Sollevare BIWC-100A User manual

INSTRUCTION MANUAL
WINE COOLER MODELS:
BIWC-100A / BIWC-100B / BIWC-100C / BIWC-100D
BIWC-150A / BIWC-150B / BIWC-150C / BIWC-150D
BIWC-408A / BIWC-408B / BIWC-408D
BIWC-120-2D

TABLE OF CONTENTS
WINE /BEVERAGE COOLERS SAFETY
2
IMPORTANT SAFE-GUIDES
3
REFRIGERANTGASWARNINGS
4
UNIT BREAKDOWNPT.1
5
UNIT BREAKDOWNPT.2
6
UNIT BREAKDOWNPT.3
7
INSTALLATION INSTRUCTIONS PT.1
8
INSTALLATION INSTRUCTIONS PT.2
9
INSTALLATION INSTRUCTIONS PT.3 /ADDITIONAL SAFETY INSTRUCTIONS
10
CARE AND MAINTENANCE
11
OPERATING YOURWINE COOLER
12-17
TROUBLE SHOOTING GUIDE
18-19

WINE CHILLER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill, maim,
injure, or damage you and others. All safety messages will follow the Safety Alert Symbol and
either the words “DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to heed this safety
statement may result in severe personal
injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety messages will alert you do what the potential hazard is, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
2

3
IMPORTANT SAFEGUIDES
Before the appliance is used, it must be properly positioned and installed as described in this
manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when
using the appliance, follow basic precaution, including the following:
! CALIFORNIA PROP 65 WARNING !: This product can expose an individual to chemicals and/or materials,
Including Styrene and/or Lead, which have been identified by the state of California to possibly be dangerous and
lead to various diseases, birth defects, or other human reproductive system harm. For more information go to
WWW.P65Warnings.ca.gov
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do not use an
extension cord.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that cannot
be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion. And do not
store or use gasoline or other flammable vapour and liquids in the vicinity of this or any other appliance. The fumes
can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in electrical
shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this material.
All other servicing should be referred to a qualified technician.

4
The symbol is a warning symbol for risk of fire/flammable material.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
Use two or more people to move and install appliance. Failure to do so can result in back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed. Choose a
well-ventilated area with temperatures above 16°C (60°F) and below 32°C (90°F). This unit must be installed in
an area protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical, water and drain connections in accordance with state and local
codes. A standard electrical supply (115V/60Hz) properly grounded in accordance with the National Electrical
Code and local codes and ordinances is required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 13 amperes.
It is important for the appliance to be leveled in order to work properly. You may need to make several adjustments
to level it.
Never allow children to operate, play with or crawl inside the appliance.
Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may damage or discolour
the interior.
Do not use this apparatus for other than its intended purpose
FLAMMABLE REFRIGERANT GAS
DANGER - Risk of fire or explosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant tubing.
DANGER -Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained service personnel.
DO NOT puncture refrigerant tubing.
CAUTION - Risk of fire or explosion. Flammable refrigerant used. Consult repair manual / owner’s guide before
attempting to service this product. All safety precautions must be followed.

5
CAUTION - Risk of fire or explosion. Dispose of property in accordance with federal or local regulations. Flammable
refrigerant used.
CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing. Follow handling instructions carefully.
Flammable refrigerant used.
CAUTION - To prevent a child from being entrapped, keep out of reach of children and not in the vicinity of the cooler.
BIWC-120-2D (Double Compartiment dual Zone)

6
BIWC-100B,D/BIWC-150B,D/BIWC-408B,D (Dual Zone)
1
Control Panel
5
Top Hinge
2
Wooden Shelves
6
Glass Door with Handle
3
Kick Plate Vent
7
Child Safety Lock
4
Adjustable Legs

7
BIWC-100A,C /BIWC-150A,C /BIWC-408A (Single Zone)
1
Control Panel
5
Glass Door with Stainless Steel
Trim
2
Handle
6
Child Safety Lock
3
Wooden Shelves
7
Kick Plate
4
Door Hinge
8
Adjustable Legs

