3
4
5
All parameters of this vehicle have been permanently set according to the national standard before leaving factory.
The company is not responsible, if the original electrical or circuit has changed and caused excess, such as increase
the speed.
SAFETY INSTRUCTION
To ensure the safety of you and others, please make sure to observe the following:
1
2
3
4
Don’t lend your vehicle to someone who can’t operate it to prevent any hurts.
Please obey local laws and regulations while operating the vehicle on the road.
Do not ride on the road after taking medications, drinking alcohol or when you feeling unwell which
may affect your riding ability.
Observe traffic regulations and traffic signs, according to the provisions of laws and regulations to carry
man and cargo. Confirm the surrounding road conditions and vechile condition any time to actively avoid
danger.

SAFETY INSTRUCTION
2
10
a ）Do not park the vehicle indoors or in the hallway.
b ）Do not charge the battery/vehicle indoors or in the hallway. The battery/vehicle should be kept away from combustible
materials when charging, and the charging time should not be too long.
c ）Please pay attention to the correct usage of the battery and warning labels.Wasted batteries should not be dismantled
without authorization, and should be managed and recycled by the relevant professional departments.
d ）Please pay attention to the safe usage and the warning labels of the charger. Make sure to use the original charger
for the same model.
e ）Please be aware of the precautions regarding water washing.
5
6
7
8
9
In rainy and snowy weather, braking distance will be extended, please slow down the vehicle.
Avoid travelling in bad weather such as storms and typhoons.
Wear safety gears, especially helmet. Wear appropriate protective clothing like boots and gloves if necessary.
To ensure the safety of you and others, please avoid using the high beam under good lighting conditions.
The continuous use of high beam will cause visual obstacles to opposite vehicles and pedestrians and
affect the safe driving. In the case of dim light, turn on the lights in time.
Please turn off the power immediately and remove the key after riding. Do not allow children play the
vehicle to avoid unnecessary losses.
Perform a basic check each time before riding.
Please pay attention to the safe operation of the electric vehicle:
11 Check before riding, if there is an abnormality, please promptly carry out maintenance or find
professional repair service:
a ）Check the status of power circuit, lighting circuit, etc.
b ）Check whether the front and rear brakes work properly.
c ）Check whether the handlebars, front and rear wheels are stable.
d ）Check tire pressure.
e ）Check whether the reflectors are stained.

2 1 1
1 12
Intelligent Remote Control Quick Start
QUICK START
ACCESSORIES CHECKLIST
01
Rearview Mirrors
Key Wrench for Rearview Mirror Charger
3

4
INSTALL REARVIEW MIRRORS
QUICK START
02

1Put in the battery pack.
2 3 4
Open battery
compartment under the
seat and remove the
cover. Turn off the air
circuit-breaker
Plug in the main
connector,and switch
on the air circuit-breaker
Put back the battery
compartment cover and
put down the seat.
INSTALL BATTERY PACK
5
03
QUICK START

Note：When the vehicle remains stationary for a long time in power-on state, it will switch to the parking
state. Gently hold the brake,and the power will be on again.
6
STARTING VEHICLE
04
QUICK START
Put on the helmet.
1Get on your CP1, retract the
side stand and center stand
23
4 5 6
Press “Unlock” button on the
intelligent remote control.
Press “Power” button on the
intelligent remote control. Or
insert the key into the keyhole
and switch to "On" position.
Power on
Press the “Parking” button,
apply the brake to unpark
the vehicle, parking indicator
turns off.
Gently twist the throttle to
ride on the road.

7
CP1 intelligent electric motorcycle supports wireless communication, GPS, etc.,
which can connect the vehicle with your smart phone.You can manage and check your
vehicle using your smart phone through the SOCO App.
Available on iOS and Android platforms, please check your smart phone operating system before installation.
iOS platform: App requires iOS 9.0 or later.
Android platform: App requires Android 4.4 or later.
Since the date of purchase, you will be presented with 1 year's free
data of SIM card to use SOCO APP function.Make sure to recharge it
before the free period expires. For those who fail to recharge within
the time limit, the operator will close the recharge interface, and the
recharge function of data cannot be restored, in which case SOCO
APP cannot be used normally.
SOCO APP
Download and install SOCO App by scanning the QR code in the last page of this manual.
QUICK START
05
DOWNLOAD APP

