SONIQ QPLAY QPC60B User manual

Dripping Warning: The product shall not be exposed to dripping or splashing
and no items filled with liquid like a filled glass or vase or cup, shall be placed on
the product.
Ventilation Warning: The ventilation openings of the product shall not be
intentionally covered.
The mains plug is used as disconnect device, the disconnect device shall
remain readily operable.
1 2
3
45 6 78 9 10
11
12
13
14
15 1516 17 18
19 20 21 22
Overview of The Player

1. "PROG" shows during Programming and in programmed play.
2. "RANDOM" shows when in RANDOM playback.
3. "INTRO" shows when in INTRO playback.
4. "WMA" shows when the file played is in WMA format.
5. "MP3" shows when the disc played is an MP3-CD.
6. "CD" shows when the disc played is a CD-DA.
7. "REPT" shows when in various repeat modes.
8. "1" shows together with "REPT" when in single track repeat mode.
9. "DIR" shows together with "REPT" when in album repeat mode.
10. "ALL" shows together with "REPT" when in all tracks repeat mode.
11. This shows when the player reads data from USB data traveller.
POWER SUPPLY
NOTE:
Insert the AC cord to the AC socket of the player, and plug the other end to
an applicable wall outlet.
qBATTERY OPERATION
1. Remove the battery compartment cover gently.
2. Install 8 x 'C' size batteries (UM-2 or equivalent) while observing the
correct polarities.
3. Replace the battery compartment cover.
= The AC cord must be detached from the AC socket of the player.
= Leaking batteries may damage the battery cabinet and the player as a
whole, so they should be removed from the cabinet when becoming flat
or when the player is not to be played on batteries for some time.
qAC OPERATION
NOTE: If the AC plug of this unit does not fit in with your AC outlet, a plug
adaptor should be used. Consult your local dealer on the type of plug
adaptor.
13 14 17 15 16
FAMILIARIZE WITH THE DISPLAYED CONTENTS IN THE LCD
TO PLAY THE RADIO
3. Tune to the desired station by rotating the TUNING control (rotate that control
back and forth until you get the strongest and clearest reception).
=
When you are receiving an FM broadcast, fully extend the TELESCOPIC
ANTENNA and rotate it for the best reception.
= For AM broadcast, rotate the whole set until the best reception is heard.
1. Set the FUNCTION switch to the RADIO position, the POWER Indicator will
light up.
2. Select the desired band with the BAND switch.
4. The built-in AM antenna and external FM TELESCOPIC ANTENNA are
directional.
5. Adjust the volume level to a comfortable listening level.
6. To turn off the radio, set the FUNCTION switch to the OFF, USB/CARD,
CD/MP3/AUX position.
12. This shows when player reads data from SD/MMC card.
13. This figure is the album number of the disc played.
14. This figure is track number of the current album on a MP3 disc or the current
track number on a CD disc.
15. This figure is the elapsed minutes of the track played.
16. This figure is the elapsed seconds of the track played.
17. English Text display. The information of the current track is displayed
scrolling forward in MP3 playback.
1 2 345
LOCATION OF CONTROLS 14. TUNING CONTROL
1. VOLUME CONTROL 15. SPEAKERS
2. SKIP DOWN BUTTON 16. USB PORT
3. SKIP UP BUTTON 17. LCD DISPLAY
4. PLAY/PAUSE BUTTON 18. SD/MMC CARD SLOT
5. POWER INDICATOR 19. PHONES JACK
6. USB/CARD BUTTON 20. FUNCTION SWITCH
7. CD DOOR 21. BAND SWITCH
8. MODE BUTTON 22. AUX JACK
9. FM ST. INDICATOR 23. FOLDING HANDLE
10. CD DOOR OPEN AREA 24. BATTERY COMPARTMENT
11. STOP BUTTON 25. FM TELESCOPIC ANTENNA
12. PROGRAM/EQ BUTTON 26. AC SOCKET
13. 10+/ALBUM BUTTON
1
678 9 10
11
12
Power Supply
Operation

HANDLING AND MAINTENANCE OF A DISC.
Follow the instructions below to handle and maintain your disc in
order that long time and trouble free performance can possibly be
obtained:
=Ensure not to caress the rain bow side of the disc; handle
the disc by the edge.
