SimpliPhi LITTLE GENNY User manual

www.simpliphipower.com • [e-mail]
OPERATOR’S MANUAL
LITTLE GENNY

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 1
TABLE OF CONTENTS
1. IMPORTANT SAFETY INFORMATION 2
Safety Instructions 2
Warnings, Cautions and Notes 2
Charging Cautions 2
Warning: Inverter Output 2
Caution: Inverter Operating Environment 2
Appliance Cautions 3
2. PRODUCT DESCRIPTION 4
Overview 4
The Little Genny Includes: 4
Knowing Your Power Requirement 5
Knowing Your Energy Requirement 5
Product Details: The Little Genny’s Power Inverter 6
3. OPERATION 7
AC Outlets’ Operation 7
USB Outlet Operation 7
Charging using the Little Genny’s Plug-In AC Charger 7
Charging using the Little Genny Emergency Power Kit’s Portable Solar Module 8
4. SPECIFICATIONS 9
5. TROUBLESHOOTING 10

LITTLE GENNEY EK OPERATING GUIDE | 2
www.simpliphipower.com • [e-mail]
1. IMPORTANT SAFETY INFORMATION
Safety Instructions
Before using the Little Genny or Little Genny Emergency Power Kit (“Little Genny EK”), read this manual
thoroughly. This manual contains information needed to achieve Little Genny product performance for
your application. Keep this manual for future reference.
Warnings, Cautions and Notes
Any operator of the inverter included in the Little Genny must read and follow all WARNINGS,
CAUTIONS and NOTES,as well as all operation instructions. Comply with WARNINGS (possibility of
serious injury or death), CAUTIONS (possibility of damage to the inverter and / or other equipment), and
NOTES (included to assist you in achieving the maximum performance and longest working life from this
advanced-design power supply).
Charging Cautions
The Little Genny may be on or off to fully charge. Recharging must be done with an approved 12 VDC
charger or with the special solar panel only thru the small barrel connector. A 12 VDC car accessory
outlet may also be used with an optional cable (the car must be running).
Always keep the battery charged as much as possible. Frequent charging does not harm the unit
and will help the performance. The LED on the Little Genny may flash a few times when plugging the
charger in or out. It flashes green continuously when charging is completed by the charger or solar panel.
When disconnected from charger, the LED will return to solid green.
Warning: Inverter Output
•The Little Genny includes an inverter device that produces voltages similar to commercial AC
power. Danger of shock or electrocution: Treat the inverter’s output the same as commercial AC
power.
•Do not use the Little Genny near flammable materials or in any locations that may accumulate
flammable fumes or gases.
•Do not allow water or other liquids into contact with the inverter.
•Do not use the Little Genny with appliances with damaged or wet cords.
•Do not connect devices or appliances to the Little Genny that exceed a draw of 300 Watts. All
outlets can be used simultaneously, provided that the combined draw is no more than 300 W.
Caution: Inverter Operating Environment
1. Keep the inverter away from direct sunlight, if possible.
•Do not expose the inverter to temperatures greater than 60°C (140°F) for extended periods of
time.
•Keep the area surrounding the inverter clear to ensure free air circulation around the unit. Do not
place items on or over the inverter during operation. The unit will shut down if the internal
temperature gets too hot. Restart the inverter after it cools.
•Do not use the Little Genny in or near flammable fumes or gases, as ignition may result in
explosion or fire.

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 3
Appliance Cautions
1. Do NOT plug in battery chargers for cordless power tools if the charger carries a warning that
dangerous voltages are present at the battery terminals.
•Route connected appliance cords and extension cords to prevent accidental pinching, crushing,
abrading and tripping people.
•The inverter included in the Little Genny is not tested for use with medical equipment.
•The inverter included in the Little Genny is not tested for use in marine applications.
•In the event of a continuous audible alarm or automatic shutdown, turn the inverter OFF
immediately. Do not restart the inverter until the source of the problem has been identified and
corrected (refer to Section 5. Troubleshooting).

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 4
2. PRODUCT DESCRIPTION
Overview
The Little Genny or Little Genny Emergency Power Kit (“Little Genny EK”) is a portable rechargeable
generator that converts low voltage direct current (DC power) to 115-volt Pure Sine Wave alternating
current (AC power). The Little Genny stores electricity from any power source (e.g. grid, solar, wind, or
car) in its 12-Volt DC Lithium Ferro Phosphate (LFP) batteries, and uses that stored energy to power
lighting, electronics, and other devices when normal AC grid power in not available, such as in the cases
of power outages, emergencies, or field work. The Little Genny Emergency Power Kit includes additional
PV charging from a portable solar module.
The Little Genny Includes (portable PV solar module with Emergency Power Kit only):
(x2) 115-Volt Pure
Sine AC Outlets
(x2) USB Outlets
for 5 VDC
Solar panel with
connector (with
Emergency Power
Kit ONLY
AC plug-in battery
charger with connector
(not shown)
Accessory option
(not included with regular purchase)
12V cable for battery recharging
using car or other source
*Phone and laptop included in the photo above are for demonstrative purposes only;
neither appliance is included with the Little Genny
2.55 mm barrel
connector port