8
INSTALLATION INSTRUCTIONS
Before using your wine / beverage coolers
−Remove the exterior and interior packing.
−Check to be sure you have all the following parts:
oShelves
o2 Keys
oStainless Steel Handle
oInstruction Manual
−Before connecting your new wine / beverage cooler to a power source, let it stand upright for approximately 12
hours. Thiswill reduce the possibility of a malfunction inthe cooling system from handling during transportation.
−Clean the interior surface with lukewarm water using a soft cloth.
−Install the handle on the left side of the door.
Installation of your wine / beverage cooler
−These wine / beverage coolers are designed to be used with free standing installation or built-in installation.
−Place your wine / beverage cooler on a floor that is strong enough to support it when it is fully loaded. To level
your wine cooler, you can adjust the front leveling legs at the bottom of your wine / beverage cooler.
−Place the wine cooler away from any direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct
sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Extreme cold
ambient temperatures may also cause the unit not to perform properly.
−Avoid installing / setting up the unit into moist or potentially moist areas.
−Plug the wine / beverage cooler into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power
and/or grounding should be directed toward a certified electrician or an authorized Products service center.
Electrical connection
Warning: Improper use of the grounded plugcan result inthe risk of electrical shock. If the power cord is damaged,
have it replaced by an authorized service center.
These wine & beverage coolers should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of
electrical shock.

9
Do not under any circumstances cut or remove the third ground prong from the power cord supplied. For personal
safety, this appliance must be properly grounded.
This appliance requires a standard 115V/60Hz electrical ground outlet with three-prong. Have the wall outlet and
circuit checked by a qualified electrician to make sure the outlet is properly grounded. When a standard 2-prong
wall outlet is encountered, it is your responsibility and obligation to have it replaced with a properly grounded
3-prong wall outlet. The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that
matches the rating label on the appliance. This provides the best performance and also prevent overloading house
wiring circuits that could cause a fire hazard from overheated. Never unplug the appliance by pulling the power
cord. Always grip the plug firmly and pull straight out from the receptacle. Repair or replace immediately all power
cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage
along its length or at either end. When moving the appliance, be careful not to damage the power cord.
Extension cord
Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an
extension cord with this appliance. However, if you must use an extension cord with this appliance, it must be
operated by professionals.
Power bar with surge protection
Most electrical appliances use a series of electric control boards to operate. These boards are very susceptible
to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone to power surges / outages; it is
suggested that you use apower surge protector for all electrical devices / appliances you use. The surge protector
that you select must have a surge block high enough to protect the appliance it is connected to. If you have any
questions regarding the type and size of surge protector needed contact a licensed electrician in your area.
Damages due to power surges are not considered a manufacturer covered defect and will void your product
warranty.

10
Installing the stainless-steel handle
Your wine / beverage cooler includes a stainless-steel handle. To install the handle please follow the below
instructions:
1. Pull away the door gasket in the area where the handle is to be installed on the left side as shown below in
Illustration # 1. The gasket is easily displaced by hand, no tools are necessary.
2. Align the handle with the screws installed. Tighten the screws using a Phillips head screwdriver until the
handle sets both flush and secured tightly against the door frame. (DO NOT over tighten as this will cause
damage to the handle assembly).
3. Replace the door gasket to its original position.
Illustration # 1 Illustration # 2
Field Code Changed
Field Code Changed

11
1
.
Gasket
3
.
Phillips Head Screwdriver
2
.
Phillips Head Screw
4
.
Handle
WARNING:
●If the applianceis power off suddenly. Pleaseturn on the appliance after 3-5 minutes later. The temperature
setting is with automatic memory function.
●If it is the first time you are using your wine cooler, it is normal that the pre-set temperature and display
temperatures are different.
CARE AND MAINTENANCE
Moving your wine / beverage cooler
-Remove all items (bottles)
-Tape down securely all loose items (shelves) inside your appliance.
-Turn the adjustable leg up to the base to avoid damage.
-Tape the door shut. Be sure the appliance stays secure in the upright position during transportation. If you
absolutely need to transport the chiller horizontally, transport the chiller on its back (door on top). Also protect
outside of appliance with a blanket, or similar item.
Energy saving tip
The wine cooler should be in the coolest area of the room, away from heat producing appliances, and out of the
direct sunlight
Cleaning your wine / beverage coolers

