RECORDER UNIT
MAINTENANCE MANUAL Part 2
Volume 1 1st Edition
DIGITAL CAMCORDER
DNW-7/7P
DNW-90/90P
DNW-90WS/90WSP
DNV-5

!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
DNV-5 Serial No. 10001 and Higher
DNW-7 Serial No. 10001 and Higher
DNW-7P Serial No. 40001 and Higher
DNW-90 Serial No. 10001 and Higher
DNW-90P Serial No. 40001 and Higher
DNW-90WS Serial No. 10001 and Higher
DNW-90WSP Serial No. 40001 and Higher

CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer’s instructions.
Vorsicht!
Explosionsgefahr bei unsachgemäßem
Austausch der Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben
des Herstellers.
ATTENTION
Il y a danger d’explosion s’il y a remplacement
incorrect de la batterie.
Remplacer uniquement avec une batterie du
même type ou d’un type équivalent recommandé
par le constructeur.
Mettre au rebut les batteries usagées
conformément aux instructions du fabricant.
ADVARSEL!
Lithiumbatteri-Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning må kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
Voor de klanten in Nederland
Dit apparaat bevat een MnO2-Li batterij voor memory
back-up.
Raadpleeg uw leverancier over de verwijdering van de
batterij op het moment dat u het apparaat bij einde
levensduur afdankt.
Gooi de batterij niet weg. maar lever hem in als KCA.
Bij dit produkt zijn batterijen geleverd.
Wanneer deze leeg zijn, moet u ze niet
weggooien maar inleveren als KCA.

1
DNV-5
DNW-7/90/90WS
Table of Contents
Manual Structure
Purpose of this manual .............................................................................................. 5
Contents ..................................................................................................................... 5
Relative manual ......................................................................................................... 6
1. Service Overview
1-1. Extension Boards ........................................................................................1-1
1-2. Fixtures........................................................................................................1-2
1-3. Lithium Battery Replacement .....................................................................1-4
2. Maintenance Mode
2-1. Setup Menu .................................................................................................2-1
2-2. DIAG Menu ..............................................................................................2-28
3. Part Replacement
3-1. General Information for Part Replacement and Adjustment.......................3-1
3-1-1. Index...........................................................................................3-1
3-1-2. Precautions .................................................................................3-2
3-1-3. Threading End State/Unthreading End State .............................3-3
3-1-4. Precaution during Manual Ejection............................................3-4
3-1-5. Oil and Grease............................................................................3-6
3-1-6. Notes on Tightening Torque and Washer ..................................3-7
3-2. Replacement of Periodic Replacement Part................................................3-8
3-2-1. Upper Drum Assembly Replacement.........................................3-8
3-2-2. Slip Ring Brush Assembly Replacement .................................3-17
3-2-3. Slip Ring Assembly Replacement............................................3-20
3-2-4. Drum Assembly Replacement..................................................3-24
3-2-5. VH Cleaner Assembly Replacement........................................3-30
3-2-6. Pinch Roller Replacement........................................................3-32
3-2-7. Tension Regulator Band Assembly Replacement....................3-34
3-2-8. Reel Drive Gear Assembly Replacement.................................3-37
http://getMANUAL.com

