Solid State Logic SSL UF1 User manual

SSL UF1
www.solidstatelogic.com
SSL UF1
User Guide

Visit SSL at:
www.solidstatelogic.com
© Solid State Logic
All rights reserved under International and Pan-American Copyright Conventions.
SSL®and Solid State Logic®are registered trademarks of Solid State Logic.
SSL UF1™ is a trademark of Solid State Logic.
All other product names and trademarks are the property of their respective owners and are hereby acknowledged.
Pro Tools® is a registered trademark of Avid®.
Live™ is a trademark of Ableton®AG.
Logic Pro®and Logic®are registered trademarks of Apple® Inc.
Studio One®is a registered trademark of Presonus®Audio Electronics Inc.
Cubase™ and Nuendo™ are trademarks of Steinberg®Media Technologies GmbH.
LUNA™ is a trademark of Universal Audio®Inc.
Pyramix™ is a trademark of Merging Technologies® SA.
Mackie® is a registered trademark of LOUD Technologies®Inc.
BOSS®is a registered trademark of Roland®Corporation.
No part of this publication may be reproduced in any form or by any means, whether mechanical or electronic, without the
written permission of Solid State Logic, Begbroke, OX5 1RU, England.
As research and development is a continual process, Solid State Logic reserves the right to change the features and
specifications described herein without notice or obligation.
Solid State Logic cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in
this manual.
PLEASE READ ALL INSTRUCTIONS, PAY SPECIAL HEED TO SAFETY WARNINGS.
E&OE
Revision 1.0 - May 2023
Initial Release

Contents
SSL UF1 User Guide
Table of Contents
Overview 5
What is SSL UF1? 5
Features 5
Safety Notices 5
Get-Started 6
Unpacking 6
UF1 Physical Specification 6
Fitting The Stands (Optional) 7
Connecting Your UF1 Hardware 8
Downloading SSL 360° Software and the SSL Meter Plug-in 9
Installing SSL 360° Software 9
System Requirements 9
Registering Your UF1 - Redeeming and Authorising Your Meter Plug-in License 10
UF1 YouTube Tutorials 12
Keyboard Identify (Mac Only) 13
UF1 Hardware Layout 14
Front Panel 14
Connector Panel 17
SSL 360° Software Overview 18
Overview & Home Page 18
UF1 Page 22
Control Setup Page 20
Switching the control layer from UF1 (Layer Set Up) 21
DAW Communication 25
SSL V-MIDI Ports 25
DAW Protocols 25
Pro Tools with UF1 - Tutorial 26
SSL 360° Setup 26
Pro Tools Setup 26
Small LCD Layout 27
Large LCD Layout 28
Tutorial 29
Logic with UF1 - Tutorial 42
SSL 360° Setup 42
Logic Setup 42
Small LCD Layout 44
Large LCD Layout 45
Tutorial 46
Cubase/Nuendo with UF1 - Tutorial 56
SSL 360° Setup 56
Cubase Setup 56
Small LCD Layout 57
Large LCD Layout 58
Tutorial 59
Ableton Live with UF1 - Tutorial 70

Contents
SSL UF1 User Guide
SSL 360° Setup 70
Live Setup 70
Small LCD Layout 71
Large LCD Layout 72
Tutorial 73
Studio One with UF1 - Tutorial 81
SSL 360° Setup 81
Studio One Setup 81
Small LCD Layout 82
Large LCD Layout 83
Tutorial 84
LUNA with UF1 - Tutorial 96
SSL 360° Setup 96
LUNA Setup 96
Small LCD Layout 97
Large LCD Layout 98
Tutorial 99
Pyramix with UF1 - Tutorial 107
SSL 360° Setup 107
Pyramix Setup 107
Small LCD Layout 108
Large LCD Layout 109
Tutorial 110
UF1 & 360°-Enabled Plug-ins 119
SSL Meter 119
Channel Strip 2 119
4K B 119
Plug-in Mixer Overview 120
Plug-in Mixer - Tutorial 121
SSL 360° Setup 121
Plug-in Mixer Setup 121
Plug-in Mixer Transport Setup 122
Tutorial 122
Small LCD Layout 122
Large LCD Layout - Channel Strip Mode 126
SSL Chanel Strip Soft Key & V-Pot Assignments 127
Large LCD Layout - Meter Mode 128
Overview 128
Analogue 129
31- Band Real-Time Analyser (RTA) 130
UF1 LCD Messages 131
SSL 360° Software Messages 134
SSL Support - FAQs, Ask a Question and Compatibility 135
Safety Notices 136

