Sonic Blue DVP853 User manual

User's Guide
DVP853 DVD Player
DP00-L0021M
7835 E. McClain Drive
Scottsdale, AZ 85260
www.sonicblue.com
[phone]

Introduction
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Safety Precautions
WARNING
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION
POUR EVITER LES CHOCS ELECTRIQUE, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.
ATTENTION
This Digital Video Disc Player employs a Laser System. To ensure proper use of this product, please read this owner's manual carefully and retain for future reference, should the unit require maintenance, contact an authorized service location-see service procedure. Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to a laser beam, do not try to open the enclosure. Visible laser radiation exists when the enclosure is open. DO NOT STARE INTO BEAM.
CAUTION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.
FCC NOTICE
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVERTISSEMENT
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated 'dangerous voltage' within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important-
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
1
This class B digital apparatus meets all requirements of the Canadian Interference- Causing Equipment Regulations. Cet apparel numŽruque de la classe B respecte toutes les exigences du R•glement sur le matŽriel brouilleur du Canada.
RECORD YOUR MODEL NUMBER MODEL NO. SERIAL NO. The model and serial number of your new DVD player are located on the back of the DVD player cabinet. For your future convenience, we suggest that you record these numbers here:
INDUSTRY CANADA REQUIREMENT
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
DTS
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
FCC WARNING
2
CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1

Introduction
Important Safety Instructions
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY. 1. Read owner's manual
After unpacking this product, read the owner's manual carefully, and follow all the operating and other instructions.
6. Water and Moisture
Do not use this product near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool and the like.
7. Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
8. Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
9. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
10. Lightning
For added protection of this product during storms, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to lightning and power-line surges.
11. Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
12. Attachments.
Do not use attachments not recommended by the product manufacturer as they may cause hazards.
2. Power Sources
This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
3. Grounding or Polarization
This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
4. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
5. Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER'S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
CAUTION
3
13. Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer's instructions, and should use a mounting accessory recommended by the manufacturer. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.
14. Disc Tray
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
15. Stacking
Do not place a heavy object on or step on the product. The object may fall, causing serious personal injury and serious damage to the product.
16. Connecting
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.
17. Sound Volume
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.
18. Sound Distortion
Do not allow the product to output distorted sound for a long time. It may cause speaker overheating and fire.
19. Headphones
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.
20. Laser Beam
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser beam. It may cause sight damage.
21. Disc
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.
23. Servicing
Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
24. Replacement parts
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
25. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
22. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) b) c) d) e) f)
When the power-supply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the product. If the product has been exposed to rain or water. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls my result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation. If the product has been dropped or damaged in any way. When the product exhibits a distinct change in performance-this indicates a need for service.
4

Introduction
Precautions
When shipping the DVD player, always use the original shipping carton and packing materials. For maximum protection, repack the unit as it was originally packed at the factory. Do not use volatile liquids, such as insect spray, near the DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. They will leave marks on the finish. The top and rear panels of the DVD player may become warm after a long period of use. This is normal and not a malfunction. When the DVD player is not in use, be sure to remove the disc and turn off the power. If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally.
Notes on Handling Notes on Locating Notes on Cleaning To Obtain a Clear Picture
When you place this DVD player near a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. In this case, move the DVD player away from the TV, radio, or VCR.
Use a soft, dry cloth for cleaning. The DVD player is a high technology, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality becomes poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every 1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.
For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzene, as they may damage the surface of the DVD player. If you use a chemical saturated cloth to clean the unit, follow that product's instructions. Warning : Cleaning and adjustment of lenses and/or other components of playback mechanism should be performed by a qualified service technician.
Moisture condensation damages the DVD player. Please read the following carefully.
Notes on Moisture Condensation
Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the opti- cal pick-up lens inside this unit, one of the most cru- cial internal parts of the DVD player.
Moisture condensation occurs during the following cases.
When you bring the DVD player directly from a cold place to a warm place. When you use the DVD player in a room where you just turned on the heater, or a place where the cold wind from the wind conditioner directly hits the unit. In summer, when you use the DVD player in a hot and humid place just after you move the unit from an air conditioned room. When you use the DVD player in a humid place.
Do not use the DVD player when moisture condensation may occur. If you use the DVD player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the DVD player to the wall outlet, turn on the DVD player and leave it "ON" for two or three hours. After two or three hours, the DVD player will have warmed up and evaporated any moisture. Keep the DVD player connected to the wall outlet and moisture condensation will seldom occur.
5
Notes on Discs
This section shows you how to handle, clean, and store discs.
Do not touch the playback side of the disc. Do not attach paper or tape to discs.
On Handling Discs On Storing Discs
Do not store discs in a place subject to direct sunlight or near heat sources. Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier. Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.
Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outward with a soft cloth. Always keep the disc clean. If you cannot wipe off the dust with a soft cloth, wipe the disc lightly with a slightly moist- ened soft cloth and finish with a dry cloth. Do not use any type of solvents such as thinner, benzene, commercially available cleaners or anti-static spray for vinyl LPs. They may damage the disc.
On Cleaning discs About This Owner's Manual
This owner's manual explains the basic instructions of this DVD player. Some DVD video discs have functions that may not be explained in this owners manual. Therefore, some instructions may differ from this owner's manual, and there may be extra instructions. In this case, follow the instructions displayed on the TV screen or package. " " may appear on the TV screen during operation. This icon means the function explained in this owner's manual is not available on that specific DVD video disc.
6

