SOCO TC User manual

USER INSTRUCTIONS
Safety Instructions
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.
Fully understand the information in this manual, include but not limited to the relevant instructions, precautions and warnings.
Welcome to the family of SOCO owners! We will guide you to know every function for the right and safe use of TC smart electric
bikes. To ensure your safety, please read this manual carefully before riding and make sure you are always following the
requirements TC below:
Please contact the SOCO Customer Service Center if you have any questions!
Wish you safe and pleasant riding experience!
To ensure the safety of you and others, please make sure to observe the following matters:
In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions. The continuous use of high
beam will cause the visual disturbance to vehicles and pedestrians on the opposite side, thus affecting normal driving.
Perform a basic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check other parts for
looseness or abnormal noise, and regularly go to SOCO Service Center for maintenance.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
Observe traffic regulations and traffic signs and confirm the surrounding road conditions and bike conditions at any time, so as to
actively avoid danger.
Fully understand the operation and contingency measures of TC smart electric motorcycle
DON’T disassemble Vehicle or any parts, if need replacement, please contact local dealer.
Be fully aware of warning labels of TC smart electric bikes.

QUICK START
CHECK LIST
REMOTE CONTROLS
ASSEMBLE MIRRORS
KEYS
LEFT MIRROR RIGHT MIRROR
CHARGER USER MANUAL
INNER HEXAGON
SPANNER SPANNER FOR
MIRRORS

QUICK START
INSTALL BATTERY PACK
OPEN STORAGE,TAKE OUT COVER. CONNECT POWER.
PUT BATTERY PACK IN.
OPEN STORAGE,TAKE OUT COVER.

Press ‘UNLOCK’ on remote control, “POWER” button on.
Put helmet on, get on tc, kick side stand out.
Press “POWER”, power on.
Press “PARKING” button, release motorcycle,
parking symbol off.
IGNITE MOTORCYCLE
QUICK START
Turn on accelerator, motorcycle move.

VEHICLE & PARTS
PARTS INSTRUCTION
Mirror
Head light
Front suspension
Storage
Seat
AL. RIM with
spokes
Disc brake system
Adjustable
foot rest
Controller
Side stand
Motor
Disc brake system
Rear
swingarm
Tail light
License plate
support
Passenger
foot rest
Instrument
Rear brake lever
Left switch
Tuning light
Right switch
Throttle
Front brake lever
Brake oil tank

7
M
3
5
VEHICLE & PARTS
INSTRUMENT
BUTTON FUNCTIONS
Change Indications ------ Range/Temperature
Speed Indication
Range/Temperature
In normal mode, Press it less than 2 seconds, change indications,
and keep the status.
Indicate current trip
range or temperature.
Can switch.
Total Range
Indicate total range.
Show current speed
Controller Temperature
SOC in Bars
Indicate real-time
battery capacity
SOC in %
Indicate real-time
battery capacity
Indicate real-time
temperature of controller
Mode
Indicate real-time riding
model
Manually start the back light of Instrument (Back light for Letters
+ LCD back light)
In normal mode, Press it longer than 2 seconds but shorter than 8
seconds, start the back light for instrument and head light.
Change between KM/Mile and KM/P & MPH
In normal mode, press it longer than 8 seconds, then release.
Errors
Charging
Data Connecting
:ECO Mode
:NORMAL Mode
:SPORT Mode
HIGH BEAM ON
MOTORCYCLE IN PARKING POSITION
TURNING LIGHT ON
BATTERY ERROR
MOTORCYCLE IS READY TO RIDE
Indication of Error
Code Details in
Error List.

OPERATION GUIDE
LEFT SWITCH RIGHT SWITCH
Move to left, left turning light on;
Move to right, right turning light
on.
Press, horn on; release, horn off.
Up position at , high beam
on;
Down position at , low beam
on.
Motorcycle is set with 3 modes:
1: ECO Mode
2: NORMAL mode
3: SPORT mode
Position at left, mode 1;
Position in the middle, mode 2;
Position at right, mode 3.
Press, light on, motorcycle at
parking position;Press again,
motorcycle ready to ride.
Up position , front light on;
Down position , front light
automatically on. (Front light
adjust the lightness automatically)
BUTTON FUNCTIONS
High/Low Beam Switch
BUTTON FUNCTIONS
Parking
Front light Mode Change

OPERATION GUIDE
POWER REMOTE CONTROL
“POWER” flash, locked status.
After unlocking the motorcycle via remote control, press
the “POWER”, motorcycle power on, press again, power
off.
Intelligent remote control, within 20 meter radius, press
the button, can lock or unlock your TC.
UN-LOCK
LOCK
LOCK, when motorcycle in standing position,
press “LOCK”, “POWER” flash, motorcycle
locked.
UNLOCK, press unlock, “POWER”
continuously on, motorcycle unlocked.
“POWER” continuously on,
stand-by status
Red circle continuously on,
motorcycle ready to ride.