Overview
5
SSL UF1 User Guide
Overview
What is SSL UF1?
UF1 is an incredibly powerful one-fader control surface that goes above and beyond the competition. It boasts not one but two
high quality displays, a 100 mm fully motorised 100 mm fader, premium soft-feel durable rubber keys and a weighted jog wheel,
all encased in a durable metal chassis. UF1 gives you comprehensive command of your DAW (pans, sends, plug-in control and
more) plus the ability to customise 46 soft keys specifically to your workflow. Furthermore, UF1 and SSL 360° integrates directly
with the SSL Meter plug-in, viewable in all its glory on the impressive 4.3” IPS TFT LCD and controllable from the surface itself.
UF1 can be used on its own or it can be partnered with the SSL UF8(s), to give you the ultimate SSL DAW controller system. UF1 is
also the perfect expansion for the SSL UC1 plug-in controller, giving you direct access to 360°-enabled channel strip parameters
on the Plug-in Mixer Layer.
Features
• 100 mm high quality motorised fader.
• 2 x high quality LCD TFT displays, including a large 4.3” TFT LCD for effortless visual feedback of DAW track names,
parameters, time display, the SSL Meter plug-in and 360°-enabled channel strips in the SSL Plug-in Mixer.
• Dedicated Transport controls and weighted jog/scrub wheel for total session control.
• Dedicated HUI and MCU DAW Profiles for: Pro Tools, Logic, Cubase, Studio One, Ableton Live, LUNA, Pyramix.
• UF1 can switch to control the MASTER fader in MCU protocol DAWs.
• Proprietary control of the SSL 360° Plug-in Mixer Layer: seamless integration with the SSL Meter plug-in (perpetual license
included), with the metering plug-in visualised on the large 4.3” IPS display and hardware control from the UF1 surface.
• SSL Meter offers essential meter tools including Peak & RMS levels, K-System, stereo balance, phase correlation bar, Lissajous
vector scope, 31-band RTA, VU and PPM metering.
• Extend the functionality of UC1: control 360°-enabled channel strips such as Channel Strip 2 and 4K B directly from the UF1
surface and view the EQ curve on the UF1 large display.
• Master mode for the Plug-in Mixer allows UF1 to control a different channel strip to the one that is selected on UC1.
• Fully-featured DAW Controller in a compact footprint. Control DAW Pans, Sends, Plug-ins and Virtual Instruments with ease.
• 46 customisable user keys ready to assign your favourite DAW commands or keyboard shortcuts.
• Secondary Transport row of keys can be customised to essential workflow shortcuts such as Loop on/off and click track on/
off. Or press the Shift button for fast access to DAW automation modes.
• Fader Mode allows you to use the 4 V-Pots underneath the large screen to control 4 track volumes at the same time.
• A large multi-purpose notched encoder allows for single channel banking, mouse wheel emulation (Focus mode and control
over computer system volume.
• Use UF1 on its own, or partner with UF8 and/or UC1 to enhance the functionality of both products.
• 2 x assignable foot-switch inputs.
• Up to 3 different DAWs can be connected simultaneously and switched between using the Layer keys.
• Powered by the SSL 360° Software application.
Safety Notices
Please read the Important Safety Notices at the end of this User Guide before use.

