Sonero X-AVT100 User manual

BIDIRECTIONAL HDCP CONVERTER
INSTRUCTION MANUAL
X-AVT100
EN
Version: 2018-06-06

TABLE OF CONTENT
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Delivery Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connection Plan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Warranty and Liability . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposel of the Device. . . . . . . . . . . . . . . . . . . . . . . . . 10
FCC compliance statement . . . . . . . . . . . . . . . . . . . . . . 10
Disclaimer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
- 2 -

INTRODUCTION
The Bidirectional HDCP Converter is the ideal solution to overcome
problems relating to HDCP, specically ones with a mix of old and new
HDCP versions. This small inline unit features a HDCP Engine that can
upgrade from v1.4 to v2.2 or downgrade v2.2 to v1.4 depending on your
requirements. Easy to read LEDs provide a quick way to determine the
system conguration and setup, showing both the input and output HDCP
version. The converter features intelligent recognition of your devices
to determine the most suitable HDCP setup. Perfect if you have an old
amplier, Sky Q box or TV that doesn’t support v2.2 but has 4k capability,
this unit covers it all. No need to replace expensive components in your
system, simply use this small, compact, affordable HDCP Converter.
Please Note: This converter does not strip HDCP
INTENDED USE
This product is intended for indoor use only. Do not use it outdoors. Contact
with moisture, e.g. in bathrooms, must be avoided under all circumstances.
For safety and approval purposes (CE), you must not rebuild and/or modify
this product. If you use the product for purposes other than those described
above, the product may be damaged. In addition, improper use can cause
hazards such as short circuiting, re, electric shock etc.
Read the instructions carefully and keep them. Make this product available
to third parties only together with its operating instructions.
- 3 -

SAFETY INSTRUCTION
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the
warranty/guarantee.
The device is not a toy. Keep it out of the reach of children and pets.
Do not leave packaging material lying around carelessly. These may
become dangerous playing material for children.
Suffocation Risk! Keep packaging materials away from children!
Protect the product from extreme temperatures, direct sunlight, strong jolts,
high humidity, moisture, ammable gases, vapors and solvents.
Do not place the product under any mechanical stress.
If it is no longer possible to operate the product safely, take it out of
operation and protect it from any accidental use. Safe operation can no
longer be guaranteed if the product:
• is visibly damaged,
• is no longer working properly,
• has been stored for an extended period in poor ambient conditions or
• has been subjected to any serious transport-related stresses.
Please handle the product carefully. Jolts, impacts or a fall even from a low
height can damage the product.
Also observe the safety and operating instructions of any other devices
which are connected to the product.
Consult an expert when in doubt about the operation, safety or connection
of the device.
- 4 -

DELIVERY CONTENTS
1x Bidirectional HDCP Converter
1x Micro USB Cable, Length: 0.80m
1x Instruction Manual
FEATURES
HDCP v2.2 to v1.4 Conversion
HDCP v1.4 to v2.2 Conversion
HDMI 2.0 18G pass-through up to 4k 60Hz 4:4:4 8bit
Provides HDMI Jitter Cleaning on the signal path
SPECIFICATIONS
Product Size in mm: 70x37x12mm
Housing Material: ABS
Input: HDMI, Micro USB, 5V DC 1A
Output: HDMI
Environmental Conditions
Operating Humidity: 5~95% Rh
Operating Temperature: 0°C ~ 70°C
Ambient Temperature: 0°C ~ 40°C
Storage Temperature: -40°C ~ 125°C
- 5 -

CONNECTION PLAN
HDMI IN HDMI OUT
Micro USB
- 6 -

INTERFACE
5V DC, 1A
PureLink GmbH
Von-Liebig-Str. 10
D-48432 Rheine
MADE IN CHINA
MODEL NO.:
X-AVT100
CHARGE NO.:
XXXX
- 7 -