Playable Discs
This DVD player can play back the following discs.
You cannot play back discs other than those listed above. (CD-ROM, CD-G, photo CD, and CD-i discs can not be played on this DVD player.)
Region Management Information: This DVD Player is designed and manufactured to respond to the Region Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that disc. The Region number of this DVD player is.
Audio+Video
(moving
pictures)
Audio
12 cm Approx. 4 hours (single sided disc)
Approx. 8 hours (double sided disc) Approx. 160 minutes (double sided disc) 74 minutes 20 minutes Approx. 80 minutes (single sided disc)
12 cm
8 cm 8 cm
Disc Requirements/Copyright Information
Disc mark
(USA/CANADA)
DVD
video
discs
Audio
CDs
Contents Disc size Maximum playback time
Region Management Information
You may not be able to play back some DVD video discs on this player if they were purchased from outside your geographic area or made for business purposes. When you try to playback an unauthorized disc, "Check Regional Code" appears on the TV screen.
Notes on Unauthorized Discs
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material without permission. DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual propertly rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Notes on Copyright
1
7
Index
Using the
setup menu
Operation
with an
MP3 disc
Introduction Disc Requirements/Copyright Information Front Panel & Display Rear Panel Remote Control
Dentification
& Controls
and Indicators
16 17 18 20 22 23 26 27 29 30 31 32 33
34 35 38 39
Operation
Basic Playback Displaying the playback status Searching for a specific screen/song during playback Setting a custom view Changing the audio/subtitle language Changing the size and angle of the screen
Operation with an MP3 disc Accessories Troubleshooting Guide Specifications Using the Setup menu Selecting a subtitle language Setting the VIDEO Setting the SPEAKER Setting the AUDIO CUSTOM settings Setting rating level and password
8
Installation
Connecting to a TV Connecting to an audio system - Connecting to a 2CH amplifier - Connecting to a Digital amplifier
13 14 15
1 7 9
10 11

9
Rear Panel
Dentification
& Controls
and Indicators
10
Front Panel & Display
1 2 3 4
10
Front Panel
Standby LED Power button Disc tray Tray open/close button
5 6 7 8
Stop button Chapter, track skip buttons Playback/Pause button Display window
1 2 3 4 5
VFD Display
Menu display DTS output display Playback/Pause display Disc type display Repeat playback display
6 7 8 9
DOLBY DIGITAL sound display
Frame angle display VIDEO/AUDIO/TRACK program display Title/chapter display Track message display
S-VIDEO OUT
MIXED AUDIO
OUT
DIGITAL AUDIO OUT
COMPONENT
OUT
VIDEO
COAXIAL OPTICAL
LY
Pr
RPb
1 2
3 4
1 2 3 4
Rear Panel
S-VIDEO OUTPUT TERMINAL Connection to a TV with an S- video input terminal MIXED AUDIO/VIDEO OUTPUT TERMINAL Connection to a TV input terminal COMPONENT VIDEO OUT TERMINAL Connection to a TV with a component video input terminal. DIGITAL AUDIO OUTPUT TERMINAL Connection to a Dolby Digital amplifier
OPEN/CLOSE
PLAY/PAUSE
STOP SKIP SKIP
::
TITLE
MENU A-B ANGLE
PROG
ALL
CHAPTER
MP3
DVD
1
1 2 3 4 5 6 7
8
10
9
2 3 4 5 6
78
::
STANDBY/ON
DVD / CD / MP3 PLAYER DVP853
DIGITAL

