Sona electronics Se-560 Installer manual

SONA ELECTRONICS, L.L.C.

WORLDWIDE LEADER IN MANUFACTURING AND

DISTRIBUTION OF CONSUMER ELECTRONICS

P.O. Box 5370, Concord, NC 28027, USA

Tel: 704.721.7800

Toll Free: 1.866.766.2353

Fax: 704.721.7803

[email protected]

www.sona-vision.com

SONA ELECTRONICS, L.L.C.

WORLDWIDE LEADER IN MANUFACTURING AND

DISTRIBUTION OF CONSUMER ELECTRONICS

P.O. Box 5370, Concord, NC 28027, USA

SE•560

5.6” Stand Alone or Headrest Monitor

• Best Mobile Video system with FAA approval

• Excellent Industry Design Tooling

• Thinnest Type, Highest Brightness among industry

• High resolution picture quality

• Compact design suitable for mounting into headrest

• Reverse Mirror function for rear view camera

• Earphone

• Video System: NTSC / PAL dual system

• 2 Video Inputs

• Audio Output

• Left/Right x 2 (Stereo)

• Wireless Remote Control

• Operating Temperature 0 ~ + 65 ¢J

• Storage Temperature -25 ~ + 70 ¢J

• Special Reverse Mirror for parking

• Dimension… 140 (L) x 117 (W) x 13 (D) mm

SE•700

7” Stand Alone or

Headrest Widescreen (16:9) TFT Monitor

• Amorphous Active Matrix TFT

• Compact Design

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Headrest Shroud or Mounting Stand Kit Included

• Independent Color Video Display System

• Full Function Remote

• Compact Size

• Bright Picture

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 178 (L) x 135 (W) x 28 (D) mm

SE•701BR

7” Wide Screen (16:9) TFT Slim Design Headrest Monitor

• Amorphous Active Matrix TFT

• Built-in Auto On/Off Signal Switch

• Very Slim and Compact Design

• Compact Headrest Shroud

• 2 Video Inputs

• OSD On Screen Display

• NTSC System

• High Resolution Picture

• Slim Headrest Shroud Kit Included

• Mounting Stand Included

• Independent Color Video Display System

• Bright Picture

• Low Reﬂ ection Panel

• Universal Installation

• Easy Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 178 (W) x 112 (H) x 27 (D) mm

HEADREST MONITORS

ROOF MOUNT MONITORS

SV•700

7” Wide Screen (16:9) Swivel TFT Roof Mount Video Monitor

• Smallest Roof Mount Monitor in the World

• Amorphous Active Matrix TFT

• Full Swivel to either direction

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Built-in Dual Dome Lights

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture

• Compact Size

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 200 (L) x 170 (W) x 38 (D) mm

SV•1240

12.4” Wide Screen (4:3) Swivel TFT Roof Mount Video

Monitor with IR Transmitter

• Amorphous Active Matrix TFT

• Built-in IR Transmitter

• Full Swivel to either direction

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Dual System

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture

• Small Foot Print and Light Weight

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Low Power Consumption

• Resolution: 800 (H) x 600 (V) = 480,000 dots

• Dimensions: 340 (H) x 310 (W) x 50 (D) mm

SV•850

8.5” Wide Screen Swivel Video Monitor

• Amorphous Active Matrix TFT Color Monitor

• Japanese Sharp High Quality Panel

• Built-in IR Transmitter for wireless headphones

• Light Weight/Slim Design

• High Resolution Picture (800x600 Dots)

• NTSC/PAL Auto Switch Format

• On Screen Display (OSD)

• Wide Angle Viewing

• Swivel 45 degrees left and right

• Dual Built-in Dome Lights

• Credit Card Size Remote

• Used as Monitor, Car Navigation System or

Video Game Console

• 2 Video Inputs for DVD, VHS, GPS, Video Games

• Overhead ﬂ ip-down with complete mounting

hardware

• Contrast ratio: 300:1

• Brightness: 500cd/M2 (NITS)