2DNV-5
DNW-7/90/90WS
3-3. Replacement of Main Parts .......................................................................3-40
3-3-1. T Soft Brake Assembly Replacement ......................................3-40
3-3-2. S/T Idler Assembly Replacement.............................................3-42
3-3-3. Timing Belt (Reel) Replacement .............................................3-44
3-3-4. Timing Belt (Threading) Replacement ....................................3-46
3-3-5. Capstan Motor Replacement ....................................................3-49
3-3-6. CTL Head Replacement ...........................................................3-52
3-3-7. TC Head Replacement .............................................................3-55
3-3-8. Reel Table Replacement ..........................................................3-58
3-3-9. Pinch Arm Assembly Replacement .........................................3-62
3-3-10. Sensor (A) Detection Pin Replacement....................................3-64
3-3-11. Sensor (B) Detection Pin Replacement ....................................3-66
3-3-12. Tension Regulator Assembly Replacement .............................3-68
3-3-13. Gear Block Assembly Replacement.........................................3-71
3-3-14. FE Head Replacement ..............................................................3-75
3-3-15. Tape Cleaner Replacement ......................................................3-78
3-3-16. Tape Guide (S1, T1, T3) Replacement ....................................3-79
3-3-17. Cassette Stopper Replacement .................................................3-81
3-3-18. S Slider Assembly Replacement ..............................................3-83
3-3-19. T Slider Assembly Replacement ..............................................3-87
3-3-20. Threading Arm Assembly Replacement ..................................3-91
3-3-21. End Sensor Assembly Replacement.........................................3-94
3-3-22. Full-Top Sensor Assembly Replacement .................................3-95
3-3-23. Top Sensor Assembly Replacement.........................................3-96
3-3-24. Cassette Compartment Replacement........................................3-97
3-3-25. Removal and Installation of Mechanical Deck Assembly .....3-100
3-4. Removal and Installation of CCD Block
(Only for DNW-7/7P/90/90P/90WS/90WSP) ........................................3-102
3-5. Fan Motor Replacement ..........................................................................3-105
4. Mechanical Alignment
4-1. Mechanical Adjustment ..............................................................................4-1
4-1-1. Reel Table Height Adjustment ...................................................4-1
4-1-2. Tension Regulator Operating Position Adjustment ...................4-3
4-1-3. FWD Back Tension Adjustment ................................................4-5
4-1-4. Brake Torque Confirmation .......................................................4-7
4-1-5. Timing Belt (Reel) Tension Adjustment ....................................4-9
4-2. Tape Running System Adjustment............................................................4-10
4-2-1. Tape Running Adjustment .......................................................4-12
4-2-2. Video Tracking Adjustment .....................................................4-19
4-2-3. CTL Head Height Adjustment .................................................4-24
4-2-4. CTL Head Position Adjustment ...............................................4-26
4-2-5. TC Head Height Adjustment ....................................................4-28
4-2-6. TC Head Position Adjustment .................................................4-30

3
DNV-5
DNW-7/90/90WS
5. Replacement of Circuit Boards
5-1. Replacement of Circuit Boards ...................................................................5-1
5-1-1. Circuit Boards in Connector Box ...............................................5-1
5-1-2. KY-293 Board ............................................................................5-4
5-2. Replacement of Board Used Exclusively for DNW-7/7P/90/90P/90WS/
90WSP.........................................................................................................5-5
5-2-1. SW-789 Board............................................................................5-5
5-2-2. MA-68 Board ............................................................................5-6
5-2-3. AIF-8 Board ...............................................................................5-6
6. General Infomation for Electrical Alignment
6-1. Notes for Adjustment ..................................................................................6-1
6-2. Equipment/Fixtures .....................................................................................6-1
6-3. Data Structure of the SETUP Menu............................................................6-2
6-4. Test Signals .................................................................................................6-3
6-5. Description of Nonvolatility Memory’s Data .............................................6-4
6-6. Electrical Adjustment After Replacement of Block or Board ....................6-4
7. VTR System Alignment
7-1. Preparation ..................................................................................................7-1
7-2. Power System Adjustment ..........................................................................7-1
7-2-1. Battery End Detection Voltage Adjustment...............................7-1
7-3. Servo System Adjustment ...........................................................................7-2
7-3-1. Automatic Servo Adjustment .....................................................7-2
7-3-2. Automatic PG Phase Adjustment...............................................7-2
7-4. Audio System Adjustment ..........................................................................7-3
7-4-1. D/A Level Adjustment ...............................................................7-3
7-4-2. Output Limiter Adjustment ........................................................7-3
7-4-3. AGC Level Adjustment..............................................................7-4
7-5. Input Level Adjustment (DNV-5 only).......................................................7-4
7-5-1. Y Input Level Adjustment..........................................................7-4
7-5-2. R-Y Input Level Adjustment......................................................7-5
7-5-3. B-Y Input Level Adjustment......................................................7-5
7-6. Y/C Delay Adjustment (DNV-5 only) ........................................................7-6
7-6-1. R-Y Delay Adjustment...............................................................7-6
7-6-2. B-Y Delay Adjustment...............................................................7-6
7-6-3. Storing the Adjustment Data ......................................................7-7
7-7. Play Back System Adjustment (DNV-5 only) ............................................7-7
7-7-1. Playback Level Adjustment .......................................................7-7
7-7-2. Burst Frequency Adjustment......................................................7-8
7-7-3. Storing the Adjustment Data ......................................................7-8

