socomec SUNSYS HES L User manual

SUNSYS HES L
USER MANUAL
Energy Storage System
EN
UL

SUNSYS HES L - 551697A - SOCOMEC
2EN
CONTENTS
EN
1. INTRODUCTION .....................................................................8
1.1. Glossary ........................................................................8
1.2. Concerned products ...............................................................9
2. IMPORTANT SAFETY INSTRUCTIONS ..................................................10
2.1. Symbols Used on the equipment labels and plates.......................................12
2.2. Important safety instructions for batteries ..............................................13
2.3. Limits to use of this equipment ......................................................13
3. OVERVIEW ........................................................................14
3.1. General description ...............................................................14
3.2. Models ........................................................................16
3.3. List of dedicated components.......................................................17
3.4. Devices with frontal access .........................................................19
3.5. Topology .......................................................................20
3.6. Modes of operation...............................................................21
3.6.1. On Grid Mode..............................................................21
3.6.2. Off-Grid Mode..............................................................21
3.7. Environmental controls ............................................................22
3.8. System communication............................................................24
3.8.1. Communication with external EMS ..............................................24
3.8.2. The PMS..................................................................25
4. TRANSPORT, STORAGE & HANDLING ..................................................26
4.1. Transport.......................................................................26
4.2. Inspection ......................................................................26
4.3. Storage ........................................................................27
4.4. Handling and Moving .............................................................27
4.5. Forklift or Pallet truck handling ......................................................28
4.6. Overhead lifting ..................................................................29
5. PREPARATION .....................................................................31
5.1. Civil and foundation requirements ....................................................31
5.2. Commissioning prerequisite ........................................................33
5.2.1. Integration prerequisite .......................................................33
5.2.2. Connection prerequisite ......................................................34
5.2.3. IoT prerequisite .............................................................34
6. SYSTEM INSTALLATION..............................................................35
6.1. Installation guidelines and considerations ..............................................35
6.2. Clearance distances ..............................................................36
6.3. Environmental conditions ..........................................................36
7. POSITIONING ......................................................................37
7.1. Cabinets order ..................................................................37
7.2. Marking of the C-Cab .............................................................38
7.2.1. Installation with only 1 C-Cab (no extension).......................................38
7.3. Marking of the B-Cab .............................................................39
7.4. Installation with more than 1 C-Cab (one Master and one Extension) .........................40
7.5. Drilling .........................................................................41
7.6. Putting cabinets in place ...........................................................41

SUNSYS HES L - 551697A - SOCOMEC 3
EN
8. CONNECTING KIT INSTALLATION......................................................42
8.1. List of parts.....................................................................42
8.2. Mounting details .................................................................44
8.3. Torque Reference Table............................................................48
8.3.1. Recommended Torques for metric (dry zinc plated) bolted class 8.8 fasteners .............48
8.3.2. Recommended Torques for imperial (dry zinc plated) bolted class 5 fasteners .............48
8.3.3. Recommended Torques for electrical mechanical lugs ...............................48
8.4. Electrical installation ..............................................................49
8.4.1. Battery Cabinet Interconnections ...............................................49
8.4.2. Converter Cabinet Interconnections .............................................50
8.4.2.1. Power cables connection ..................................................54
8.4.3. AC, DC and ground connection ................................................57
8.4.3.1. DC Power Connections ...................................................58
8.4.3.2. Grounding..............................................................60
8.4.3.3. AC Power connections ....................................................61
8.4.3.4. Auxiliary power connection .................................................62
8.4.4. Communication and signal connections ..........................................66
8.4.4.1. Control Box Connections ..................................................66
8.4.4.2. Aux. interface box connection...............................................67
8.4.4.3. Connections of automation box .............................................68
8.4.4.4. Connection to automation Digiware ..........................................71
8.4.5. Connection path ............................................................72
8.5. Metering package for CRD (import only) application ......................................74
8.6. Digiware package for PMS .........................................................75
8.7. Parallel connection ...............................................................76
8.7.1. DC Power Connection .......................................................76
8.7.2. AC Power Connection .......................................................77
8.7.3. Communication Connection ...................................................77
8.8. List of fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
8.9. Installation of MSD ...............................................................83
8.10. 4G Antenna Installation ...........................................................85
8.11. HMI installation .................................................................87
9. COMMISSIONING...................................................................89
10. HMI PRESENTATION ...............................................................89
11. PRODUCT OPERATION .............................................................90
11.1. Normal system power on .........................................................90
11.2. System power off ...............................................................92
11.3. Operations ....................................................................92
11.4. RCD setup ....................................................................93
12. PRODUCT EVOLUTION .............................................................94
12.1. Power module insertion...........................................................94

