Solaris smart 54w User manual

USER MANUAL

SOLARIS® SMART 54W™ 2
INDEX PAGE NO.
SAFETY INFORMATION 3-4
INTRODUCTION 5
INSTALLATION 6
AC POWER 7
FIXTURE OVERVIEW 8
DMX DATA LINK 9
CONNECTING AND USING DMX DATA LINK 10
FIXTURE OPERATION 10-11
TOKENS 11
FIXTURE MENU STRUCTURE CHART 12
DMX MODES CHARTS 12
MAINTENANCE 13
SMART 54W SPECIFICATIONS 14-15
INCLUDED ITEMS 16
TABLE OF CONTENTS

3SOLARIS® SMART 54W™
WARNING!
Read the safety precauons in this manual before installing
operang or servicing this product.
SAFETY NOTES
Read all the following Safety Notes before working with this product.
These notes include important informaon about the installaon, us-
age, and maintenance of this product.
This product contains no user-serviceable parts. Any reference to ser-
vicing in this User Manual will only apply to properly trained GLOW®
Professional cered technicians. Do not open the housing or aempt
any repairs.
All applicable local codes and regulaons apply to proper installaon of
this product.
PERSONAL SAFETY
· Avoid direct eye exposure to the light source while the product is on.
· Always disconnect this product from its power source before servicing.
· Always connect this product to a grounded circuit to avoid the risk of
electrocuon.
· Do not touch this product’s housing during operaon because it may
be very hot.
MOUNTING & RIG-
GING
· This product is for indoor use only! To prevent risk of re or shock, do
not expose this product to rain or moisture. (IP20)
· Mount this product in a locaon with adequate venlaon, at least 20
in (50 cm) from adjacent surfaces.
· Make sure there are no ammable materials close to this product while
it is operang.
· Always carry this product by the handles. Do not carry from the head.
· When hanging this product, always secure to a fastening device using
a safety cable.
SAFETY INFORMATION

SOLARIS® SMART 54W™ 4
POWER & WIRING
· Always make sure you are connecng this product to the proper volt-
age in accordance with the specicaons in this manual or on the prod-
uct’s specicaon label.
· Never connect this product to a dimmer pack or any rheostat.
· Never disconnect this product
OPERATION
· Do not operate this product if you see damage to the housing, lenses,
LED lights or cables. Have the damaged parts replaced by an authorized
technician at once.
· Do not cover the venlaon slots when operang to avoid internal
overheang.
· Do not aim this product toward the Sun. The lenses could concentrate
the solar energy and cause internal overheang.
· The maximum ambient temperature is 120 °F (49 °C). Do not operate
this product at a higher temperature.
· In case of a serious operang problem, stop using this product imme-
diately
In the unlikely event that your GLOW® product may require service, contact GLOW®
Technical Support.

5SOLARIS® SMART 54W™
The SOLARIS® Professional SMART 54W™ is a high-performance 3 X 54W cold white warm
white Led Par lighng xture. A compact design makes it ideal for Venue Installaons, Theat-
rical, Cinema, TV and Stage Use.
The xtures is deemed for its silent operaon achieved by temperature detectors and silent
fans. The Unit is made of a sturdy aluminum casng, designed to withstand touring applica-
ons as well as xed installaons.
The use of CW-WW (Cold White - Warm White) 3W LED allows you to reach almost idencal
Color tones as those achieved by the use of Convenonal lighng.
The Smooth Flicker Free operaon makes this xture Ideal for TV use.
The xture can be controlled using any DMX-compliant controller (3 Channel Mode | 2 chan-
nel mode) as well as automac operaon mode , sound to light mode and manual mode.
BEFORE USING THE PRODUCT FOR THE FIRST TIME
1. Read ’Safety informaon’ on page 4 before installing, operang or servicing the xture.
2. Unpack and ensure that there is no transportaon damage before using the xture. Never
aempt to operate a damaged xture.
3. If the xture is not going to be hard-wired to a mains supply, aach a local power plug to
the end of the supplied power cable.
4. Before operang, ensure that the voltage and frequency of the power supply match the
power requirements of the xture.
5. Refer to the GLOW® website for the most recent user documentaon and technical infor-
maon about this xture.
INTRODUCTION