=Long time exposure to sunshine, high temperatures and
humidity will damage the disc. And keep storage area clean.
=Avoid sticking labels on both sides of a disc. Writing with
pointed articles on the disc should be strictly avoided.
=Clean the disc wiping the centre and then working out to the
edge with a dry & soft cloth or a disc brush. Avoid any
cleansing lotion or chemical eradicator.
=Store them in their cases when they are not to be used.
HANDLE DISC ONLY AS SHOWN
CLEAN FROM CENTER TO EDGE
DO NOT STORE NEAR HEAT
NOTES:
NOTE: When external headphones/earphones are connected, the speakers will
be muted.
=If a particular FM (STEREO) station is weak, or you hear too much
background noise, try moving the band selector switch to the FM (MONO)
position. This can often result in a much clearer reception.
=When the band selector switch is set to FM ST. and a stereo broadcast is on
the air. The FM ST. indicator will light up.
STEREO PHONES JACK
A stereo phones jack has been provided on the side of the player so that you can
listen without disturbing others. To use this jack, plug in the headphones/
earphones (NOT INCLUDED) and adjust the VOLUME control to a preferred level.
ANTI-SHOCK PROTECTION
A special circuitry inside the player guarantees that there will be no sound
skipping when the player is subject to shock and shaking in music playback.
The laser scans the CD/MP3 disc and saves data for up to 60/120 seconds
ahead of where the playback is on the disc. In case of shocks or shaking or
vibrations, the player reads from the memory until the laser can read CD again.
But if there is too much vicious vibration or shaking exerted on the player, the
player may malfunction and sound skipping is caused.
When this happens, place the player on a level table where no vibration will be
brought. Normal sound will resume immediately.
LOAD A DISC
1. Open the CD door by the Door open area.
2. Load a disc on the disc tray with the label side facing up.
3. Close the CD door.
PLAY A DISC
1. Slide the Function switch to CD/MP3/AUX position.
2. Follow the steps above to load a disc.
3. The player begins reading disc immediately the CD door is closed,
"READING" shows in the LCD.
4. When the disc is successfully read, TOC (total of contents) shows in the
LCD and playback follows with the first track.
5. Press PLAY/PAUSE button once to halt music playback, the elapsed time of
the current track flashes to indicate the player in Pause mode; press STOP
button to cease music playback. The LCD shows the TOC again with
"STOP" on the bottom.
SKIP TRACKS AND SEARCH FOR A SPECIFIC POINT TO PLAY
1. Press once the SKIP UP button in music play to skip to the next track. To
skip to a specific track ahead, press this button several times.
2. Press once the SKIP DN button in music play to skip to the beginning of the
current track. To skip to a specific track at back, press this button several
times.
3. Press +10 /ALBUM button once in play to skip to the track 10 tracks ahead,
twice to skip to the track 20 tracks ahead. You can reach the last track of the
disc using this button. Press this button again at the last track of disc to go to
the first track for playback.
4. Hold the SKIP UP button in music play to search at quick rate for a specific
point to play.
5. Hold the SKIP DN button in music play to search at quick rate for a specific
point to play.
REPEAT A SINGLE TRACK
To repeat a preferred track in playback, press MODE button once, "REPT 1"
shows in the LCD. Then select the preferred track using SKIP UP/DN buttons or
+10/ALBUM button. The player will repeat the chosen track until you press
STOP button.
REPEAT ALL TRACKS
To repeat all tracks, press MODE button twice in play mode, "REPT ALL" shows
in the LCD. The player will repeat all tracks until you press STOP button.
INTRODUCTION PLAY
Introduction play is that the first ten seconds of each track are played in a
sequential order. Press MODE button three times to enter this mode during play,
"INTRO" shows in the LCD. Press PLAY/PAUSE button to begin Introduction
play from Track NO.1. Press PLAY/PAUSE button to exit Introduction play mode
and normal music play resumes. Press SKIP UP button in Introduction mode to
begin Introduction play from the next track immediately after the current track.
Press SKIP DN button in Introduction mode to begin Introduction play from the
current track.

RANDOM PLAY
Random play is that tracks on the disc are played by the player at random.
