Solplanet Ai-HB G2 Series User manual

Ai-HB 050A/ Ai-HB 075A/
Ai-HB 100A/Ai-HB 125A/
Ai-HB 150A / Ai-HB 175A /Ai-HB 200A
Quick Installation Guide
Ai-HB G2 Series Battery
Android iosiOS

The product is a battery system for residential and works with the solar hybrid invert-
ers. It is a high voltage Li-ion battery storage system that has its own control unit. It
can be operated in on-grid, o-grid and backup modes with all the compatible
inverters.
The product is suitable for indoor and outdoor use.
The product must only be operated with the inverters which are claimed by AISWEI.
The inverters must be compatible with this product.
The battery system must only be used as stationary equipment.
Alterations to the product are not allowed unless the written permission of AiSWEI is
achieved. Unauthorized alterations will void the guarantee and warranty claims.
AiSWEI will not be held liable for any damage caused by such illegal changes.
The product is not suitable for supplying life-sustaining medical devices. Please
ensure that no personal injury would lead due to the power outage of the battery
system.
The product must only be used in countries for which it is approved or released by
AISWEI and the grid operator.
Use this product only in accordance with the information provided in this documen-
tation and with the locally applicable standards and directives. Any other application
may cause personal injury or property damage.
The type label must remain permanently attached to the product.
This document does not replace any regional, state, provincial, federal or national
This quick installation guide does not replace the description in the user manual.
The contents of this guide may be updated or revised due to product development.
The information in this guide is subject to change without notice. The latest version
of this document and the manual for installation, commissioning, conguration and
decommissioning are to be found in PDF format at www.solplanet.net.
2.1 I
ntended use
SAFETY
2
GENERAL INFORMATION
1
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
1

2.2 Important safety instructions
The product has been designed and tested in accordance with international safety
requirements. As with all electrical or electronical devices, there are residual risks
despite careful construction. To prevent personal injury and property damage and to
ensure long term operation of the product, read this section carefully and observe all
safety information at all times.
DANGER
！
Danger to life due to high voltage of the battery！
When the battery system connected to the inverter, and the breaker is closed, the
batteries generate high DC voltage which is present in the DC cable and live compo-
nents.
• Do not touch non-insulated parts or cables.
• Do not touch the DC conductors.
• Do not touch any live components of the product.
• Do not open the product.
•All work on the product must only be carried out by qualied personnel who have
read and fully understood all safety information contained in this document.
•Disconnect the product from voltage sources and ensure it cannot be reconnect-
ed before working on the product.
• Wear suitable personal protective equipment for all work on the product.
•Make sure the circuit breaker is o before assembly.
laws, regulations or standards that apply to the installation, electrical safety and use
of the product.
WARNING
！
Danger to life due to electric shock from destruction of the measuring
device due to overvoltage！
Overvoltage can damage a measuring device and result in voltage being present in
the enclosure of the measuring device. Touching the live enclosure of the measuring
device results in death or lethal injuries due to electric shock.
• Only use measuring devices with a higher volatge range than the battery voltage.
2
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

NOTICE
Damage to the battery system due to electrostatic discharge
Internal components of the battery system can be irreparably damaged by electro-
static discharge.
• Ground yourself before touching any component.
NOTICE
Damage to BCU due to pollutants
The pollutants (e.g. sand, dust, moisture) can damage the BCU and impair its func-
tionality.
•Only open the BCU cover when the humidity is within the permitted range of the
product and the environment is free of dust and sand.
WARNING
！
Risk of injury due to weight of product！
Injuries may result if the product is lifted incorrectly or dropped while being trans-
ported or mounted.
•Transport and lift the product carefully. Take the weight of the product into
account.
•Qualied persons wear appropriate personal protective equipment.
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
3