SOLARIS® SMART 54W™ 6
INSTALLATION
The xture is designed for indoor use only and must be used in a dry locaon with adequate
venlaon. Ensure that none of the xture’s venlaon slots are blocked and ensure that the
xture is fastened to a secure structure or surface. Do not use the xture to illuminate sur-
faces less than 8 m (approx 26.) from the xture.
FASTENING THE FIXTURE TO A FLAT SURFACE
The xture can be fastened to a hard, xed, at surface that is oriented at any angle. Ensure
that the surface and all fasteners used can support at least 10 mes the weight of all xtures
and equipment they will support. Fasten the xture Securely. Do not place it on a surface or
leave it where it can be moved or fall over. If you install the xture in a locaon where it may
cause injury or damage if it falls, secure it as directed below with a securely anchored safety
cable that will hold the xture if the primary fastening method fails.
MOUNTING THE FIXTURE ON A TRUSS
The xture can be clamped to a truss or similar rigging structure in any orientaon. When
installing the xture hanging vercally down, you can use an open-type clamp such as a
G-clamp. When installing in any other orientaon, you must use a half-coupler clamp
that completely encircles the truss or pipe circumference. To clamp the xture to a truss:
1. Check that the rigging structure can support at least 10 mes the weight of all xtures and
equipment to be installed on it.
2. Block access under the work area.
3. Working from a stable plaorm, hang the xture on the
truss and fasten the rigging clamps onto the truss.
4. Secure the xture with a safety cable as directed below.
5. Check that the head will not collide with other xtures or objects.
SECURING WITH A SAFETY CABLE
Secure the xture with a safety cable (or other secondary aachment) that is approved for
the weight of the xture so that the safety cable will hold the xture if a primary aachment
fails. Loop the safety cable through and around a secure metal anchoring point.
WARNING! READ SAFETY INFORMATION ON
PAGE 3 BEFORE INSTALLING THE FIXTURE.

7SOLARIS® SMART 54W™
Socket outlets or external power switches used to supply the xture with power must be
located near the xture and easily accessible so that the xtures can easily be disconnect-
ed from power.
Do not insert or remove power cable to apply or cut power, as this may cause arcing at the
terminals that will damage the connectors.
Do not use an external dimming system to supply power to the xture, as this may cause
damage to the xture that is not covered by the product warranty.
The xture can be hard-wired to a building electrical installaon if you want to install it
permanently, or a power plug (not supplied) that is suitable for the local power out- lets
can be installed on the power cable.
If you replace power plug on the power cable, install a grounding type (earthed) plug with
integral cable grip that is rated minimum 250 V, 5 A.
The xture has an auto-ranging power supply that accepts AC mains power at 100-240 V
at 50/60 Hz. Do not apply AC mains power at any other voltage or frequency to the xture.
For protecon from electric shock, the xture must be grounded (earthed). The
power distribuon circuit must be equipped with a fuse or circuit breaker and
ground-fault (earth-fault) protecon.
AC POWER
WARNING! READ SAFETY INFORMATION ON
PAGE 3 BEFORE INSTALLING THE FIXTURE.

SOLARIS® SMART 54W™ 8
1Tokens® – symbol indicang the xture DMX personality, Beam Angle, Weight and
Power Supply
2Power Breakout cable with IP65 connectors input and output
3DMX data Link Input and Output XLR Connectors
4Digital Screen for accessing menu with 4 buons for navigaon: Menu, Up, Down
and Enter
5Aluminum body with fan and Heat sink
UP Press UP to change current value
DOWN Press DOWN to change current value
MENU Press MENU to toggle between modes
ENTER Use ENTER to save the parameter aer you made the desires adjustments
1
2
3
4
5
FIXTURE OVERVIEW

9SOLARIS® SMART 54W™
DMX DATA LINK
A DMX 512 data link is required in order to control the xture via DMX. The xture has
3-pin XLR connectors for DMX data input and output. The number of daisy-chained x-
tures is limited by the number of DMX channels required by the xtures in relaon to the
maximum 512 channels available in one DMX universe. Note that if independent control
of a xture is required, it must have its own DMX channels.
Fixtures that are required to behave idencally can share the same DMX address and
channels. To add more xtures or groups of xtures when the above limit is reached, add
a DMX universe and another daisy-chained link.
CONNECTING AND USING DMX DATA LINK
To connect the xture to data:
1. Connect the DMX data output from the controller to the rst xture’s male XLR
DMX input connector.
2. Connect the rst xture’s DMX output to the DMX input of the next xture and conn-
ue connecng xtures output to input.