12
Turn off the power, unplug the appliance, and remove all items including shelves. Wash the inside surfaces with
warm water and a baking soda solution. The solution should be about 2 tablespoons of baking soda to 1 cup of
water.
Wash the shelves with a mild detergent solution. Wring excess water out of the sponge or cloth when cleaning
area of the controls, or any electrical parts.
Wash the outside cabinet with warm water and a mild liquid detergent. Rinse well and wipe dry with a clean, soft
cloth. Do not use steel wool or a steel brush on the stainless steel. These will scratch the stainless steel, allowing
contaminants into the metal composition, potentially causing rusting (depending on occurrence and scratch depth).
OPERATING YOUR WINE COOLER
It is recommended you install your wine / beverage cooler in a place where the ambient temperature is between
19ºC-24ºC (66ºF-75ºF), and humidity is under 60%. If the ambient temperature is above or below recommended
temperatures, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot
conditions may cause interior temperatures to fluctuate.
Recommended temperature settings
Wine conservation: 12°C-14ºC (53°F-57ºF)
Rose and sparkling wines: 5°C-8ºC (41°F-46ºF)
Dry/white wines: 9°C-12ºC (48°F-53ºF)
Red wines: 14°C-18ºC (59°F-65ºF)
*Temperature ºC may varies between < + 2 ºC
BIWC-120-2D(Each Compartment)/BIWC-100A,C/BIWC-150A,C/BIWC-408A ：

13
Temperature setting range：2-10℃ (35-50℉)/5-18℃ (41-65℉)
Turn on/off the blue interior lights
Adjusts the temperature in 1 degree increments or decrements
Press and hold for 3 seconds, Toggles the temperature display between Celsius and Fahrenheit
Press and hold for 3 seconds to turn on /off the appliance

14
BIWC-100B/BIWC-150B/BIWC-408B:
C
F
¡ã
¡ã
F/ C
Temperature setting range：Upper zone：5-13℃(40-55℉) Lower zone：13-18℃(55-65℉)
Turn on/off the interior light
F/ C
Toggles the temperature display between Celsius and Fahrenheit
Press to begin adjusting the temperature for upper or lower zone
Adjusts the temperature in 1 degree increments
Adjusts the temperature in 1 degree decrements
Press and hold for 3 seconds to turn on /off the appliance
BIWC-100B,D/BIWC-150B,D/BIWC-408B,D:
Temperature setting range：Upper zone：5-13℃ (40-55℉) Lower zone：13-18℃ (55-65℉)
Turn on/off the blue interior lights
Toggles the temperature display between Celsius and Fahrenheit
Press to begin adjusting the temperature for upper or lower zone
Adjusts the temperature in 1-degree increments

15
Adjusts the temperature in 1-degree decrements
Press and hold for 3 seconds to turn on / off the appliance
Storage
Many bottles may differ in size and dimensions. As such the actual number of bottles you may be able to store
may vary. The bottle capacity is based on standard Bordeaux bottles.
Door Lock
Your unit is provided with a lock and key. The keys are located inside the plastic bag that contain the Instruction
Manual. Insert the key into the lock and turn it counter clockwise to unlock the door. To lock the door, do the
reverse of the prior action, making sure the metal pin is engaged completely. Remove the key and place it in a
secure place for safekeeping.
Shelves
The racks of some of our wine and beverage cooler models are equipped with a telescopic runner assembly
(except for the bottom shelves, the BIWC-120-2D, and the BIWC-60A). This allows you can move the wooden
shelves in and out smoothly with little resistance, maximizing usage efficiency and the overall lifespan of your
product.
To prevent damaging the door gasket, please make sure to have the door(s) all the way open when pulling each
of the shelves out of the rail compartment. For easy access to the bottles, you must pull the shelves approximately
1/3 out of the rail compartment.
To remove the shelves out of the rail, pull each shelf approximately 1/3 out. Use a long flat screwdriver to press
down the right plastic notch as shown in Figure A and at the same time lift the left plastic notch as shown in Figure
B. Then proceed to pull out the shelf slowly.