SUNSYS HES L - 551697A - SOCOMEC
4EN
CONTENTS
EN
13. MAINTENANCE....................................................................96
13.1. Timely inspections and corrective actions .............................................96
13.2. Preventative maintenance .........................................................96
13.3. Detailed instructions – C-Cab ......................................................98
13.3.1. Air filters .................................................................98
13.3.2. UPS ....................................................................99
13.3.3. SPD ...................................................................100
13.4. Detailed instructions – B-Cab .....................................................101
13.4.1. Battery unit ..............................................................101
13.4.2. Coolant .................................................................102
13.4.3. Battery disposal and recycling ...............................................103
13.5. Capacity and efficiency measurements of the Battery System. . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
14. TROUBLESHOOTING ..............................................................105
15. GRID SUPPORT UTILITY INVERTER ..................................................106
15.1. Interconnection system response to abnormal voltages .................................106
15.2. Interconnection system response to abnormal frequencies ...............................106
16. RECYCLING INFO ................................................................107
17. TECHNICAL DATA.................................................................108
17.1. Dimensions and weights .........................................................108
17.2. SUN-HES-L-480 ...............................................................110
18. UL9540A TEST REPORT ...........................................................113

SUNSYS HES L - 551697A - SOCOMEC 5
EN

SUNSYS HES L - 551697A - SOCOMEC
6EN
FIGURES INDEX
EN
Figure 01. SUNSYS C-Cab L composition ...................................................14
Figure 02. SUNSYS B-Cab L composition ...................................................15
Figure 03. View of Frame 1 ..............................................................16
Figure 04. View of Frame 2 ..............................................................16
Figure 05. View of the B-Cab .............................................................16
Figure 06. View of the dedicated components inside the C-Cab ..................................18
Figure 07. Detailed view of the Automation box ...............................................18
Figure 08. View of the devices accessible from the front of the C-Cab..............................19
Figure 09. Example of C-Cab layout with autotransformer and options installed ......................20
Figure 10. Modes of operation of SUNSYS HES L .............................................21
Figure 11. Architecture of the installation in case of operation with Islanding .........................22
Figure 12. Air flows inside the SUNSYS C-Cab L ..............................................22
Figure 13. Environmental logic diagram .....................................................23
Figure 14. System network architecture .....................................................25
Figure 15. B-Cab aux supply connectors ....................................................26
Figure 16. Other plug-in connectors........................................................26
Figure 17. MSD .......................................................................27
Figure 18. Panels to remove from the C-Cab .................................................28
Figure 19. Handling of the unit using pallet truck with 1.30m long forks.............................28
Figure 20. Lifting lug on the top of the rack ..................................................29
Figure 21. C-Cabs front top screws ........................................................29
Figure 22. Lifting lugs on top of the C-Cab ..................................................30
Figure 23. Vertical load spreader ..........................................................30
Figure 24. Concrete depth – SDS 2.5 ......................................................31
Figure 25. Concrete space around the equipment .............................................32
Figure 26. Clearance distances ...........................................................36
Figure 27. In line installation ..............................................................37
Figure 28. Back-to-back installation ........................................................37
Figure 29. Cabinets order................................................................37
Figure 30. Top view of the drilling template mounted ...........................................38
Figure 31. Holes to drill for 1 C-Cab installation ...............................................38
Figure 32. Holes to prepare B-Cab installation next to the C-Cab .................................38
Figure 33. Holes to drill for the B-Cab installation..............................................39
Figure 34. Holes to drill to prepare next B-cab installation .......................................39
Figure 35. Holes to drill for 1 C-Cab + 1 C-Cab ext. installation ...................................40
Figure 36. Holes to drill for the C-Cab installation..............................................40
Figure 37. Holes to prepare B-Cab installation next to the C-Cab. .................................40
Figure 38. C-Cab front panel removal.......................................................44
Figure 39. Installation of the back part of the C-Cab connection kit ................................44
Figure 40. Specific connection parts for back-to-back installations ................................45
Figure 41. Details of the parts for back-to-back installations .....................................45
Figure 42. Installation of the B-Cab back part connection kit .....................................46
Figure 43. Connection of C-Cab and B-Cab parts .............................................46
Figure 44. Connection of two B-Cab parts...................................................46
Figure 45. Cable connection kits locking ....................................................47
Figure 46. Cables organization inside the cable gutter ..........................................47
Figure 47. Location of isolation switch QS and breakers QF1 & QF2 ...............................49