OPERATION GUIDE
HANDLEBAR LOCK STORAGE & SEAT
Motorcycle in parking position, turn handlebar to the extreme
left position, put key in handlebar lock, and turn the key to
right, motorcycle handlebar locked.
Put the key in handlebar lock, and turn the key to left,
handlebar unlocked.
Put key in, turn key to right, when hear sound “click”, storage
open.
Put key in, turn key to left, seat open, under seat, there is
tools with motorcycle.
LOCK
UNLOCK

OPERATION GUIDE
KILL SWITCH ADJUSTABLE FOOT REST
Kill switch, protection of power, when current over than the set range
cause by abnormal situation or short circuit, kill switch will be stop the
connection with battery automatically, for safety reason.
Unique adjustable foot rest, offer 3 riding positions,
adjustable according to rider’s request.
TIPS:for your own safety, please put kill switch at “OFF” position:
A. before taking out battery pack;
B. before cleaning motorcycle;
C. long time storage the motorcycle.
Open seat, take out the inner hexagon spanner.
Lose the bolt under the foot rest.
Adjust the foot rest to suitable position, then fix the bolt.

OPERATION GUID
CHECK LIST BEFORE RIDING
Whether the handlebar is stable and flexible when turning.
Whether the switches on the right and left handlebars can work correct.
Whether the throttle work correct.
Make sure to check the following items before riding a TC
Make sure the tyre pressure is ok. The suggested tire pressure is 200Kpa for front wheel, 200Kpa for rear with rider only, 225Kpa for
rear when 1 rider with 1 passenger.
Check tyre surface, make sure no cracks, damage, and foreign matter puncture or attachment.
Whether the tread depth is sufficient (>0.8 mm).
Whether any error warning light on the instrument with power on.
Whether the battery capacity is sufficient for your trip.
Whether all light work correct.
Whether the horn work correct.
Whether the mirrors are clean. Adjust them to the appropriate angle.
Whether the brake oil is sufficient, whether the brake lever and brake system work correct.
For any questions, please contact SOCO Customer Service Center.

RIDING GUIDE
POWER ON
Press “UNLOCK” on remote control, “POWER” continuously on.
Put on helmet, riding TC, kick out side stand.

RIDING GUIDE
Press “POWER”, power on.
Turn throttle, motorcycle run.
Press “PARKING”, parking light off, free motorcycle from parking.
Before riding, making sure side stand is kicked out, handlebar is unlocked.
DON’T press “PARKING” during riding, in case any dangerous due to
power off in parking status.
Motorcycle can power on in steady standing position. In case any unusual
situation, please move to side road, in case any dangerous.
DON’T put side stand at standing position, in case any dangerous due to
power off in standing position.

BATTERY USE INSTRUCTION
Connect the charger with motorcycle.
Connect the charger with power, green light on charger flash one by one according to the battery capacity, when charing.
Fully charged, all green lights on charge on.
Charging on-board
Battery capacity indication.
Charging: single
green light flash
one by one;
Fully charged: all
lights on.
Error: all lights
flash.

BATTERY USE INSTRUCTION
External charing
Open storage, put off kill switch, take out storage room cover. Disconnect the power connector.
Put key in battery locker, turn to right, then can take out the
battery pack from motorcycle.
Connect charger with battery, then connect charger with power, charger working, green lights on charger flash one by one.