SOLARIS® SMART 54W™ 10
FIXTURE OPERATION
This secon explains the xture sengs and ulies that the user has access to when us-
ing the control panel. Sengs are retained when the xture is powered o.
The SOLARIS® SMART 54W™ can funcon in dierent modes:
DMX 3 CHANNEL MODE. When operated in DMX 3 channel mode the xture back
screen will show A001 when rst accessed. By seng a value dierent from 001 you can
change the unit’s DMX address according to your lighng setup. Oponal DMX address
values are 1 to 512. When you reach the desired value, press ENTER to save your changes.
DMX 2 CHANNEL MODE. When operated in DMX 2 channel mode the xture back
screen will show d001 when rst accessed. By seng a value dierent from 001 you can
change the unit’s DMX address according to your lighng setup. Oponal DMX address
values are 1 to 512. When you reach the desired value, press ENTER to save your changes.
STANDALONE MODE COLOR BLENDING which allows you to manually change the pa-
rameters of the xture without using DMX data link. When operated in Standalone mode
the xture back screen will show either: u000 (Cold White), C000 (Warm White) when
rst accessed. By seng a value between 000-255, using the UP & DOWN buons below
the screen, you can control the desired amount of every color (CW-WW). When you reach
the desired value, press ENTER to save your changes.
You can also manually control strobe ashing by changing the values when the back
screen shows F000 (Strobe Flash). By seng a value between 000-255, using the UP &
DOWN buons below the screen, you can control the desired speed (strobe). When you
reach the desired value, press ENTER to save your changes.

11 SOLARIS® SMART 54W™
TOKENS®
The TOKENS® are symbols we use to mark the features of our xtures. every xture has
its own unique set of TOKENS® according to the xture’s qualies. Those marks can be
especially useful and informave for the technicians using Solaris xtures.
The TOKENS® are located above the digital screen on the back panel of the xture.
This token indicates the maximum amount of power consumpon
(Displays in Was)
This token indicates the angle of the xture’s beam (Displayed in degrees)
This token indicates the possible DMX footprint (DMX Personality) of the xture
(according to the dierent dmx modes of operaon)
This token indicates the weight of the xture (Displayed in Kilograms)

SOLARIS® SMART 54W™ 12
DISPLAY FUNCTION INSTRUCTIONS
d001 DMX Address DMX512 address, 2 channel mode (001-512)
A001 DMX Address DMX512 address, 2 channel mode (001-512)
u001 Cold White Up & Down Buons change Cold White intensity (000-
255)
C001 Warm White Up & Down Buons change Warm White intensity
(000-255)
F001 Manual Strobe
Funcon Up & Down Buons Increases Strobe Speed (001-255)
FIXTURE MENU STRUCTURE CHART
DMX MODES
CHANNEL 3 CHANNEL DMX MODE FUNCTION
1COLD WHITE DIMMER DARK TO BRIGHT
2WARM WHITE DIMMER DARK TO BRIGHT
3STROBE SLOW TO FAST
CHANNEL 2 CHANNEL DMX MODE FUNCTION
1COLD WHITE DIMMER DARK TO BRIGHT
2WARM WHITE DIMMER DARK TO BRIGHT

