Baja motorsports SC150 HSun 150cc User manual

SC150 SCOOTER
Read this manual carefully. It contains important safety information.
No one under the age of 16 should operate this scooter.
Always wear a helmet; It could save your Life!
Do not remove this operator’s manual from this vehicle.
Please obtain, review, and follow provincial / municipal government acts and
regulations pertaining to owning and operating this scooter.
OWNER’S MANUAL
Minimum Recommended Age
Requirement 16
Rev. B
030909

II
Congratulations on your purchase of the BAJA INC. SC150 Scooter.
Your Scooter is warranted to be free of manufacturing defects in
material and workmanship for a period of 90 days from the date of
purchase. During the warranty period BAJA INC. will at its option,
repair, provide replacement parts or replace your BAJA INC. 150cc
Scooter at no charge. This warranty does not cover normal wear
items or damage caused by neglect or misuse of the product.
Engine Warranty – 90 days
Frame Warranty – 90 days
Warranty is void if:
Frame is bent or broken due to abuse
Wheels are bent or broken
Fender bent or broken due to abuse
Any sign of impact, accident, jumping, spin-outs or roll over.
BAJA INC. is not liable for any damage claim or liability claim person
or otherwise resulting from the operation of this product in any way.
Should you experience with your vehicle, please contact Baja Inc. customer
service line toll free at 1-888-863-2252 between the hours of 7am and 5pm
Monday through Friday MST (Mountain Standard Time). MDT (Mountain
Daylight Time) during daylight savings time. You will be instructed how to
proceed.
A COPY OF THE SALES RECEIPT IS REQUIRED.

III
This manual should be considered as a permanent part
of the vehicle and should remain with the vehicle when
resold or otherwise transferred to a new user or operator.
The manual contains important safety information and
instructions which should be read carefully before
operating the vehicle. All operators should obtain, review,
and follow provincial and municipal government acts and
regulations pertaining to owning and operating an
on-road vehicle. Children under the age of 16 should
never operate this vehicle.
WARNING
It is the operators responsibility to know and obey all
applicable local, state and federal laws at all times while
operating this vehicle including but not limited to trafc
safety, vehicle registration, emissions, and noise
WARNING
!
The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth
defects or other reproductive harm.
CALIFORNIA PROPOSITION 65
WARNING
!
!

1
IMPORTANT ........................................................................................................ 2
GENERAL PRECAUTIONS/WARNINGS ............................................................ 3
NHTSA SAFETY NOTICE.................................................................................... 8
PRE RIDE CHECK LIST...................................................................................... 9
LOCATION OF WARNING LABELS................................................................... 12
OPERATION ........................................................................................................ 13
STARTING THE ENGINE............................................................................. 13
DRIVING SAFELY........................................................................................ 14
SHUTTING OFF THE ENGINE .................................................................... 15
STOPPING THE VEHICLE .......................................................................... 15
PARKING ..................................................................................................... 15
BREAKING IN.............................................................................................. 15
IGNITION SWITCH ...................................................................................... 16
BRAKE LEVERS AND THROTTLE............................................................. 16
RIGHT BRAKE/SWITCH ASSEMBLY......................................................... 17
KICK STARTER ........................................................................................... 18
LEFT BRAKE/SWITCH ASSEMBLY ........................................................... 18
INSTRUMENT PANEL ................................................................................. 19
SEAT LOCK ................................................................................................. 20
FUEL TANK.................................................................................................. 20
BATTERY INSTALLATION .................................................................................. 21
MAINTENANCE................................................................................................... 24
SPARK PLUG .............................................................................................. 24
TRANSMISSION OIL ................................................................................... 24
ENGINE OIL................................................................................................. 25
CHANGING ENGINE OIL, CLEANING OIL SCREEN................................. 26
BRAKES ...................................................................................................... 27
AIR FILTER .................................................................................................. 28
IDLE SPEED ADJUSTMENT/FUEL HOSE INSP. ....................................... 29
TIRES ........................................................................................................... 30
TRANSPORTING................................................................................................. 31
STORAGE PROCEDURE.................................................................................... 32
MAINTENANCE CHART ..................................................................................... 33
TROUBLESHOOTING......................................................................................... 34
SPECIFICATIONS................................................................................................ 36
ELECTRIC DIAGRAM ......................................................................................... 37
SERIAL NUMBER LOCATION ............................................................................ 38
EMISSION CONTROL SYSTEM WARRANTY.................................................... 39
Table of Contents

2
Please read this manual and follow all instructions carefully. To emphasize
the special information, the symbol and the words WARNING or CAUTION
have some special meanings. Pay attention to the messages.
NOTE: Indicating special information which is to make maintenance easier or
instructions clearer.
WARNING and CAUTION are arranged like this:
This user’s manual contains important safety and maintenance information.
Read it carefully before riding. Failing to follow the warnings contained in this
manual could result in INJURY or DEATH.
It is important that this manual remain with the vehicle when you transfer it to
another user or owner.
All information, illustrations, photographs and specications contained in
this manual are based on the latest product information available at the time
of publication. Due to improvements or other changes, there will be some
discrepancies in this manual. We reserve the right to make product changes
at any time, without notice and without incurring any obligation to make the
same or similar changes to the vehicle previously built or sold.
WARNING-or-CAUTION
The rst part will identify a POTENTIAL HAZARD.
The second part will describe WHAT COULD HAPPEN if you ignore
the WARNING or CAUTION.
The third part will describe HOW TO AVOID THE HAZARD.
CAUTION
Indicates a potential hazard that could result in vehicle damage.
WARNING
Indicates a potential hazard that could result in death or injury.
!