DESCRIPTION OF COMPONENTS AND PARTS
OPERATIONGUIDE
RIDING GUIDE
BATTERY USE INSTRUCTION
APP INSTRUCTIONS
MAINTENANCE
COMMON PROBLEMS AND TEOUBLESHOOTING MENTHOSD
9
11
16
19
22
23
24
CONTENTS
8

SIDE VIEW
Headlight
Rearview
mirror
Brake
system
Motor
number
Rear
Swingar
License Plate
Bracket
Side stand
FOC Vector
Controller
Name plate
Aluminum
Alloy Rim
TOP VIEW
Front brake
lever
Rear brake
lever
Taillight
Left
Handlebar
Control Assy
Throttle
Control
Right Handlebar
Control Assy
Brake
cylinder
Turn
Signal
Dash
Saddle
9
a. Schematic diagram of components and parts
DESCRIPTION OF COMPONENTS AND PARTS

DESCRIPTION OF COMPONENTS AND PARTS
b. Dashboard Oerview
SPORT Mode
NORMAL Mode
ECO Mode
High Beam Indicator
Indicate high beam is on
Turn Signal Indicator
Flashing when left or right
turn signal is on.
Battery Error Indicator
indicates in
Forward Mode
indicates in
Forward Mode
Parking Indicator
The indicator displays P
when the vehicle is in
Parking state.
Error Indicator
Charging light
OBD Checking Error Codes
READY Start Indicator
The vehicle is ready to go when the READY
Indicator illuminates.
See Page 26 TROUBLESHOOTING for reference.
1
5
8
2
Speedometer
Display current speed
of the vehicle. Display current time.
Power Display Bar
Display current amount
of energy remaining in
battery A and B.
Ride Mode/Forward
or Reverse Mode
Clock 3
Display current
endurance mileage
EnduranceMileage 4
Display current ambient
temperature.
Ambient Temperature
7
Display total distance the
vehicle has been ridden.
Total Mileage
6
9
Display the SoC in percentage.
(*When using two batteries, the SoC shows
the percentage
State of Charge (SoC)
Controller Output Current
Display real-time Controller
Output Current.
10 Controller Temperature
Display current operating
temperature of the controller.
1
2
4
3
7
5
6 810
Display Ride Mode/Forward
or Reverse Mode.
10

2
3
1
132
Press, horn on;
Release, horn off.
Horn ButtonTurn Signal SwitchHigh/Low Beam Switch
Turn to left, left winker on;
Turn to right, right winker on.
Up position, high beam on;
Down position, low beam on.
11
a. Left Handlebar Control Assy
OPERATION GUIDE

12
3
R
3Forward and Reverse Switch
Mode switch
2Parking switch
he vehicle provides three ride
modes: 1 eco, 2 normal, 3 sport.
Position Right for Mode 1;
Position Middle for Mode 2;
Position Left for Mode 3.
When the parking switch is pressed to the
up position, the vehicle enters parking state,
and the parking indicator (P) illuminates;
When the parking switch is pressed to the
down position, the READY indicator illuminates,
and the vehicle exits parking state.
Gently press the “Forward and Reverse Switch” R twice, the Mode
Number on the dash switches to F, and the vehicle enters Forward
Mode, gently twist the throttle to push the vehicle forward; press
again to switch to R, and the vehicle enters Reverse Mode, press
and hold the R switch and gently twist the throttle to reverse the
vehicle; then press the switch and the dash displays Mode Number
and the vehicle returns to normal Forward Mode.
12
b. Right Handlebar Control Assy
OPERATION GUIDE

3. Lock Button
2. UNLOCK
1. Key less start
After unlocking the vehicle via Intelligent Remote Control,
pres s the “ POWER ” button, power on, pres s again, power
off.
When the vehicle is in a stationary state, press “Lock”
button, the vehicle enters locked state.
Press “Unlock” button, the vehicle enters unlocked state.
CP1 is equipped with second generation SOCO Intelligent Remote Control, with a press of the button, you can lock or unlock
the vehicle within an effective distance.
c. Intelligent Remote Control Operation
OPERATION GUIDE
13

d. Mechanical key
1. Start the vehicle with Mechanical Key 2. Steering Wheel Lock Operation
3. Open the Battery Compartment
After unlocking the vehicle via Intelligent Remote
Control, insert the key and turn the key to
“ON” position, power on; turn the key to
“OFF” position, power off.
Insert the key, press it down and turn it counterclockwise
Insert the key, and turn it counterclockwise.
After parking the vehicle, turn the handlebar
to extreme left position. Insert the key to the
steering wheel lock, press down the key and
turn counterclockwise to lock the steering
wheel..
Insert the key to the steering wheel lock,
press down the key and turn clockwise to
unlock the steering wheel.
Insert the key and turn the key clockwise
to unlock the battery compartment.
Press and hold the unlock button on the
Intelligent Remote Control for 3 seconds
under the power on state, when you hear
the beep, you can open the battery
compartment.
OPERATION GUIDE
14

