Audiovox MM850 User manual

MM850 1
MM850
8.5” LCD OVERHEAD MONITOR
OPERATION MANUAL
POWER
MENU/
ENTER
ON OFF AUTO
UP
DOWN
PP
1287264.P65 11/2/2004, 9:48 AM1

2MM850
Important Notice
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the
driver if the LCD panel or video monitor is used for vehicle information, system control,
rear or side observation or navigation. If the LCD panel or video monitor is used for
television reception, video or DVD play, the LCD panel or video monitor must be installed
so that these features will only function when the vehicle is in “park” or when the vehicle’s
parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that
operates when the vehicle is in gear or when the parking brake is not applied must be
installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to
the operator of the motor vehicle.
Warnings
Do not use any solvents or cleaning materials when cleaning the video monitor.
Do not use any abrasive cleaners,
Safety Precaution
For safety reasons, when changing video media it is recommended that the vehicle is
not in motion, and that you do not allow children to unfasten seatbelts to change tapes
or discs or make any adjustments to the system. System adjustments can be
accomplished using the remote control unit, while seatbelts remain fastened. Enjoy
your Movies 2 Go entertainment system but remember-safety of all passengers remains
the number one priority.
1287264.P65 11/2/2004, 9:48 AM2

MM850 3
Congratulations on your purchase of the Movies 2 Go MM850 drop-down Video
Monitor. The MM850 has been designed to give you and your family many
years of video entertainment in the mobile environment. Please read the
directions that follow to familiarize yourself with the product and to ensure
that you obtain the best results from your equipment.
NOTE: Installation options vary, see the individual owner’s manuals for
each component in your system to obtain a full understanding of each
component’s operation.
FEATURES
!8.5” TFT (Thin Film Transistor) Active Matrix LCD (Liquid
Crystal Display) Monitor
!OSD (On Screen Display) for Control of Picture Quality and
Functions
!Infrared Transmitter for Optional IR Wireless Headphones
!Two Audio / Video Source Inputs
!Dome Lights with Built-in Three Way Switch
!Video Display ON/OFF Switch (when LCD Panel is
Opened and Closed)
!Full Function Remote Control
1287264.P65 11/2/2004, 9:48 AM3

4MM850
POWER
MENU/
ENTER
ON OFF AUTO
AUX
12
33
4
5
67 8
10
9
11
UP
DOWN
12
FRONTPANELFEATURES
1287264.P65 11/2/2004, 9:48 AM4

5MM850
1. Infrared Transmitter – Used to transmit audio to the optional wireless
headphones.
2. Remote Sensor – To allow Remote Control operation of the MM850.
3. Dome Lights – Provide additional interior illumination.
4. Three Position Dome Light Switch
• Auto – Automatically switches on the dome lights in conjunction with the
vehicle’s interior illumination.
• Off – The Dome lights will not turn on in this position.
• On – Turns on the Dome lights.
5. Power ON/OFF – Turn the MM850 on and off.
6. Menu/Enter Button – Pressing this button will display the OSD menu for
picture quality adjustments (Brightness, Contrast, Color, Tint & Reset) and
source selection. After accessing the menu, it is used as the Enter function.
7. Select Up Button – For selection of menu items, source selection and
adjustment of picture quality.
8. Select Down Button – For selection of menu items, source selection and
adjustment of picture quality.
9. Screen Release – Slides in the direction of the arrow to release the drop
down screen.
10. LCD Panel – Display the video source and the On Screen Display (OSD).
11. AUX – Auxiliary input jack allows easy connection of an external A/V source.
12. LCD Cut Off Switch – Turns off the LCD backlighting when the screen is in
the closed position.
FRONT PANEL
1287264.P65 11/2/2004, 9:48 AM5

6MM850
TURNING THE MM850 ON OR OFF
1. Sliding the screen release lock forward will unlock the LCD screen and allow it
drop down slightly. Move the screen downward until a comfortable viewing
angle is reached. The internal hinge friction will hold the screen in position while
the system is in use.
2. Press the power button to turn the MM850 on.
3. After the unit is turned ON and begins to display a picture, adjust the viewing
angle by pivoting the screen to optimize the picture quality. (NOTE: The video
source (DVD/VCP/Game will need to be turned on also).
4. Remember to turn the unit OFF and pivot the LCD to the locked position when
not in use.
Power
ON/OFF
Switch
1287264.P65 11/2/2004, 9:48 AM6

