Assembly Instructions
Pitch
Product Information
and Warnings
3250, 3252
Wall Lamp, Long Wall
Lamp
IMPORTANT
Always disconnect the power before installing, cleaning, or
other maintenance.
Please read all included assembly instructions and warnings carefully
before installation. Contact Customer Service if you have any
questions or concerns. Before installation, please confirm that the
fixture is compatible with your supply voltage and dimming system,
if present.
LEDs are highly sensitive electronic devices, and must be treated
with care. Do not open any factory sealed compartments, and avoid
touching the LEDs with your hands or any object.
Although all our fixtures are equipped with protective devices,
LED electronic systems are vulnerable to power surges and supply
variations. Do not install LED fixtures on the same circuit as any
motors, appliances, or HVAC systems.
Do not remove or bypass any LED Driver or Transformer that is
provided with the fixture, and do not replace or substitute with
another power supply.
Fixtures must be wired in parallel on independent leads; do not
"daisy chain" multiple fixtures together or wire them in series.
All factory-made splices and connections must remain intact. LED
circuits are carefully designed and built, and improper connections
may damage the fixture.
The ends of coaxial pendant cords have been precisely stripped
and split at the factory and must not be field cut. Excess cord or
cable should be neatly coiled and reserved in the fixture canopy.
Any mounting hardware is provided for your convenience
and should be used with discretion. Always use the appropriate
hardware for the mounting surface.

Instructions D'Installation
Multiple U.S. and foreign patents pending.
Assembly Instructions
1. Drill holes in wall, using backplate (A) as a template, and install anchors (B)..
2. Install backplate (A) to wall using provided screws (C)..
3. Install xture (D) to backplate (A) and secure using provided set screws (E).
4. Connect power supply plug adapter (F) to lamp cord (G) (Fig. 1). Insert power supply plug into wall outlet.
5. Use the stem (H) inside the lamp shade to turn the lamp on and o. Rotate the stem to adjust brightness (Fig. 2).
Care Instructions:
Use a clean, dry cloth when dusting.
To protect the nish, avoid any harsh
abrasives or chemicals.
(A)
(B)
(C)
Fig. 1
Fig. 2
(E)
(D)
(F)
(G)
(H)
3252
3250
