Sonoff MINIR4M User manual

1
MINI R  M ( EN )
MINI Extreme is an extremely compact Wi-Fi smart switch that can be installed in the mounting
box, transforming your regular switch into smart switch. It supports Matter protocol, enabling
seamlessly work with other smart devices from different brands to create a customized home
automation system.
Introduction
Wi-Fi Smart Switch
User Manual V1.0
Voice Control
External switch
Timer Schedule
OTA Upgrade

2
Support Matter Power-on State LAN Control Inching Mode
Group Control Smart Scene
① Button
Press once: Changing the on/off state of relay
contacts
Press and hold for 5 seconds : Device enters
the pairing mode.
② Wi-Fi LED indicator (Blue)
eWeLink Mode
Keeps on: Device is online.
Flashes twice: LAN
Flashes once: Offline
Flashes two short and one long: Device
is in pairing mode.
Flashes three times: Trigger mode
switched successfully
Matter Mode
Keeps on: Device is online.
Flashes once: Offline
Flashes two short and one long: Device
is in pairing mode.
Flashes three times: Trigger mode
switched successfully; Identify
③ Wiring ports
●
●
●
●
●
●
●
●
●

3
1. Power off
Matter-compatible ecosystem
Specification
Installation
Model MINIR4M
MCU ESP32-C3FN4
Rating 100-240V~ 50/60Hz 10A Max Resistive Load μ
Max. power 2400W@240V
Wireless Connectivity Wi-Fi IEEE802.11b/g/n2.4GHz
Net Weight 26.7g
Dimension 39.5x33x16.8mm
Color White
Casing Material PC V0
Applicable Place Indoor
Working Temperature -10 ℃ ~40 ℃
Working Humidity 5%~95% RH, non-condensing
Certified Compliance CE/FCC/RoHS/SRRC/TUV/ISED
Executive standard EN IEC 60669-2-1

4
*Please install and maintain the device by a professional electrician. To avoid electric shock
hazard, do not operate any connection or contact the terminal connector while the device is
powered on!
2. Wiring instruction
To ensure the safety of your electrical installation, it's essential either a Miniature Circuit Breaker
(MCB) or a Residual Current Operated Circuit Breaker (RCBO) with an electrical rating of 10A
has been installed before the MINIR4M.

5
No matter S1 and S2 are connected or left idle to the external switch, this device can be
controlled by automation or the App.
It is prohibited to connect S1 and S2 terminals to the neutral or ground wire, in order to
avoid damaging the equipment and causing danger.
Make sure all wires are connected correctly.
3. Power on
After powering on, the device will enter the Pairing Mode defaulted during the first use,and the
Network indicator flashes in a cycle of two short and one long.
●
●
●

6
*The device will exit the Pairing Mode if not been paired within 10mins. If you want to enter this
mode again, please long press the button for 5s until the Network indicator flashes in a cycle of
two short and one long and then release.
Method 1: Matter Pairing
Open a Matter-compatible App ( e.g. Alexa App, Google Home App, or Apple Home App, etc ) to
scan the Matter QR code on the Quick Guide or the device itself to add the device.
Method 2: eWeLink App Pairing
Add device
Add to Alexa via Matter Add to Google via Matter Add to Apple via Matter

7
Please download the " eWeLink " App from Google Play Store or Apple App Store .
1.Download the “ eWeLink ” App
2.Add device
Please follow the wiring instructions to
connect the wires (ensure power is
disconnected in advance and consult an
electrician if needed)
Power on the device

8
Enter “ Scan QR code ” Scan the Matter QR code on the device body
or the back page of the Quick Start Guide.
Long press the button for 5 seconds Check Wi-Fi LED indicator flashing status
(Two short and one long flashes)

9
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Select “ Add Device ” Search for the device and start connecting
Select the "Wi-Fi" network and
enter the password.
Device “ Added completely".

10
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20 cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada ’ s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1)This device may not cause interference.
(2)This device must accept any interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with RSS-247 of Industry Canada.
Operation is subject to the condition that this device does not cause harmful interference.
ISED Notice

11
L ’ émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d ’ Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L ’ exploitation est autorisée aux deux conditions suivantes :
(1)L ’ appareil ne doit pas produire de brouillage;
(2)L ’ appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d ’ en compromettre le fonctionnement.
Cet appareil numérique de la Classe B conforme à la norme NMB-003 du Canada.
Cet appareil est conforme à la norme RSS-247 d'Industrie Canada. Le fonctionnement est
soumis à la condition que cet appareil ne provoque pas d'interférences nuisibles.
ISED Radiation Exposure Statement
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance of 20 cm between the
radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Cet équipement est conforme aux limites d ’ exposition aux rayonnements de la ISED établies
pour unenvironnement non contrôé.
Cet équipement doit être installé et fonctionner à au moins 20cm de distance d ’ un radiateur ou
de votre corps.
Cet émetteur ne doit pas être co-localisé ou fonctionner en conjonction avec une autre antenne
ou un autre émetteur.
Under normal use of condition, this equipment should be kept a separation distance of at least
20cm between the antenna and the body of the user.
Dans des conditions normales d ’ utilisation, cet équipement doit être maintenu à une distance
d ’ au moins 20 cm entre l ’ antenne et le corps de l ’ utilisateur.
SAR Warning

12
Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment type MINIR4M
is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
https://sonoff.tech/usermanuals
WEEE Warning
EU Declaration of Conformity
WEEE Disposal and Recycling Information All products bearing this symbol
are waste electrical and electronic equipment (WEEE as in directive
2012/19/EU) which should not be mixed with unsorted household waste.
Instead, you should protect human health and the environment by handing
over your waste equipment to a designated collection point for the recycling
of waste electrical and electronic equipment, appointed by the government or
local authorities. Correct disposal and recycling will help prevent potential
negative consequences to the environment and human health. Please contact
the installer or local authorities for more information about the location as
well as terms and conditions of such collection points.
Scatola Manuale Neto
PAP 21 PAP 22 EVA7
Carta Carta Plastica
RACCOLTA DIFFERENZIATA
Verifica le disposizioni del tuo Comune.
Separa le componenti e conferiscile in modo corretto.

13
Manufacturer: Shenzhen Sonoff Technologies Co., Ltd.
Address: 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China
ZIP code: 518000 Service email: [e-mail]
Website: sonoff.tech Made in China