• Dimensions: 215x218x35 MM

SV•104F

10.4” Wide Screen TFT Roof Mount SWIVEL Video Monitor

with built in IR Transmitter

• Amorphous Active Matrix TFT

• Full Swivel of monitor to either direction

• Built-in IR Transmitter

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching, SECAM Available

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Multi-Language Menu Support

• RCA Jack for Easy Installation

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture, Non Reﬂ ective TFT

• Very Compact Size

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Low Power Consumption

• Safety Certiﬁ cation: UL, FCC, CE, TUV

• Resolution: 800 (H) x 3 (RGB) x 600 (V) dots

• Dimensions: 268 (H) x 265 (W) x 40.8 (D) mm

SN•350RM

3.5” Swivel Roof Mount TFT-LCD Monitor

• HannStar New panel (wide angle view)

• TFT- LCD Color Monitor

• Automatic reverse trigger

• Screen Size: 3.5 inches

• Resolution(HxV): 480x234 dots

• CCFT Backlight

• 2 video inputs

• NTSC/PAL

• Adjustable Brightness and View

• Normal and/or mirror image

• Dimensions(LxHxD): 125mm*120mm*80mm

• Easy Installation

• Flip Down or Stand Alone Available

SV•114F

11.4” Wide Screen

TFT ROOF MOUNT SWIVEL VIDEO MONITOR

• Amorphous Active Matrix TFT

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching, SECAM

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Multi-Language Menu Support

• Composite Video (RCA Jack) x 2

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture, Non Reﬂ ective TFT

• Very Compact Size

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Low Power Consumption

• Resolution: 800 (H) x 600 (V) =480,000 dots

• Dimensions: 268 (H) x 265 (W) x 40.8 (D) mm

SMD•850

8.5” TFT LCD Flip-down Monitor

with DVD Player/TV Combo

• 8.5” Sharp diagonal screen

• Audio and Video input

• NTSC/PAL Color System (SECAM optional)

• High Resolution Picture (1440x234 dots)

• Swivel Right and Left

• Built-in Speaker, TV Tuner, and FM Modulator

• DVD, VCD, CD, MP3, CD-R, CD-RW compatible

• Full Function Remote Control, OSD Menu

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• IR Headphone Transmitter Built-in

• Earphone cable and TV Antenna included

• Dimensions: 11.02x9.055x1.575 inches

SID•720

7.2” TFT Motorized In-Dash Monitor with DVD and Tuner

• Fully Motorized, Fully Automatic

• Built-in TV Tuner

• Switchable PAL/NTSC System

• Built-in AM/FM Stereo Receiver

• CD Changer Controller

• Audio CD/DVD/VCD/SVCD/MP3 Compatible

• Single DIN & Single Harness Mounting

• 200 Watt (50W x 4CH) & Center 20 Watt

• Clock Display

• AV1, AV2, AV3 (Navigation System), AUX

• Antenna Provided

• Electronic Volume, Bass, Treble, Balance,

Woofer Center

• Last Position Memory

• Anti-Shock/Anti-skip Mechanism

• Multi-Audio/Subtitles/Angle

• Full Remote Control

• Picture Reversal for rear camera

SMD•104 COMBO

10.4” TFT Monitor with DVD Player

• Amorphous Active Matrix TFT

• Full Swivel of Monitor to either direction

• Built-in FM Modulator

• Built-in IR Transmitter

• Wide Screen (Wide: 16:9 or 4:3)

• OSD On Screen Display

• NTSC/PAL

• Built-in Dual Dome Lights

• Mirror Function

• Noise Reduction Feature

• Overhead Console Bracket

• Multi-Language Menu Support

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture

• Anti-Glare Surface Treatment

• Very Light Weight and Compact Design

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Resolution: 800 RGB (W) x 480 (H)