Remote Controller
11
Remote Controller
NOTE
The symbol displayed on the screen when a button is pressed on the remote control means that function is inactive for the disc that is currently being played.
12
Dentification
& Controls
and Indicators
3
7
8
11
12
13
10
15
16
18
19
21
23
24 25
POWER button NUMBER buttons PROGRAM button For playback in a specified order SCAN/SLOW buttons For fast and slow playback STOP button SKIP button For skipping to the next chapter or song track MENU button For displaying the menu contained on the disc Arrow buttons For selecting and executing items in the setup menu REPEAT button For repeated playback of disc titles, chapters or sound tracks. AUDIO button For selecting the audio language SUBTITLE button For selecting the subtitle language STEP/SLOW button For playing one frame at a time or slow playback MUTE button OPEN/CLOSE button ZOOM button For magnifying the screen
3D Surr button For stereophonic sound effect DISPLAY button For checking the current disc status SETUP button For initial DVD player settings CLEAR button To erase a program content PLAY/PAUSE button TITLE button For selecting a title on the disc REPEAT A-B button For specifying and repeating playback of a segment. GOTO button For jumping to a specified location MARK button For saving and viewing a specified scene. ANGLE button For viewing scenes from different angles.
1 2 3 4 6 5 7 8 9
11
12 13 14 15
10
16
17 18 19 20 21 22 23 24 25
POWER
CLEAR PROGRAM
ENTER
1 456 789
0
23
OPEN/CLOSE
A
U
D
I
O
M
A
R
K
A
N
G
L
E
M
U
T
E
1
2
14
3D SURR
STEP/SLOW
GOTO
ZOOM
DISPLAY REPEAT
REW
S REW S FWD
STOP PLAY/PAUSE
FWD
A-B
22
9
17
4
6
5
20

Connecting to a TV
13
Connecting to an audio system
14
Installation
to
any
DIGITAL AUDIO OUT
any
SOCKET
SOCKET
SOCKET
DIGITAL AUDIO OUT
an
SOCKET
to
SOCKET
SOCKET

Connecting to an audio system
15
Basic Playback
16
1
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH FRENCH GERMAN ITALIAN SPANISH DUTCH
Turn on the TV and select the VIDEO input source connected to the DVD player pressing the TV/VIDEO select button. If the S-VIDEO is connected, select the S-VIDEO mode. Turn on the audio system and select the input source connected to the DVD Player. When the DVD is turned on, the DVD SCREEN will appear. Set the initial settings according to the desired language, audio or the connected TV or audio system. Turn to instructions on initial setting on page 26 for more details.
Before operating Playback
To STOP PLAYBACK, press STOP button. To temporarily STOP PLAYBACK, press the PLAYBACK/PAUSE button. To resume PLAYBACK, press the PLAYBACK/PAUSE button once again.
Open the tray by pressing OPEN/CLOSE button.
1
2
Place a disc properly on the tray with the playback side down.
2
3
Close the tray by pressing OPEN/CLOSE button.
3
NOTE
The DVD player automatically memorizes the location where the stop button was pressed during playback and resumes from that point when the playback button is pressed again. Playback is stopped after 10 minutes have passed in the pause state. After a minute from the moment playback is stopped, the screen oscillates between dark and light shades to protect the TV hardware. And after 10 minutes, the power is automatically turned off.
Operation
When you connect DVD player to TV and turn it on and if you find that colors are lost and the screen waves, open the door of DVD player and press "DISPLAY" button until a clear scene appears.
DIGITAL AUDIO OUT
SOCKET
SOCKET
SOCKET
SOCKET
to
/DTSD