4DNV-5
DNW-7/90/90WS
8. Camera System Alignment
8-1. Initial Setting for Switches ..........................................................................8-1
8-2. VCO CONT Frequency Check ...................................................................8-2
8-3. AD Clock Phase Adjustment ......................................................................8-2
8-4. ENC OUT Adjustment ................................................................................8-3
8-4-1. ENC Level Adjustment ..............................................................8-3
8-4-2. Chroma Adjustment ...................................................................8-4
8-4-3. INT SC Phase Adjustment .........................................................8-5
8-5. TEST OUT Level Adjustment ....................................................................8-6
8-6. Modulator Balance Adjustment ..................................................................8-6
8-7. TEST SAW Adjustment..............................................................................8-7
8-8. R/B AD Gain Adjustment ...........................................................................8-8
8-9. VA Gain Adjustment...................................................................................8-9
8-10. Preset White Adjustment...........................................................................8-10
8-11. Shading Adjustment ..................................................................................8-10
8-11-1. Black Shading Adjustment.......................................................8-10
8-11-2. White Shading Adjustment ......................................................8-11
8-12. Gamma Correction Adjustment ................................................................8-12
8-13. Black Set Adjustment................................................................................8-13
8-14. Flare Adjustment .......................................................................................8-13
8-15. Knee and White Clip Adjustments............................................................8-14
8-15-1. Manual Knee and White Clip Adjustments .............................8-14
8-15-2. Pre Knee Adjustment ...............................................................8-15
8-15-3. DCC Pre Knee Adjustment ......................................................8-16
8-15-4. DCC Knee Adjustment ............................................................8-17
8-16. Detail Signal Adjustment ..........................................................................8-17
8-16-1. Crispening Adjustment.............................................................8-17
8-16-2. Level Depandent Adjustment...................................................8-18
8-16-3. Detail Frequency Adjustment ..................................................8-18
8-16-4. H/V Ratio Adjustment..............................................................8-19
8-16-5. Detail Level Adjustment ..........................................................8-19
8-16-6. Knee Aperture Adjustment ......................................................8-20
8-16-7. H Detail Clip Adjustment.........................................................8-20
8-16-8. V Detail Clip Adjustment.........................................................8-21
8-17. Skin Tone Adjustment...............................................................................8-21
8-18. Zebra Adjustment ......................................................................................8-22
8-19. Automatic Iris Adjustment ........................................................................8-23

5
DNV-5
DNW-7/90/90WS
Purpose of this manual This manual is maintenance manual of Recorder Unit DNV-5 and Digital Camcord-
er DNW-7/7P/90/90P/90WS/90WSP.
This manual describes the information items (parts replacement and electrical
adjustments) that premise the service based on the components parts.
Contents The following is a summary of the sections for understanding the contents of this
manual.
Maintenance Manual Part 2 Volume 1
Section 1 Service Overview
Explains the information for extension boards and fixtures for adjustment.
Section 2 Maintenance Mode
Explains the SETUP menu (in SVC mode) and DIAG menu of this unit.
Section 3 Parts Replacement
Explains how to replace the mechanical parts.
Section 4 Mechanical Alignment
Explains how to adjust the mechanical parts.
Section 5 Replacement of Circuit Boards
Explains how to replace the circuit boards.
Section 6 General Information for Electrical Alignment
Explains the general information for electrical adjustments.
Section 7 VTR System Alignment
Explains the electrical adjustments for VTR.
Section 8 Camera System Alignment
Explains the electrical adjustments for camera (DNW-7/7P/90/90P).
Maintenance Manual Part 2 Volume 2
Section 1 Spare Parts
Section 2 Semiconductor Pin Assignments
Section 3 Block Diagrams
Section 4 Board Layouts
Section 5 Schematic Diagrams
Manual Structure

6DNV-5
DNW-7/90/90WS
Relative manual Besides this “Maintenance Manual Part 1”, the following manuals are available for
this unit.
..
..
.Operation Manual (Supplied with this unit.)
This manual is necessary for application and operation of this unit.
..
..
.Maintenance Manual Part 2 (Not supplied with this unit.)
This manual describes the information items (adjustments, board layouts, sche-
matic diagrams, detailed parts list, etc.) that premise the service based on parts.
If this manual is required, please contact Sony’s service organization.
..
..
.BVF-V10/V10CE or BVF-V20W/V20WCE
Maintenance Manual (Not supplied with this unit.)
This manual describes the service information of the viewfinder.
If this manual is required, please contact Sony’s service organization.