• Safety Certiﬁ cations: UL, FCC, CE, TUV

DVD Features

• Compatible for FCD/MP3/CD/CD-R/CD-RW

• Side Vacuum Loader DVD

• Auto Single DVD Play

• Electronic Digital Anti-shock

• Soft Touch Front Panel Controls

• Jumbo LCD Back Lit Display

• High Resolution Output

ROOF MOUNT MONITORS

SV•154F

15.4” Wide Screen (4:3) TFT ROOF MOUNT SWIVEL VIDEO

MONITOR with built in IR TRANSMITTER

• Amorphous Active Matrix TFT

• Built-in IR Transmitter

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching, SECAM Available

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Multi-Language Menu Support

• RCA Jack for Easy Installation

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture, Non Reﬂ ective TFT

• Very Light Weight

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and

Sharpness

• Universal Console Installation

• Low Power Consumption

• Safety Certiﬁ cation: UL, FCC, CE, TUV

• Resolution: 1280 (H) x 3 (RGB) x 768 (V) dots

• Dimensions: 328 (H) x 418 (W) x 38 (D) mm

SE•5˝ or 7˝ Sun Visor

TFT LCD Sun Visor Monitor with light and mirror

• OSD

• 1 video and 1 audio input

• All Function Remote Control

• PAL/NTSC System

• Resolution: 1440x234

• Compact Size

COMBO UNITS

SVP•700SV

SV•700, SD•700, SI•IR 1600,

2 Headphones, SI•FM Modulator

• 7” Roof Mount Swivel TFT Monitor

• Smallest Roof Mount in the World

• Amorphous Active Matrix TFT

• Full Swivel of monitor to either direction

• Built-in Dome Lights

• Universal Console Installation

• Multi-Angle Viewing

• 2 Video Inputs

• IR Transmitter

• Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Compact Size

• High Resolution Picture

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory, Digital

Anti-Shock, Auxiliary Outputs on front

SVP•850SV

SV•850ESV, SD•700, SI•IR 1600,

2 Headphones, SI•FM Modulator

• 8.5” Roof Mount Swivel TFT Monitor

• Amorphous Active Matrix TFT

• Built-in Dome Lights

• Japanese Sharp Panel

• Multi-Angle Viewing

• 2 Video Inputs

• IR Transmitter

• Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Compact Size

• High Resolution Picture

• Safety Certiﬁ cation: UL, FCC, CE, TUV

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory,

Digital Anti-Shock, Auxiliary Outputs on front

SVP•104SV

SV•104F, SD•700, 2 Headphones, SI•FM Modulator

• 10.4” Roof Mount Swivel TFT Monitor

• Amorphous Active Matrix TFT

• Full Swivel of monitor to either direction

• Built-in Dome Lights

• Multi-Angle Viewing

• 2 Video Inputs

• Built-in IR Transmitter

• Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Compact Size

• High Resolution Picture

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory,

Digital Anti-Shock, Auxiliary Outputs on front

SVP•154SV

SV•154F, SD•700, 2 Headphones, SI•FM Modulator

• 15.4” Roof Mount TFT Monitor

• Amorphous Active Matrix TFT

• Multi-Angle Viewing

• 2 Video Inputs

• Built-in IR Transmitter

• Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Very Light Weight

• High Resolution Picture

• Safety Certiﬁ cation: UL, FCC, CE, TUV

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory,

Digital Anti-Shock, Auxiliary Outputs on front

SVP•2x560SE

SE•560, SD•700, SI•IR 1600,

2 Headphones, SI•FM Modulator

• Two 5.6” Headrest/Stand Alone

Wide Screen (16:9) TFT Monitors

• Amorphous Active Matrix TFT

• Compact Headrest Shroud

• Universal Console Installation

• Multi-Angle Viewing

• 2 Video Inputs

• IR Transmitter

• Two Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Compact Size

• Bright Picture

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory, Digital

