SOLUXTEC PowerSlate Framed Mono Dark Blue Series User manual

USER MANUAL
PowerSlate Framed Mono Serie Dark Blue ™
Version 1.1 2010

SOLUXTEC GmbH
Page 2 of 10
Index of contents
1. Introduction 3
2. Basic safety instructions 4
3. Transport and storage 5
4. Installation options 6
5. Instructions for mounting 12
6. Maintenance and cleaning 13

SOLUXTEC GmbH
Page 3 of 10
1. Introduction
This User Manual refers to the installation, wiring, handling, maintenance and general
administration of our PV-modules. Please read this Manual accurately and completely before
configuration and installation of the PV-plant. All advices given in this document are to be
handled by a qualified person, who has due to his professional qualification the necessary
technical know-how. Attention should also be paid to the live threatening risk, which may
occur because of the tension in conjunction with a grid-feeding PV-plant. In case of an
improper installation of the module there is a danger of fire risk.
This User Manual refers to the on-roof mounting, on flat-roof bracing and on shore
installations with or without tracker.
In case of divergence towards this user manual SOLUXTEC GmbH does not incur liability for
personal damages or property damages, which arise because of improper utilization,
maintenance or incorrect assembly of the photovoltaic module. SOLUXTEC GmbH
furthermore does not provide warranty for utilisability and functional capability of the
laminates in that case of divergence towards the in this user manual given advices.
Notice :
All details given in this document are corresponding to the technical condition on creation
date.
Subject to modifications and amendments.

SOLUXTEC GmbH
Page 4 of 10
2. Basic safety instructions
Risk of death by electric shock! Solar modules create electricity and are
even energized under a slight illumination level. A series connection of modules leads
to an accumulation of voltage. A parallel connection addition leads to an
accumulation of current. The wiring of several modules to a generator control panel is
only to be handled by authorized specialized staff.
The network plug of the photovoltaic-panel has to be handled by a franchised certified
electrician.
During the assembly and handling of the photovoltaic-plant, all local legal norms,
technical building regulations and accident safety regulations, especially concerning
activity on the roof have to be kept.
The safety instructions of all plant components as well as all regulations of the
respective energy provider to the grid feeding operation of the PV-plant are to be
considered.
Also during low temperatures the maximum admissible Open circuit voltage of the
modules must not be exceeded.
Never open the junction box of the photovoltaic module.
Only use inspected safety equipment and tools for the installation.
Risk of death by electric arc! The solar modules have to be disconnected
through DC switch before the beginning of any operation on any current-carrying
party of the photovoltaic-plant.
Do never disconnect the solar power generator from the inverter or the assembly of
the solar modules under load current. First turn off the DC switch.
Please protect the panel, plug and jack against damage or dirt contamination.
Do not establish a connection with dirty or wet plugs or jacks.
The tools that you use for the installation have to be dry.
Examine all tools for damage before the installation.
Do never introduce conductive parts in the connection box and joining pieces and
never try to touch the plugs on the inside.
Do not modify or decompose the solar panel. And do not remove any from the
manufacturer attached notices or type plates.
Avoid any contact of the PV-element with metal parts.
Pay attention to all warning notices and safety indication that are attached to the
panel.
The realized PV generator must not be perpetrated.

SOLUXTEC GmbH
Page 5 of 10
3. Transport and stockage
During transport and interim storage the following point are to be observed:
The handling with the modules should always been handled with due care.
Any operation of the photovoltaic panel is to be made with clean and soft protective
gloves.
The modules are very shock-sensitive. During transport, charging and discharging,
store temporarily and disassembling and laying of the PV-elements therefore you
have to be extremely carefully with the handling. Never lay down the solar panels
rough or on the corners and use a correspondingly soft surface. Enter the modules
with both hands. Do not drop the modules.
Never use the junction box as a handle bar.
Pay attention on the low deflection.
For component storage use a dry, ventilated room.
Do not accumulate the photovoltaic panels.
Do not use the photovoltaic panels as a support.
Keep all parts clean, which may come in contact with the PV-element.
The modules are rated for practice in application class A: Dangerous voltage (IEC
61730: greater then 50Vdc; EN 61370: greater then 120Vdc); machines with
dangerous performance, where you can expect an absolute accessibility (Modules,
that are in this application class according to EN IEC 61730-1 and -2 qualified, you
can assume that they fulfill safety class II)

SOLUXTEC GmbH
Page 6 of 10
4. Installation options
Installation of a Photovoltaic Module
The solar modules can be installed vertically and horizontally. For installation you have to
use a suitable mounting rack. SOLUXTEC approves the application of the mounting rack and
the clamp from Schletter GmbH. The mounting system belongs to the Schletter Standart
Serie, the exactly type designification of the rails are ,,Module Bearing Profile Solo 05‘‘ and
those of the clamps is ,,Middelclamp or Endclamp mm or Rapid 2+ Clamp‘‘. The fixing has to
be effected on 4 points on the long side of the module. The only exception which allows a
mounting on the short sides is the use with a tank elevation support for flat roofs. In this case
a fixing on the narrow sides of the module is allowed. To assess an ideal brick course, it is
necessary to calibrate the generator control panel on roof before beginning of the installation.
In doing so the rail system should be justified absolutely equal, otherwise it will come to
bracing of the module and thereby it can lead to a breakage in the module. Inside the PV-
plant use middle-clamps. At the borders of the PV-plant use end-clamps.
The substructure and the material for the fixing of the module have to be layed out and
installed, so that they resist to local burden like wind and weather.
During clamping of the modules a minimum distance of 20% and a maximum distance from
25% of the long side to the narrow side is to be adhered. Both alternate clamps have to
occur to the same edge distance vertically to the long side of the module.
Fig.: 1 landscape mounting This mounting is only suited for tank
elevation support for flat roofs
Fig.: 2 portrait mounting

