thomann Botex NETcon 8-3 User manual

NETcon 8-3 / 8-5
ArtNet DMX converter
User manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
18.10.2019, ID: 464561, 464598

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 15
4 Installation and starting up................................................................................................................ 16
5 Connections and controls................................................................................................................... 18
6 Operating.................................................................................................................................................... 21
6.1 Menu overview................................................................................................................................. 28
7 Technical specications....................................................................................................................... 29
8 Plug and connection assignment.................................................................................................... 31
9 Protecting the environment.............................................................................................................. 33
Table of contents
NETcon 8-3 / 8-5 3
ArtNet DMX converter

4NETcon 8-3 / 8-5
ArtNet DMX converter

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
NETcon 8-3 / 8-5 5
ArtNet DMX converter

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
6NETcon 8-3 / 8-5
ArtNet DMX converter

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Text inputs that are carried out on the device are indicated by typewriter font.
Example: 2323
Letterings
Displays
Text input
General information
NETcon 8-3 / 8-5 7
ArtNet DMX converter

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General information
8NETcon 8-3 / 8-5
ArtNet DMX converter

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
NETcon 8-3 / 8-5 9
ArtNet DMX converter

2 Safety instructions
This device is designed to convert DMX signals into ArtNet signals or vice versa. Use the device
only as described in this user manual. Any other use or use under other operating conditions is
considered to be improper and may result in personal injury or property damage. No liability
will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
10 NETcon 8-3 / 8-5
ArtNet DMX converter

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or re. If in doubt, seek advice from a registered electrician.
Safety instructions
NETcon 8-3 / 8-5 11
ArtNet DMX converter

NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
Safety instructions
12 NETcon 8-3 / 8-5
ArtNet DMX converter

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Safety instructions
NETcon 8-3 / 8-5 13
ArtNet DMX converter

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or re.
NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC oor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad
oor protectors or a carpet.
Safety instructions
14 NETcon 8-3 / 8-5
ArtNet DMX converter

3 Features
Bidirectional ArtNet DMX converter for professional demands with the following features:
nConguration via display on the device
nAdjustable DMX repetition rate (10 … 40 Hz)
n4096 channels
nUp to eight DMX universes
nLEDs to visualize the transmission status of network and DMX signal
nSupported protocols: DMX, RDM, ArtNet, sACN
nClear OLED display (four lines each with a maximum of 16 characters)
n2 × lockable RJ45 Ethernet port
n8 × XLR in / output socket (female), 3-pin (item no. 464561) or 5-pin (item no. 464598)
nPower Twist in and outputs (on the back)
n19" rack-mountable
Features
NETcon 8-3 / 8-5 15
ArtNet DMX converter

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Installation and starting up
16 NETcon 8-3 / 8-5
ArtNet DMX converter

The unit has been designed for rack mounting in a standard 19-inch rack; it occupies one rack
unit.
The converter is connected to a computer network via one of the Ethernet interfaces or via an
Ethernet switch or directly to a PC or notebook. The data is transferred to the converter and
then sent internally to the XLR connectors for the DMX output. If more than eight universes are
needed, the other Ethernet interface can be used to daisy chain multiple converters.
The data can also be received via the correspondingly congured DMX connections and trans‐
mitted via the Ethernet interfaces to a set IP address or via a broadcast device via ArtDMX.
Rack mounting
Data connections
Installation and starting up
NETcon 8-3 / 8-5 17
ArtNet DMX converter

5 Connections and controls
Front NETcon 8-3 (464561) and
NETcon 8-5 (464598)
Connections and controls
18 NETcon 8-3 / 8-5
ArtNet DMX converter

1[USB]
USB interface for updates
2 Rubber feet
3 OLED display (4 lines of 16 characters each)
4 Operating key panel
[Up]: Increases the value by one
[Down]: Decreases the value by one
[Back]: Menu level up
[Setup]: Conrms the selection
: Calls up the lock screen or activates the display.
5 Network input (RJ45)
6 Network output (RJ45)
7 8 × DMX connection socket, XLR, 3-pin (item no. 464561)
8 8 × DMX connection socket, XLR, 5-pin (item no. 464598)
Connections and controls
NETcon 8-3 / 8-5 19
ArtNet DMX converter

9 Power Twist input socket
10 Power Twist output socket
Rear panel
Connections and controls
20 NETcon 8-3 / 8-5
ArtNet DMX converter
