Huawei AP8130DN Technical specifications

AP8130DN
Product Description
Issue
02
Date
2014-12-05
HUAWEI TECHNOLOGIES CO., LTD.

Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
Copyright ©Huawei Technologies Co., Ltd. 2014. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://enterprise.huawei.com

AP8130DN
Product Description
Contents
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
Contents
1 Product Positioning and Characteristics...................................................................................1
1.1 Product Positioning..........................................................................................................................................1
1.2 Product Characteristics.....................................................................................................................................6
2 Hardware Structure.......................................................................................................................9
2.1 AP8130DN.......................................................................................................................................................9
3 Product Features ..........................................................................................................................14
3.1 WLAN Features .............................................................................................................................................14
3.2 Network Features ...........................................................................................................................................15
3.3 QoS Features..................................................................................................................................................15
3.4 Security Features............................................................................................................................................15
3.5 Maintenance Features.....................................................................................................................................16
3.6 BYOD ............................................................................................................................................................16
3.7 Locating Service.............................................................................................................................................17
3.8 Spectrum Analysis..........................................................................................................................................17
4 Technical Specifications ........................................................................................................xviii
4.1 Basic Specifications ....................................................................................................................................xviii
4.2 Radio Specifications......................................................................................................................................xix
4.3 Standards Compliance................................................................................................................................xxvii

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Product Positioning and Characteristics
1.1 Product Positioning
Table 1-1 Product positioning
Product
Model
Frequency
Band
IEEE
Standard
Compliance
Positioning
Usage
Scenario
AP8130DN
Dual band:
2.4 GHz
5 GHz
The AP8130DN
can provide
services
simultaneously
on the 2.4 GHz
and 5 GHz
frequency
bands to
support more
access users.
It supports
2.4G-to-5G
switchover and
works on dual 5
GHz frequency
bands.
IEEE
802.11a/b/g/n/a
c
Huawei
AP8030DN,
physically
hardened,
supports 3x3
MIMO and
offers enhanced
outdoor
coverage
performance.
The AP can
provide services
simultaneously
on the 2.4 GHz
and 5 GHz
frequency
bands to
support more
access users. It
provides
comprehensive
service support
capabilities and
features high
reliability, high
security, simple
network
deployment,
automatic AC
discovery and
Huawei
AP8130DNs
comply with
IP67 dustproof
and waterproof
protection
standards,
applicable to
coverage
scenarios (for
example,
squares,
pedestrian
streets, and
amusement
parks) and
bridging
scenarios (for
example,
wireless
harbors, data
backhaul, video
surveillance,
and
train-to-ground
backhaul).

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Product
Model
Frequency
Band
IEEE
Standard
Compliance
Positioning
Usage
Scenario
configuration,
and real-time
management
and
maintenance,
which meets
requirements of
outdoor
deployment.
The AP8130DN can work as a Fat AP or FitAP and switch flexibly between the two working
modes based on the network plan.
When the wireless network scale is small, customers need to purchase onlyAP products and
set theAPs to work as Fat APs.As the network scale expands, tens of or hundreds of APs
exist on the network. To simplify network management, customers are advised to purchase
ACs to perform centralized management on the APs and set the APs to work as FitAPs.
Typical networking modes are as follows:

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Figure 1-1 FitAP networking (APmode)
AP n
AP1
……
NMS
AC
Authentication system
Switch
Management channel between
NMS and AC
Management channel between the
AC and the AP and data channel
Where data flows are
encapsulated with CAPWAP
Channel where data flows are not
encapsulated with CAPWAP
Business
users
Residential
users
STA STA
In this networking, the AP functions as a fitAP and provides only data forwarding functions.
The AC is responsible for user access,AP go-online, AP management, authentication, routing,
security, and QoS.HuaweiAC products include theAC6605, AC6005, andAccess Controller
Unit (ACU2).