Anti-Shock, Auxiliary Outputs on front

SVP•1240SV

SV•1240, SD•700, 2 Headphones, SI•FM Modulator

• 12.4” Roof Mount Swivel TFT Monitor

• Amorphous Active Matrix TFT

• Full Swivel of monitor to either direction

• Built-in Dome Lights

• Multi-Angle Viewing

• 2 Video Inputs

• Built-in IR Transmitter

• Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Compact Size

• High Resolution Picture

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory,

Digital Anti-Shock, Auxiliary Outputs on front

SONA PACKAGES

SVP•2x701BRSE

SE•701BR, SD•700, SI•IR 1600,

2 Headphones, SI•FM Modulator

• Two 7” Headrest/Stand Alone Wide Screen

(16:9) TFT Monitors

• Amorphous Active Matrix TFT

• Compact Headrest Shroud

• Universal Console Installation

• Multi-Angle Viewing

• 2 Video Inputs

• IR Transmitter

• Two Infrared Wireless Headphones

• FM Modulator

• Auto Picture Focus

• NTSC System

• Anti-Reﬂ ective Glass

• Compact Size

• Independent Color Video Display System

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory, Digital

Anti-Shock, Auxiliary Outputs on front

SVP•2x700SE

SE•700, SD•700, SI•IR 1600,

2 Headphones, SI•FM Modulator

• Two (2) - 7” Headrest/Stand Alone

Wide Screen (16:9) TFT Monitors

• Amorphous Active Matrix TFT

• Compact Headrest Shroud

• Universal Console Installation

• Multi-Angle Viewing

• 2 Video Inputs

• IR Transmitter

• Two Infrared Wireless Headphones

• Full Function Remote

• FM Modulator

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Anti-Reﬂ ective Glass

• Reverse Image Picture

• Compact Size

• Independent Color Video Display System

• In-dash DVD Player with multi-angle mounting,

500 line resolution, Last Position Memory, Digital

Anti-Shock, Auxiliary Outputs

SONA PACKAGES

DVD PLAYERS

SD•700

DVD, VCD, DVCD, SVCD, CD, MP-3, CDR, CD-RW Player

• Slot Loading DVD for Multiple Angle Mounting

• In-Dash, Floor & Under Dash Mounting

Brackets

• Last Position Memory

• Dolby Pro-logic/DTS Compatible

• Remote Control

• Front Panel AV RCA Inputs

• Auxiliary Audio Output on Mini-Plugs

• S/Video Output

• NTSC/PAL

• Electronically switch from Handheld Remote to

Video Games or Camcorders

• Dolby Coaxial Digital Output for SPDIF/RAW or

SPDIF/PCM

• Front Panel Infrared Remote Eye

• 19” Infrared Remote Eye

• OSD On Screen Display

• Digital Anti-Shock

• Built-in Screen Saver

• Jumbo LCD Back Lit Display

• Multi Function I/R Remote Control

• 500 Line High Resolution Output

• Multi-Language Menu in 6 Languages

• Four Speed Disc Scan (2 x 4 x 6 x 8 x)

• Frame-by-Frame and Slow Motion Feature

• Dimensions: 178 x 168 x 50 mm

SD•700T

DVD, VCD, DVCD, SVCD, CD, MP-3, CDR, CD-RW Player

(This is the same DVD player as the SD•700, but with a built-in Tuner option.)

• Slot Loading DVD for Multiple Angle Mounting

• Built-in Tuner

• In-Dash, Floor & Under Dash Mounting

Brackets

• Last Position Memory

• Dolby Pro-logic/DTS Compatible

• Remote Control

• Front Panel AV RCA Inputs

• Auxiliary Audio Output on Mini-Plugs

• S/Video Output

• NTSC/PAL

• Electronically switch from Handheld Remote to

Video Games or Camcorders

• Dolby Coaxial Digital Output for SPDIF/RAW or

SPDIF/PCM

• Front Panel Infrared Remote Eye

• 19” Infrared Remote Eye

• OSD On Screen Display

• Digital Anti-Shock

• Built-in Screen Saver

• Soft Touch Front Panel Controls

• Jumbo LCD Back Lit Display

• Multi Function I/R Remote Control

• 500 Line High Resolution Output

• Multi-Language Menu in 6 Languages

• Four Speed Disc Scan (2 x 4 x 6 x 8 x)