Get-Started
6SSL UF1 User Guide
Get-Started
Unpacking
The unit has been carefully packed and inside the box you will find the following items in addition to your UF1 control surface:
UF1 Physical Specication
Dimensions
Width 205 mm x Height 265.9 mm x Depth 62.5 mm
Weight
Unboxed (unit only) - 1.8 kg
Boxed - 2.88 kg
12V, 2A AC/DC Power Adapter with swappable plugs for various
regions
2 x Stands
1 x Hex Key
4 x Screws

Get-Started
7
SSL UF1 User Guide
Fitting The Stands (Optional)
UF1 has been designed to be used with or without the included screw-in stands, depending on your preference. Attaching the
included screw-in stands has the added benefit of angling the unit towards you. Three different fixing positions (the holes are
arranged in pairs) allow you to choose an angle that is best for your setup. Use 2 screws per stand. Please be careful not to over-
tighten to avoid stripping the screw threads. For those with a torque measuring device, tighten to 0.5 Nm.
Additional Elevation Angles
If you need a steeper angle of elevation, you can rotate the stands and fix them to the chassis using the shorter side. This gives
you three additional angle options to choose from.
1. Unscrew the rubber feet and move to the other end 2. Rotate the stands so that the short side fixes to the chassis

Get-Started
8SSL UF1 User Guide
C to C cable
or C to A cable
Power Supply
UF1 Connector Panel
UF1 UF8
A to C USB Cable
Connecting Your UF1 Hardware
1. Connect the included power supply to the DC socket on the connector panel.
2. Connect one of the included USB cables from your computer to the USB socket.
USB Cables
Please use one of the provided USB cables ('C' to 'C' or 'C' to 'A' with the provided adapter) to connect UF1 to your computer. The
type of USB port you have available on your computer will determine if the adapter is required for connecting the cable to your
computer. Newer computers may have 'C' ports, whereas older computers may have 'A'. Please ensure that you are connecting
to the port labelled USB on UF1 which is a 'C' type connection.
Connecting the UF1 to UF8
If you are using a UF1 and a UF8, you can use the THRU port (USB 'A' type) to link the two devices - this means that only one USB
port is required at your computer.
Theoretically, you can chain 4 x UF8, a UC1 and a UF1 together in the way described above. However, by doing so you may exceed
the number of hub tiers permitted by your PC/Mac computer. As such, you may need to connect your UF1 unit directly to another
USB port on your computer. The same applies regarding the use of USB hubs; the UF1 may need to be plugged directly into a
different USB port on your computer.
Tip: The THRU port can also be used to plug in USB dongles for DAW software or plug-in licenses.

Get-Started
9
SSL UF1 User Guide
Downloading SSL 360° Software and the SSL Meter Plug-in
UF1 requires the SSL 360° software to be installed on your computer in order to function. SSL 360° is the brains behind your
UF1 control surface. Once you have connected your UF1 hardware to your computer as described on the previous page, please
download SSL 360° from the SSL website.
1. Go to solidstatelogic.com/support-page/downloads
2. Select UF1 from Products drop-down list.
3. Download the SSL 360° software for your Mac or Windows system.
4. Download the SSL 360° Meter Plug-in for your Mac or Windows system
Installing SSL 360° Software
System Requirements
Computer operating systems and hardware are constantly changing. Please search for 'UF1 Compatibility' in our online FAQs to
check if your system is currently supported.
Mac
1. Locate the downloaded SSL 360°.dmg on your
computer.
2. Double-click to open the .dmg.
3. Double-click to run the SSL 360°.pkg.
4. Proceed with the installation, following the on-
screen instructions.
Windows
1. Locate the downloaded SSL 360°.exe on your
computer.
2. Double-click to run the SSL 360°.exe.
3. Proceed with the installation, following the on-
screen instructions.

