SOHODESK SD03
ASSEMBLY INSTRUCTIONS - PLEASE KEEP FOR FUTURE REFERENCE
IMPORTANT - PLEASE READ THE INSTRUCTIONS FULLY BEFORE STARTING ASSEMBLY
page 1
Dimensions
Length - 120cm
Depth - 60cm
Height - 76cm
Weight - 19,80kg
Maximum Weight Tolerance
50kg

SAFETY AND CARE ADVICE
Important - Please read these instructions fully before starting assembly
!
!
!
!
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
!
!
!
!
Do not stand or put weight on the
product during assembly, this could
cause damage.
Assemble the item as close to its
final position (in the same room) as
possible.
Assemble on a soft level surface to
avoid damaging the unit or your
floor.
Parts of the assembly will be
easier with 2 people.
!We do not
recommend the use
of power drill/drivers
for inserting screws,
as this could damage
the unit. Only use the
allen key provided, or
a hand screwdriver.
!Dispose of all packaging
carefully and responsibly.
Care and maintenance
!Only clean using a damp cloth
and mild detergent, do notuse
bleach or abrasive cleaners.
!From time to time check that
there are no loose screws on this
unit.
!Do not stand on the unit.
!Do not use this unit as a step ladder.
!This product should not be discarded with household waste.
Take to your local authority waste disposal centre.
Handy Hints
!Assemble all parts and bolts loosely
during assembly, only once the product is
complete should you fully tighten the bolts.
!Regularly check and ensure that all
bolts and fittings are tightened properly.

COMPONENTS - FIXINGS
PLEASE CHECK YOU HAVE ALL THE PARTS LISTED BELOW
Puller Nut 10 x 13
x 4
D
BA C
page 3
Height Adjustable Foot x 4
( Size M6 x 25 mm )
Size M6 x 50 Bolt
x 8
Note : the quantities below are the correct amount to complete the assembly.
In some cases more fittings may be supplied than are required.
Tools required
Nut Sticker
x 4
Tape measureSmall hammer
Phillips screwdriver

COMPONENTS - PARTS
PLEASE CHECK YOU HAVE ALL THE PARTS LISTED BELOW
page 4
Desktop
1Modesty Panel
2
Legs x 2
3

B
B
B
B
A
page 5
C
A
A
A
C
C
B
A
Step 2
3
3
2
2
3
3
ASSEMBLY INSTRUCTIONS
Step 1
C
C
Carefully screw in
adjustable feet B into
the leg frames .
3
Align the modesty
panel holes with the
leg frames as shown
in the assembly
instruction image.
2
3
Once aligned use the
M6 x 50mm Bolt A to
fix the modesty panel
and legs together,
making sure all bolts
are tight and no
gapping is visible.

A
A
A
A
page 6
1
3
3
ASSEMBLY INSTRUCTIONS
Step 3
D
D
Align the leg frames
with the pre-drilled
and inserted holes in
the desktop .
3
1
Once all 4 x holes are
aligned, use the M6 x
50mm Bolts A to fix
the leg and wooden
desktop together.
1
Please make sure all
bolts are tight and no
gapping is visible
between the legs and
desktop.