1-1
DNV-5
DNW-7/90/90WS
Section 1
Service Overview
1-1. Extension Boards
Extension boards are supplied as optional fixture for check and adjustment of the following boards.
For using of the extension boards, refer to the following sections of the Maintenance Manual Part 1.
.DNV-5 “1-15-1. Extension Boards”
.DNW-7/7P/90/90P/90WS/90WSP “1-14-1. Extension Boards”
Extension board assembly : EX-501, EX-541, EX-542, stays
Part No. : A-8312-804-A
Extension Assembly Board to be checked DNV-5 DNW-7/7P DNW-90WS
board to be extend and adjusted DNW-90/90P DNW-90WSP
EX-501 DVP Assembly DVP-1 OO O
DVP-2 OO O
DCP Assembly DCP-1 OO
ES-11 OO
CN-1193 O
RC-61 O
IF Assembly IF-634 O
CT-187 O
EX-542, EX-542 _MDC-5 OO O

1-2 DNV-5
DNW-7/90/90WS
1-2. Fixtures
Fig. No. Part No. Description For use
1 A-8312-292-A TP Tool Video tracking adjustment
2 A-8312-804-A Extension Board Assembly Plug-in board check/adjustment
(EX-501/541/542, Stays)
3 J-6026-100-A Resolution Chart (4:3) *1Camera adjustment
J-6394-320-A Resolution Chart (16:9) *2
J-6026-110-A Burst Chart *1
J-6026-130-A Gray Scale Chart (4:3) *1
4 J-6394-080-A Gray Scale Chart (16:9) *2
5 J-6029-140-B Pattern Box, PTB-500 *1
6 J-6035-070-A IC External Tool (ICT-2101) Extraction of IC (PLCC type)
7 J-6080-840-A Inspection Mirror Video tracking adjustment
8 J-6152-450-A Wire Clearance Check Gauge Clearance check
9 J-6322-420-A Tape Guide Adjustment Driver (45) Tape path adjustment
J-6322-420-3 TG Driver Spare Bit (45)
10 J-6323-530-A Stop Washer Fastening Tool Installation of stop washer
11 J-6323-890-A FWD Back Tension Measuring Cassette FWD back tension adjustment
12 J-6324-150-A Reel Table Height Adjustment Tool Reel height adjustment
13 J-6325-110-A Torque Driver Bit (for M1.4) Tightening screws
J-6325-380-A Torque Driver Bit (for M2)
14 J-6325-400-A Torque Driver Bit (for 3 kg)
15 J-6326-120-A Hexagonal Bit
16 J-7032-610-A Cassette Reference Plate Reel height adjustment
17 3-184-527-01 Cleaning Cloth Cleaning
18 3-703-358-08 Parallel Pin Mechanical adjustment
19 7-651-000-10 Grease, SGL-601 (50 g) Lubricant
7-651-000-11 Grease, SGL-801 (50 g)
20 7-661-018-18 Oil
21 7-700-736-05 Hexagonal Wrench (d = 1.5 mm) Removal of screws
22 8-960-075-01 Alignment Tape, SR5-1 Digital video/audio adjustment (NTSC)
8-960-075-11 Alignment Tape, SR2-1 Video tracking adjustment (NTSC)
8-960-075-51 Alignment Tape, SR5-1P Digital video/audio adjustment (PAL)
8-960-075-61 Alignment Tape, SR2-1P Video tracking adjustment (PAL)
23 9-919-573-01 Cleaning Fluid TTP cleaning
_7-432-114-11 Screw Locking Compound
_Product Blank Tape, BCT-30MA For recording
or Betacam SX Tape, BCT-60SX
Cleaning Tape, BCT-5CLN Cleaning
*1 : For DNW-7/7P/90/90P/90WS/90WSP only
*2 : For DNW-90WS/90WSP only
1-2. Fixtures

1-3
DNV-5
DNW-7/90/90WS
3456
78910
19 20 21 22
23
15 16 17 18
11 12 13 14
12
d
1-2. Fixtures
MW-389
10
JB-OOOO

1-4 DNV-5
DNW-7/90/90WS
1-3. Lithium Battery Replacement
1-3. Lithium Battery Replacement
The unit has a lithium battery on the TC-80 board. When
replacing, desolder two terminals for the lithium battery.
If the lithum battery runs down, the internal clock data (the
time of day, the date) is cleared. The lithium battery
running down, set up the unit again as necessary.
c
In replacing, ensure that the battery is installed with “+”
and “_” poles connected to the correct terminals. An
improper connection may cause an explosion or leakage of
fluid.

