Solwise WL-STATION-N5 User manual

1
5GHz 802.11a/n Outdoor AP/CPE
User Guide

2
INTRODUCTION...............................................................................................................3
HARDWARE DESCRIPTION.....................................................................................3
HARDWARE INSTALLATION.....................................................................................4
INITIAL CONFIGURATION.................................................................................................6
CONNECTING TO THE LOGIN PAGE.........................................................................6
STATUS PAGE ................................................................................................................6
EASY SETUP...................................................................................................................7
OPERATION MODE –APROUTER.........................................................................7
SETTINGS –PPPoE(ADSL).........................................................................8
SETTINGS –STATIC (FIXED IP).....................................................................9
SETTINGS –CABLE/DYNAMIC IP (DHCP) ..................................................10
SETTINGS –PPTP /L2TP..........................................................................11
SETTINGS –IPSEC ......................................................................................13
OPERATION MODE –APBRIDGE ........................................................................15
OPERATION MODE –CLIENT ROUTER ................................................................15
OPERATION MODE –CLIENT BRIDGE..................................................................17
ADVANCED SETUP .......................................................................................................20
MANAGEMENT ..............................................................................................21
ADVANCED SETTINGS..................................................................................23
OPERATION MODE .......................................................................................25
FIREWALL CONFIGURATION .................................................................................25
MAC/IP/PORT FILTERING ...........................................................................25
VIRTUAL SERVER SETTINGS........................................................................27
DMZ.............................................................................................................28
FIREWALL .....................................................................................................28
QoS..............................................................................................................29
CONTENT FILTERING....................................................................................30
NETWORK SETTINGS............................................................................................31
WAN............................................................................................................31
LAN..............................................................................................................35
VLAN...........................................................................................................35
DHCP STATIC LEASE LIST ........................................................................36
ADVANCED ROUTING ...................................................................................36
WIRELESS SETTINGS...........................................................................................38
BASIC............................................................................................................38
SECURITY.....................................................................................................39
ADVANCED ...................................................................................................44
ACCESS CONTROL .......................................................................................46

3
INTRODUCTION
The OUTDOOR AP/CPE is a 2x2 MIMO IEEE 802.11a/n wireless outdoor AP/CPE
which support data rates up to 300Mbps. It is rain and splash proof when install in
upright position. OUTDOOR AP/CPE available with integrated 14dBi patch antenna
or two RSMA connectors for external antenna. Also uses passive PoE for simplify
installation.
HARDWARE DESCRIPTION
Below are OUTDOOR AP/CPE hardware descriptions
①
②
③
①PoE LAN
②PoE WAN (in Rouer mode )
PoE LAN (in Bridge Mode)
③Reset
L-Mount (Option)
Pole Mount Holders
Wall Mount Hole
Wall Mount Hole
LED Indicator

4
HARDWARE INSTALLATION
◆How to open the sliding door
Unlatch the weatherproof
sliding door from the rear of
the base to open.
Slide the weatherproof sliding
door downwards by griping
onto the indented surface of
the weatherproof sliding door
and the rear.
Align the base with the
weatherproof sliding door.
Slide the weatherproof
sliding door upwards until it
clicks into place.
◆How to close the sliding door
◆How to tie the strap on the pole

5
◆Mounting and Radio forward Diagram
Standard Pole Mount
*Option Adjust Antenna L- Mount
*Option Wall Mount

6
INITIAL CONFIGURATION
The outdoor 5GHz AP/CPE offers a user-friendly web-based management interface
for the configuration of all the unit’s features. Any PC directly attached to the unit
can access the management interface using a web browser, such as Internet
Explorer (version 6.0 or above).
CONNECTING TO THE LOGIN PAGE
It is recommended to make initial configuration changes by connecting a PC directly
to the OUTDOOR AP/CPE’s LAN port. The OUTDOOR AP/CPE has a default IP address
of 192.168.2.1 and a subnet mask of 255.255.255.0. You must set your PC IP
address to be on the same subnet as the OUTDOOR AP/CPE (that is, the PC and
OUTDOOR AP/CPE addresses must both start 192.168.2.x). To access the
OUTDOOR AP/CPE’s management GUI interface, follow these steps:
1. Use your web browser to connect to the management interface using the default
IP address of 192.168.2.1.
2. Log into the interface by entering the default username “admin” and password
“admin,” then click OK.
STATUS PAGE
After logging in to the web interface, the Status page displays. The Home page
top-menu-bar shows the Status, Easy Setup, Advanced and Language.