• Frame-by-Frame and Slow Motion Feature

• Dimensions: 178 x 168 x 50 mm

SI•IR1600

Two Wireless Infrared Headphones with IR Transmitter

• Frequency Response: 20 Hz - 23Hz

• High Frequency Modulation

• Infrared Wavelength: 8445 mm +/-5mm

• Impedance: 32 Ohm +/- 6.4 Ohm

• Effective Range: 10 yards

• Power Source: 2 x AAA batteries

• FM Frequency System Carrier

• Auto Mute Feature on Receiver

• Auto Power Off Volume Control and

On/Off Power Switch

• Adjustable Headphone Straps

• Contoured and Designed for Perfect Comfort

• Studio Quality Sealed Ear Piece

• Compatible with DVD/VHS Players

SI•IRHT

Single Wireless Infrared Headphone with IR Transmitter

• Frequency Response: 20 Hz - 23Hz

• High Frequency Modulation

• Infrared Wavelength: 8445 mm +/-5mm

• Impedance: 32 Ohm +/- 6.4 Ohm

• Effective Range: 10 yards

• Power Source: 1 x AAA batteries

• FM Frequency System Carrier

• Auto Mute Feature on Receiver

• Auto Power Off Volume Control and

On/Off Power Switch

• Adjustable Headphone Straps

• Contoured and Designed for Perfect Comfort

• Studio Quality Sealed Ear Piece

• Compatible with DVD/VHS Players

SI-IRH

Single Wireless Infrared Headphone

• Power Source: 1 x AAA batteries

• Auto Mute Feature on Receiver

• Auto Power Off Volume Control and

On/Off Power Switch

• Adjustable Headphone Straps

• Contoured and Designed for Perfect Comfort

• Studio Quality Sealed Ear Piece

• Compatible with DVD/VHS Players

SI•IRT100

IR Wireless Transmitter

• Frequency Response: 20 Hz - 23Hz

• High Frequency Modulation

• Infrared Wavelength: 8445 mm +/-5mm

• Impedance: 32 Ohm +/- 6.4 Ohm

• Effective Range: 10 yards

• FM Frequency System Carrier

• Studio Quality Enhanced Performance

• Compatible with DVD/VHS Players

SC•40B

B/W CMOS MINI CAMERA

• TV system: CCIR/EIA

• Resolution: 240 Lines

• Minimum illumination: 0.5LUX/F=1.2

• Visual angle: 69 degrees

•12 Volt DC Power consumption

• Professional design applicable for any vehicle

• Wide-angle view image function

SC•600C

COLOR CMOS MINI CAMERA

• TV system: PAL/NTSC

• Resolution: 380TV lines

• Minimum illumination: 3LUX/F=1.2

• 12 VDC power consumption

• Professional design applicable for any vehicle

• Wide-angle view image function

SI•FMM

Digital PLL Wired FM Modulator

• 2 Frequency Settings Via Slide Switch

• Ground Loop Isolator Circuit

• Auto-switch antenna signal

• Integrated Anti-Howling System

• Shielded Metal Housing for Noise Rejection

SI•RFW2000

Wireless 4 Channel FM Modulator

• Connects to VCD, DVD, CD, MP3 players or

other audio sources

• Transmits sound to car radio or home stereo

• No messy wiring: live video on TFT-LCD Monitor

• Four channels at 87.7, 88.1, 88.3, and 88.7 MHz

• Stereo audio input

• Operating distance is 30+ feet

STV•860

Digital TV Tuner Interface

• Built in high performance PLL FM transmitter

• Built in high performance diversity antenna

control circuit for better TV reception

• Infrared remote control

• CATV: 181 channels.

• Five bands FM transmitter frequency control

• Recall : Last channel and volume level memory

• Direct channel selector

• Ten stations memory

• Stereo broadcast reception for NTSC system

• Return function : recall last 2 stations to select

• Last Memory

• OSD

• Two stereo A/V input

• One stereo A/V output

ACCESSORIES

MVA3

MULTI-VIDEO AMPLIFIER

• Maintains video levels when using more than

one LCD screen for given video signal.

