01 TheKrixStory
04 BookshelfSpeakers
12 CentreSpeakers
22 FloorStandingSpeakers
32 SubWooferSpeakers
40 ConcealedSpeakers
50 On-WallSpeakers
56 OutdoorSpeakers
62 Accessories

AsateenagerScottKrixwasinlovewithsound.Scotttinkeredinthegarage
withkitampliers,andmadeexperimentalspeakerswithscavengeddrivers
fromoldradios.ScotthadadreamtomakeAustralianspeakersthatcould
competesuccessfullyontheworldmarket.
Morethan34yearson,Scott’sdreamisnowareality.TheKrixteam
manufacturehighqualityloudspeakersforhomeandcommercialuse.With
closeto2100commercialcinemainstallationsglobally,youhavepossibly
alreadyexperiencedKrixsound.
Distributedthroughouttheworld,Krixareattheleadingedgeofloudspeaker
design.Utilisingthelatesttestequipment,3Dmodellingandcomputer
simulateddesigntechnology,Krix’sinnovativeresearchanddevelopmentteam
areapioneeringforceintheAustralian
loudspeakerindustry.
Whetheryouarelookingforyourrst
pairofstereospeakersoryourown
ultimatehometheatreexperience,Krix
willexceedyourexpectations.Krix’s
rangeofloudspeakersdeliverthe
experienceofsound.
the krix story

Scott Krix founder and designer

Bookshelf Speakers

Krix’srangeofcompactspeakersdeliverunprecedented
soundqualityforsize.Designedforstereoorhometheatre
use,thesebookshelfmodelsconveyhighdelitysoundthatisunmatchedin
thiscategory.Solidconstructionfeatures,internalbracing,standardandcustom
nishesusingrealwoodveneersorpaintlacquers.

dynamic experience

Frequency Range 75Hz-20kHzinroomresponse
Power Handling Maximum60wattsRMSamplierpower
Sensitivity 87dBfor2.83voltsat1metre
Conguration 4inch2-way
Bass Driver Fibrereinforcedmouldedpolymerbasket 
withanominal100mm(4”)doped
papercone.25mm(1”)voicecoil
woundonhighpoweredaluminiumformer.
Doublemagnetshielded
Tweeter 25mm(1”)fabricdome.Ferrouidcooled 
Neodymiummagnet
Crossover Point 3kHz
Impedance Nominally6ohms
Enclosure Type Bassreex,rearvented
Dimensions 230mmhighx150mmwidex190mmdeep
Material 12mmMDF
Finish Vinylorlacqueredtimberveneer
Volume 3litresinternal
Weight 3kgeach
Mounting Provisionsmadeforbracketmounting
7
Brixisdesignedtobesmallinsizeyetbiginsound,deliveringdetailedaccuracy
andstunningclarity.Versatileforanyapplication,fromcompactstereospeakers,
rearchannelspeakersinyoursurroundsoundsystemorforuseinasecond
zone,Brixareideal.Thetwo-waybassreexdesign
featuresa25mmtextiledometweeteranda100mm
diameterbassdriver.Brixisalittlespeakerthatwilloffer
adynamicexperience.
“What was simply stunning was the stereo imaging that’s
possible with the Brix, particularly if you stand-mount
them around a metre out from a rear wall. With some
careful positioning, we were rewarded with sound that
was almost headphone-like in its spatial treatment of the
two channels.” –AustralianHi-Fi

phenomenal experience

Frequency Range 45Hz-20kHzinroomresponse
Power Handling Maximum100wattsRMSamplierpower
Sensitivity 88dBfor2.83voltsat1metre
Conguration 5inch2-way
Bass Driver Castaluminiumbasketwithanominal 
130mm(5”)dopedcurvilinearpapercone.
25mm(1”)voicecoilwoundonhigh
poweredaluminiumformer,withcopper
shortingring.Ventedanddouble
magnetshielded
Tweeter 28mm(1”)dopedfabricdome.Ferrouid
cooled.Doublemagnetshielded
Crossover Point 1.8kHz
Impedance Nominally6ohms
EnclosureType Bassreex,rearvented
Dimensions 295mmhighx175mmwidex235mmdeep
Material 12mmMDFwithinternalbracing
Finish Vinylorlacqueredtimberveneer
Volume 8litresinternal
Weight 6kgeach
Mounting Provisionsmadeforbracketmounting
9
Developedtodispelthemyththatsmallspeakerscannotsoundbig,the
Equinoxdeliversphenomenalsoundforsize.Foruseinanyhighdelity
application,theEquinoxhasnocompetitioninthisclass.Featuringultralow
uxleakageshieldingonthe130mmbassdriverand
28mmtweeter,theEquinoxcanbeplacedclosetoyour
television.Equinoxareaphenomenalexperience.
“A High End Loudspeaker For A Bargain Price – The
question must be: what faults has this little boy? My
skilled and experienced friend has also had problems to
point out any serious faults in the three weeks while the
Krix Equinox have played daily, both as a test object and
purely and simply as a music promoter. Possible faults
must lie in the limitations, which is the actual size. Facts
are that this product must have been subject to a long,
and at times laborious amount of tweaking and maturing
with a producer who has gone to unusually professional
lengths to make it work.” –AudioMagazine–Norway