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 5
Knowing Your Power Requirement
The loads connected to the Little Genny should have a combined power draw that does not exceed the
inverter’s 300-Watt continuous power rating / 700-Watt surge power rating. Prior to connecting an
appliance to the Little Genny, determine how much power your appliance requires to run (“continuous
load”) and to start up (“starting load” or “peak load”).
Power consumption is rated in Watts, or it can be calculated from Amperes (Amps). This information is
usually stamped or printed on most appliances and equipment. If this information is not indicated on the
appliance or equipment that you wish to connect to the Little Genny, check the appliance’s manual for its
power ratings.
Calculate power consumption (Watts) by multiplying the appliance’s AC Amperage rating by its AC
Voltage rating:
AC Amps x 120 Volts = AC Watts
This formula yields a close approximation of the continuous load of your appliance.
When a motorized appliance or a tool turns on, there is an initial surge of power to start. This surge of
power is referred to as the “starting load” or “peak load.” Once started, the tool or appliance requires less
power to operate (referred to as the “continuous load”).
Calculate the appliance’s starting load by multiplying the appliance’s continuous load draw by two:
AC WattsContinuous x 2 = AC WattsStarting
This formula yields a close approximation of the starting load of most appliances. To ensure that the Little
Genny is capable of powering the appliance at hand, check the appliance’s manual for its Starting Watts
rating.
Knowing Your Energy Requirement
The amount of energy consumed by loads connected to the Little Genny is equal to the loads’ power
draw multiplied by the loads’ runtime:
Power Draw (Watts) x Runtime (hours) = Energy Draw (Watt-hours)
The batteries included in the Little Genny have a rated capacity of 322 total Watt-hours DC / ~257.6 Watt-
hours AC (assuming an inverter efficiency of 80%). Connected loads consuming more energy than
~257.6 Watt-hours will result in low battery voltage and inverter shutdown. See Table 1 below for
expected runtimes for various loads.
Table 1 –Little Genny’s Approximate Potential Load Runtimes
Load Draw (Watts)
Approximate Runtime (hours, minutes)
300 W
51 minutes
250 W
1 hour, 1 minute
200 W
1 hour, 17 minutes
150 W
1 hour, 43 minutes
100 W
2 hours, 34 minutes
50 W
5 hours, 9 minutes
*Runtime may vary depending on the Little Genny battery’s starting State of Charge, the type of
connected appliance (AC or DC), and the operating efficiency of the Little Genny’s inverter while the
loads are connected.

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 6
Product Details: The Little Genny’s Power Inverter
•AC Power Switch: This switch controls AC output of the inverter.
•US Sockets: These two outlets can supply up to 2.6 Amps combined at 115V AC / 60 Hz.
•USB Charging Ports: These power ports can supply 5 Volts DC at 2.4 Amps for charging or
powering tablets, e-readers, smart phones and other small electronic devices. The USB outlets
on the inverter are always on. The LED light on the Little Genny’s inverter indicates how full the
battery is. A green LED light represents a State of Charge of 50% or greater. A yellow LED light
means that the battery’s voltage is low, red is very low, and flashing red will appear just before
the unit turns off.
•LED Power Indicator:
oGreen light indicates the inverter is working normally.
oRed light indicates the inverter shut down due to overheating, overload, over voltage,
low voltage, or another fault condition.
▪Immediately turn off all connected AC appliances if the red FAULT LED is lit.
Allow the inverter to cool before resuming normal operation. Make sure that the
ventilation vents are not blocked.
•Cooling Fan: The cooling fan runs in the case of normal inverter operation.

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 7
3. OPERATION
Charge the Little Genny fully before first-time use. Refer to either the Charging using the Little Genny’s
Plug-In AC Charger section below or the Charging using the Little Genny Emergency Power Kit’s
Portable Solar Module section on the following page for further instruction.
AC Outlets’ Operation
Connecting Loads:
1. After confirming that the appliance you plan on connecting to the Little Genny is turned off, plug
the appliance cord into one of the two AC outlets on the front panel of the Little Genny’s inverter.
2. Turn ON the inverter. Verify that the green LED is lit.
3. Turn the appliance on.
4. Plug in additional appliances and turn them on.
Note: If an extension cord is used from the inverter to the appliance, limit the extension cord length to 25
feet or less. Make sure that the cord is safety approved and rated at 14 AWG or greater to carry the
appliance load. Remember that extension cords are intended for temporary use.
Disconnecting Loads:
1. Turn off the connected appliance.
2. Turn OFF the inverter.
3. Unplug the appliance from the Little Genny.
USB Outlet Operation
1. Plug the USB cable into the USB outlet located on the front panel of the Little Genny’s
inverter, then into the device to be charged. Ensure that the device is charging.
2. The inverter does not have to be ON to charge devices using the USB outlet.
3. After the device is finished charging, unplug the USB cable from inverter.
Charging using the Little Genny’s Plug-In AC Charger
1. Connect the charger to the Little Genny via the 2.5 mm barrel connector.
2. Plug the AC charger into an AC wall outlet or AC power source.
Never plug the AC charger into the Little Genny inverter’s socket.
3. The charger will automatically turn on after qualifying the battery. At this point, the
charger’s LED should be lit red.
4. When the charger’s LED changes to solid green, charging is complete and the charger
should be disconnected.
5. To disconnect the AC charger, unplug the charger from the AC power source, then
disconnect the charger from the Little Genny via the 2.5 mm barrel connector.
•Keep the Little Genny fully charged whenever possible for best performance.
Note: Charging can stop at any time, even if the Little Genny’s battery has only been partially
charged. No battery memory will develop.