Press MODE button four times to enter this mode during play, "RANDOM"
shows in the LCD. Press PLAY/PAUSE button to begin Random playback.
Tracks on the disc will be selected at random for playback and the player stops
automatically after all tracks are played. Press MODE button once more to exit
random and return to normal playback from the track it's reached.
PROGRAMMED PLAY
Programmed play is that tracks on the disc can be edited for playback in a
preferred order with the use of PROG. button.
In CD stop mode, press PROG./EQ button once, "PROG" shows in the LCD
with a flickering "000" and the program sequence indication "P-01", select the
first track to be programmed using SKIP UP/DN buttons or +10/ALBUM button,
and press PROG. button again to store and advance to the next programming
step. The program sequence indication changes to "P-02" waiting for your next
input.
Repeat the steps above to program more tracks. A maximum of 20 tracks can
be programmed in memory in a preferred order.
Press PLAY/PAUSE button to begin programmed play in the preferred order
after you are done with programming. The player stops automatically after all
programmed tracks are played.
You may press STOP button to terminate programmed playback. In program
stop mode, press STOP button again to clear the programming; press
PLAY/PAUSE button to begin the programmed playback with the programming
order identical with the previous one done.
4. Hold the SKIP UP button in music play to search at quick rate for a specific
point to play.
5. Hold the SKIP DN button in music play to search at quick rate for a specific
point to play.
To repeat a preferred track in playback, press MODE button once, "REPT 1"
shows in the LCD. Then select the preferred track using SKIP buttons or
+10/ALBUM button. The player will repeat the chosen track until you press
STOP button.
REPEAT AN ALBUM
REPEAT ALL TRACKS
To repeat all tracks, press MODE button three times in play mode, "REPT ALL"
shows in the LCD. The player will repeat all tracks until you press STOP button.
INTRODUCTION PLAY
Introduction play is that the first ten seconds of each track are played in a
sequential order. Press MODE button four times to enter this mode during play,
"INTRO" shows in the LCD. Press PLAY/PAUSE button to begin Introduction
play from Track NO.1. Press PLAY/PAUSE button to exit Introduction play mode
and normal music play resumes. Press SKIP UP button in Introduction mode to
begin Introduction play from the next track immediately after the current track.
Press SKIP DN button in Introduction mode to begin Introduction play from the
current track.
RANDOM PLAY
Random play is that tracks on the disc are played by the player at random.
Press MODE button five times to enter this mode during play, "RANDOM"
shows in the LCD. Press PLAY/PAUSE button to begin Random playback.
Tracks on the disc will be selected at random for playback and the player stops
automatically after all tracks are played. Press MODE button once more to exit
random and return to normal playback from the track it's reached.
6. Hold the +10/ALBUM button once during play, the album number flashes;
select the desired album using the SKIP UP/DN buttons or the +10/ALBUM
button; confirm this album selection by holding +10/ALBUM button again,
the track number"000" flickers for your input; select the desired track of the
chosen album using the SKIP UP/DN button or +10/ALBUM button. Finally,
press PLAY/PAUSE button again to begin playing this chosen track.
REPEAT A SINGLE TRACK
UP/DN
To repeat a preferred album in playback, press MODE button twice, "REPT DIR"
shows in the LCD. Then select the preferred album using +10/ALBUM button
and SKIP UP/DN buttons. The player will repeat the chosen album until you
press STOP button.
MP3-C PLAYBACK
This player is capable of MP3-CDs. It takes longer time for this player to read an
MP3-CD than it does CD-DA. Wait patiently while it is reading.
After an MP3-CD is successfully read, the icon of "MP3" shows in the LCD
together with the total number of albums and tracks. And a second later,
playback begins from the first track of the first album.
SKIP TRACKS AND SEARCH FOR A SPECIFIC POINT TO PLAY
1. Press once the SKIP UP button in music play to skip to the next track. To
skip to a specific track ahead, press this button several times.
2. Press once the SKIP DOWN button in music play to skip to the beginning of
the current track. To skip to a specific track at back, press this button several
times.
3. Press +10/ALBUM button once in play to skip to the track 10 tracks ahead,
twice to skip to the track 20 tracks ahead. You can reach the last track of the
disc using this button. Press this button again at the last track of disc to go
to the first track for playback.