SUNSYS HES L - 551697A - SOCOMEC 7
EN
Figure 48. Screws of the plastic panel ......................................................54
Figure 49. Cable glands plates ............................................................55
Figure 50. Power and ground connections...................................................57
Figure 51. DC Power connections .........................................................59
Figure 52. Battery cabinet ground terminal...................................................60
Figure 53. AC power connections positioning ................................................61
Figure 54. Location of the auxiliary connections in the C-Cab ....................................62
Figure 55. C-Cab connector for B-Cabs aux power supply ......................................63
Figure 56. Connection of the B-Cabs aux power supply from the C-Cab............................64
Figure 57. Location of the communication and signal connections in the C-Cab ......................66
Figure 58. Connection of the communication with the control box .................................69
Figure 59. Connection of the communication between B-Cabs and C-Cab ..........................70
Figure 60. Rogowski probe ..............................................................75
Figure 61. Connection of the probes .......................................................75
Figure 62. B-Cabs connection distribution ...................................................76
Figure 63. Location of the RJ cables for C-Cabs Master-Extension paralleling ........................77
Figure 64. Connection of the communication for the paralleling ...................................78
Figure 65. Figure 66 - Connection of the communication for the Digiware package ....................80
Figure 66. Location of the Emergency Power Off connections ....................................81
Figure 67. Location of the fuses inside the C-Cab .............................................82
Figure 68. MSD covers installed in the battery modules .........................................83
Figure 69. MSD diagram ................................................................84
Figure 70. MSD cover inserted in the receptacle ..............................................84
Figure 71. Completely installed MSD cover ..................................................84
Figure 72. Dividers of the right side door ....................................................85
Figure 73. Hole drilling in the roof ..........................................................85
Figure 74. Antenna installation on the C-Cab .................................................86
Figure 75. Cable direction from antenna to inside the C-Cab .....................................86
Figure 76. Connection of the antenna cable inside the C-Cab ....................................86
Figure 77. View of the External HMI of the C-Cab .............................................89
Figure 78. Location of the switch Q3 in the C-Cab.............................................90
Figure 79. Location of the UPS in the C-Cab .................................................90
Figure 80. Location of the power button of the UPS ...........................................91
Figure 81. Reinstallation of the panel .......................................................91
Figure 82. Location of the AC and DC switches (Q1 and Q2) in the C-Cab ..........................91
Figure 83. Power module screws location ...................................................94
Figure 84. Insertion of the power module ....................................................94
Figure 85. Order of insertion of the modules .................................................95
Figure 86. Location of the C-Cab air filters ...................................................98
Figure 87. Details of the air filters ..........................................................99
Figure 88. Installation of the air filter ........................................................99
Figure 89. Location of the SPDs inside the C-Cab ............................................100
Figure 90. Location of chiller on B-Cab ....................................................102
Figure 91. Coolant port ................................................................102
Figure 92. C-Cab dimensions............................................................108
Figure 93. B-Cab dimensions............................................................109

SUNSYS HES L - 551697A - SOCOMEC
8EN
1. INTRODUCTION
1.1. Glossary
For the purpose of this document, the following abbreviations are used:
BESS: Battery Energy Storage System
BMS: Battery Management System
C-Cab: Conversion cabinet (SUNSYS C-Cab L)
C-Cab Master: First cabinet of 2 or more paralleled cabinets
C-Cab Extension: Cabinet in parallel with C-Cab Master
EMC: Electro Magnetic Compatibility
EMS: Energy Management System
ESS: Energy Storage System
HMI: Human Machine Interface
IM: Islanding Mode
IoT: Internet of Things (internet-connected devices)
PCS: Power Conversion System
PE: Protective Earth
PMS: Power Management System
RCD: Residual current device
SOC: State of Charge
SOH: State of Health
SPD: Surge Protection Device
THDI: Total Harmonic Distortion of Current
THDV: Total Harmonic Distortion of Voltage