SOLUXTEC GmbH
Page 7 of 10
Further advices for installation:
Pay attention to contact corrosion due to different fastening material.
Environmental condition and asset location
The modules are intended for application in temperate zones. To avoid damaging of the
module by corrosion, a minimum distance of 500m to the bordering of sea is suggested. It’s
not allowed to make an installation in locations with an abnormally high chemical loading,
e.g. pollution by industrial enterprises. The solar modules are not supposed to be exposed by
concentrated light e.g. by mirrors bundled sunlight. The module must neither be plunged nor
come in touch with a constantly water inflow like a fountain.
Alignment and falling gradient
The ideal arrangement of the photovoltaic module may vary according to the location. The
module surface should stay vertically to the sun to get the best possible earnings.
In addition you should pay attention on the following points:
The collector slope of the module should be at least 10°, based on the rain-
conditioned self-purification.
Please avoid a partial or completely shading of the module.
All module connected together in series should have the same slope in order to
prevent losses in gain.
Wiring
A series connection can only be effected if all modules have the same current rating.
In doing so attention should be paid to the tension of the module in series, the
maximum tension must not exceed 1000V.
For the parallel connection only modules with the same tension are to be used. If
three or more strings per MPP-Tracker of the inverter are interconnected in parallel,
you have to revert to a stringbox. The reverse current load capacity of the panel is
12A. Accordingly the string-box hast o be equipped with stirng-fuses with a maximum
of 12A.
Transformerless inverters are generally adapted.
Maximum amount of generator surface
During the planning and the dimensioning of a PV-generator surface you have to take the
permitted maximum amount of 2400 Pa (Suction) and 2400 Pa (compression) into account.
On installation site all respective snow and wind loads have to be considered and respected.
In case of doubt please consult a stress analyst or rather an expert.

SOLUXTEC GmbH
Page 8 of 10
Grounding and substructure
The grounding has to be effected at the metallic substructure. In general the installer has to
ground the rails accordingly. The grounding has to be performed with a self-locking screw. All
metallic parts of the substructure including module frames have to be connected to the main
equipotential bonding of the building. The use of a cable of 10mm² is recommended for this
task. The grounding has to be performed with a section of cable of 16mm² to the main
equipotential bonding. If a lightning protection already exists or is planned the PV-plant has
to be integrated in this concept. In doing so all related engineer standards have to be
respected.
In Europe the technical standard IEC 60364-7-712 has to be respected.
Advice for fire protection
The PV-modules are not explosion-proofed electric elements and must not be installed on
explosive environment. Furthermore the installation cannot be effected near flames or on
inflammable materials. The PV-modules must not be installed on inflammable roofs.
Further notice for wiring
During the development of the PV-plant a small cable loop has to be realized in order to
reduce the impact of an electro-magnetic induction in case of lightning. The surface covered
by the wiring has to be kept as small as possible.
Example of a bad wiring Example of a good wiring
For the wiring the use of a solar-single-wire cable which resists against Ozone, Weather &
UV is required. The wire should also be free of halogen and should possess a double
insulation. During the wiring please pay attention to the advices given from the cable
manufacturer!

SOLUXTEC GmbH
Page 9 of 10
Further Installation Options:
It is not allowed to install the laminates in a roof-overhanging situation.
To assure an ideal operation of the PV-generator you have to mind a sufficient
ventilation of the module.
During operation of the PV-plant it could be that the given technical values of tension
and current are in real higher than calculated before under STC. In order to prevent a
possible disproportion between theoretical and real values it is recommends to add a
security margin of 1,25 on all technical values including cable cross section, inverter
power etc.
It has to be taken into consideration that the load of the PV-plant into the grid is
balanced on all three phases of the public power grid. All technical standards for grid-
feeding inverters have to be respected. In every case during development the
technical data-sheet of the inverter has to be taken into account.
All inverters have to respect the national and local grid-feeding standards including
EMC regulations.
It is requested to install on DC side a switch, which interrupts both poles of a string at
the same time. The switch has to make sure the galvanic separation.

SOLUXTEC GmbH
Page 10 of 10
5. Instruction for installation
The following reference notes are to be adhered during the installation on location:
During work on roof all accident prevention regulations have to be respected. It is
recommended to protect all uninvolved people nearby. A scaffold should be installed
during work.
During installation make sure not to strain the modules.
If lengthening of string wiring is necessary the polarity has to be respected.
The modules have to be mounted in a way which prevents rain water penetrating into
the plugs.
6. Maintenance and cleaning :
In general it is not necessary to clean the modules if the inclination is >10°. In case of
persistent dirt use only classic glass cleaner or cleaning alcohol. Do not use galling or
chemical cleaners, do not scrape the module.
All modules are maintenance free, but it could be useful to verify the PV-installation regularly
against following criteria’s:
Integrity of the cables
Safety purchase of all fixings
Cleanness, free of corrosion and safety connection of all cables connections
Industriestrasse 28 |B-4700 EUPEN
T+32 (0)87 59 16 50 |F+32 (0)87 59 16 55
E-mail: [email protected] |Internet: www.accubel.be