Get-Started
10 SSL UF1 User Guide
Registering Your UF1 - Redeeming and Authorising Your Meter Plug-in License
You'll need to register your UF1 hardware in the SSL user portal to claim your Meter plug-in license
To register your product, head to www.solidstatelogic.com/get-started and follow the on-screen instructions to create an
account or log into your existing one.
Once logged into your account, click on REGISTER PRODUCT on the Dashboard page and on the following page choose
REGISTER HARDWARE PRODUCT.
Choose SSL UF1 and complete the form.
SSL UF1

Get-Started
11
SSL UF1 User Guide
You will need to input the serial number of your UF1. This can be found on the label on the base of your UF1 unit (it is not the
number on the packaging box).
Once you have successfully registered your UF1, it will appear in your Dashboard. Click Get Your Additional Software.
On this page, enter your iLok User ID into the box, wait for your iLok account to be validated and then click DEPOSIT LICENSE.
Finally, open iLok License Manager, locate the SSL Meter plug-in license and right-click Activate onto your computer or physical
iLok.

Product Overview & Features
12 SSL UF1 User Guide
UF1 YouTube Tutorials
The SSL YouTube channel hosts in-depth tutorials on how to setup and use UF1 with your DAW.

Get-Started
13
SSL UF1 User Guide
Keyboard Identify (Mac Only)
One of the special features of UF1 is its ability to trigger keyboard command sequences of your favourite DAW shortcuts. These
are assigned using the SSL 360° software and this is covered later in this User Guide.
When you first plug in your UF1, Mac OS will present the above 'Keyboard
Setup Assistant' window because Mac OS wants you to identfy which region
(Europe, America or Japan) this, as yet unidentified, keyboard is from. If
you connected your UF1 to your computer before installing SSL 360°
software, you need to close this setup assistant because SSL 360°
needs to be installed on your computer in order to continue through this
setup process. To make the Keyboard Setup Assistant appear again once
SSL 360° is installed, do the following: Open up Mac's 'System Preferences'
> Go to 'Keyboard' > Click 'Change Keyboard Type' (please note, your UF1
must be connected to your computer via a USB cable) and click 'Continue'.
• When presented with 'Identifying Your Keyboard' and you are being asked to 'Press the key immediately to the right of the
Shift Key', at this point, press and hold the 360° key on UF1 and press the MacKeyID button on the top-right soft key of UF1.
• This will move you through to the final step of the process, where you can choose the appropriate option (Europe, America or
Japan) for your region and then click 'Done'.
STEP 1: Go to System Preferences and
click 'Keyboard'.
STEP 4: When presented with the message 'Press the key immediately to the right of
the Shift Key', press and hold the 360° key on UF1 and then press MacKeyID.
STEP 5: Select your region and click
'Done'.
STEP 2: Click 'Change Keyboard Type' STEP 3: Click 'Continue'.

Product Overview & Features
14 SSL UF1 User Guide
UF1 Hardware Layout
Front Panel
This section will help familiarise yourself with the front panel controls of the UF1 surface. It is intended to be an overview, rather
than a comprehensive explanation of each function or mode. For more detail on the integration of features with each DAW, please
refer to the DAW Tutorials sections of this User Guide.
10
11
1
2
3
4
5
7
6
8
9
13
12
14
15
19
20
21
17
18
16