Displaying the playback status
1
For DVD Playback
Press the DISPLAY button on the remote control.
The title, chapter number and the time elapsed is shown. Pressing the button again shows the remaining time. Pressing the button again shows the time elapsed for the chapter. Pressing the button again shows the remaining time for the chapter. Pressing the button again exits the status display.
1
TITLE 01/02 CHAPTER 001/009
00 : 01 : 05
SINGLE ELAPSED 00 : 01 : 05
1
For CD playback
Press the DISPLAY button on the remote control.
The elapsed time for the track is shown. Pressing the button again shows the remaining time for the track. Pressing the button again shows the total playback elapsed time. Pressing the button again shows the total remaining time. Pressing the button again exits the status display.
1
17
Searching for a specific screen/song during playback
Scan fast forward or fast reverse
1
Press the or button on the remote control.
1
NOTE
What is a chapter? A chapter is on of the several sections which a movie is divided into. What is a title? A title refers to a single whole movie.
For DVD playback, pressing the button successively executes the function in the following order : 2X 4X 8X 16X 32X 64X normal playback. For CD playback, the order is Fast or normal. To return to the normal playback speed, press the PLAY button.
You can use one of the functions listed below to jump to a specific chapter or track during playback.
To skip a chapter or a track
1
Press the or button on the remote control.
1
When the button is pressed, playback skips to the next chapter or track during DVD or CD playback. When the button pressed, playback skips to the beginning of the current chapter during DVD playback and to the previous chapter when it is pressed again.
18
Operation

Searching for a specific screen/song during playback
1
To view frame by frame
Press STEP/SLOW button on the remote control.
The picture advances one frame at a time each time the button is pressed. To return to PLAYBACK, press the PLAY/PAUSE button. This function is not activated for CD PLAYBACK.
1
NOTE
No sound is heard during fast/slow/frame-by-frame PLAYBACK. However, sound is heard during FAST CD PLAYBACK.
1
To play backwards or forwards in slow motion
Press STEP/SLOW button on the remote control.
For DVD playback, each successive press of the button executes the function in the following order : 1/2X 1/4X 1/8X. For VCD playback, the order is 1/2X 1/4X 1/8X and the SR button is inactivated. To return to normal PLAYBACK, press the PLAYBACK/PAUSE button. This function is not activated for CD PLAYBACK.
1
2
Press the or button.
2
19
Setting a custom view
Setting a specific DVD title or chapter
1
Press the GOTO button on the remote control.
1
Go to the title or chapter using the arrow buttons( ). Press the number of the title or chapter and the press the ENTER button.
TITLE 01/02 CHAPTER 001/009
TITLE 01/02 TIME : :
Setting a specific frame within a chapter of a DVD
1
Press the GOTO button on the remote control twice.
Set the time location of the frame using the number buttons and then press ENTER.
1
20
Operation
NOTE
This function does not work in a title which contains multiple camera angles in its track.

22
each track and select one of the frames, then it playback from that track. In case more than 9 tracks, It is several pages. Use SKIP button( , ) for movement between pages.
MONO LEFT or MONO RIGHT by successively
Operation
Setting a custom view
1
Repeat playback
Press the REPEAT button on the remote control.
This function repeats the playback of a chapter, title or track.
1
1
Press the STEP button on the remote controller
1
Press the SF or SR button.
Chapter repeat Title repeat Repeat off Repeat track Repeat disc
: Repeats playback of a single chapter. : Repeats playback of a single title. : Exits repeat mode. : Repeats playback of a single track. : Repeats playback of the whole disc.
1
Repeat playback of a specified segment
Pressing REPEAT A-B button selects the beginning(A) of the repeated playback segment and pressing it again selects the end(B).
Only the specified section is repeatedly played back. Pressing the button again returns to normal playback.
1
A TO B SET A
21
Pressing the button successively for a DVD executes the function in the following order: CHAPTER REPEAT TITLE REPEAT REPEAT OFF. For CD the order is REPEAT TRACK REPEAT DISC REPEAT OFF.
CHAPTER REPEAT
NOTE
Titles/chapters are repeated on DVDs and disc/tracks are repeated on CDs. This function may not work for some discs. Press Repeat A-B button before the next title or track begins. Otherwise, the setting is cancelled. This function does not work in a title which contains multiple camera angles.
AUDIO
AUDIO
and
on

