Automatic power on circuit for GM/GR 47/48
LZT 123 7876 R1A 3
Contents
1INTRODUCTION ................................................................................................................. 4
2SONY ERICSSON MODULE ACTIVATION CIRCUIT PROPOSAL ................................... 5
2.1 DETAILED DESCRIPTION OF THE ACTIVATION SEQUENCE ................................................... 5
APPENDIX ................................................................................................................................. 6

Automatic power on circuit for GM/GR 47/48
LZT 123 7876 R1A 4
1 Introduction
This Application Note describes a method by which the GR47 GSM/GPRS
Module may be activated automatically when power is applied.
The solution requires external circuitry for monitoring the supply voltage
and generating a pulse on the GR47 ON/OFF signal line.

Automatic power on circuit for GM/GR 47/48
LZT 123 7876 R1A 5
2 Sony Ericsson Module Activation Circuit Proposal
The Sony Ericsson proposal for ensuring that the module automatically
switches on when power is applied is detailed here. The description refers
to circuitry presented in the schematic of Figure 1 in the Appendix.
The circuit uses a MAX6804 supervisory circuit to detect when the power
applied to the GR47 reaches an acceptable level.
A 74HC123A one-shot circuit presents a pulse to the ON/OFF signal
connection of the GR47. The pulse is designed to exceed 0.5 seconds in
accordance with the GR47 design specification to activate the module.
Note: If the one-shot pulse is designed to be greater than 0.5 seconds but
less than 1.0 second, it may provide an ‘ON’ signal but not an ‘OFF’
signal.
Feedback of activated GR47 signals is used to disable the one-shot when
operation is normal. If the GR47 is turned off, this feedback mechanism
retriggers the one-shot and will automatically activate the module again. A
full datasheet for the 74HC123A can be downloaded from
www.fairchildsemi.com.
2.1 Detailed Description of the Activation Sequence
When power is applied to VCC, the MAX6804 holds ‘CLR’ low to allow ‘A’
and ‘B’ to stabilise and ‘Q’ stays low. When VCC reaches 3.3V, ‘RST’
goes high triggering the one-shot. ‘Q’ goes high and pulls ON/OFF low.
This activates the module and changes the state of ‘A’ disabling further
one-shot pulses. The one-shot pulse lasts for RC seconds.
When the one-shot pulse ends, the module should have stayed on. ‘CLR’
is high, ‘Q’ is low, ‘A’ is high and ‘B’ is low (both held by VIO output from
module).
If the module switches off, the VIO output from the module will deactivate
and turn ‘A’ low and ‘B’ high, one of which will re-trigger the one-shot. The
module will be turned back on again.
Note : It may be necessary to delay the OFF to ON transition time with a
small RC delay on the ‘A’ and ‘B’ inputs.

Automatic power on circuit for GM/GR 47/48
LZT 123 7876 R1A 6
Appendix
Figure 1 - One-Shot Switch-on Proposal Schematic
