INSTALLATION INSTRUCTIONS
95-9323B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DDIN radio provision
• Includes all necessary data interfaces, wiring harnesses,
and antenna adapter, for a complete installation
•
Includes components necessary to relocate the factory climate control
• Painted black to match the factory dash
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) (4) Radio screws (short) • D) Climate control trim panel • E) Climate control brackets
• F) (4) Climate control screws (long) • G) Climate control extension harness • H) ASWC-1 interface and wiring harness (not shown) TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Cutting tool • 3mm Allen screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly ..........................................................3
Axxess Interface Installation .................................4
Final Assembly .......................................................7
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with kit
Antenna Adapter: Included with kit
Steering Wheel Control Interface: Included with kit
A B D E
GF
C
BMW X1 (with iDrive, without MOST® Amp) 2013-2015
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle specific applications

1.800.221.0932
|
MetraOnline.com
2
Radio Removal
1. Unclip the trim panel surrounding the gear
shifter, then set to the side. (Figure A)
2. Unclip, unplug, and remove the climate
control panel. (Figure B)
3. Remove (2) screws and (2) metal clips
securing the radio. Slide the radio out, then
unplug and remove the radio. (Figure C)
Pocket Removal
4. Unclip, unplug, and remove the a/c vent
trim panel above the radio. Remove (2)
screws exposed. (Figure D & E)
5. Unclip and remove the storage pocket on
the top of the dash. Connect the climate
control extension harness to the harness
removed in step 2, then route the extension
harness to this location. (Figure F)
Continue to Kit Preparation
(Figure B)
(Figure D) (Figure F)(Figure A) (Figure C)
(Figure E)
DASH DISASSEMBLY

REV. 2/5/2019 INST95-9323B 3
Climate Control Relocation
1. In one motion, attach the climate control
brackets to the factory climate control
panel, then secure both to the climate
control trim panel using (4) climate
control screws provided. (Figure A)
2. Connect the climate control assembly to
the climate control extension harness
in the dash, then secure the assembly
to the dash using the screws removed in
step 2 from Dash Disassembly.
3. Reconnect the a/c vent trim panel
removed in Dash Disassembly, then clip
the panel back to the dash.
Sub-Dash Modification
4. Cut the sub-dash to allow room for the
aftermarket radio. (Figure B)
Continue to Kit Assembly
1. Secure the radio brackets to the radio
using either the screws supplied with
the radio, or the radio screws provided.
(Figure A)
Continue to Axxess Interface Installation
KIT PREPARATION KIT ASSEMBLY
(Figure B)
(Figure A)
(Figure A)

1.800.221.0932
|
MetraOnline.com
4
AXXESS INTERFACE INSTALLATION
• Provides accessory power
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio/phone† controls on the steering wheel
• Retains chimes
• Retains balance and fade
• Micro-B USB updatable
INTERFACE FEATURES
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• 9323 interface
• 9323 harness
• Chime retention interface
• Chime speaker
• ASWC-1 interface
• ASWC-1 harness
• Female 3.5mm connector with stripped leads
Connections ..............................................................................................................................................5
Installation ...............................................................................................................................................6
Programming ........................................................................................................................................6-7
INTERFACE COMPONENTS
TABLE OF CONTENTS
† Radio dependent

REV. 2/5/2019 INST95-9323B 5
From the 9323 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
Note: There will an accessory wire from the ASWC-1 harness to connect as well.
• Connect the Blue wire to the amplifier turn-on wire.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
• Tape off and disregard the Brown wire, it will not be used in this application.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the speed sense wire.
•
Connect the Green/Purple wire to the reverse wire .
• Connect the Light Green wire to the parking brake wire.
• Connect the 6-foot long Yellow wire with a fuse-holder directly to the battery.
From the ASWC-1 harness to the aftermarket radio:
This harness is to be used if the vehicle is equipped with steering wheel controls.
• Connect the Red wire to the accessory wire.
•
For the radios listed below: Connect the female 3.5mm connector with stripped leads, to the
male 3.5mm SWC jack from the ASWC-1 harness. Any remaining wires tape off and disregard
:
• Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White
wire from the connector. Then connect the remaining steering wheel control wire,
normally Brown/White, to the Brown wire from the connector.
• Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire.
• Kenwood or select JVC with a steering wheel control wire: Connect the Blue/Yellow
wire to the Brown wire.
Note: If the Kenwood radio auto detects as a JVC, manually set the radio type to Kenwood. Refer
to the Changing Radio Type document available at axxessinterfaces.com/product/ASWC
-1.
• XITE: Connect the steering wheel control SWC-2 wire from the radio to the Brown wire.
• Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT (sold
separately). Then connect the 4-pin connector from the AX-SWC-PARROT to the radio.
Note: The radio must have rev. 2.1.4 or higher software.
• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to
as Key-A or SWC-1, to the Brown wire from the connector. Then connect the remaining
steering wheel control wire, referred to as Key-B or SWC-2, to the Brown/White wire from
the connector. If the radio comes with a third wire for ground, disregard this wire.
Note: After the interface has been programmed to the vehicle, refer to the manual provided with
the radio for assigning the SWC buttons. Contact the radio manufacturer for more information
.
• For all other radios: Connect the 3.5mm jack from the ASWC-1 harness into the jack from the
aftermarket radio designated for an external steering wheel control interface. Please refer to
the aftermarket radios manual if in doubt as to where the 3.5mm jack should connect to
.
CONNECTIONS