SUNSYS HES L - 551697A - SOCOMEC 9
EN
1.2. Concerned products
The present manual covers the SUNSYS HES L range.
SUNSYS HES L System is composed of an assembly of 2 types of cabinets:
C-Cab
• Bidirectional power converter
• 50 to 300 kVA / cabinet. Based on 50kVA power modules.
• Automation functions
• AC/DC distribution and protection
• Battery management system
• IoT connected cabinet
• Possible to put up to 2 units in parallel per system to reach 550 kVA (system design limit)
B-Cab
• Lithium-ion battery
• LFP technology
• 186 kWh nameplate / rack - 176 kWh useable / rack
• Liquid cooling thermal management
• Integrated re safety detection and extinguishing system included
• Possible to put up to 6 units in parallel per system to reach 1116 kWh nameplate / 1056 kWh useable
SUNSYS HES L Congurations
SUNSYS HES L system is available with different combinations of power and energy.
The table below shows all these congurations with the quantity of cabinets you will get for each conguration.

SUNSYS HES L - 551697A - SOCOMEC
10 EN
2. IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS– This manual contains important instructions for SUNSYS HES L systems (see “Concerned
products”) that shall be followed during installation and maintenance of the storage inverter.
A potential Shock and Injury Hazard exists when working on or around electrical systems which could lead to serious
injury or even death. Only qualied competent personnel who have been trained in and are familiar with the Risk of Electric
Shock and Plasma Arc Flash Hazards may perform installation and maintenance on electrical systems. It is the sole
responsibility of the personnel doing the work to be fully cognizant of all necessary safety regulations and procedures and
be familiar with the installation instructions detailed in this manual.
CAUTION!
Any work carried out on the equipment must be performed by skilled, qualied technicians.
The input and output circuits are isolated from the enclosure; the system grounding, when required by
Sections 690.41, 690.42, and 690.43 of the National Electric Code, ANSI/NFPA 70, is the responsibility of the
installer
The wiring methods in accordance with the National Electrical Code, ANSI/NFPA 70 and Canadian Electric
Code (CEC) are to be used. All national standards applicable to batteries must be observed.
CAUTION!
Each power supply line must be provided with overcurrent protection according to the indication contained in
the present manual.
This inverter complies with Part 15 of the FCC Rules Operation so it may not cause harmful interference and
must accept any interference received, including interference that may cause undesired operation.
Overcurrent protection for the AC circuit is to be provided by the installer.
Before carrying out any operations read the SUNSYS HES L system instruction manual and Battery Energy
System (BES) safety instructions carefully, in order to work under safe conditions.
If the Battery Energy System (BES) is not supplied by SOCOMEC, overcurrent protection for the BES is to be
provided by the installer.
CAUTION!
Any work carried out on the equipment must be performed by skilled, qualied technicians.
CAUTION!
Before carrying out any operations on the unit read the installation and operating manual carefully. Keep this
manual safe for future reference.
DANGER!
Failure to observe safety standards could result in fatal accidents or serious injury, and damage equipment or
the environment.
CAUTION!
If the unit is found to be damaged externally or internally, or any of the accessories are damaged or missing,
contact SOCOMEC. Do not operate the unit if it has suffered a violent mechanical shock of any kind.
CAUTION!
Install the unit in accordance with the minimum distances from near walls in order to guarantee sufcient
ventilation and access to handling devices (see Environmental requirements chapter).
CAUTION!
Only use accessories recommended or sold by the manufacturer.
CAUTION!
When the equipment is transferred from a cold to a warm place wait before operating the unit to avoid
condensation.

