Sonarto YM-100 User manual

P. 1
P. 5
P. 2 P. 3
P. 4
Bluetooth®
Speaker
YM-100
Please read these instructions thoroughly
before use and retain for future reference.
Instructions for use
Please read all instructions carefully.
Getting started
• Remove the Bluetooth® speaker & accessories from the box.
• Remove all packaging from the Bluetooth® product.
• Retain instructions for future reference.
• Place the packaging inside the box to either store or dispose of safely.
In the box
• Mini Lightup Wireless Speaker
• Micro USB plug to 3.5mm and USB plug
• Instruction manuals
Features
• Enjoy music wirelessly.
• Every time the speaker turns on, it connects to last connected device
automatically.
• Built-in Lithium rechargeable battery.
• Working time : 2~3 hours
SAFETY INSTRUCTIONS
• Keep the unit away from heat sources,
direct sunlight, humidity, water and
any other liquids.
• Do not operate the unit if it has been
exposed to water, moisture or any
other liquids to prevent against electric
shock, explosion and / or injury to
yourself and damage to the unit.
• Do not use the unit if it has been
dropped or damaged in any way.
• Repairs to electrical equipment should
only be performed by a
qualied electrician. Improper repairs
may place the user at serious risk.
• Do not use the unit with wet hands.
• Do not put objects into any of the
openings.
• Keep the unit free from dust, lint etc.
• Do not use this unit for anything other
than its intended use.
• Keep the unit out of reach of small
children.
• This product is not a toy.
• Do not use abrasive cleaning solvents
to clean.
Instructions for Use
Charging Instructions
• The speaker comes with a built in rechargeable battery before using it
for the rst time it is recommended you charge the battery fully.
• Connect the Micro USB charge cable to a computer USB port or a USB
wall charger (not included). And, connect the Micro USB plug to the
charging slot of the speaker. The Red battery charging LED indicator
illuminates while the speaker is being charged. It takes around 3-5
hours for the unit to fully charge. When the battery is low, you can hear
the indicated sound from speaker, please charge the speaker.
Turning on/off the speaker
There is an on/off switch at the bottom of the speaker. You can turn on/off
the speaker with this switch. In order to save power, put the switch to off
position when the speaker is not in use.
Pairing the speaker with Bluetooth® devices (phone or music device)
• Switch on the speaker, you can hear the indicated sound from speaker.
• Place the speaker and Bluetooth® device (phone or music device) so
that they are no further than 3 feet apart; Activate the Bluetooth®
function on your Bluetooth® device (phone or music device). Please
refer to the manufacturer’s instructions for instructions on enabling
Bluetooth® on your device.
• Once you have activated Bluetooth® on your device, select the speaker
“SONAR076720” from the list of available Bluetooth® devices.
ON / OFF switch
Micro USB charging slot

P.8 P.9
P.6 P.7
P.10 P.11
Please note
•Not all mobile phones support all the functions listed above. Please
Using the FM radio
Turn on the metal speaker,and press the Mode button to select the FM
radio mode.Must be inserted the charging cable as an antenna.
(1) Press the Play/Pause button,FM radio will automatic search and will
save automatically
(2) Press the Volume up & Volume down button to select the desired
radio station
TF card playback
After the metal speaker is turned on,insert the TF card slot, it will switch
to micro SD card mode and start playing the music and the Bluetooth
mode will be disconnected. Hold the volume buttons down to adjust
the volume level and press the volume buttons once to adjust to the
previous or next track.
Using Line - in
After the metal speaker is turned on,connect one end of the Micro USB
cable(included) into charging port/Line in jack, the other end of the
3.5mm Line in cable to connect MP3/Smartphone,press the Mode button
to select the Line in mode to play music.
refer to your cell phone’s user’s manual for further information.
•Certain functions and indication tones may vary depending on your
mobile phone.
•When the volume is adjusted to max, you will hear an indication tone.
LED indicators
(3) When play music, blue colour LED will be on.
Power Supply Mode
The wireless speaker is powered by the built-in 3.7V lithium battery. Push
the “OFF/ON”switch to the “ON” position to power on the speaker.
Remarks :
(A) We re
and remember to charge the battery at least once every month.
(B) In any state or during any time, you can charge the built-in battery by
connecting one end of the attached USB charging cable to the PC and the
other end to the USB port of the wireless speaker (it takes about 3 – 4 hours
to fully charge an empty battery).
(C) You can use any DC 5V (1A) power adaptor with USB output port to charge
(not included).
(D) The wireless speaker may not work properly during charging, so please fully
charge the battery and disconnect the USB charging cable before use.
Cleaning & Maintenance
Please use soft cloth to clean the speaker and do not attempt to
disassemble the speaker.
Do’s and Don’ts
Read the following recommendations before using the speaker.
•Do not expose the speaker to liquid, moisture or humidity to avoid the
•Don’t use abrasive cleaning solvents to clean the speaker.
•Do not expose the speaker to extremely high or low temperature as this
will shorten the life of electronic devices, destroy the battery or distort
certain plastic parts.
•Don’t expose the speaker to contact with sharp objects as this will
cause scratches and damage.
damaged.
•Don’t attempt to disassemble the speaker as this can damage the
speaker or cause injury.
Tation
Note : Battery life & charging time may vary based on usage & types of devices used.
•Once paired successfully, you can hear the indicated sound from
speaker.
•You can now start to use the speaker.
following the above steps.
•Once you have paired the speaker with a device, the speaker will
remember this device and will pair automatically when the device’s
Bluetooth®is activated and in range. You do not need to re-pair any
previously connected devices.
•The speaker will attempt to automatically connect to the last device it
was paired with when switched on. If you want to pair it with a new
device, please follow the steps outlined above.
•Once the speaker is paired with your device, the music will transmit
directly to the speaker. Please refer to our device’s user manual for
further information.
reboot to pair.
Bluetooth® ® V4.1
Operating Distance Max. 10m (approx.)
Working Time 2-3 hours (may vary, depend on
music type and volume)
Charging Input DC5V
Speaker Power 3W
Built-in Rechargeable
Lithium Battery
Troubleshooting
1. There is a barrier between the mobile
phone and Bluetooth® speaker, please
clear it away.
2. The distance between the Bluetooth®
unit and connected mobile phone is too
far away, out of normal connection range.
Please put them nearer.
There is a barrier between the mobile
phone and Bluetooth® speaker, please
remove.
Bluetooth® may be
connected and playing
normally, but sometimes,
there is an interruption
Poor Bluetooth®
connection
Other mobile phone or equipment has been
connected before connection, and has not left
yet and Bluetooth® cannot be switched o .
When connection feature is employed again,
the Bluetooth® unit will automatically search
for this Bluetooth® equipment for connection.
First tur the Bluetooth® feature of
Bluetooth® equipment and the next
Bluetooth® equipment can search, pair and
connect normally.
Bluetooth® pair
and connection
fall
s n o i t u l o St l u a F
Made in China
is a trademark on a registered trademark of
Bluetooth®SIG Inc.
This appliance should not be put into the domestic garbage at the end of its useful life, but must be disposed
of atacentral point for recycling of electric and electronic domestic appliances. This symbol on appliance,
instruction manual and packaging puts your attention to this important issue. The materials used in this
appliance can be recycled. By recycling used domestic appliances you contribute an important push to the
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
protection of our environment. Ask your local authorities for information regarding the point of recollection.
Guidelines for protection of the environment
400mAh
LED
V4.2