OPERATION
The Bidirectional HDCP Converter will convert either HDCP v1.4 to HDCP
v2.2 or HDCP v2.2 to v1.4. If both devices have the same HDCP version
then the unit will operate in a pass through mode.
To use simply connect a HDMI cable from your source to the input and a
HDMI cable from the output to the display. A USB Micro-B port is provided
if your source does not provide enough power.
LEDs indicate the input and output HDCP version, Red LED – v1.4, Blue LED
- v2.2. No LEDs indicate that no HDCP is present on the source.
MAINTENANCE
There are no components located inside the product that require
maintenance. Never open or attempt to dismantle the product.
Maintenance, modications and repairs are to be performed exclusively by
an expert or at a qualied shop.
If you have questions which remain unanswered by these operating
instructions, contact our technical support service or other technical
personnel.
CLEANING
Before cleaning the product, it must be disconnected from all other
connected products.
Only use dry and soft cloth to clean the product housing of the.
Do not use abrasives or solvents.
- 8 -

Do not use any aggressive cleaning agents, rubbing alcohol or other
chemical solutions as they can cause damage to the housing or cause
malfunctions.
To clean the product, use a soft, dry cloth. Do not apply too much pressure
to the housing as this may cause scratch marks.
You can easily remove dust using a soft bristled brush.
WARRANTY AND LIABILITY
The manufacturer guarantees full statutory warranty terms on all new
devices.
As the manufacturer has no inuence on installation, warranty only applies
to the product itself.
If any fault or damage is detected on your product, please contact your
dealer and provide your sales slip or invoice as evidence of the purchase, if
necessary. Your dealer will repair the fault either on site, or send the device
to the manufacturer. You make the work of our technicians considerably
easier, describing possible faults in detail – only then can you be assured
that intermittent faults, will be found and repaired with certainty!
The manufacturer is not liable for damages to persons or property caused
by improper installation, operation or maintenance, not described in this
manual.
Do not alter or modify the product or its accessories.
Any use other than described in this user`s manual is not permitted and
causes loss of warranty, loss of guarantee, and non-liability.
- 9 -

CE CONFORMITY
PureLink GmbH hereby declares that this product X-AVT100
complies with Directive 2014/30/EU.
The full text of the EU Declaration of Conformity is available at
the following Internet address:
www.purelink.de/ce/4251364709771_CE.pdf
DISPOSEL OF THE DEVICE
WEEE-Reg. No.: DE 93 847 290
According to the European WEEE directive, any electrical and
electronic equipment must not be disposed of along with
consumer waste. As a consumer, you are committed by law to
deposit electrical and electronic devices at public collecting points
or to the dealer for free at the end of the device’s lifetime. Details are
regulated in the respective national legislations. The Wheelie Bin symbol on
the product, in the manual or on the packaging refers to these terms. With
the return of your used devices you actively take part in protecting the
environment.
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
- 10 -

Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Important: Changes or modications to this product not authorized by
PureLink could void the electromagnetic compatibility (EMC) and wireless
compliance and negate your authority to operate the product.
This product has demonstrated EMC compliance under conditions that
included the use of compliant peripheral devices and shielded cables
between system components. It is important that you use compliant
peripheral devices and shielded cables between system components to
reduce the possibility of causing interference to radios, television sets, and
other electronic devices.
- 11 -

Exposure to radio frequency energy The radiated output power of this
device meets the limits of FCC/IC radio frequency exposure limits. This
device should be operated with a minimum separation distance of 20 cm (8
inches) between the equipment and a person’s body.
Responsible party (contact for FCC matters only):
PureLink GmbH
Von-Liebig-Straße 10
48432 Rheine
Germany
DISCLAIMER
This product complies with the statutory national and European
requirements. All company names and product names are trademarks of
their respective owners.
All rights reserved.
We reserve our right for misprints and changes to the device, packaging
or user manual.
HDMI®is a registered trademark of HDMI Licensing Administrator, Inc.
Sonero®
PureLink GmbH
Von-Liebig-Straße 10
D-48432 Rheine
[email protected]
www.purelink.de
- 12 -