1.800.221.0932
|
MetraOnline.com
6
With the key in the off position:
1. Zip tie the chime speaker under the dash to a location where it will be heard clearly by the
driver, then route the harness to the radio location.
2. Connect the chime speaker to the connector on the right side of the chime retention
interface.
3. Connect the 9323 harness to the chime retention interface.
4. Connect the 9323 harness to the 9323 interface, and then to the wiring harness in the
vehicle.
5. Connect the ASWC-1 harness to the ASWC-1 interface, and then to the 9323 interface.
6. Locate the factory antenna connector in the dash and complete all necessary connections to
the radio. Use the antenna adapter provided to adapt the factory antenna connector to the
aftermarket radio.
Attention! If retaining steering wheel controls, ensure that the SWC jack/wire is connected to the
radio before proceeding. If this step is skipped, the interface will need to be reset for the steering
wheel controls to function.
1. Press and hold the Volume Up button on the steering wheel.
2. Turn the ignition on, the L.E.D. in the ASWC-1 interface will start flashing rapidly, which
means the ASWC-1 interface is looking for the vehicle and the radio.
3. After a few seconds the L.E.D. should stop flashing rapidly, then go out for approximately 2
seconds.
4. After 2 seconds there will be a series of 7 Green flashes, some short, and some long.
The long flashes represent the wires that are connected from the vehicle to the ASWC-1
interface. The 3rd, 4th, 5th, and 6th flashes should be longer.
5. The L.E.D. will pause for another 2 seconds, then flash Red up to 18 times depending on
which radio is connected to the ASWC-1 interface. Refer to the L.E.D. Feedback section for
more information.
6. This is the end of the auto detection stage. If the ASWC-1 interface detected the vehicle and
radio successfully, the L.E.D. will light up solid. If not, refer to the troubleshooting documents
available at axxessinterfaces.com/product/ASWC-1.
7. Test all functions of the installation for proper operation before reassembling the dash. Refer
to the ASWC-1 Steering Wheel Control documents available at
axxessinterfaces.com/product/ASWC-1 for customizing the buttons, if so desired.
Continued on the next page
I N S TAL L ATI O N PROGRAMMING

REV. 2/5/2019 INST95-9323B 7
FINAL ASSEMBLYPROGRAMMING (CONT)
L.E.D. Feedback
The (18) Red L.E.D. flashes represent the brand of radio the ASWC-1 interface believes it is
connected to. Each flash count represents a different radio Manufacturer. For example, if you
are installing a JVC radio, the ASWC-1 interface will flash Red (5) times, then stop. Following is a
legend that explains which radio Manufacturer corresponds to the flash count provided.
L.E.D. feedback legend
* If the ASWC-1 interface flashes Red (7) times, and an Alpine radio is not installed, that means
an open connection. Verify that the 3.5mm jack is connected to the correct steering wheel
jack/wire in the radio.
** The AX-SWC-PARROT is required (sold separately). Also, the software in the radio must be rev.
2.1.4 or higher.
† If a Clarion radio is installed and the steering wheel controls do not function, change the radio
type to the opposite Clarion radio type; likewise for Eclipse. Refer to the Changing Radio Type
document available at axxessinterfaces.com/product/ASWC-1.
‡ If a Kenwood radio is installed and the L.E.D. feedback comes back showing as a JVC radio,
change the radio type to Kenwood. Refer to the Changing Radio Type document available at
axxessinterfaces.com/product/ASWC-1.
1. Secure the radio assembly to the dash using the factory screws.
2. Clip the radio trim panel to the dash.
3. Clip the gear shifter trim panel back to the vehicle to complete the installation.
Flash Count Radio
1 Eclipse (type 1) †
2 Kenwood ‡
3 Clarion (type 1) †
4 Sony / Dual
5 JVC
6 Pioneer / Jensen
7 Alpine *
8 Visteon
9 Valor
Flash Count Radio
10 Clarion (type 2) †
11 Metra OE
12 Eclipse (type 2) †
13 LG
14 Parrot **
15 XITE
16 Philips
17 TBA
18 JBL

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Metra. The World’s Best Kits.®MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 2/5/19 INST95-9323B
INSTALLATION INSTRUCTIONS
95-9323B
If you are having difficulties with the installation
of this product, contact our Tech Support line
either by phone at 1-800-253-TECH, or email at
[e-mail]. Before
doing so, look over the instruction booklet a
second time and ensure that the installation was
performed exactly as the instruction booklet
is stated. Have the vehicle apart and ready to
perform troubleshooting steps before contacting
Metra/Axxess Tech Support.