7
EASY SETUP
The Easy Setup is designed to help you to configure the basic settings required to
get the OUTDOOR AP/CPE up and running. There are only a few basic steps you
need to set up the OUTDOOR AP/CPE to get the connection.
Click on Easy Setup to bring up the wizard
OPERATION MODE –AP ROUTER
In AP Router mode, your OUTDOOR AP/CPE unit is turned to a wireless router and
wireless interface will become the LAN side; if your PC is connected to the PoE port,
the management IP will change to the LAN IP (192.168.2.1). The remote
management will be automatically turned on to allow you managing the device from
the PoE LAN port.

8
SETTINGS –PPPoE(ADSL)
1) Select PPPoE to be assigned automatically from an Internet service provider (ISP)
through a DSL modem using Point-to-Point Protocol over Ethernet (PPPoE).
2)
◆User Name —Sets the PPPoE user name for the WAN port.
◆Password —Sets a PPPoE password for the WAN port.
◆Verify Password —Prompts you to re-enter your chosen password.
◆Operation Mode —Enables and configures the keep alive time and configures the
on-demand idle time.
3)
Security Setup

9
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
SETTINGS –STATIC (FIXED IP)
1) Select Static (Fixed IP), if your Internet service provider (ISP) to be permanent
address on the Internet. A Static IP address is a number (in the form of a dotted
quad)
2)
◆IP Address —Sets the static IP address.
◆Subnet Mask —Sets the static IP subnet mask. (Default: 255.255.255.0)
◆Default Gateway —The IP address of a router that is used when the requested
destination IP address is not on the local subnet.
◆Primary DNS Server —The IP address of the Primary Domain Name Server. A DNS
maps numerical IP addresses to domain names and can be used to identify network
hosts by familiar names instead of the IP addresses. To specify a DNS server, type
the IP addresses in the text field provided. Otherwise, leave the text field blank.
◆Secondary DNS Server —The IP address of the Secondary Domain Name Server.

10
3)
Security Setup
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
SETTINGS –CABLE/DYNAMIC IP (DHCP)
1) Select Cable/Dynamic IP (DHCP), if your Internet service provider (ISP) use a
DHCP service to assign your Router an IP address when connecting to the
Internet.
2)
The host name that you selected from the DHCP service provider.
3)

11
Security Setup
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
SETTINGS –PPTP /L2TP
1) Select PPTP, if you are using PPTP service to gain connection to the Internet.
2)
◆Server IP —Sets the PPTP server IP Address. (Default: pptp_server)
◆User Name —Sets the PPTP user name for the WAN port.
◆Password —Sets a PPTP password for the WAN port.
◆Address Mode —Sets a PPTP network mode. (Default: Dynamic IP)
◆Operation Mode —Enables and configures the keep alive time.
◆Primary DNS Server —The IP address of the Primary Domain Name Server. A

12
DNS maps numerical IP addresses to domain names and can be used to identify
network hosts by familiar names instead of the IP addresses. To specify a DNS
server, type the IP addresses in the text field provided. Otherwise, leave the text
field blank.
◆Secondary DNS Server —The IP address of the Secondary Domain
Name Server.
3)
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
SETTINGS –L2TP
1) Select L2TP, if you are using PPTP service to gain connection to the Internet.
2)

