1. Product Overview
l 2G / 3G / 4G Global Frequency Bands Supported;
l Support cell ID base LBS(Location base service);
l Support all Global Navigation Satellite Systems (GNSS) that have been
deployed, default GPS+Beidou hybrid mode;
l Support cell ID base LBS (Location base service);
l Ultra-low current consumption, less than 10uA in hibernation mode;
l SIM card is plug-and-play, no current leakage without SIM;
l High-temperature safety explosion-proof rechargeable lithium polymer
battery: charging current> 1A @ 5V;
l Support reset button, you can restart the device without disassembling;
l Support multiple working modes: regular reporting, periodic reporting,
real-time tracking, intelligent tracking, refer to 4.1;
l Support low power alarm, refer to 4.2;
l Built-in rear light detection alarm function or front light detection(optional)
refer to 4.3;
l Support collision alarm and flip alarm, refer to 4.4;
l Support data reporting of rapid acceleration, rapid deceleration, and sharp
turns, refer to 4.5;
l Support weak signal alarm function;
l Support signal recovery alarm function;
l Support real-time reporting of satellite signal strength;
l Support real-time reporting of network signal strength;
l Support real-time reporting of working voltage;
l With powerful magnet, adsorption installation;
l Support WIFI position.

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
2. Product specifications
Characteristic
Description
Battery
Disposable Lithium-ion battery and (3.7V 5400mAh) and
ultra-low discharge rate: less than 1%, store one year
below 25°C
Power consumption
MODE 1/3 sleep current: <10uA
MODE 21 sleep current: <3mA
MODE1/2/3/21 normal working current: <60mA
Standby Time
MODE 1 @ Daily report:> = 600 days
MODE 3 @ Hourly report:> = 30 days
MODE 21 @ Report 2 hours per day:> = 30 days
MODE 2 @ Real-time positioning:> = 4 days
Dimension
68*48*26mm
Weight
100g
Working Temperature
-20°C~80°C
Humidity
5%~95%
Frequency Bands
4G LTE FDD: B1/B2/B3/B4/B5/ B7/ B8/ B20/B28/B66
4G LTE TDD: B38 / B40/B41
2G GSM / GPRS / EDGE: 850/900/1800MHz
GNSS
TD1030, ublox-8030 optional
Channels: 50
Sensitivity: -147dBm
Position accuracy: 3-5 m
Cold start＜30s
Hot start＜5s

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
3. Instructions for use
3.1. Start-up and setup process
Insert the SIM card into the device to turn it on, and then turn it off after
removing the SIM card. The following flowchart indicates a complete
installation and use process.
Remove!SIM!card!
cover!
Insert!the!SIM!card!to!power!on!
the!device!
The!device!works!in!MODE,!21!intelligent!
tracking!mode!by!default.! !
LED!status:!
1) LED!flashing!slowly:!Registered!to!the!
network;!
2) LED!flashing!quickly:!Connected!to!the!
server;!
3) LED!is!always!on:!GPS!fixed;!
!
Open!the!app!login!to!the!system,!and!check!the!
positioning.! Tap! on! the! menu! or! send! server!
command! to! reconfigure! the! working! mode! of!
device,! such! as! regular! reporting,! periodic!
reporting,!etc.!
Assemble!the!SIM!cover!
Find!a!place!to!put!the!equipment!

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
Figure 1, SIM insertion indication
Note:
l Insert SIM card to power on the device, and remove SIM to power off the
device automatically.
l Please make sure the SIM with data service from your operator.
l If your SIM card with a PIN code, please refer to your mobile phone user
manual to remove the PIN code.
3.2. Charging instructions
The device needs to be fully charged before use. It is recommended that a
5V / 2A charger to be used to support the fast charging mode. The charging
time is about 5 hours. The use of different chargers will vary. The red LED
lights up when charging and the green LED lights up when the battery is fully
charged. The charging cable is a standard Micro-USB charging cable.
3.3. Manage your device
1) Manage device on WEB: visit http://www.basegps.com and use the
account and password provided by the dealer to login for device
management and location tracking.
2) Mange device using APP or WeChat: visit the website
http://www.basegps.com and scan the QR code to download the APP or
follow the “Domilink”.