7MM850
OPERATION
OVERHEAD DOME LIGHTS
The Dome Lights integrated into the MM850 are controlled by a three position slide
switch. Sliding the switch to the ON position will turn the lights ON. The OFF
position will prevent the lights from turning ON with the vehicle’s interior lighting,
and the auto position will allow the lights to turn ON and OFF with the vehicle’s
interior lighting. Do not leave the vehicle unattended with the dome light switch in
the ON position as this could result in a discharged battery.
Consult the Installation Manual for dome light wiring information.
Dome
Light
Switch
1287264.P65 11/2/2004, 9:48 AM7

8MM850
REMOTE CONTROL SENSOR
The MM850 incorporates an infrared sensor that will relay signals from the remote
control to allow a source connected to the AV1 input to be controlled simply by
pointing its remote control at the remote sensor eye. This provides control of
source equipment such as a Video Cassette Player or DVD Player. The infrared
sensor can relay signals from most manufacturer’s remote controls to the
component connected to the AV1 input, such as a DVD player. In this case you
must use the remote control supplied with the DVD player.
Infrared Transmitter Remote Sensor Eye
1287264.P65 11/2/2004, 9:48 AM8

9MM850
LCD SOURCE
MENU /
ENTER
V
CP
STOP
PLAY
REW FWD
1
4
5
7
10
2
3
6
8
9
1 LCD : Power On / Off Button for the MM850 monitor
2 VCP : Power On / Off Button for an Optional Audiovox VCP
3 SOURCE : Button for selection of AV1 and AUX
4 MENU/ENTER Button
5 – : Select Down Button
6 + : Select Up Button
7 REW : ........Rewinds Tape
8 FWD : ........ Fast Forwards Tape
9 STOP : ........Stops Tape
10 PLAY : ........ Plays Tape
REMOTE CONTROL UNIT BUTTONS CONTROLS
1287264.P65 11/2/2004, 9:48 AM9

10 MM850
PICTURE ADJUSTMENT
When watching the program, the quality of the picture can be adjusted to your
preference.
Press the MENU button, the main menu
will appear. Then press the UP or DOWN
button to select from picture, source or
display off. Press the MENU button again
to select the item. For example: Press the
MENU button, highlight PICTURE using the UP or DOWN buttons. Press the MENU
button to enter the picture adjustment menu. The PICTURE menu will appear,
highlight the item you want to adjust using the UP or DOWN buttons and press the
MENU button to enter. Then press the UP or DOWN button to adjust the selected
item.
Description of Adjustment Items:-
Item Press DOWN button Press UP button
To darken the picture
Decrease the contrast
for soft color
To decrease the color
intensity
Increase the greenish
skin tones
To brighten the picture
Increases the picture
contrast for vivid color
To increase the color
intensity
Inceases the redish skin
tones
To restore the factory settings, select RESET and press the UP or DOWN
button. All of the picture adjustments (BRIGHTNESS, CONTRAST, COLOR and
TINT) will return to the factory settings.
CONTRAST
COLOR
TI NT
RESET
BRIGHTNESS 32
32
32
00
CONTRAST
COLOR
TI NT
RESET
BRIGHTNESS
32
32
00
32
32 BRIGHTNESS 32 BRIGHTNESS
MENU
SOURCE
DISPLAY OFF
PI CT URE
MENU
SOURCE
DISPLAY OFF
PI CT URE
BRIGHTNESS
CONTRAST
COLOR
TINT
1287264.P65 11/2/2004, 9:48 AM10

11MM850
SOURCE SELECT
There are 2 inputs to select from in the SOURCE Select Menu: AV1 and AUX.
To select the source, highlight SOURCE and press the MENU button to enter the
source select menu.
Then, press the UP or DOWN button to select from AV1 or AUX.
Press the MENU button to select the source.
EXITING THE MENU
To exit the main menu, highlight DISPLAY OFF and press the MENU button to
enter, the menu will disappear.
NOTE: The menu will also disappear from the screen automatically if you do
not press any button within five seconds.
MENU
SOURCE
DI SPLAY OFF
MENU
DI SPLAY OFF
SOURCE
SOURCE
AUX
AV1
1287264.P65 11/2/2004, 9:48 AM11