D (WMA)

PROGRAMMED PLAY
Programmed play is that tracks on the disc can be edited for playback in a
preferred order with the use of PROG. button.
In MP3 stop mode, press PROG. button once, "PROG" shows in the LCD with a
flickering album "01" and the program sequence indication "P-01"; select the
album number to be programmed using SKIP UP/DN buttons or +10/ALBUM
button, and press PROG. button again to store; the track number "000" flickers
waiting for your selection. Choose the desired track with SKIP UP/DN buttons or
+10 /ALBUM button. Press PROG. button again to confirm the first programming
and advance to the next programming step. The program sequence indication
changes to "P-02" waiting for your next input.
Repeat the steps above to program more tracks. A maximum of 20 tracks can
be programmed in memory in a preferred order.
Press PLAY/PAUSE button to begin programmed play in the preferred order
after you are done with programming. The player stops automatically after all
programmed tracks are played.
You may press STOP button to terminate programmed playback. In program
stop mode, press STOP button again to clear the programming; press
PLAY/PAUSE button to begin the programmed playback with the programming
order identical with the previous one done.
Press and hold SKIP buttons to initiate high-rate scanning between tracks;
release one of them to begin playback of music at normal speed.
REPEAT MODES
Press MODE button once in play mode to repeat the current track; the LCD
shows the icon for single track repeat.
Press MODE button twice to repeat tracks in the current folder as a whole; the
LCD shows the icon for DIR repeat.
Press MODE button three times in play mode to repeat tracks on stored on this
storage media (USB/MMC card) as a whole; the LCD shows the icon for all
tracks repeat.
INTROSCAN PLAY
Press MODE button for the four times in play mode to activate introscan
playback immediately; the player will pick up tracks for playback of the first 10
seconds of each track in a sequential order after PLAY/PAUSE button is
pressed. You may press PLAY/PAUSE button once again to exit introscan play
mode and return to normal playback from the track it's arrived at.
RANDOM PLAY
Press MODE button for the five times in play to activate random playback
immediately; the player will pick up tracks in a random sequence for playback
after PLAY/PAUSE button is pressed. You may press MODE button once again
to exit random play mode and return to normal playback.
AUXILIARY IN
Your player can be used as a power amplifier to playback the programs from
portable radio, TV set or MP3 player or whatever provided this appliance is so
designed that audio signal may be produced through a LINE-OUT jack or the
like.
Observe the following steps to connect the player to another appliance:
1. Power the player on using the supplied AC Power Cord.
2. Slide Function Switch to CD/MP3/AUX position.
3. Connect the appliance into the player's AUX in socket with the supplied LINE
OUT cable of the appliance.
4. Power on the appliance and begin play.
Easy job, right? At this time you will be able to hear the sound produced from
the programs the connected appliance is broadcasting.
EQ SELECTION
Press PROG./EQ button continuously during disc playback mode to select EQ
sound effects among DBB, POP, CLASSIC, JAZZ, ROCK, and NORMAL.
EXTERNAL MEMORY MEDIA OPERATION (USB,MMC/SD)
Prepare the player for external memory media operation
Insert a USB data traveller into the USB port OR insert a MMC/SD card into the
card slot; slide the FUNCTION switch to the USB/CARD position and playback
will start from the first track.
NOTES:
1. The player reads data from the SD/MMC card by default if both USB data
traveller and MMC/SD cards are inserted. You may press the USB/CARD
button to switch between these modes in stop mode.
2. Operation for switching between USB and SD/MMC is only in stop mode.
3. In USB playing mode: when a SD/MMC card is inserted into the card slot,
USB playing will stop automatically and the SD/MMC card will start playing
from the first track.
4. In SD/MMC card playing mode: when a USB data traveller is inserted into
the USB port, SD/MMC playback will stop automatically and then restart
from the first track.
VARIOUS PLAY MODES
SKIPPING TRACKS AND SEARCHING BETWEEN TRACKS
Press SKIP UP button once to skip the current track and play the next track,
press this button continuously to go to corresponding tracks ahead;
Press SKIP DOWN button once to skip the current track and go back to the
beginning of this track, press this button continuously to go back to
corresponding tracks at back.