13 SOLARIS® SMART 54W™
Disconnect the xture from mains power and allow to cool completely before cleaning or
servicing. Service xtures in an area where there is no risk of injury from failing parts, tools
or other materials. Excessive dust, smoke uid, and parcle buildup degrades performance,
causes overheang and will damage the xture. Damage caused by inadequate cleaning or
maintenance is not covered by the product warranty.
CLEANING
The cleaning of lenses must be carried out periodically to opmize light output. Cleaning
schedules for lighng xtures vary greatly depending on the operang environment. It is
therefore impossible to specify precise cleaning intervals for the xture. Environmental fac-
tors that may result in a need for frequent cleaning include:
• Use of smoke or fog machines.
• High airow rates (near air condioning vents, for example).
• Presence of cigaree smoke.
• Airborne dust (from stage eects, building structures and ngs or the natural environ-
ment at outdoor events, for example).
If one or more of these factors is present, inspect xtures within their rst 100 hours of oper-
aon to see whether cleaning is necessary. Check again at frequent intervals. This procedure
will allow you to assess cleaning requirements in your parcular situaon.
Use gentle pressure only when cleaning, and work in a clean, well-lit area. Do not use any
product that contains solvents or abrasives, as these can cause surface damage.
CLEANING THE FIXTURE
1. Disconnect the xture from power and allow it to cool for at least 10 minutes.
2. Vacuum or gently blow away dust and loose parcles from the outside of the xture and
air with low-pressure compressed air
3. Clean lenses by wiping gently with a so, clean lint-free cloth moistened with a weak de-
tergent soluon. Do not rub the surface hard: li parcles o with a so repeated press. Dry
with a so, clean, lint-free cloth or low pressure compressed air. Remove stuck parcles with
an unscented ssue or coon swab moistened with glass cleaner or dislled water.
4. Check that the xture is dry before reapplying power.
MAINTENANCE
WARNING! READ SAFETY INFORMATION ON
PAGE 3 BEFORE INSTALLING THE FIXTURE.

SOLARIS® SMART 54W™ 14
Specicaons are subject to change without noce.
For latest product specicaons, see www.Glow-Lighng.com
SMART 54W SPECIFICATIONS
INSTALLATIONS
Locaon Indoor Use Only, Must be fastened to surface or
structure
Mounng points Two adjustable bracket with clamp inseron point
Orientaon Any
PHYSICAL DIMENSIONS
LAMP
Lamp type 54 X 3W
Color system COLD \ WARM White
Temperature Adjustable
FEATURES
Strobe Strobe Eect 01-16
Dimmer 0 – 100% Full Linear Dimming
Cooling Silent Fan With Heat sink
Max ambient temperature 40° C (104° F)
Min Ambient temperature -25°C (-13° F) Total
Heat Dissipaon (calculated, +-10%) 1200BTU/hr.
THERMAL
4Kg 8.81 lbs.
WEIGHT
Led Surface Diameter 230mm 9.055”
Body Width 118mm 4.65”

15 SOLARIS® SMART 54W™
INCLUDED ITEMS
User Manual
3 . PowerCon Cable
CONNECTIONS
AC Power Input Power-Con Power cable (included)
DMX512 Data 3-pin locking XLR, 1 Input, 1 Output
ELECTRICAL
AC Power 110-230V 50\60Hz
Fuse T5A
Power Supply Auto Ranging Electronic Switch Mode
CONTROL AND PROGRAMMING
Control System DMX512
Sengs & Addressing USITT DMX512/1990
CONSTRUCTION
Color Black
IP Rang IP20
Power consumpon 180W
MAX POWER CONSUMPTION
Beam Angle 25° Degrees
OPTICS
Fixture Channel Mode 3Ch. Mode | 2Ch. Mode
DMX MODES

SOLARIS® SMART 54W™ 16
2015 SOLARIS BY GLOW® PROFESSIONAL.
INFORMATION SUBJECT TO CHANGE WITHOUT NOTICE. SOLARIS BY GLOW®
PROFESSIONAL DISCLAIM LIABILITY FOR ANY INJURY, DAMAGE, DIRECT OR
INDIRECT LOSS, CONSEQUENTIAL OR ECONOMIC LOSS OR ANY OTHER LOSS
OCCASIONED BY THE USE OF, INABILITY TO USE OR RELIANCE ON THE
INFORMATION CONTAINED IN THIS MANUAL. THE GLOW LOGO, THE
SOLARIS LOGO, THE GLOW®
PROFESSIONAL NAME THE SOLARIS PROFESSIONAL NAME AND ALL OTHER
TRADEMARKS IN THIS DOCUMENT PERTAINING TO SERVICES OR
PRODUCTS BY GLOW® PROFESSIONAL OR ITS AFFILIATES AND
SUBSIDIARIES ARE TRADEMARKS OWNED OR LICENSED
BY GLOW® PROFESSIONAL
GLOW® PROFESSIONAL
WWW.GLOW-LIGHTING.COM