Product Overview & Features
15
SSL UF1 User Guide
1 - Small Screen Soft Key
This allows control over certain V-Pot parameters. The behaviour of this key varies for each DAW. Please see the relevant DAW
Tutorial section for more information.
2 - Small Screen
Colour LCD TFT provides visual feedback of track metering, track names, V-POT readouts, track record-arm states and more.
3-Small Screen V-Pot
"V-Pot" is short for "virtual pot" and this is used to control various DAW parameters including Pan position, Send levels and Plug-in
parameters. The small screen V-Pot controls the selected parameter of the currently selected channel shown on the fader.
4 - 100 mm Motorised Fader
High quality motorised fader with touch sense.
5 - SOLO, CUT, SEL
The most common controls found in all DAWs.
6 - FLIP Key
FLIP is used to assign the current V-Pot parameter to the fader and can be used for tasks such as riding send levels.
7- Master Key
Changes the fader to control the DAW's master fader. Please note this varies per DAW and is not available in all DAWs. Please see
the relevant DAW Tutorial section for more information.
8 - 4 x Large Screen Soft Keys
A line of 4 soft keys allow access to various V-Pot parameters or, up to 40 user-assignable keys (across 10 pages). The label for
the function of each key is displayed in the top section of the large screen.
9 - Large Screen
A large colour LCD TFT provides visual feedback of the DAW's time display, track names, V-Pot parameter readouts and more.
This is also where the SSL Meter plug-in is visualised.
10 - 4 x Large Screen V-Pots
"V-Pot" is short for "virtual pot" and these are used to control various DAW parameters including Pan position, Send levels and
Plug-in parameters.
11 - 360°/Layer Key
A short press opens/minimises the SSL 360° software on your computer screen. A long press will open the DAW layer selection
indicated at the top of the large Screen and selectable via one of the 4 large screen soft keys.
12 - BANK < > Keys
These keys allow you to bank through the tracks in your DAW, bringing them onto your UF1 control surface.
13 - MODE &5-8 Keys
The MODE key toggles between various control states dependant on your DAW, as well as providing direct access to the SSL
Meter Plug-In control. The 5-8 key expands the V-pot controls beyond the 1st 4 channels of the selection to the 5 to 8 Channels
of the bank of 8.

Product Overview & Features
16 SSL UF1 User Guide
14 - < > Keys
These keys page through the 10 soft key pages.
15 - Large Notched CHANNEL Encoder
The large encoder can function in several different modes:
• < > - The encoder will bank DAW tracks one at a time.
• NUDGE Mode (Pro Tools only) Allows you to use the encoder to move selected audio regions by the currently set Nudge value.
• FOCUS Mode - This mode turns the operation of the large encoder into a mouse wheel scroll emulation and is great for
controlling plug-ins. Simply hover your computer mouse over the desired control and turn the encoder. The sensitivity of this
mode will be determined by your computer's mouse scroll sensitivity settings
• VOLUME Mode - This mode allows the Channel Encoder to act as a volume control when the currently active audio interface
allows control of system audio level.
16 - Cursor Keys and Mode (Circle) Key
In standard operation, these keys perform various functions including DAW timeline zooming and important tasks such as selection
of plug-in slots (Logic only). Refer to the DAW Tutorials section for more information on this.
17 - Jog Wheel
Large Jog wheel to move through the DAW timeline.
18 - Scrub key
Puts the Jog wheel into Scrub mode.
19 -Transport Keys
Control the DAW's Rewind, Forward, Stop, Play, and Record command.
20 - Secondary Transport Keys
These keys expand on the most common DAW transport controls and for most DWA profiles come preassigned to common
functions such as, Loop on/off, Metronome on/off. These 6 keys are customisable via SSL 360° . Refer to the DAW Tutorials section
for more information on this.
21 - SHIFT Key
Engaging the SHIFT key re-purposes the secondary transport keys to access various DAW automation modes such as Off, Read,
Write, Trim, Touch and Latch (DAW dependant). Use in conjunction with the SEL key to select a DAW track and then put it into the
desired automation mode.

Product Overview & Features
17
SSL UF1 User Guide
Connector Panel
The recessed section hosts UF1's connectors.
USB - 'C' Type Connector
Connect the included USB cable from your computer to the USB port on UF1. This handles all of the communication between your
DAW and UF1, via the SSL 360° software application.
THRU - 'A' Type Connector
The THRU connector is an in-built USB hub and it can be used to chain a UF1 and UF8/UC1 unit together, without needing to plug
each unit into your computer individually. It can also be used to plug in USB dongles.
DC Connector
Use the included AC/DC Power Supply to provide power for your UF1.
FS1 & FS2 - 1/4" Jack Connectors
These allow for the connection of foot-switches, which can be used to trigger DAW commands or user-assigned keyboard shortcut
sequences.
UF1 has been tested with popular foot-switches such as the BOSS FS-6 (other brands are available), whose foot-switch behaviour
(or polarity as it is often referred to), is a 'normally closed' switch. In some cases, these foot-switches offer the ability to change
the polarity.
Please use a foot-switch designed for 'normally closed' operation and also, to ensure full compatibility use a momentary action
foot-switch, or choose a foot-switch that can be set to momentary. This will ensure correct operation with assigned DAW commands.

