Sonken Ezy Mic User manual

Easy-Use
16 CHANNEL PROFESSIONAL WIRELESS MICROPHONE SYSTEM
Thank you for buying our excellent wireless microphone series
products . Before you use our products please read this Owner's
Manual ,so that you can enjoy it.
Before using the machine please
Read this owner's manual
16 CHANNEL PROFESSIONAL WIRELESS MICROPHONE SYSTEM
1.COMPREHENSIVE PERFORMANCE
CARRIER FREQUENCY: UHF 700 ~ 870MHz
FREQUENCY STABILIZATION: < 30ppm
DYNAMIC RANGE: > 100dB
TOTALHARMONIC DISTORTION: < 0.5%
FREQUENCY RESPONSE: 40Hz--15KHz 3dB
AUDIO OUTPUT LEVEL: SEPARATE TYPE: 0-- 400mV
POWER VOLTAGE: 1.5V AA BATTERY
CONSUME POWER: 100mA
SIGNAL/NOISE RATIO: > 100dB
IMAGE & SPURIOUS REJECTION: > 80dB
BORDER UPON CHANNEL REJECTION: > 80dB
RECEIVING SENSITIVITY: > 5dBuV(SINAD=30dB)
DE-EMPHASIS: 50us
2.FIXED RECEIVER
3.HANDING MICROPHONE
CONSUME POWER: 30mW
MODULATIONTYPE: FM
MAX DEVIATION: 40KHz
SPURIOUS EMISSION: MORE THAN 60dB (WITH CARRIER)
BATTERYVOLTAGE: 1.5V x1
CONTINUOUS USING: 6 HOURS
SPECIFICATION
4.BODYPACK MICROPHONE
CONSUME POWER: 30mW
MODULATIONTYPE: FM
MAX DEVIATION: 25KHz
SPURIOUS EMISSION: MORE THAN 40dB (WITH CARRIER)
BATTERYVOLTAGE: 1.5V x2
CONTINUOUS USING: 6 HOURS
1.Receiver........................x1
2.Handheld microphone.....x1
(Or bodypack...................x1)
3.Battery 1.5V ..................x2
(Or battery 1.5V...............x3)
4.Operation manual...........x1
TM
MODEL: Ezy Mic
FREQUENCY TABLE
CH01:790.00MHz
CH02:790.40MHz
CH03:792.30MHz
CH04:794.80MHz
CH05:798.00MHz
CH06:802.00MHz
CH07:807.60MHz
CH08:793.40MHz
CH09:795.80MHz
CH10:797.40MHz
CH11:801.00MHz
CH12:805.00MHz
CH13:810.60MHz
CH14:811.00MHz
CH15:808.80MHz
CH16:809.20MHz

1.Microphone
2.Input socket
3.Power indicator
4.Power switch
5.Volume adjust
6.Antenna
7.Channel select switch
8.Adjustable gain controls
9.Squelch adjust
10.Battery sink
11.Battery cover
1. Power switch
2. Volume- controlling knob
3. Antenna
4. Power supplyindicator
5. Signal andaudio indicator
6. Battery cover
7.Mix output plug
8.Channel select switch
1.Open the batterycover of receiver, then place1 piece 1.5Vbattery.
(The polarity should be correct.)
2.Tune up the channel selectswitch, choose the frequency channel.
3.Connect the receiverto 6.35mm audioamplifier system to work.
1.Grille
2.Power supply indicator
3.Power and theaudio mute switch
4.Channel select switch.
Must choose the samefrequency
of the receiver.
5.Battery sink
6.Battery cover
7.Changer hole
1
2
3
4
5
6
7
CONTROL AND FUNCTION LIST (RECEIVER)
OPERATION OF THE RECEIVER
CONTROL AND FUNCTION LIST (HANDHELD)
BODY-PACK TRANSMITTER (ACCESSORIES)
