Solent RemoteF4 User manual

RemoteF4 - Fan Four Speed only
RemoteF4
INSTALLATION INSTRUCTIONS
OFF
HI
MED LOW SLOW
Hi Fan OFF
Med Slow
Low
To open battery
housing cover:
Press down and
slide out
Receiver
IR Sensor
VIEW AFTER INSTALLATION
Ceiling
OR
IR SENSOR POSITIONING
TRANSMITTER
IR Sensor
To fan/NEUTRAL
To fan/LIVE
BLACK
WHITE
BLACK RED
N L AC Power Input
Receiver
Fan Motor
L
N
Toggle Switch
on bottom canopy
t+27 (0) 31 563 4600 | [email protected] | www.solent.co.za
IMPORTANT POINTS
1. Before installation, TURN OFF the power to your ceiling fan.
2. The installation must be done by a QUALIFID ELECTRICIAN.
3. This unit is to be used in an AC 220/240 Volt 50Hz supply only.
4. Rating: Maximum 100 watts for the fan motor.
5. For indoor use only. Do not install in damp locations or immerse in water.
6. Do not pull on or cut the leads shorter.
7. Do not drop or bump the unit.
8. The batteries will weaken with age and should be replaced before leaking
takes place as this will damage the transmitter.
9. The electric shock protection of the INFRA RED receiver shall depend on its
installation
10. The INFRA RED remote controller shall be used within its rating range,otherwise
overheating and dangerous phenomenon may occur.
FUNCTIONS OF THE TRANSMITTER
Point the transmitter at the Infra Red sensor and press buttons for desired operation.
1. OFF : Turn off ceiling fan.
2. HI : Turn on ceiling fan at High speed.
3. MED : Turn on ceiling fan at Medium speed
4. LOW : Turn on ceiling fan at Low speed
5. SLOW : Turn on ceiling fan at Slow speed
OVERLOAD PROTECTION FOR FAN MOTOR
If your fan goes off suddenly, it may be because of the fan motor overload
protection function.
Press the Fan OFF button to reset the overload and to turn the fan on again.
CONNECTION OF THE RECEIVER & INFRA RED SENSOR
1. Connect the RECEIVER as shown in wiring diagram.
2. Plug in the INFRA RED SENSOR and position it outside the canopy.
3. Once connections made place the RECEIVER in the canopy
and slide the canopy up and tighten in position.
4. Caution: Incorrect wire connections will damage
the receiver.

RemoteLD4 - Fan Four Speed with Light On/Off and Dimmer
RemoteLD4
INSTALLATION INSTRUCTIONS
t+27 (0) 31 563 4600 | [email protected] | www.solent.co.za
To open battery
housing cover:
Press down and
slide out
Receiver
IR Sensor
VIEW AFTER INSTALLATION
OFF
HI
MED LOW SLOW
Hi Fan OFF
Med Slow
Low
Light ON/OFF Dimmer
DIMMER
LIGHT
ON/OFF
TRANSMITTER
Ceiling
OR
IR SENSOR
POSITIONING
To fan/NEUTRAL
To fan/LIVE BLACK WHITE
IR Sensor
BLACK RED
N L AC Power Input
Receiver
Fan Motor
To Light/LIVE ORANGE L
N
Toggle Switch
on bottom canopy
IMPORTANT POINTS
1. Before installation, TURN OFF the power to your ceiling fan.
2. The installation must be done by a QUALIFID ELECTRICIAN.
3. This unit is to be used in an AC 220/240 Volt 50Hz supply only.
4. Rating: Maximum 100 watts for the fan motor.
5. For indoor use only. Do not install in damp locations or immerse in water.
6. Do not pull on or cut the leads shorter.
7. Do not drop or bump the unit.
8. The batteries will weaken with age and should be replaced before leaking
takes place as this will damage the transmitter.
9. The electric shock protection of the INFRA RED receiver shall depend on its
installation
10. The INFRA RED remote controller shall be used within its rating range,otherwise
overheating and dangerous phenomenon may occur.
FUNCTIONS OF THE TRANSMITTER
Point the transmitter at the Infra Red sensor and press buttons for desired operation.
1. OFF : Turn off ceiling fan.
2. HI : Turn on ceiling fan at High speed.
3. MED : Turn on ceiling fan at Medium speed
4. LOW : Turn on ceiling fan at Low speed
5. SLOW : Turn on ceiling fan at Slow speed
6. LIGHT ON/OFF : Press and release to turn the underfan light on and off.
7. DIMMER : Press and hold the dimmer button to dim or brighten the
underfan light to the desired level and release.
NOTE: DO NOT use energy saving lamps with this remote.
OVERLOAD PROTECTION FOR FAN MOTOR
If your fan goes off suddenly, it may be because of the fan motor overload
protection function.
Press the Fan OFF button to reset the overload and to turn the fan on again.
CONNECTION OF THE RECEIVER & INFRA RED SENSOR
1. Connect the RECEIVER as shown in wiring diagram.
2. Plug in the INFRA RED SENSOR and position it outside the canopy.
3. Once connections made place the RECEIVER in the canopy
and slide the canopy up and tighten in position.
4. Caution: Incorrect wire connections will damage the receiver.