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
3) APP or WeChat login method: Scan the device’s “bar code” or “QR code”
to login in the APP or WeChat. The default password is ”123456” or find the
cipher text that comes with the device package.
4) You can use third party server to management your device, contact us for
more detail information.
4. Common setting commands.
4.1 Reporting logic on different working mode
No.
Command Format
Command Descriptions
1
Position type command:
POITYPE, 0/1/2 #
0: LBS [Report LBS only]
1: LBS + GPS [Priority report to base station, GPS
will be reported after successful positioning]
2: LBS + WIFI + GPS [This device does not support
WIFI]
2
Parameter clear command:
MODECNTCLEAR, 0/1 #
0: Auto, automatically clear MODE 1/2 parameters
after full charge;
1: Forcibly clear the reporting times of MODE 1/3
and the working time of MODE 2/21;
Note:
For mode 1/3, each time it is reported, mode 1 will
increase by 1. Mode 2/21 Every 3 minutes of work,
mode 2 times increase by 1.
3
Intelligent reporting mode
MODE, 21, <T1>, <T2>,
<T3>#Instruction
T1, T2, T3: Time point format for the device to report
regularly after ACC OFF: HHMM
1. When ACC OFF: The device will turn off the GPS,
4G module, and the MCU will go to sleep.

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
2. When ACC ON: the device turns on GPS, 4G
module, MCU wakes up.
How the device wakes up: Any alarm signal of the
built-in G-sensor will wake up the device.
Note:
This command is valid when ACCCTLGNSS, 1 #
Default: MODE, 21,2200 # is the factory default
working mode of the device. And real time ping is
10second
4
Timing reporting mode:
Mode, 1, T1, ..., T5, D #
Mode, 1, T1 #
Mode1, T1, T2, D #
The time of device wake up and report, the format of
T1-T5 is: HHMM stands for 24-hour hour and
minute, D is the reporting period, and the default is 1
for daily reporting, [1, 31].
Example:
MODE, 1,0800,1314,2 #
It means device will wake up at 8:00 and 13:14 every
2 days.
5
Periodic reporting mode:
MODE, 3, T #
T = [5, 1440], The range of T.
Unit: minute
T is the gap time for MODE 3 reporting.
6
Real-time tracking mode:
MODE, 2, T #
T = [5,999], The range or T.
Unit: second
Default value: 10
The position reporting period when the device is
moving.
4.2 Application Notes on Low Power Alarm
Table 4.2 Application Notes on Low Power Alarm
1
Low battery alarm command
LOWW, V, N #
V: a 3-digit integer, the third digit
is the number after the decimal
point;
N: 0/1
If the voltage of the equipment is lower than LOW
30S, a low power alarm will be reported, and it will
be reported once after device is turned on;
N = 0: execute current working mode
N = 1: if it is MODE2, forcibly switch to MODE, 1
Default: LOWW, 360,0 #

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
4.3 Light-Detected Alarm Description
Place the device in a dark place for more than 60S. When the device detect
light from the device window for more than 1S, it will trigger a light-detected
alarm, (sometimes call removal alarm)
1
ALARMMODE,L1/L0
L1: Light-Detected Alarm: Enable [default]
L0: Light-Detected Alarm: Disable
4.4 Vehicle Collision Alarm Parameter setting
Use to adjust parameters according to actual installation and use.
1
GSENCOL, V, T, C #
Used to set the sensitivity of collision alarm.
Default: 32/2/3
V = 1-255, the higher value, the less sensitive.
T = 0-11, the time V keeps.
C = 0-3, the number of interrupts
Different vehicles have different parameters. It is
recommended to set the parameters as follows:
Motorcycle: GSENCOL, 128,3,3 #
Car: GSENCOL, 48,3,3 #
.
4.5 Vehicle Acceleration / Deceleration and Sharp Turn Parameter setting
1
Driving habits algorithm
selection:
GPSGSE, <A> instruction
1. When A = 1, use GPS to calculate rapid
acceleration, rapid deceleration, and sharp turns
2. When A = 0, use G-sesnor to calculate rapid
acceleration, rapid deceleration, and sharp turns
Default: A = 1
When GPSGSE, 1 #, the following settings about angle increment and speed
increment are valid

