SolarPath 2SPBL13 User manual

TOOLS REQUIRED
•5/32 inch hex key
•3/4 inch wrench or deep socket
SOLAR BOLLARD 2SPBL13/2SPBL14
Installation instructions
INSTALLATION
With a one to two foot setback from the path or area to be illuminated, install concrete footing with supplied
anchor bolts. Align anchor bolts to path as shown below using the supplied cardboard template to hold the
bolts in position.
2SPBL13/14-T2
123 Town Square Pl., #333 Tel. [phone]
Jersey City, NJ 07310 www.solarpathusa.com
2SPBL13/14-T5
Ø10.23”
Ø5.90”
Ø8.50”
32.26”
24.46”
0.84”
1.65”
Option 1 Option 2
3.14”
0.39”
0.78”
15.74”
3.93”
PRIOR TO INSTALL
Ensure install location receives at least 2 to 3 hours of midday
sun on average. Please handle bollard with care as scratches will
affect appearance and powder coat durability.
2SPBL13/14 MODEL
Please refer to the diagram below to identify the model you are
installing.

PUT BACK HEAD
Place the head back on the post and fasten with the supplied 1/4 - 20 screws and tighten to 65 in-lbs.
Path
For 2SPBL13/14-T3 model only
Ensure the LED optic is facing the pathway.
CONNECT BATTERY
Remove the head of the bollard from the post and connect the battery cables. Observe the light to ensure it
illuminates for approximately 20 seconds after connecting the battery. If the light does not illuminate after
connecting the battery, please call us .
SOLAR BOLLARD 2SPBL13/ 2SPBL14
Installation instructions
123 Town Square Pl., #333 Tel. [phone]
Jersey City, NJ 07310 www.solarpathusa.com
BASEPLATE DIMENSIONS
Switch ON/OFF
LED Color button

How to operate this bollard light ?
Steps:
•Press the button for 2-3 seconds, Flash two times, bollard goes to mode 1
•Press button ( no need press it for 3 seconds), Flash three times, it goes to mode 2
•Press button, Flash four times, it goes to mode 3
•Press button, Flash five times, it goes to mode 4
All modes completed, if you press button again, it goes to mode 1 again, and again cycle......
If you need to turn off the light, just Press the button for 2-3 seconds.
Four operation modes
Mode 1: 6 hours 100% brightness, then 25% to dawn.
Mode 2: 4 hours 100% brightness, then 25% to dawn.
Mode 3: 1st hour 100%, 2nd-4th hrs 50% , then 25% to dawn.
Mode 4: 100% brightness Dusk to dawn.
Then, fix bollard head and base by screw (Option)
Install the bollard to the ground by explosion screw