24
Programming in a specific order
1
Press the PROGRAM button.
1
NOTE
Instructions on using the number buttons ex) Inputting track number 25 Press " 2 " and then " 5 " within 2 seconds. For discs that contain less than 25 tracks, pressing " 2 " " 5 " within 2 seconds will input track 2 and track 5. ex) Inputting track numbers 2 and 5 Press " 2 " and then " 5 " after 2 seconds.
Press the track number using the number buttons. Press the ENTER button. Pressing the PLAY button again plays back the tracks according to the program. A total of 99 songs can be programmed. This function is activated for CD playback only.
Music can be played in a specific order. Programming is only possible in stop mode.
PROGRAM P00 : 00
Operation
Use the ( ) buttons to move to the desired location. Press the ENTER button where you want to mark the scene. You can bookmark up to three scenes. Use the( ) buttons to highlight the marked scenes. Press the PLAY button on the scene you want. Press the CLEAR button if you want to delete a marked scene.
Viewing from another angle
having scenes
23
NOTE
This function does not work in a disc which contains multiple camera angles.
the the the
ZOOM
Deleting a program
Pressing the STOP button during playback of a programmed song will erase that song from the program. Pressing the CLEAR while programming will delete a song from the program in the reverse order which songs were selected. Pressing the STOP button while programming will erase the whole program.

25
1
Selecting a menu listed on the disc
Press the MENU button.
The menu contained on the disc will appear on the screen. The menu appears differently with different discs. This function does not work for CDs.
1
NOTE
Simulated surround effect does not work with the digital audio output (optical/coaxial).
1
To create stereophonic sound effects
Press the 3D SURR button.
This fuction lets you enjoy surround effects in stereo mode.
1
1
Muting the sound
Press the MUTE button.
Pressing the button toggles the MUTE function on and off. If no sound is heard with MUTE turned on, turn it off to hear sound.
1
1
To view the title menu
Press the TITLE button.
The title menu contained on the disc will appear. The title menu appears differently with different discs. This function will not work with CDs.
1
26
Using the setup menu
Pressing the SETUP button will show a screen with which various menu items can be set. Press the SETUP button in the STOP mode.
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH FRENCH GERMAN ITALIAN SPANISH DUTCH
Using the
setup menu
MOVE SELECTPREVIOUS SETUP
output
TEST TONE : For testing speaker output
rating.
CAPTIONS : For selecting the subtitle language of a disc which contains captions.

Setting the language
The language used for on-screen displays, disc menu audio and subtitles can be selected by following these instructions.
27
1
Selecting the on-screen language
Press the SETUP button on the remote control.
1
2
Go to LANGUAGE using the arrow buttons.
2
3
Go to OSD using the arrow buttons.
3
4
Choose the desired language using the arrow buttons and select it by pressing Enter button.
4
1
Press the SETUP button on the remote control.
1
2
Go to LANGUAGE using the arrow buttons.
2
3
Go to DISC MENU using the arrow buttons.
3
4
Choose the desired language using the arrow buttons and select it by pressing the ENTER button.
4
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH FRENCH GERMAN ITALIAN SPANISH DUTCH PORTUGUESE
Selecting a menu language
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH CHINESE FRENCH GERMAN SPANISH PORTUGUESE KOREAN
NOTE
This function only works in DISC STOP mode.
Setting the language
1
Selecting a subtitle language
Press the SETUP button on the remote control.
1
2
Go to LANGUAGE using the arrow buttons.
2
3
Go to SUBTITLE using the arrow buttons.
3
4
Choose the desired language using the arrow buttons and select it by pressing the ENTER button.
4
1
Selecting an audio language
Press the SETUP button on the remote control.
1
2
Go to LANGUAGE using the arrow buttons.
2
3
Go to AUDIO using the arrow buttons.
3
4
Choose the desired language using the arrow buttons and select it by pressing the ENTER button.
4
NOTE
If a selected language is not listed on the disc, the language will not appear on the menu. This function only works in DISC STOP mode.
NOTE
This function only works in DISC STOP mode.
28
Using the
setup menu
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH CHINESE FRENCH GERMAN SPANISH PORTUGUESE KOREAN
LANGUAGE SETUP LANGUAGE SETUP
OSD DISC MENU SUBTITLE AUDIO
ENGLISH CHINESE FRENCH GERMAN SPANISH PORTUGUESE KOREAN