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
2
CARSET,A,B,C,D#
A: Sharp turn angle: Degree
B: Average turn speed: KM
C: Rapid acceleration increment: KM
D: Rapid deceleration reduction: KM, default:
75,20,8,18
When GPSGSE, 0 #, the following settings about G-sensor are valid
1
GSENACC,A#
Used to set the sensitivity of device acceleration
events (A = 1-6, Default: 5)
The following values indicate that the acceleration
event will be detected from 0 to 100Km/h in X time
range (unit: S).
A = 1, X = 58; A = 2, X = 29; A = 3, X = 19; A = 4, X =
14; A = 5, X = 11; A = 6, X = 9
2
GSENDIR,D#
Used to set the coordinate system of the device (D =
0-15),
The default is D = 5: the GPS antenna is facing the
sky, and the cable is facing the rear of the car.
D = 7: GPS antenna is facing the sky, wire is facing
the front
D = 4; GPS antenna is facing the sky, wire is facing to
the left
D = 6; GPS antenna is facing the sky, wire is facing to
the right
3
GSENCAL,D#
Used to calibrate equipment
When D = 1, the device will calibrate immediately after
receiving this command.
When D = 0, the device will be calibrated next time
after receiving this command.
Note:
It is recommended to adjust the coordinate system
under re-calibration

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
4.6 Time Zone Settings
1
GMT,<A>,<B>,<C>
Set time zone:
A: E or W, represent east and west.
B: 0 ~ 12 time zone
C: half time zone
Example: GMT,E,8,0#
2
USELOCALTZ,1
Associated time zone: The reported data time is
synchronized to the set time zone.
3
USELOCALTZ,0
Non-associated time zone: The default reported data
time is fixed to the time zone of UTC + 8
4.7 Common Query Commands
1
VERSION#
Query software version
2
PARAM#
Query the device parameters
3
STATUS#
Query working status
4
123
Query the device address, the device will force a
position data to be reported to the server after
receiving the 123 command.
5
FACTORY
Restore factory settings, IP and domain names will
not restored.
6
RESET#
Device restart.

ZT09%Long%Life%Tracker%User%Manual%
!
Web:!www.sonaltrack.com!Email:![e-mail]!Ph:!8613857402537!
4.8 Common Setting Instructions
1
SERVER,1,<domain/ip>,<port>
Set server command.
<domain/ip>: server domain or IP
<port>: server port
2
LANG,<language>
Set language.
1: Chinese
0: English
Default: English
3
CENTER,A,<TelNumber>
Set the center number: PARAM # can check the
center number information, which is use for some
remote control.
4
CENTER,D,<TelNumber>
Delete center number.
5
APN,<name>
Set APN.
6
APN,AUTOAPN
Set to automatic APN.
7
RELAY,0/1#
1: Remote control set.
0: Remote control clear.
8
LED,0/1#
Controls whether the LED is always on:
LED, 1 # is always on;
LED, 0 # is off after five minutes (default is 0)
5. Cautions
1) Do not short circuit.
2) Do not put in fire or heat.
3) It is strictly prohibited for users to assemble or disassemble the
battery by themselves.
4) Do not use outside the allowed temperature range.
5) It is strictly forbidden to knock, disassemble or disassemble this
product for repair or modification.
6) The operating temperature environment and usage scenarios of the
device will affect the battery discharge efficiency.
