solarcentre GUILDFORD User manual

GUILDFORD
3-IN-1 SOLAR GARDEN, WALL &
PILLAR LIGHT
USER GUIDE
Do NOT charge
behind glass
Do NOT place your
solar panel in shaded
areas.
E
W
S
Ensure your solar
panel is South facing
or as near as possible
Clean your solar
panel from time
to time
Thank you for choosing the Guildford Solar 3-in-1 Light. Please read these instructions carefully
before using your light.
Important notes
Always take care when installing your light. If you are at all unsure, please contact your retailer or a professional trades person for
advice.
The lights will turn ON/OFF automatically when left in the on position. Please note it is

charge in their location.
Installation
Remove all packaging and put to one side. Please carefully consider where you wish to install your light before making alterations
to your property. It’s particularly important that the solar panel receives as much sunlight as possible. Ensure that it is not
obstructed by buildings, fences, trees, sheds, etc, or the shadows that these create. If the solar panel is installed in a poor
location, it may not perform to the best of its ability.
To maximise the battery capacity, the lights should be charged in direct sunlight for at least

the battery life or performance of the light.
How to use:
Lighting mode:
1. Power-saving Mode

[Best for winter performance].
2. Full Brightness


Speci�cation
• Solar Panel: 1.2W • LED Bulb: 1 pcs
• Waterproof: IP65 • Material: Plastic
Box Contents
• Solar Lamp • Instructions
• Connection Pole • Ground Spike
• Screw Anchors • Wall Mount
• Screws • Pier Mount
1- Solar Panel 2 - Switch 3 - LED Bulb
4 - Pier Mount 5 - Wall Mount
A: Connection Pole B: Ground Stake
A B
1
2
345

Recharge Procedure
1. Double check the location of your solar panel to ensure it is in a clear location and as South facing as possible.
2. Turn the light off at the switch and leave it to recharge for 3-5 days ensuring one sunny day has passed.
3. After 3-5 days return to the light and turn it back on at the switch.
4. If your light still does not illuminate after dark, please contact your retailer.
GUILDFORD 3-IN-1 SOLAR GARDEN, WALL & PILLAR LIGHT
MODEL NUMBER: SC2224
SOLARCENTRE®
44-46 COLDHARBOUR LANE
HARPENDEN
HERTFORDSHIRE
AL5 4UN
WWW.SOLARCENTRE.CO.UK
Troubleshooting
Please ensure that there are no nearby light sources shining on the solar panel after dark. These could be bright indoor/outdoor
lights from your property or neighbours, or street lights.
If you are unsure, take the light inside and test it in a dark room.
If you are encountering any problems with your light often you can resolve this yourself by following our troubleshooting guide. If
the light has it’s solar panel in a poor location it will struggle to work, but that doesn’t mean there is a fault with the unit. Please
remember that the light will arrive with some charge and will likely work for a few days even if the solar panel is poorly located. Please
try the troubleshooting tips below before contacting your retailer.
Installation
Ground Plug Mount
1. Firmly slide the Connection Pole (A) into the solar housing-Fig 1

Fig 1 Fig 2
A
A
B
Pier Mount
123
CCCB
Wall Mount
1. Using the pier base (A) as a template, mark and drill two
holes no larger than the provided anchors.
2. Place the anchors in the holes and secure the pier base (A)
with the provided screws.
1 2 3
AA
A
B
1. Using the wall mount (C) as a template, mark and drill
two holes no larger than the provided anchors.
2. Place the anchors in the holes and secure to wall
mount (C) with the provided screws.

secure.