digital dimension experience

Frequency Range 50Hz-20kHzinroomresponse
Power Handling Maximum110wattsRMSamplierpower
Sensitivity 89dBfor2.83voltsat1metre
Conguration Pointsourcedual5inch2-way
Bass Drivers Fibrereinforcedmouldedpolymerbaskets
with2xnominal130mm(5”)doped
papercones.25mm(1”)voicecoil
woundonhighpoweredaluminiumformer.
Doublemagnetshielded
Tweeter 26mm(1”)fabricdome.Ferrouidcooled
Crossover Point 2.6kHz
Impedance Nominally6ohms
Enclosure Type Bassreex,rearvented
Dimensions 435mmhighx185mmwidex265mmdeep
Material 17mmMDF
Finish Vinylorlacqueredtimberveneer
Volume 14litresinternal
Weight 9kgeach
11
TheKDXLoudspeakerSystemcomprisestheKDX-M(main/rear)andthe
KDX-C(centre).Althoughdesignedprimarilyfora5,6or7channeldigital
soundexperience,theKDXsystemisalsothebasisforahighqualitystereo
systeminacompactbookshelfdesign.Themajorfocus
istoprovideprecisetimbralmatchingtotheleft,centre,
rightandrearchannelwhichisachievedbyusingidentical
cabinets,dual130mmbassdriversand26mmtweeterfor
eachloudspeaker.Availableaspairs(KDX-M)orasasingle
unit(KDX-C)thedigitaldimensionisamusttoexperience.
“Not only do the KDX deliver the cinematic goods in
exemplary style, they’re one for the cerebral music
lover too.” –AudioandVideoLifestyle–Australia

Centre Speakers

MakeeverychairthebestseatinyourhousewithaKrix
centrespeaker.Krix’scentrespeakersreproducevocals
andothercomplexinformationaccurately,optimizing
imagingandsoundstage.Thecentrechannelinyour
hometheatresystemcandeliveraround70%oftheactionandshouldbeof
asimilarsonicqualitytoyourmainspeakers.Forhometheatreapplications
andmusiclisteningpleasure,aKrixcentrespeakerwillenhanceyoursound
experience.Krixcentrespeakers(excludingtheEpicentrix)aremagnetically
shieldedtoallowplacementclosetoyourtelevision.

discreet experience

Frequency Range 75Hz-20kHzinroomresponse
Power Handling Maximum80wattsRMSamplierpower
Sensitivity 87dBfor2.83voltsat1metre
Conguration Pointsourcedual4inch2-way
Bass Drivers Fibrereinforcedmouldedpolymerbaskets
with2xnominal100mm(4”)doped
papercones.25mm(1”)voicecoilwound
onhighpoweredaluminiumformer
Doublemagnetshielded
Tweeter 25mm(1”)fabricdome.Ferrouidcooled 
Neodymiummagnet
Crossover Point 2kHz
Impedance Nominally8ohms
Enclosure Type Bassreex,rearvented
Dimensions 150mmhighx360mmwidex145mmdeep
Material 12mmMDF
Finish Vinylorlacqueredtimberveneer
Volume 5litresinternal
Weight 4kg
 

15
MicroCentrixiscompactwhileprovidingdetailedvocalimagery.Comprising
dual100mmbassdriversmatchedwitha25mmtweeterthiscompactspeaker
deliversamazingdepthandclaritydemandedbymovie
soundtracks.Recommendedforusewithsmallersystems,
thisspeakerwilldeliveradiscreetexperienceplacedeither
ontopofyourtelevisionorinacabinet.

kdx centre digital dimension experience

Frequency Range 50Hz-20kHzinroomresponse
Power Handling Maximum110wattsRMSamplierpower
Sensitivity 89dBfor2.83voltsat1metre
Conguration Pointsourcedual5inch2-way
Bass Drivers Fibrereinforcedmouldedpolymerbaskets
with2xnominal130mm(5”)doped
papercones.25mm(1”)voicecoilwoundon
highpoweredaluminiumformer.
Doublemagnetshielded
Tweeter 26mm(1”)fabricdome.Ferrouidcooled
Crossover Point 2.6kHz.ThemajorfocusoftheKDX-M/ 
KDX-Csystemwastoprovideprecisetimbral
matchingtoall5channels,byusingidentical
cabinets,bassdriversandtweetersforeach
speaker.Theonlydifferenceisfoundinthe
crossovernetworkfortheKDX-C,because
thecentrechannelishorizontallyalignedand
placedontopofatelevisionorinacabinet.
Thiscreatesadditionallowfrequencyfor
whichthecrossovercompensates.
Impedance Nominally6ohms
Enclosure Type Bassreex,rearvented
Dimensions 185mmhighx435mmwidex265mmdeep
Material 17mmMDF
Finish Vinylorlacqueredtimberveneer
Volume 14litresinternal
Weight 9kg
17
TheKDXsystemisdesignedprimarilyfora5,6or7channeldigitalsound
experience,butisalsothebasisforahighqualitystereosysteminacompact
bookshelfdesign.TheKDXsystem,comprisestheKDX-M(main/rear)andthe
KDX-C(centre).Themajorfocusistoprovideprecisetimbralmatchingtothe
left,centre,rightandrearchannelwhichisachievedbyusingidenticalcabinets,
dual130mmbassdriversand26mmtweeterforeach
loudspeaker.Availableaspairs(KDX-M)orasasingleunit
(KDX-C)thedigitaldimensionisamusttoexperience.
“On all my audiophile CDs I heard tremendous depth – it
really sounded like some of the musicians were 20 feet
behind the room’s front wall. The imaging on the percussion
instruments was nothing short of amazing; it seemed like
the percussionists were right there between the speakers.”
–HomeTheaterMagazine–USA

essential experience