30
Using the
setup menu
1
Press the SETUP button on the remote control.
1
2
Go to VIDEO using the arrow buttons.
2
3
Go to one of the items using the arrow buttons.
3
4
Choose the desired setting using the arrow buttons and select it by pressing the ENTER button.
4
Setup TV video settings as follows.
VIDEO SETUP VIDEO SETUP
TV DISPLAY CAPTIONS SCR SAVER
4:3 PS 4:3 LB 16:9 WIDE
1
2 3
29
1
Press the SETUP button on the remote control.
1
2
Go to SPEAKER using the arrow buttons.
2
3
Go to the desired item using the arrow buttons.
3
4
Choose the desired setting using the arrow buttons and select it by pressing the ENTER button.
4
Speaker settings can be selected as follows
DOWNMIX
1
Activates surround sound test tone for setting speaker levels. TEST TONE
2
SPEAKER SETUP SPEAKER SETUP
DOWN MIX TEST TONE LT/RT
STEREO
Setting the VIDEO Setting the SPEAKER

31
CUSTOM settings
CUSTOM MENU CUSTOM MENU
VFD DISPLAY PARENTAL PASSWORD DEFAULTS
BRIGHT DIMMER
32
1
Press the SETUP button on the remote control.
1
2
Go to CUSTOM using the arrow buttons.
2
3
Go to the desired item using the arrow buttons.
3
4
Choose the desired setting using the arrow buttons and select it by pressing ENTER button.
4
VFD DISPLAY BRIGHT : Turn on the display panel DIMMER : Darken the display panel PARENTAL Set a password and select rating level for DVDs unsuitable for children. For more details, turn to page 33. PASSWORD Turn to page 33 for more details. DEFAULTS Return to the factory settings.
1
2 3 4
Using the
setup menu
Setting the AUDIO
Audio system settings can be selected as follows.
1
Press the SETUP button on the remote control.
1
2
Go to AUDIO using the arrow buttons.
2
3
Go to the desired item below using the arrow buttons.
3
4
Choose the desired setting using the arrow buttons and select it by pressing the ENTER button.
4
AUDIO SETUP AUDIO SETUP
DIGITAL DUAL MONO DYNAMIC
OFF ON

Setting rating level and password
1
Pressing the SETUP button on the remote control.
1
2
Go to CUSTOM using the arrow buttons.
2
3
Go to PARENTAL using the arrow buttons.
3
4
Choose the desired level using the arrow buttons and select it by pressing the ENTER button.
4
5
Please enter your password
1
Pressing the SETUP button on the remote control.
1
2
Go to CUSTOM using the arrow buttons.
2
3
Go to PASSWORD using the arrow buttons.
3
4
Go to CHANGE using the arrow buttons and press Enter button.
4
5
Input your old password using the number buttons. The password is initially set to 4412.
5
6
Input a new password twice using the number buttons.
6
7
Press the ENTER button.
7
A message appears when the password is incorrect "The password is incorrect" A high level number means that the movie is more oriented to the adult audience.
5
This is to prohibit the playing of specified DVDs which are unsuitable for children.
Some DVD discs contain a restriction level which enables parents to remove scenes or prevent playback of discs by children. DVD players are equipped with a password designed to prevent children changing the level.
Setting your password
CUSTOM SETUP CUSTOM SETUP
VFD DISPLAY PARENTAL PASSWORD DEFAULTS
2 3 PG 4 PG 13 5 6 PG-R 7 NC-17 8 ADULT
CUSTOM SETUP CUSTOM SETUP
VFD DISPLAY PARENTAL PASSWORD DEFAULTS CHANGE
33
Operation with a MP3 disc
Confirming the playback status
001 003 005 007 009 011
002 004 006 008 010 012
34
Operation
with a
MP3 disc
001 003 005 007 009 011
002 004 006 008 010 012
OPEN/CLOSE
the ENTER
the PLAY

