Sonance VISUAL PERFORMANCE VP62R TL User manual

THINLINE: VP62R TL, VP62R SST/SUR TL,
VP66R TL, + Square Adapter
Product Family Overview
From the company that invented the category, comes the
BEST SOUNDING, best looking and most complete range of
in-wall and in-ceiling speakers ever. Visual Performance®Series
comes in various shapes and sizes to compliment down lights and
décor and a complete range that allows you to enjoy a consistent
aesthetic for any application in any room.
Features and Benefits
Visual Performance THINLINE speakers feature shallow
2 1/2” and 3 5/32” (64mm and 80mm) depths that
allow installation in areas that will not accommodate
conventional speakers.
Absolute best sonic performance at all price points
•Designedusingstate-of-the-artcomputermodelingsoftware
to vastly improve magnetic field and suspension linearity
for consistent sonic performance at any SPL for
best-in-class performance
Latest high-tech driver and tweeter material technology
•Improvedlowfrequencyperformance
•Improveddriverconematerials
•Lowdiffractionwooferandtweeterdesign
•Pivotingtweeterforimprovedfrequencyresponsein
off-axis installations
•Chamberedtweeterdesignonallmodels
The chambered tweeter design does the following
•Lowerstheresonancefrequencyofthetweeter
•Allowsforalowercrossoverfrequencytothewoofer
•Reducesthebackpressureonthetweeterdome
•Reducesthedistortionofthetweeternearthe
crossover frequency
Easier to install
•EasiertoaccessRoto-Lock®screws
•Removedmetalhangtabs
•One-piecepaintablegrillewithpeelandstickscrimclothfor
easier painting
•Twopiecetogglefeetallowsinstallationwithdoubledrywall
and thicker ceiling and wall materials
VP62R TL VP62R SST/SUR TLVP66R TL Square Adapter w/ Grille
Specifications
Diameter: 93/4”(248mm)
Depth: 35/32”(80mm)
CutOutDiameter: 81/4”(210mm)
9.76 [247.9]
3.10 [78.8]
Diameter
CutOut
Diameter
9.76 [247.9]
3.10 [78.8]
Depth
VISUAL PERFORMANCE®SERIES

SPECIFICATIONS
1" (25mm) cloth dome,
Ferrofluid-cooled, pivoting,
in acoustic back chamber
1" (25mm) powder coated
aluminum dome, Ferrofluid-cooled,
pivoting, in acoustic back chamber
Tweeter
UOM
Woofer
Frequency Response
Impedance
Power Handling
Sensitivity
Grille
Dimensions
(Dia. x D)
Cut-Out Dimensions
(Dia.)
Shipping Weight
9 3/4" x 3 5/32"
(248mm x 80mm)
8 1/4"
(210mm)
9 3/4" x 3 5/32"
(248mm x 80mm)
8 1/4"
(210mm)
Dimensions with
Square Grille (W x H)
9 7/8" x 9 7/8"
(251mm x 251mm)
9 7/8" x 9 7/8"
(251mm x 251mm)
Perforated steel Perforated steel
9 lbs (4.1kg) pair 9 lbs (4.1kg) pair
SKU 93020 93021
89dB SPL
(2.83V/1 meter)
90dB SPL
(2.83V/1 meter)
5 watts minimum;
125 watts maximum
5 watts minimum;
140 watts maximum
8 ohms nominal;
6 ohms minimum
8 ohms nominal;
6 ohms minimum
45Hz – 20kHz ±3dB 43Hz - 20kHz ±3dB
Pair Pair
6 1/2" (165mm)
textured polypropylene cone
with a rubber surround
6 1/2" (165mm) Kevlar /
Nomex laminated cone
with a rubber surround
VP62R TL +VP6SQ
Two 1" (25mm) cloth dome,
Ferrofluid-cooled, pivoting,
in acoustic back chamber
9 3/4" x 3 5/32"
(248mm x 80mm)
8 1/4"
(210mm)
9 7/8" x 9 7/8"
(251mm x 251mm)
Perforated steel
5 lbs (2.3kg) pair
93022
89dB SPL
(2.83V/1 meter)
5 watts minimum;
125 watts maximum
8 ohms nominal;
6 ohms minimum
45Hz – 20kHz ±3dB
Each
6 1/2" (165mm)
textured polypropylene cone with a
rubber surround, dual voice coil
VP62R SST/SUR TL +VP6SQ
VP66R TL +VP6SQ
©2013Sonance.Allrightsreserved.
Sonance,VisualPerformanceandRoto-Lock,areregisteredtrademarksofDanaInnovations.
Duetocontinuousproductimprovement,allfeaturesandspecificationsaresubjecttochangewithoutnotice.
For the latest Sonance product specification information visit our website: www.sonance.com
SONANCE•212AvenidaFabricante•SanClemente,CA92672-7531USA
(800)582-7777or(949)492-7777•FAX:(949)361-5151•TechnicalSupport:(800)582-0772
www.sonance.com