12 MM850
A/V SOURCE SELECTION
AV 1
In most installations, a DVD Player will be connected to the AV1input. To view a DVD,
turn the MM850 ON and press the Menu button, the main menu will appear. Select
SOURCE and then press the menu/enter button. Then press the “UP or DOWN”
button until “AV1” is highlighted on the screen then press the menu/enter button to
confirm your selection. The source can also be selected by pressing the source
button on the remote control.The MM850 is now ready to play the audio and video
signals from the DVD connected to the “AV1” input. Press play on the DVD or on
the DVD remote control to view the DVD. For more information see the operator’s
manual accompanying your DVD player.
AUX
The second AV input may be connected to a DVD player, video game system,
camcorder or other audio/video source connected to the AUX input with the supplied
AV adapter cable. To play the AUX source, turn the MM850 ON and press the Menu
button, the main menu will appear. Select SOURCE and then press the menu/enter
button. Then press the UP or DOWN” button until “AUX” is highlighted on the screen
then press the menu/enter button to confirm your selection. The source can also
be selected by pressing the source button on the remote control.Turn the source
component on with its power button or remote control. The MM850 is now ready to
play the audio and video signals from the source connected to AUX input.
1287264.P65 11/2/2004, 9:48 AM12

13MM850
OPTIONAL ACCESSORIES
WIRED FM MODULATOR (P/N FMM100A)
Your video system can be equipped with an optional RF modulator, that allows you
to listen to the MM850’s audio signal by tuning your vehicle’s radio to the selected
frequency, (88.7 or 89.1- check with your installer) and tuning on the remote mounted
RF modulator switch. (In most cases this toggle switch will be located underneath
the driver’s side of the dash, check with your installer for the exact location.)
Whenever the RF Modulator is ON, broadcast radio reception will be poor. Turning
the remote mounted toggle switch OFF will allow for normal radio reception.
WIRELESS HEADPHONES
The MM850 includes a built in infrared transmitter for use with optional Movies
2 Go wireless headphones (P/N MMIRHS). Turning the Wireless Headphone
switch ON will activate the internal IR receiver and the volume can then be
adjusted separately with the control on each headset. Any number of wireless
headphones can be used, but all must be within direct line of sight of the
transmitter. See the documentation accompanying your Movies 2 Go wireless
headphones for more detailed information.
1287264.P65 11/2/2004, 9:48 AM13

14 MM850
TROUBLESHOOTING
1. When there is No Picture
• Check that the signal source is connected.
• Check that AV1/AUX is selected correctly.
• Check that the signal source is turned on.
2. When the IR Sensor is Inoperative
• Verify that the batteries in the remote are fresh.
• Verify that the remote sensor eye is not obstructed.
• Verify that the infrared transmitter is affixed over the sensor
eye of the component to be controlled.
1287264.P65 11/2/2004, 9:48 AM14

15MM850
SPECIFICATIONS
LCD Backlighting CCFL
Resolution 1440 X 234
Pixels 336,960
Operation Temperature 0 - 60º C
Storage Temperature -20 - 70º C
Expected Backlight life 10,000 Hours
Video Display System NTSC / PAL
Dimensions W x H x D
9.5” x 1” x 8.5”
1287264.P65 11/2/2004, 9:48 AM15

16 MM850
AEC (the Company) warrants to the original retail purchaser of this product that should this product or any
part thereof, under normal use and conditions, be proven defective in material or workmanship within 12
months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned
product (at the Company's option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof
of warranty coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to the
Company at the address shown below.
This Warranty does not extend to the elimination of externally generated static or noise, to correction of
antenna problems, to costs incurred for installation, removal or reinstallation of the product, or to damage
to tapes, discs, speakers, accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered
or been damaged through alteration, improper installation, mishandling, misuse, neglect, accident, or by
removal or defacement of the factory serial number/bar code label(s). THE EXTENT OF THE COMPANY'S
LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE
AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY
PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS
WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 24 MONTHS
FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. No person or representative is authorized to assume for the
Company any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damage so the above limitations or exclusions may not apply to you. This
Warranty gives you specific legal rights and you may also have other rights which vary from state to state.
U.S.A. : AEC, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 "1-800-645-4994
CANADA : CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA
12 MONTH LIMITED WARRANTY
Applies to AEC Mobile Video Products
© Copyright 2004 AEC, 150 Marcus Blvd. Hauppauge, NY 11788
128-7264
1287264.P65 11/2/2004, 9:48 AM16