SUNSYS HES L - 551697A - SOCOMEC 11
EN
DANGER! LIVE DEVICE! RISK OF ELECTRIC SHOCK: Up to ve separately fused voltage supplies can be
connected to the unit:
1. DC line – supply from the batteries or other DC sources
2. AC line – supply to/from the grid and/or loads
3. AC line – auxiliary voltage supply (3 phases)
4. AC line – auxiliary voltage supply (1 phase)
5. AC line – auxiliary voltage supply from internal UPS (1 phase)
DANGER! RISK OF ELECTRIC SHOCK!
If the C-Cab is provided with internal UPS, switch off the UPS before maintenance. The input switches do not
switch off the power coming from internal UPS. See the dedicated chapter for details.
CAUTION!
Before cleaning, performing maintenance work or connecting appliances to the unit, switch the unit off and
disconnect all power sources.
DANGER! Live device! RISK OF ELECTRIC SHOCK!
- Carry out the following steps before C-Cab maintenance:
- Disconnect the batteries
- Disconnect the AC power supplies
- Disconnect the DC disconnection switches (Q2)
- Disconnect the AC disconnection switches (Q1 and Q3)
- Switch off the UPS
- Make sure the system cannot be restarted
- Make sure the power supply (AC and DC voltages) has been disconnected
DANGER! RISK OF ELECTRIC SHOCK!
After disconnecting all power sources wait approx. 5 minutes for the complete discharge of the unit.
CAUTION! RISK OF BURNS!
During operation the casing of the heaters located in the bottom of the machine can reach high temperatures.
Do not touch the surfaces!
CAUTION!
The tightening torque for DC and AC terminals must be in accordance with the indication of the present
manual.
CAUTION!
Any use other than the specied purpose will be considered improper. The manufacturer/supplier shall not be
held responsible for damage resulting from this. Risk and responsibility lie with the system manager.
The unit is intended to be used only with batteries having the characteristics indicated in the present manual.
See the dedicated chapter for further details.
WARNING!
The unit must operate within the ambient temperature range specied. Refer to relevant sections of this
manual for limits and additional notes.
The unit is not intended to operate at ambient temperatures higher than 50°C (122°F) or lower than -20°C
(-4°F).
Use 75°C or 90°C wire, either copper or aluminum; refer to “Electrical installation” chapter for further details
about the suggested AWG size.
If one of the units is found to be damaged externally or internally, or any of the accessories are damaged or
missing, contact SOCOMEC. Do not operate the system if it has suffered a violent mechanical shock of any
kind.
NOTICE
The maximum operating currents in controlled busbars or conductors are limited by the settings of the power
control system (PCS) and may be lower than the sum of the currents of the connected controlled power
sources. The settings of the PCS controlled currents may be used for calculation of the design currents used
in the relevant sections of NEC Article 690 and 705.
WARNING!
Only qualied personnel shall be permitted to set or change the setting of the maximum operating current
of the PCS. The maximum PCS operating current setting shall not exceed the busbar rating or conductor
ampacity of any PCS controlled busbar or conductor.

SUNSYS HES L - 551697A - SOCOMEC
12 EN
NOTICE
For supplementar power control system:
“This system is equipped with a power control system. All power control systems controlled busbars or
conductors shall be protected with suitably rated overcurrent devices appropriately sized for the busbar rating
or conductor ampacity”.
NOTICE
For branch circuit power control system:
“This system is equipped with a power control system. All power control systems controlled busbars or
conductors shall be protected with suitably rated overcurrent devices appropriately sized for the busbar rating
or conductor ampacity”.
WARNING
Conguration of power control settings system or changes to settings shall be made by qualied personnel
only. Incorrect conguration or setting of the C-Cab may result in unsafe conditions.
WARNING!
California proposition 65 warning:
Product range: Energy storage system
This product can expose you to chemicals including lithium ions, Styrene and glycol which are known to the State of
California to cause cancer and birth defects or reproductive harm. For more information go to:
http://www.p65warnings.ca.gov»www.P65Warnings.ca.gov
2.1. Symbols Used on the equipment labels and plates
The words "CAUTION", "WARNING" or "DANGER” are used in accordance to the meaning dened by UL1741 standard.
Symbols Description
UL1741; CSA-C22.2 No.107.1-16; MET le E113907
General warning – Important safety information.
Risk of Electric Shock and/or ARC Flash Hazard: Life threatening voltages may be present with the risk
of ARC Flash in the event of an inadvertent short circuit.
Risk of explosion! Avoid short circuits!
IThe switch is ON
OThe switch is OFF
Waiting time before operating: 5 min
Protective earth terminal.
Authorised personnel only.
No smoking.