16
●
To remove the shelves out of the CABINET without a telescopic runner, you can pull out the shelf
to the shelf holder position, then lift the shelf to remove the shelf. (See figure below)
To avoid the damage of door sealing, please open the door fully when you slide out the shelves.
●For your convenience of taking wine, you can pull out the shelf by 1/3. Our product is designed with
shelf holder to prevent the shelf pull over and fall off the cabinet.
Figure B
Figure A
Figure B
Figure A

17
Power failure
Most power failures are corrected within a few hours and should not affect the temperature of your appliance if
you minimize the number of times the door is opened. If the power is going to be off for a longer period, you need
to take the proper steps to protect your contents.
Moving your wine / beverage cooler
- Remove all items (bottles)
- Tape down securely all loose items (shelves) inside your appliance.
- Turn the adjustable leg up to the base to avoid damage.
- Tape the door shut.
- Be sure the appliance stays secure in the upright position during transportation. If you absolutely need to
transport the chiller horizontally, transport the chiller on its back (door on top). Also protect outside of
appliance with a blanket, or similar item.
Field Code Changed

18
Energy saving tip
Your wine / beverage cooler should be in the coolest area of the room, away from heat producing appliances and
out of any direct sunlight.
Charcoal filtration system
You could say that your wine is alive and breathes through the cork of its bottle. In order to consistently maintain
the wine’s quality, purity, and taste the corks must be stored at an ideal temperature with ambient conditions.
This allows the cork to maintain a maximum lifespan and preserve the finest of beverages inside.
To help accomplish this your cellar is equipped with an active charcoal filtration system to ensure air purity and
cooling efficiency. An odor & moisture free cabinet will offer optimal storage conditions for the best possible
future corkage. The filter assembly is located at the rear panel inside your cellar.
Keep in mind, this filter must be changed every 12 months.
1
Remove the bottles of wine stored on the shelves in
front of the filter.
Turn Left to remove filter.
2
Remove the shelves and set aside to be replaced
once you have changed the filter
3
Hold the filter and turn it at 45 degrees in the counter
clockwise direction and then pull it out.
4
Remove the existing filter and replace with a new
one.
5
Put the new filter into the hole and then turn the filter
at 45 degrees in clockwise direction.

19
Dual-zone temperature control system (Models BIWC-100B,D, BIWC-120-2D, BIWC-
150B,D, BIWC-408B,D)
Some of our wine cooler and beverage cooler models come equipped with a smart thermostat
dual-zone inner climate control system. This dual-zone temperature control system utilizes a
42 - 45 dB rated premium grade closed isobutane compressor unit, and each compartment is
separated by a centralized insulated divider wall. Within each compartment there are
individualized circulatory systems utilizing silent but efficient premium refrigeration fans to
quickly stabilize the temperature by keeping the air flow spread out evenly, while speeding up
and/or slowing temperature change. This allows each compartment to accurately maintain its
own individual climate to maximize the long-term storage of your wine and/or beverage types
with minimal to near-zero temperature fluctuations.
This dual-zone temperature control system also utilizes smart thermostats, which support a
memory retaining function within the system to store your most recent settings. In the event of
a power failure or accidental unplugging, the system will automatically set the temperature
settings back to the most recent settings chosen prior to the loss of power. Afterwards the
temperature control system will immediately begin to stabilize the individual climate zones of
each inner compartment until the desired settings have been met.