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Figure 1-2 FitAP networking (WDS mode: point-to-point)
Figure 1-3 FitAP networking (WDS mode: point-to-multipoint)
In this networking, the AP connects two or more independently wired or wireless LANs
through wireless links to construct a network on which users can exchange data. In Wireless
Distribution System (WDS) mode, the AP supports point-to-point (P2P) and
point-to-multipoint (P2MP) networking modes. With 5 GHz and 2.4 GHz frequency bands,
the AP can implement wireless bridging and access functions.

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Figure 1-4 FitAP mesh networking
On the preceding network,APs function as mesh points (MPs) and are fully-meshed to
establish an auto-configured and self-healing wireless mesh network (WMN).APs with the
gateway function can work as the mesh portal points (MPPs) through which the WMN can
provide access to the Internet. Terminals connect to APs to access the WMN. The WMN uses
dedicated mesh routing protocols to guarantee high transmission quality and is more
applicable to scenarios that require high bandwidth and highly stable Internet connections.

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Figure 1-5 FatAP networking
AP n
AP1
……
Switch
STA STASTA STA
On the preceding network, the device functions as a Fat AP to implement functions such as
user access, authentication, data security, service forwarding, and QoS.
1.2 Product Characteristics
Product
Characteristics
Description
High-speed and
reliable wireless
access
Complies with IEEE 802.11a/b/g/n/ac.
Supports 3×3 MIMO and provides a maximum rate of 1.75 Gbit/s.
Supports Wi-Fi Multimedia (WMM) and priority mapping on the
air interface and wired interface.
Supports wired link integrity check.
Provides two GE auto-sensing uplink electrical ports and supports
PoE power supply.
Supports load balancing.
Supports roaming without service interruption in Fit AP mode.
Supports AC dual-link backup in Fit AP mode.
Uses the latest 802.11ac chip to provide higher performance and
wider coverage.
Uses a metal shell and heat dissipation design to ensure high
reliability.

AP8130DN
Product Description
1 Product Positioning and Characteristics
Issue 02 (2014-12-05)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Product
Characteristics
Description
Supports airtime scheduling which ensures fairness in channel
occupation time for all users.
Comprehensive
user access control
capability
Supports access control lists (ACLs) and implements user access
control based on the user group policy.
Provides fine-grained bandwidth management for each user.
Supports user isolation policies.
Supports unified authentication on the AC in Fit AP mode.
Identifies the device type according to the organizationally unique
identifier (OUI) in the MAC address, user agent (UA) information
in an HTTP packet, and DHCP options in Fit AP mode.
The RADIUS server delivers packet forwarding, security, and QoS
policies according to the device type carried in the RADIUS
authentication and accounting packets in Fit AP mode.
High network
security
Open system authentication
WEP authentication/encryption
WPA/WPA2/WPA-WPA2-PSK authentication and encryption
WPA/WPA2/WPA-WPA2-802.1x authentication and encryption
WPA, WPA2, and WPA-WPA2 support TKIP and CCMP
encryption algorithms, where CCMP uses 128-bit advanced
encryption standard (AES) encryption algorithm and has high
security.
WAPI authentication and encryption
Supports wireless intrusion detection system (WIDS) and wireless
intrusion prevention system (WIPS), including rogue device
detection and countermeasure, attack detection and dynamic
blacklist, STA/AP blacklist and whitelist.
Flexible
networking and
environment
adaptability
Provides flexible networking capabilities and applies to various
application scenarios. Mesh and WDS scenarios are supported only
in Fit AP mode.
Has strong environment adaptability. The AP can automatically
select the transmission rates, channels, and transmit power to adapt
to various radio environments and avoid interference in real time.
Adjusts bandwidth allocation based on the user quantity and
environment to improve user experience.
Supports the MIMO antenna system and connects to external
dual-band antennas (2.4 GHz and 5 GHz). The antennas can be
flexibly adjusted.
Identifies interference sources such as baby monitors, Bluetooth
devices, digital cordless phones (at 2.4 GHz frequency band only),
wireless audio transmitters (at both the 2.4 GHz and 5 GHz
frequency bands), wireless game controllers, and microwaves in Fit
AP mode and works with eSight to locate interference sources and
display spectrums.
Easy device
Automatically goes online and loads the configuration, and