Operation with a MP3 disc
36
Initial settings
Pressing the SETUP button displays a screen where various menus can be set beforehand. For more details, turn to page 26.
Operation
with a
MP3 disc
Operation with a MP3 disc
To create 3D surround effects
35
NOTE
Simulated surround effect does not work with digital audio outputs (optical/coaxial).
sound function
REPEAT TRACK REPEAT DISC REPEAT OFF
REPEAT TRACK REPEAT DISC REPEAT OFF
disc
SURR
m

Accessories
Accessories
User's Manual Batteries (2 AA size batteries)
1 Audio/video connection cable
Remote control
Remove the battery compartment cover.
Install Batteries in the
Remote
1
Insert two 'AA' Alkaline batteries. Make sure that the batteries are inserted with their positive and negative poley.
2
Close the cover until it clicks.
3
Check the polarity + - of the batteries (Dry-Cell) Check if the batteries are drained. Check if remote sensor is blocked by obstacles. Check if there is any fluorescent lighting nearby.
If remote doesn't operate
properly:
37 38
Troubleshooting Guide
Check the following guide for the possible cause of a problem before contacting service.
Plug the power cord into the wall outlet securely. Insert a disc. (Check that the DVD or, audio CD indicator in the DVD display is lit.) Select the appropriatevideo input mode on the TV so the picture from the DVD player appears on the TV screen. Connect the video cable into the jacks securely. Turn on the TV. Select the correct input mode of the audio receiver so you can listen to the sound from the DVD player. Connect the audio cable into the jacks securely. Turn on the equipment connected with the audio cable. Set the Digital Audio Output to the correct position, then turn on the DVD player again by pressing the POWER button. Clean the disc. Insert a disc.(Check that the DVD, or audio CD indicator in the DVD display is lit.) Insert a playable disc.(Check the disc type, color system and Regional code.) Place the disc with the playback side down. Place the disc on the disc tray correctly inside the guide. Clean the disc. Press the SETUP button to turn off the menu screen. Cancel the Rating function or change the rating level. Point the remote control at the remote sensor of the DVD player. Operate the remote control within about 23 ft (7m). Remove the obstacle. Replace the batteries with new ones.
The power cord is disconnected.No power.
Symptom Cause Correction
No disc is inserted.
The power is on, but the DVD player does not work.
The TV is not set to receive DVD signal output The video cable is not connected securely.
No picture.
The connected TV power is turned off. The equipment connected with the audio cable is not set to receive DVD signal output.
No sound.
The audio cables are not connected securely. The power of the equipment connected with the audio cable is turned off. The digital Audio Output is set to the wrong position. The disc is dirty.
The playback picture is poor.
No disc is inserted.The DVD player
does not start playback. An unplayable disc is inserted.
The disc is placed upside down. The disc is not placed within the guide. The disc is dirty. A menu is on the TV screen. The Rating level is set. The remote control is not pointed at the remote sensor of the DVD player.
The remote control does not work properly. The remote control is too far from the
DVD player. There is an obstacle in the path of the remote control and the DVD player. The batteries in the remote control are exhausted.
POWER
3DSURR
STEP/SLOW
GOTO
ZOOM
DISPLAY
REPEAT
REW
SREW SFWD
STOP
CLEAR PROGRAM
ENTER
1
456
789
0
23
PLAY/PAUSE
FWD
A-B
OPEN/CLOSE
A
U
D
I
O
M
U
T
E
A
N
G
L
E
B
O
O
K
M
A
R
K