BATTERY USE INSTRUCTION
After fully charged, all lights turn into green.
In case long time no use battery, please charge it till half (in case battery capacity was 0% before charging, charging f3 hours).
Store in dry ventilated place, charge 2 hours each 2 months.
Battery pack and charger need to be stored in clean, dry ventilated place, avoid connect with corrosive material, stay away from
heating point.
Disconnect the charger and battery when storing them.
Battery storage condition: temperature :-20 - 45 ℃, humidity ≤ 65%RH.
Keey battery pack away from water;
Charging battery pack after using, if don’t use the motorcycle
for long time, must take out battery pack out motorcycle;
Forbidden to connect battery pack input and output;
Charging temperature: 0 - 45℃, discharging temperature:-20
- 45 ℃;
Forbidden to connect battery pack input and output;
Must use appointed charger, forbiddent to use any other
charger to charge battery pack;
Forbidden strong impact and press on battery pack;
Before delivery, battery pack already passed quality checking,
forbidden to open it；
In case any questions, contact local dealer.
Storage、maintenance、transport

MAINTENANCE
Regular maintenance can enhance the service life and driving safety of TC. Please refer to the following suggestions and take care of
your motorcycle.
Cleaning: Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the surface; it is prohibited
to use metal brushes, sandpaper or the like to clean it, in order not to scratch the parts surface. After cleaning, dry it with soft cloths.
Please disconnect the kill switch before cleaning.
Do not use strong water jet to directly wash it, so as to avoid the default of mechanical parts caused by water invasion.
Storage: try to park it in a dry and ventilated space to reduce the exposure to sun and rain, avoid rusty of parts.
In case don’t use for long time, please turn off kill switch and disconnect the power supply, prevent over discharging.
After long-term storage, please fully charge it before use.
All service and maintenance must operate by SOCO Service Center, use parts from manufacturer.
In case rider failed service and maintenance the motorcycle as requested, SOCO reserve rights refuse the warranty claims, if any.
In case rider open the vehicle without authorization, or using parts not from manufacturer, SOCO reserve rights refuse the warranty
claims, if any.
The new motorcycle must do the first inspection and maintenance in the SOCO Service Center when it reaches 1,000 km or two
months (whichever comes first).
ROUTINE CLEANING AND MAINTENANCE
REGULAR INSPECTION AND MAINTENANCE
The motorcycle is recommended to do a regular inspection and maintenance in the SOCO Service Center at every 3,000 km or six
months (whichever comes first).

FAQ & TROUBLE SHOOTING
Error Causes Solutions
Regular maintenance can enhance the service life and driving safety of TC. Please refer to the following suggestions and take care
of your motorcycle.
1.Battery is poorly connected
2.Kill switch is not turned on
1.Connect the power cable appropriately
2.Turn on the kill switch
1.Low battery
2.Side stand is on
3.At parking mode
4.Brake handle does not reach the right position
5.Throttle error
6.The controller plug is loose
7.Controller error
1.Charge the battery
2.Side stand off
3.Press parking button
4.Place the brake handle at the right position
5.Change throttle
6.Re-plug controller
7.Change controller
1.Low battery
2.Flat Tyre
3.Heavily overloaded
4.Brake pads need to be replaced
5.Battery aging or normal scrap
Charge the battery
Pump up the tyres, check tyre pressure before riding
Foster a good habit, keep an appropriate load
Change the brake pads and check the brake system
before riding
Change battery
1.Poor contact of charger plug
2.Used wrong charger
3.Battery aging or normal scrap
1.Check whether the plug is at right position
2.Use SOCO charger
3.Change battery
No power, “POWER” not on
Power on, turning throttle,
motor not work
DAILY CLEAN AND MAINTENANCE
Speed is slow or mileage
is short
Battery cannot be charged
1.
2.
3.
4.
5.

Failure Causes Solutions
Error 99 on Instrument Controller communication error Please contact after-sales service or dealer
Error 98 on Instrument Controller pauses operation (possibly over
current, blocking, under voltage, over temperature) Please stop for a while and then start again
Error 97 on Instrument Controller power tube error Please contact after-sales service or dealer
Error 96 on Instrument Controller Hall sensor error Please contact after-sales service or dealer
Error 95 on Instrument Controller throttle error Please check if battery connector at right position,
contact after-sales service or dealer
Error 94 on Instrument Battery communication error Please check if battery connector at right position,
contact after-sales service or dealer
Error 93 on Instrument Charging, over current Stop charging, check the charger
Error 92 on Instrument Charging, over voltage Stop charging, check the charger
Error 91 on Instrument Battery at high temperature Stop charging, stop riding
Error 90 on Instrument Discharge, over current Stop riding
Error 89 on Instrument Low temperature charge Park indoor or in a warm place, wait for a moment
Error 88 on Instrument Low temperature discharge Park indoor or in a warm place, wait for a moment
Error 87 on Instrument Internet connection error Go to an open area, contact after-sales service or dealer
Error 86 on Instrument GPS connection error Go to an open area, contact after-sales service or dealer