OFF
ON
OPERATION GUIDE
e. Air Circuit-breaker
TIPS：To ensure the safety of the vehicle and the user, please turn o the air circuit-breaker when washing the vehicle,
storing the vehicle for extended periods of time or taking out the battery pack
The air circuit-breaker serves as the main power protection for the entire vehicle. When the vehicle circuit is abnormal or short
circuit causes the current to exceed the safety setting, the air circuit-breaker will automatically disconnect to ensure safety
15

6
RIDING GUIDE
If you have any questions, please contact SOCO Customer Service.
1
2
3
4
5
6
7
8
9
10
11
12
a. Pre-ride Checklist
Before operating your CP1 Smart Electric Scooter, check the following to ensure your own safety:
Check whether the handlebar is stable and flexible when turning.
Check whether the left and right handlebar controls work properly.
Check whether the throttle control works properly.
Make sure the tire pressure is within normal range. The suggested tire pressure is 175 kPa for the front tire, 225 kPa for
the rear tire.
Make sure that there are no cracks, damage, wear, foreign object puncture or adhesion on the tire surface.
Check trend depth of both tires is enough. If the tire is worn to the black shaded mark
on the diagram, it needs to be replaced.
Check if any error warning sign illuminates on the dash when power on.
Check whether the battery capacity is sufficient for your trip.
Check whether all lights function properly.
Check whether horn function properly.
Check whether rearview mirrors are clean and
adjust them to appropriate angle.
Check whether brake fluid is sufficient, whether the
handlebar and brake system function properly
16

RIDING GUIDE
b. Starting the vehicle
17
Put on the helmet.
1Get on your CP1, retract the
side stand and center stand
23
4 5 6
Press “Unlock” button on the
intelligent remote control.
Press “Power” button on the
intelligent remote control. Or
insert the key into the keyhole
and switch to "On" position.
Power on
Press the “Parking” button,
apply the brake to unpark
the vehicle, parking indicator
turns off.
Gently twist the throttle to
ride on the road.
Note：When the vehicle remains stationary for a long time in power-on state, it will switch to the parking
state. Gently hold the brake,and the power will be on again.

c. Riding Safety Tips
TIPS：
1
2
3
4
5
6
Before riding, make sure side stand and main stand is kicked out, handlebar is unlocked.
DON’T press “PARKING” button or kick out the kickstand while riding, as it will cut off the power suddenly,
which may cause unforeseen danger.
You can only start the vehicle when it’s in the stationary state. If an error occurs while riding, please slide or
push the vehicle to a safe area. Do not attempt to restart the vehicle while riding or in the driving lane to avoid
danger.
1
2
3
RIDING GUIDE
When the vehicle is starting, you should slowly accelerate in order to avoid excessive starting current caused by
instantaneous rapid acceleration and increased energy consumption.
Under the premise of ensuring safety, try to maintain a constant speed, reduce frequent start, brake, instant
acceleration, etc. to avoid increased energy consumption.
The maximum load for CP1 is 150KG. Overloading is strictly prohibited.
When pushing the vehicle, please press the “Parking” button or switch to Forward Mode to prevent
accidents caused by sudden start of the vehicle due to unintentional turning of the throttle control.
Please cut off the power while parking, and remove the key or switch to Forward Mode.
When the vehicle remains stationary for a long time in power-on state, it will switch to the parking state.
Gently hold the brake,and the power will be on again.
18

BATTERY USE INSTRUCTION
a. On-board Charging
Charging:
the indicator illuminates red
Fully charged:
the indicator illuminates green.
Error:
the indicator flashes red and green
alternately
Plug the charger into on-board charger socket.
Connect the charger to a power supply, and the indicator on the charger illuminates red during
normal charging.
Once the vehicle is fully charged, the indicator on the charger illuminates green.
1
2
3
19