SUNSYS HES L - 551697A - SOCOMEC 13
EN
Symbols Description
Read the user instructions carefully.
Read the user manual before performing any operations.
Wear protective gloves.
Wear safety shoes.
Wear protective goggles.
In the event of contact with the eyes, wash immediately with plenty of water and call a doctor.
Call a doctor immediately in the event of accidents or illness.
Do not dispose of in normal waste stream (symbol waste electrical and electronic equipment).
2.2. Important safety instructions for batteries
Warning! a battery can present a risk of electrical shock and burn from high short-circuit current. Observe
proper precautions.
When replacing batteries use only batteries approved by Socomec.
Do not connect the C-Cab to batteries that are not approved; this may cause serious damage to the equipment.
For any further information, contact Socomec.
Proper disposal of batteries is required. Refer to your local codes for disposal requirements.
The battery installation must be done in accordance with the storage battery rules of the Canadian Electrical
Code, Part I.
The characteristics of the batteries must be compatible with the ratings of the C-Cab.
For any further information, contact Socomec.
2.3. Limits to use of this equipment
This equipment is rated for permanent connection to an electrical low voltage power supply according to the
ratings reported in the present manual.
Devices and connections to the ancillary inputs and outputs (other than to external power) have specic limits with
regard to voltages and isolation requirement; refer to relevant sections of this manual for limits and additional note.
Any use other than the specied purpose will be considered improper. The manufacturer/supplier shall not be
held responsible for damage resulting from this. Risk and responsibility lie with the system manager.
Utility interconnection may require approval from the authority having jurisdiction in the local area.

SUNSYS HES L - 551697A - SOCOMEC
14 EN
3. OVERVIEW
The information in this manual is provided to aid in the installation, operation, and maintenance of the SUNSYS HES L
energy storage system. Please read, understand and follow the procedures given to ensure trouble-free installation and
operation.
3.1. General description
The SUNSYS HES L is a fully integrated AC connected energy storage system that supports a host of applications such as
rming renewable production, stabilizing the electrical grid, controlling energy ow, optimizing asset operation and creating
new revenue which provides greater control, efciency and reliability across the electric grid. Another important function
of the system is to provide backup power in the event of a grid failure or during power quality anomalies, therefore we are
supplying the Island Mode version of the system.
The SUNSYS HES L system comprises two major cabinets namely, a converter for DC to AC conversion (referred to as
C-Cab) and the Battery cabinets (B-Cabs). The unit has been designed to operate natively outdoors, potentially making
installation simpler and not burdening the facility cooling and ventilation systems. This unique capability is facilitated by
utilizing liquid cooling loops for the batteries which minimizes the cabinet ow through air volume, facilitating internal
environmental control using ltered normal environmental air. The battery requires tighter temperature control for life and
performance, consequently the battery cabinets utilize an active chiller to control the temperature within closely controlled
limits to maximize battery life and performance. For the C-Cab we utilise proper air ltering and ventilation system in order
to keep internal ambient under controlled conditions. Active cabinet heating is also employed for low temperatures and
humidity condensation control.
The internal power ow between the modules of the system is controlled by a Power Management System (PMS), which is
integrated inside the C-Cab.
The SUNSYS C-Cab L, Shown in Figure 1, comprises the conversion modules of 50kVA each with their control, an optional
automation box that can contain the PMS and IoT devices, a DC part with protection and connection and an AC part with
protection and connection.
The unit has been designed to operate natively outdoors, potentially making installation simpler and not burdening the
facility cooling and ventilation systems. This unique capability is facilitated by utilizing proper air ltering and ventilation
system in order to keep internal ambient under controlled conditions. Active cabinet heating is also employed for low
temperatures and humidity condensation control.
Figure 01. SUNSYS C-Cab L composition

SUNSYS HES L - 551697A - SOCOMEC 15
EN
CHILLER
SWITCHES
BATTERY
MODULES
Figure 02. SUNSYS B-Cab L composition