Product Overview & Features
18 SSL UF1 User Guide
SSL 360° Software Overview
Overview & Home Page
SSL 360° software is not only the 'brains' behind the UF1 control surface, it is also the command centre from which new versions
of software and firmware can be downloaded for your 360° compatible device.
The HOME screen:
1 - Menu Toolbar
This toolbar allows you to navigate through the various pages of SSL 360°.
2 - Update Software Button
When software updates become available, the Update Software button (pictured above) will appear. Click this to download and
update your software.
3 - Connected Units
This area shows any 360°-enabled devices (including UF1) connected to your computer, along with their respective serial numbers.
Please allow 10-15 seconds for units to be discovered once they are plugged in.
1
2
34
5987 6

Product Overview & Features
19
SSL UF1 User Guide
4 - Firmware Updates
If a firmware update becomes available for your UF1, then an Update Firmware button will appear below each unit. Click on the
button to start the firmware update process, being sure to not disconnect the power or USB cable(s) whilst it is in progress.
5 - Sleep Settings
Clicking this will open a pop-up window that allows you to determine the length of time before your connected 360° control surfaces
go into Sleep mode. Simply click your mouse in the green digit area and type a number between 1 and 99. To force a control
surface out of sleep mode, press any button or move any control on the surface itself. You can untick the box to disable Sleep
mode.
6 - About
Clicking this will open a pop-up window detailing software licensing relating to SSL 360°.
7 - SSL Socials
The bar at the bottom has quick links to the SSL website, Support section and SSL Socials.
8 - Export Report
Should you encounter any issues with your UF1 or SSL 360° software, you may be asked by a support agent to use the EXPORT
REPORT feature. This feature generates a text file containing the essential information about your computer system and UF1,
alongside technical log files relating to SSL 360° activity, which may help to diagnose any issues. When you click EXPORT
REPORT, you'll be asked to choose a destination on your computer to export the generated .zip file to, which you can then forward
onto the support agent.
9 - SSL 360° Software Version Number
This area displays the version number of SSL 360° that is running on your computer. Clicking on the version text will take you to
the Release Notes information on the SSL website.

Product Overview & Features
20 SSL UF1 User Guide
Control Setup Page
DAW Conguration
The CONTROL SETUP page in SSL 360° allows you to nominate up to 3 different DAWs for use with UF1. In the DAW
CONFIGURATION section, select up to 3 DAWs using the drop-down lists. In the example pictured below, DAW 1 is set to Pro
Tools, DAW 2 is set to Logic Pro and DAW 3 is set to Cubase. Once you have nominated the DAW(s) on this page, they will become
available for you to assign to each UF1 Layer on the UF1 Page (covered in more detail on the following pages).
DAW 1 (LAYER 1): SSL V-MIDI Ports 1-4
DAW 2 (LAYER 2): SSL V-MIDI Ports 5-8
DAW 3 (LAYER 3): SSL V-MIDI Ports 9-12
Plug-in Mixer Transport
When a UF1 layer is set to control the SSL 360° Plug-in Mixer, the
transport keys on the bottom of UF1 and the jog wheel will operate the
DAW's Transport commands. The DAW that drives (the one that is
linked to) these buttons on UF1 must be selected from the drop-down
list here. You'll be able to choose from any of the 3 DAWs you have
nominated in the DAW CONFIGURATION section.
Select your DAW from the drop-down list, starting with DAW 1. If you only use 1 DAW then leave DAW 2 and DAW 3 set to 'None'.
DAW drop-down list