• One video input and 7 balanced outputs

• Small compact size: 1” x 25” x 3.5”

SI•MVA4

One In & Four Output Video Signal Ampliﬁ er/Booster

• Four Individual Output Trimmer Gain Controls

• Shielded Metal Housing for Noise Rejection

• Video Output Gain Control

• One RCA video input

• On/Off Power LED Indicator

SI•MV404

Digital Video Switcher

• Audio Video Distribution Center

• 4 Inputs to 4 Output Switching Device

• 4 Input to 2 Output Switching Device

• Can Independently switch between 4 different

sources to four different monitors

• Highest quality video components to prevent

any degradation in the video quality.

• Each video source and corresponding audio

(stereo included) is individually controlled.

• All four different Source Selectors have

indicators as to which source is being viewed.

SI•400GPI

600 Watt 12 Volt Power Inverter

• Dual Output 110 Volts

• AC to DC Power Inverter

• 12 V Input

• Thermal Protection

• Short Circuit Protection

• Great Use for Video Games

SI•150GPI

Power Inverter and Game Plate Combo

• AC to DC Power Inverter

• 150 Watt Continuous Power

• Game Port Connector/Adapter

• 12 V Input/110V Output (x2)

• Over/Under Voltage Projection

SI•GP100

Game Plate Control

• On/Off Power Switch

• Gold Plated RCS/s

• Injection Molded Housing

• Easy Snap•on Mounting System

SDA•50

Internal Car Antenna

• High Sensitivity/Gain Conductor

• Has Superior Signal Strength

• Equipped with High Gain Conductor

• Small Size

• Can be Mounted on windows of any size

• Compact Design, Easy to Hide, Easy to Install

SDA•100

Diversity Antenna with Booster

• Channel : VHF 1-12 Ch HF 13-62 Ch

• Power Source:DC13.2 V (10.8- 16V)

• Antenna terminal: 3.5

• Cable 75 Ohm

• High Sensitivity Type

• High Gain Conductor/VHF-UHF

• Booster Included

• Indoor type Diversity Antenna which allows for

simple and easy installation

• Flexible Antenna element for ease of installation

STV•100

Ampliﬁ ed Antenna for TV

• Reception Channels: FM (60-100MHZ)

• VHF (Ch. 2 - Ch. 13)

• UHF (Ch. 14 - Ch. 62)

• High Sensitivity Type

• High Gain Conductor / VHF-UHF

• Indoor type Diversity Antenna which allows for

simple and easy installation

• Flexible Antenna element for ease of installation

SA•MB100

Universal Mounting Bracket

for Monitors * Fully adjustable.

SSSA•GN100

Universal Mounting Bracket for Monitors

* Flexible 16” Gooseneck

SA•GN200

Universal Mounting Bracket for Monitors

Flexible 21” Gooseneck

ACCESSORIES

FEATURES

• Superior quality at cost sensitive price points

• Coaxial high-power speakers

• Injected carbon PP cones

• Kapton-Glass Fiber

• Stontium magnet rubber edges

• Various popular sizes available: 4˝, 4˝x6˝, 5.25˝ 6.5˝, 6˝x9”, 5˝x7˝

SV•SPEAKER4630 - 4x6”SV•SPEAKER4030 - 4”

SV•SPEAKER5530 - 5.25”

SV•SPEAKER6530 - 6.5”SV•SPEAKER5730 - 5x7”

SPEAKERS

SONA ELECTRONICS, L.L.C.

WORLDWIDE LEADER IN MANUFACTURING AND

DISTRIBUTION OF CONSUMER ELECTRONICS

P.O. Box 5370, Concord, NC 28027, USA

Tel: 704.721.7800

Toll Free: 1.866.766.2353

Fax: 704.721.7803

[email protected]

www.sona-vision.com

This manual suits for next models

Table of contents

SONA Electronics SE-560 Installer manual

Popular Car Video System manuals by other brands