SUNSYS HES L - 551697A - SOCOMEC
16 EN
3.2. Models
The C-Cab is composed of the 480Vac cabinet (SUN-HES-L-480) integrating an auto-transformer, operational at 60Hz, with
up to 6 modules (SUN-HES-MOD50) 50kVA each installed.
2 systems versions are available:
• SUNSYS HES L that is on-grid only
• SUNSYS HES L IM that integrates the Islanding Mode function
C-Cab Available power sizes:
Frame 1: one SUNSYS C-Cab L Master from 50kVA to 300kVA, modulo 50kVA
Frame 2: one SUNSYS C-Cab L Master + one SUNSYS C-Cab L extension, from 350kVA to 600kVA, modulo 50kVA.
Figure 03. View of Frame 1 Figure 04. View of Frame 2
For the specic as shipped unit conguration please refer to the nameplate included with each unit or contact Socomec for
support with reference to the nameplate serial number. Units may be additionally supplied with congurations and options
as dened by the customer at time of order.
B-Cab Frame: 186kWh 4 modules
Figure 05. View of the B-Cab

SUNSYS HES L - 551697A - SOCOMEC 17
EN
3.3. List of dedicated components
Each C-Cab can have different options installed, allowing a very high exibility of setup to satisfy the user’s requirements.
In the table below are listed all the optional components that can be installed inside the unit.
The items having spare parts available can also be installed outside of the factory, while the other items can only be installed
in the factory.
Only options provided by Socomec can be installed inside the unit.
ID Item C-Cab
Master
C-Cab
Extension Description
1PC tablet Yes No Support plate for a computer
2Parallel board Yes Yes "Parallel board" to parallelize Master and Extension C-Cabs
3Digiware inverter DC Yes Yes
Digiware meter connected to DC-bus
Includes a U-32 module, an I-35 module and the probes
Enables high precision of DC current measurement
4Auxiliary supply SPD Yes Yes SPD for auxiliary power supply
Required if the Overvoltage Category of the supply line is OCV>II
5SPD DC No Yes SPD for additional protection of the DC input line.
6UPS Yes Yes UPS for auxiliary line
For protection of the auxiliary supply line during service interruptions
7Insulation
monitor RCD Yes Yes Residual Current Detector
8Neutral contactor Yes Yes Contactor to manage the Neutral wire connection/disconnection
9ETH switch Yes No Ethernet switch
10 Router Yes No CheckPoint 1570R Ethernet router
11 Wireless 4G modem Yes No
Wireless 4G-modem + spare Antenna (Sierra Wireless)
The antenna is delivered as spare-part w/ the C-Cab, i.e., not mounted
on the roof top in the factory
12 PMS (Power management
System) Yes No PMS package (PLC, I/O, relays, commons)
13 Digiware package for PMS Yes Yes
Digiware meters for the PMS (M70, U-30, I-35 + probes) to be installed
in the C-Cab Master and Digiware meters for the PMS (I-35 + probes)
to be installed in the C-Cab Extension
14 Diris AUX power supply
measurement Yes Yes Diris B-30 device for AUX power supply measurement
15 Internal HMI for Automation Option No Schneider 10» display for the Automation package
16 Data logger Yes No Socomec H-80 Industrial PC
17 EMS Option No KARBON 300 computer, Energy Management System (ETB CPU)
18 Battery control package Yes No CATL battery control devices (MBMU + ETH box)

SUNSYS HES L - 551697A - SOCOMEC
18 EN
Automation box
detailed in Figure 7
Figure 06. View of the dedicated components inside the C-Cab
Figure 07. Detailed view of the Automation box

SUNSYS HES L - 551697A - SOCOMEC 19
EN
3.4. Devices with frontal access
When the C-Cab’s door is open, it is possible to access to all the devices and ports available on the front of the machine.
These devices are described in the gures below.
Some of them are optional and may not be present, as explained in the “List of options” section.
Figure 08. View of the devices accessible from the front of the C-Cab

SUNSYS HES L - 551697A - SOCOMEC
20 EN
3.5. Topology
The SUNSYS C-Cab L has been designed to operate autonomously thanks to the PMS (with compatible batteries) or from
the external commands of a device called Energy Management System (EMS) which is not a part of this manual. The EMS is
provided by a third party and has full control over the Energy Storage System (ESS), our privileged partner for this offer is ETB.
Figure 09. Example of C-Cab layout with autotransformer and options installed