2.3 Symbols on the label
Beware of a danger zone!
This symbol indicates that the product must be additionally grounded if additional
grounding or equipotential bonding is required at the installation site.
Beware of high voltage and operating current！
The product operates at high voltage and current. Work on the product must only be
carried out by skilled and authorized electricians.
Beware of explosion!
The battery is an electro chemical, and there is an explosion risk in extreme cases. Please
keep away of it when the danger occurs.
Beware of danger for children!
Keep the battery system away of the children.
Beware of danger with am!
Keep the battery system away of the open am or ignition sources.
CE marking
The product complies with the requirements of the applicable EU directives.
Certication mark
The product has been tested by TUV and got the quality certication mark.
RCM Mark
The product complies with the requirements of the applicable Australian standards.
The battery is recyclable
After the battery marked lifetime is use out, the battery can be recycled by the profes-
sional recycling organization and do not discard it.
WEEE designation
Do not dispose of the product together with the household waste but in accordance with
the disposal regulations for electronic waste applicable at the installation site.
Observe the documentation
Observe all documentation supplied with the product.
4
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

PARALLEL SYSTEM WIRING DIAGRAM
3
Ai-HB 050A/075A/100A/125A/150A/175A/200A
P+
P-
P+
P-
P+
P-
P- P+ COM
…
Terminal
resistor
12N
（1≤N≤4）
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
5

EU DECLARATION OF CONFORMITY
4
Within the scope of the EU directives:
-Electromagnetic compatibility directive 2014/30/EU
(L 96/79-106, March 29, 2014)(EMC)
-Low voltage directive 2014/35/EU (L 96/357-374, March 29, 2014)(LVD)
Restriction of the use of certain hazardous substances 2011/65/EU
(L 174/88, June 8, 2011) and 2015/863/EU (L 137/10, March 31,2015) (RoHS)
AISWEI New Energy Technology (Yangzhong) Co., Ltd. conrms herewith that the
products described in this document are in compliance with the fundamental
requirements and other relevant provisions of the above mentioned directives. The
entire EU Declaration of Conformity can be found at www.solplanet.net.
6
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

OVERVIEW
5
1
1LED指示灯 指示逆变器当前的工作状态
Object Description
3
2Battery Module
Battery control unit(BCU)
4
5
6
Base
SOC Light
Circuit Breaker
7
9
8
Link port in
Link port out
10
11
P-
P+
On/o
1
2
3
5
6
10
11
9
7
8
4
Grounding
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
7

SCOPE OF DELIVERY
6
6.1 BCU and Base Package
6.2 Battery Module Package
BCU and Base×1 Quick installation
guide×1
Positive cable and
negative cable×1 Hanger×2
M5X12 Screw×2 Terminal resistor×1
Battery Module×1 M5×25 Screw×2
M6×16
Hexagon screw ×1
M8×40 Expansion
Anchor Bolt×2
8
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

MOUNTING ENVIRONMENT
7
-20℃
+50℃
RH.+5%~+95% max.3000m
≥350mm
≥600mm
≥350mm
×××
√√√
10~20mm
IP65
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
9

DIMENSIONS
8
MOUNTING
9
Unit：mm
12
155
≥350mm ≥350mm ≥350mm ≥350mm
130
1250
55
540 390
M5
N.W: 15kg
10
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

(2≤N≤8）
90°
Φ8mm
50mm
M5
4N.m
…
1
2
N
N.W: 30.5kg
34
5 6
78
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
11

PROTECTIVE GROUNDING
10
1
2
M6
6N
· m
E
L=E+(2~3)mm L
M5
4N.m
M8
≥10mm²
copper wire
OK
3
4
5
910
12
11
12
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223

BATTERY CONNECTION
11
OK
P-
P+
OK
OR
12
34
55
QG0048_Ai-HB 050-200A_EN_540-300266-00_0223
13

Please contact our Service Department if you have any technical questions about our
products.
The following information is needed to provide necessary assistance:
——Battery model
——Battery control unit and module series number
——Fault code
——Installation location
EMEA
Service email: [e-mail]
APAC
Service email: [e-mail]
LATAM
Service email: service.LAT[email protected]
Aiswei Greater China
Service email: [e-mail]
Hotline: [phone]
Taiwan
Service email: [e-mail]
Hotline: [phone]
https://solplanet.net/contact-us
CONTACT
12
iOS
Scan QR code:
Android
Scan QR code:
