THERE’S A NEW REASON IT’S CALLED THE GREAT OUTDOORS.

WE’VE GONE TO GREAT WAVE-
LENGTHS TO
DELIVER PRISTINE SOUND.
To the true audio aficionado, everything goes with
music. Dining. Entertaining. Working. Relaxing.
And now, even the great outdoors goes with it
perfectly. Introducing the all-new Mariner®Series
outdoor speakers from Sonance. Acoustical
brilliance designed to hold up under all conditions.
Yours and Mother Natureʼs.
THE SONANCE
MARINER SERIES.

HIGH-FIDELITY.
LOW MAINTENANCE.
One doesnʼt often characterize a sonata as rugged. An
aria as sleek. Or a ballad as versatile. But coming from
the masterful acoustics of a Mariner speaker, thatʼs
exactly what comes to mind. Because Mariner outdoor
speakers artfully blend true audio fidelity with their
surroundings. Protecting deep bass notes and crisp
treble from the harshest of elements is a tough,
paintable, sealed polypropylene enclosure and
perforated aluminum grille. So whether you place
any of the eight contoured models in corners, on
enclosures, you can expect pristine stereo sound
unaffected by the elements and unfettered by the
need for regular maintenance. A good rain or a quick
hosing-down is all that is needed.

Granite Sandstone
INSTALLATION THAT’S
MUSIC TO YOUR EARS.
Utter simplicity finally comes to outdoor speaker
installation. Mariner speakers feature the exclusive
Fastmount®bracket system, enabling you to just push
and lock each speaker into place—no threaded
knobs or extra hardware necessary. Once mounted,
Fastmount makes it possible to pivot speakers a full
180 degrees. Click-stops make movement precise
and repeatable.
NEITHER RAIN, NOR HAIL…
Another Sonance innovation, Protected Access
Connection Terminal (PACT), helps keep connections
dry and safe from harsh weather conditions while
simplifying installation.
A wire entry grommet helps protect
connections from the weather and acts like
an extra hand, holding the speaker wire
in place during installation and mounting.
A protective channel safeguards wires all
the way to the front panel speaker terminals.
After connection, a snug-fitting cover further
protects against moisture and the elements.
THE PERFECT COVER.
All you hear is music when you camouflage
the Mariner Series with the SoundHenge®Redux
collection. These outdoor rock speaker enclosures
are designed to blend into any environment. They
come in a choice of finishes and fit all Mariner
60 and 50-series speakers.

MARINER 82
Tweeter: 1" (25mm) Polyurethane dome
Woofer: 8" (203mm) One-piece black Polypropylene cone with a rubber surround
Frequency Response: 45Hz – 20kHz ±3dB
Impedance: 6 ohms nominal; 4 ohms minimum
Power Handling: 5 watts minimum; 125 watts maximum
Sensitivity: 91dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 14" x 9" x 9-1/4" (356mm x 229mm x 235mm)
MARINER 63
Tweeter: 1" (25mm) Aluminum dome
Woofer: 6-1/2" (165mm) One-piece black Carbon Fiber cone with a rubber surround
Frequency Response: 50Hz – 20kHz ±3dB
Impedance: 6 ohms nominal; 4 ohms minimum
Power Handling: 5 watts minimum; 100 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 12" x 7-1/2" x 7-1/8" (305mm x 191mm x 181mm)
MARINER 62
Tweeter: 1" (25mm) Polyurethane dome
Woofer: 6-1/2" (165mm) One-piece black Polypropylene cone with a rubber surround
Frequency Response: 55Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 80 watts maximum
Sensitivity: 89dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 12" x 7-1/2" x 7-1/8" (305mm x 191mm x 181mm)
MARINER 61
Tweeter: 3/4" (25mm) Polyurethane dome
Woofer: 6-1/2" (165mm) One-piece black Polypropylene cone with a rubber surround
Frequency Response: 60Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 80 watts maximum
Sensitivity: 88dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 12" x 7-1/2" x 7-1/8" (305mm x 191mm x 181mm)
MARINER 52
Tweeter: 1" (25mm) Polyurethane dome
Woofer: 5-1/4" (133mm) One-piece black Polypropylene cone with a rubber surround
Frequency Response: 65Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 70 watts maximum
Sensitivity: 88dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 10-1/4" x 6-1/2" x 6" (260mm x 165mm x 153mm)
MARINER 51
Tweeter: 3/4" (25mm) Polyurethane dome
Woofer: 5-1/4" (133mm) One-piece black Polypropylene cone with a rubber surround
Frequency Response: 70Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 60 watts maximum
Sensitivity: 87dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 10-1/4" x 6-1/2" x 6" (260mm x 165mm x 153mm)
MARINER 62SS
Tweeter: Two 1" (25mm) Polyurethane domes
Woofer: 6-1/2" (165mm) One-piece black Polypropylene cone with a rubber surround, dual voice coil
Frequency Response: 55Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 80 watts maximum
Sensitivity: 89dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 12" x 7-1/2" x 7-1/8" (305mm x 191mm x 181mm)
MARINER 52SS
Tweeter: Two 1" (25mm) Polyurethane domes
Woofer: 5-1/4" (133mm) One-piece black Polypropylene cone with a rubber surround, dual voice coil
Frequency Response: 65Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 70 watts maximum
Sensitivity: 88dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 10-1/4" x 6-1/2" x 6" (260mm x 165mm x 153mm)
MARINER H20
Tweeter: 1" (25mm) Cloth dome, magnetically-shielded
Woofer: Two 5-1/4" (133mm) Magnetically-shielded black Polypropylene cones with rubber surrounds
Frequency Response: 55Hz – 20kHz ±3dB
Impedance: 8 ohms nominal; 4 ohms minimum
Power Handling: 5 watts minimum; 100 watts maximum
Sensitivity: 90dB SPL (2.83V/1 meter) / Grille Material: Perforated aluminum
Dimensions (H x W x D): 7-1/2" x 21" x 7-1/4" (191mm x 533mm x 184mm)
WhiteBlack White GrilleBlack Grille
WhiteBlack
NUMEROUS CHOICES. ALL OF THEM SOUND.
Superb-quality audio transcends boundaries—and the Mariner line of speakers is the vehicle of choice for transporting
that sound flawlessly to the great outdoors. In fact, weʼve created eight different speaker models—including those that
offer full stereo sound in a single unit—to suit just about any application.
WhiteBlack White GrilleBlack Grille
White GrilleBlack Grille
White GrilleBlack Grille
WhiteBlack White GrilleBlack Grille
White GrilleBlack Grille
White GrilleBlack Grille
White GrilleBlack Grille
WhiteBlack
WhiteBlack
WhiteBlack
WhiteBlack

BREAKING SOUND
BARRIERS SINCE 1983.
What began with a set of high-fidelity speakers master-
fully built into the wall, has resulted in one of the most
innovative and respected architectural audio companies
in the world. Sonance has since kept its edge in the
market by developing some of todayʼs most brilliant and
inspired audio products that let you savor your music
among family, friends and guests. From in-wall and
in-ceiling home theater systems to whole-house-yard
and distributed audio, all Sonance innovations are
designed to seamlessly blend sonically superior music
into any home or environment. Our talented engineers
utilize our state-of-the-art anechoic chambers, listening
rooms, and laboratories to create superior product
performance that gives you an unsurpassed audio
experience wherever you enjoy music.
212 Avenida Fabricante
San Clemente, CA 92672-7531
TEL [phone] | 949-492-7777
FAX [phone] | 949-361-5151
© 2005 Sonance, all rights reserved. Sonance, Mariner, FastMount
and SoundHenge are registered trademarks of Dana Innovations.
33-4002 7/05