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 8
Charging using the Little Genny Emergency Power Kit’s Portable Solar Module
The portable solar module is included with Little Genny EK models only; the solar module is not
included with regular Little Genny models.
1. Ensure that the portable solar module is closed, so that the panels are not exposed to
sunlight.
2. Connect the portable solar module to the Little Genny EK using the 2.5 mm barrel
connector.
3. Open the portable solar module and orient it to fully face the sun.
4. The red light inside the pocket of the solar panel case shows that the solar panel is
working.
5. When the LED is lit solid green, a full battery charge has been reached.
6. After the battery is charged, the portable solar panel can be disconnected by closing the
solar panel and disconnecting from the Little Genny EK via the 2.5 mm barrel connector.
•The Little Genny EK can be used to power devices / appliances while the solar module is
connected. However, the Little Genny EK’s inverter would ideally be turned off while solar
charging for quicker and more efficient battery charging.
Charging a fully discharged unit (indicated by a red LED) via solar should take about three and a half to
four hours with full sun.
Charging a partially discharged unit (indicated by a yellow LED) via solar should take about two to two
and a half hours with full sun.

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 9
4. SPECIFICATIONS
Little Genny and Little Genny Emergency Kit (EK)
Dimensions
13” L x 11”W x 7”H / 33 cm L x 28 cm W x 18 cm H
Weight
12 lbs. / 5 kg
Charger Connection
2.5 mm Barrel Connector (for AC plug-in charger or solar panel)
Little Genny and Little Genny EK’s Battery
DC Voltage - Nominal
12.8 Volts DC
Amp-Hours
25 Ah
Rated Watt-Hour Capacity
322 Watt-hours DC
Operating Temperature
-4°F to 140°F (-20°C to 60°C)
Charging Temperature
32°F to 120°F (0°C to 49°C)
Battery Chemistry
Lithium Ferro Phosphate (LFP)
Memory Effect
None
Charge Retention
< 1% loss per month
Charge Cycles
2,500 cycles
Charging Requirements
14.65 VDC / up to 8 Amps DC
Cell Certifications
ROHS, UL, CE, UN-DOT
Little Genny and Little Genny EK’s Inverter
Continuous Output Rating
300 Watts (2.6 Amps @ 115 VAC)
Surge Capacity (Peak Power Rating)
700 Watts (6 Amps @ 115 VAC)
AC Output Rating
115 Pure Sine Volts AC
Frequency Rating
60Hz
Output Wave Form
Pure Sine Wave
DC Input Rating
12 Volts DC
Input Voltage Range
11 to 15 Volts DC
Low Battery Shutdown
10 to 11 Volts DC
Over Voltage Shutdown
15 to 16 Volts DC
USB Output Rating
5 Volts DC MAX / 2.4 Amps DC
AC Output Sockets
2 x North American Standard Outlets
Operating / Storage Humidity RH
5 to 95%
Little Genny EK’s Solar Module (not included with regular Little Genny models)
Peak Output
80 Watts / 4.44 Amps at 18 VDC
Solar Input
12 to 18 VDC, up to 15A
Folded Dimensions
22” L x 20” W x 0.4” D
Opened Dimensions
22” L x 40” W x 0.2” D
Net Weight
4.8 lbs. / 2.2 kg

805-640-6700 •[e-mail]
© SimpliPhi Power, Inc. REV072319
LITTLE GENNY OPERATOR’S MANUAL | 10
5. TROUBLESHOOTING
Problem
Possible Cause
Solution
The inverter’s power
switch is on, the LED is lit
red and the cooling fan
does not run. No loads
are connected.
There may be a short circuit inside the
inverter. The red LED might indicate
that the inverter is in a state of
overcurrent protection.
Consult SimpliPhi regarding potential Little
Genny repair.
The battery input voltage may be
insufficient or too high.
Charge the battery.
The inverter’s power
switch is on, the LED’s
green color becomes dim
or turns red, and the
cooling fan does not run.
Connected devices’ / appliances’
power draw exceeds the inverter’s
power rating.
Disconnect the connected loads from the
inverter. Do not use the devices /
appliances that caused the inverter fault
with this inverter; use a higher Wattage-
rated inverter instead.
