SONNEMAN E Series User manual

Important: Always unplug the power cord before installing or replacing bulb and before cleaning or other maintenance.
studs
lower stem
assembly
shade
socket tube
handle
FIG. A
HEIGHT ADJUSTMENT
•To increase height of lamp, loosen the Stem Clutch and
carefully pull up on the Upper Stem. Tighten the Clutch once
lamp is at desired height. (Fig. A)
•To decrease height of lamp, loosen the Stem Clutch and
carefully push down on the Upper Stem. Tighten the Clutch once
lamp is at desired height.
Assembly Instructions for: item 3046
Series E - Dome Double Boom Arm Lamp
stem
clutch
power cord
washers
assembly nuts
base
1. Disconnect and allow to cool for at least 5 minutes before
replacing bulb.
2. Bulb gets HOT quickly! Be sure power is off when re-lamping.
3. Do not touch hot enclosure.
4. Do not direct light at persons.
5. Do not look directly at lighted bulb.
Important Safety Instructions Lighted lamp is HOT!
6. Keep lamp away from curtains, draperies, and similiar materials.
7. Use only a 120v, 75watt, mini can (E11) base, halogen bulb.
8. Do not touch bulb at any time. Use a soft cloth to clean. Oil from skin
may damage bulb integrity.
9. Do not operate the lamp with damaged or missing shield.
10. Damaged shields should be replaced before lamp is used.
LAMP ASSEMBLY
1. Insert the studs of lower stem assembly into holes in the base
and secure with washers and assembly nuts. (Fig. A)
2. Screw counterweights on to threaded couplers of the boom arms.
counterweight
upper stem
clutch lever
boom arm
high/low
switch
BOOM ARM ADJUSTMENT
To adjust boom arm, loosen
Clutch Lever and set position.
To lock position, tighten Lever.
(Fig. E) Clutch
Lever
FIG. E
BULB INSTALLATION/REPLACEMENT (Fig. B)
1. Remove bulb from box. Hold the bulb by the ceramic part or
use protective cloth. Push in bulb while screwing it into the socket.
The socket is spring loaded.
NOTE: DO NOT TOUCH THE GLASS PART OF THE BULB WITH BARE
HANDS. Oil from fingerprints will reduce life of the bulb.
FIG. B
©2006 SONNEMAN - A WAY OF LIGHT
FIG. C
SHADE INSTALLATION (Fig. C)
1. Slide Shade Socket Tube. Make sure slot in Teflon Ring
aligns with shade hole.
2. Secure Shade to Socket Tube by screwing in hex screw
with hex key provided.
3. Plug in power cord. The High-Low Switch is located on the
underside of the Socket Tube.
1
2
bulb
hex key
hex screw

Important: Always unplug the power cord before installing or replacing bulb and before cleaning or other maintenance.
HEIGHT ADJUSTMENT
•To increase height of lamp, loosen the Stem Clutch and
carefully pull up on the Upper Stem. Tighten the Clutch once
lamp is at desired height. (Fig. A)
•To decrease height of lamp, loosen the Stem Clutch and
carefully push down on the Upper Stem. Tighten the Clutch once
lamp is at desired height.
1. Disconnect and allow to cool for at least 5 minutes before
replacing bulb.
2. Bulb gets HOT quickly! Be sure power is off when re-lamping.
3. Do not touch hot enclosure.
4. Do not direct light at persons.
5. Do not look directly at lighted bulb.
Important Safety Instructions Lighted lamp is HOT!
6. Keep lamp away from curtains, draperies, and similiar materials.
7. Use only a 120v, 75watt, mini can (E11) base, halogen bulb.
8. Do not touch bulb at any time. Use a soft cloth to clean. Oil from skin
may damage bulb integrity.
9. Do not operate the lamp with damaged or missing shield.
10. Damaged shields should be replaced before lamp is used.
LAMP ASSEMBLY
1. Insert the studs of lower stem assembly into holes in the base
and secure with washers and assembly nuts. (Fig. A)
2. Screw counterweights on to threaded couplers of the boom arms.
BOOM ARM ADJUSTMENT
To adjust boom arm, loosen
Clutch Lever and set position.
To lock position, tighten Lever.
(Fig. E) Clutch
Lever
FIG. E
BULB INSTALLATION/REPLACEMENT (Fig. B)
1. Remove bulb from box. Hold the bulb by the ceramic part or
use protective cloth. Push in bulb while screwing it into the socket.
The socket is spring loaded.
NOTE: DO NOT TOUCH THE GLASS PART OF THE BULB WITH BARE
HANDS. Oil from fingerprints will reduce life of the bulb.
Assembly Instructions for: item 3047
Series E - Dome Boom Arm Lamp
lower stem
shade socket tube
handle
FIG. A
stem clutch
clutch lever
power cord
base
threaded coupler
upper stem
boom arm
high/low
switch
counterweight
©2006 SONNEMAN - A WAY OF LIGHT
SHADE INSTALLATION (Fig. C)
1. Slide Shade Socket Tube. Make sure slot in Teflon Ring
aligns with shade hole.
2. Secure Shade to Socket Tube by screwing in hex screw
with hex key provided.
3. Plug in power cord. The High-Low Switch is located on the
underside of the Socket Tube.
bulb
hex key
hex screw
FIG. C 1
2
FIG. B