13
◆Server IP —Sets the L2TP server IP Address. (Default: l2tp_server)
◆User Name —Sets the L2TP user name for the WAN port.
◆Password —Sets a L2TP password for the WAN port.
◆Address Mode —Sets a L2TP network mode. (Default: Dynamic IP)
◆Operation Mode —Enables and configures the keep alive time.
◆Primary DNS Server —The IP address of the Primary Domain Name Server. A DNS
maps numerical IP addresses to domain names and can be used to identify network
hosts by familiar names instead of the IP addresses. To specify a DNS server, type
the IP addresses in the text field provided. Otherwise, leave the text field blank.
◆Secondary DNS Server —The IP address of the Secondary Domain Name Server.
3)
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
SETTINGS –IPSEC
1) Select IPSec, if you are using IPSec service to gain connection to the Internet.
2)

14
Verify the desire settings and use scroll down for more options.
◆IPSec Connection Type –Use drop down menu to select from Road Warrior
Tunnel, Host to Host Tunnel, Subnet to Subnet Tunnel, Host to Host Transport,
Pass trough, Drop, or Reject. Default setting is Road Warrior Tunnel
◆IPSec Authentication –Use drop down menu to select from SHA-1, or MD5.
◆SA Connection Life Time –Specify how often each SA should be rekeyed,
measured in hour.
◆Local IP address / Subnet / Gateway –Local end point IP address, Subnet, and
Gateway IP address.
◆IPSec Operation Mode –Use drop down menu to select from Add, Route Start,
Manual, or Ignore.
◆IKE Key Retry –Specify maximum retry limits for negotiate key to Internet Key
Exchange.
◆Peer IP address / Subnet / Gateway –Remote end point IP address, Subnet, and
Gateway IP address.
3)
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, WEP-AUTO, WPA-PSK, WPA2-PSK, WPA-Auto-PSK,

15
WPA, WPA2, WPA-Auto, 802.1X; Default: Disabled)
OPERATION MODE –AP BRIDGE
1) In this mode bridge your OUTDOOR AP/CPE to another Access Point.
2)
Network Name (SSID) —SSID (Service Set Identification) must be assigned to all
wireless devices in your network. Considering your wireless network security.
Security Mode —Select the security method and then configure the required
parameters. (Options: Disabled, Open, Shared, WEP-AUTO, WPA-PSK, WPA2-PSK,
WPA-PSK_WPA2-PSK, WPA, WPA2, WPA1_WPA2, 802.1X; Default: Disabled
OPERATION MODE –CLIENT ROUTER
In the Client Router mode is also known as WISP. The OUTDOOR AP/CPE wireless
side is connected to the remote AP (Base-Station) as in Client Infrastructure mode.
Between the wireless and LAN is the IP sharing router function. This is used to
share Client Router connection. The WAN is on the wireless side.
2) Press Site Survey button and look for available wireless network then click on the
SSID that you attempt to connect to it; 5G is the SSID that we are going to

16
connect in this example. Press Next button when finished.
3) Now, it shows the Profile Name, SSID, BSSID, and encryption type received from
your target network and press Next button to continue.

17
4) Finally, you need to tell the system about IP address received from WAN, DHCP
Hostname, and DNS Server then press Next button to finish the wizard.
OPERATION MODE –CLIENT BRIDGE
In the Client Bridge mode your OUTDOOR AP/CPE will behave just the same as
Wireless adapter. With Client Bridges, the WLAN and the LAN are on the same
subnet. Consequently, NAT is no longer used and services that are running on the
original network.

18
2) Press Site Survey button and look for available wireless network then click on the
SSID that you attempt to connect to it; 5G is the SSID that we are going to
connect in this example. Press Next button when finished.

19
3) Now, it shows the Profile Name, SSID, BSSID, and encryption type received from
your target network and press Next button to finish the wizard.

20
ADVANCED SETUP
In the Advanced Manual Bar, it includes all the settings such as firmware upgrade,
LAN, WAN and wireless settings that change the RF behaviors. It is important to
read through this section before attempting to make changes.