2-1
DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Section 2
Maintenance Mode
2-1. Setup Menu
This unit has the SETUP menu required for the settings and adjustments of the camera.
This section describes the SVC (SERVICE) mode.
Data structure
The menu has the following data structure.
Set value of the data (or adjust value) = fixed data (absolute value) + set value of the SVC mode (relative value) + set value
of the ENG mode (relative value) + set value of the USER mode (relative value)
.The fixed data is stored in IC74 (this IC is mounted in the IC socket (CNI1) on the DCP-1 board), and the set values of
the USER, ENG and SVC modes are stored in IC152 (on the DCP-1 board).
.The set values of the USER, ENG and SVC modes are set to 0 when the unit is shipped from the factory. Execute the
DATA RESET of each mode to return to the factory shipping data. (The adjustment is required.)
1. SVC mode
.The replacement boards for repair purpose supplied from the repair parts center is adjusted at the factory. However, due
to the variability of respective products, perform the adjustment using the SVC mode after the board replacement, or
when you require the fine-adjustment.
.When adjustment is performed using the SVC mode, the values of items adjusted in the ENG mode and the USER mode
become 0.
2. Setup card
.The set values of the USER mode and ENG mode are stored separately in the setup card.
.The set value at the factory is stored as fixed data. This value may differ for each unit. The [fixed data + set value in SVC
mode] in each state must be made the same when an identical setup card is used before and after board replacement or
between different units.
Using the reference unit it is recommended to store the set values of the USER mode and the ENG mode beforehand in
the setup card. Then replace the board or use another unit, perform adjustment using the SVC mode, and download the
stored data from the setup card.
USER mode data (relative value) Save the setup card
Set value of the SETUP menu
(or adjust value) Data at the factory
ENG mode data (relative value)
SVC mode data (relative value)
Fixed data (absolute value)
http://getMANUAL.com

2-2 DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Switch description
1. MENU switch
OFF : Terminate the SETUP menu.
Usually, set to OFF.
ON : Execute the SETUP menu.
PAGE : Search page of the SETUP menu.
CANCEL/PRST: Cancel the setting value (during level control) or reset to the factory-setting value.
ITEM : Select item.
2. Rotary encoder
Rotary encoder uses to change the set value of selected item or to decide the changed setting value.
Operation
The SETUP menu is set to the USER mode when shipped from the factory.
Perform the following procedures to enter the SVC mode.
1. Turn the main power off.
2. Set the switch S4-1 on the DCP-1 board to ON.
3. Turn the main power on.
4. Set the MENU switch to ON. The SETUP menu appears on the viewfinder screen.
Setting Change (MENU switch operation)
1. To select the page, throw the MENU switch to PAGE. The page will be shifted to the next page every time the switch
is thrown to PAGE.
2. To select the item, throw the MENU switch to ITEM. The cursor pointing the item will be shifted to the next item
every time the switch is thrown to ITEM. By pressing the rotary encorder, selected item is entered.
3. To change the setting value, turn the rotary encoder.
4. To exit from the SETUP menu, set the MENU switch to OFF.
Setting Change (Rotary encorder operation)
1. To select the page, turn the rotary encoder until the desired page is appeared and press it down.
2. To select the item, turn the rotary encoder until the cursor pointng the item is shifted to the desired item and press it
down.
(When pressing the rotary encoder down with the cursor pointing the title of item, the menu display will be returned to
the state in procedure 1.)
3. To change the setting value, turn the rotary encoder.
4. When pressing the rotary encoder down again, the menu display will be returned to the state in procedure 2
5. To exit from the SETUP menu, set the MENU switch to OFF.
n
When the unit is externally controlled by the remote control unit RM-P9, some functions cannot be controlled. (Refer to
pages 2-20 to 2-27.)
OFF
POWER
ON OFF
GAINVTR OUTPUT WHITE BAL
ON
PAGE
CANCEL/PRST
ITEM
MENU
MENU switch
Rotary encoder

2-3
DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Pages configuration of the SETUP menu
Viewfinder screen (Factory default setting) Description
*** MARKER 1/2 ***
SAFETY ZONE : ON ...........Sets the safety zone marker display to ON or OFF.
SAFETY AREA : 90 % ...........Sets the safety zone area to 80 %, 90 % or 100 %.
CENTER : ON ...........Sets the center marker display to ON to OFF.
CENTER H ...........Moves the center marker horizontally.
CENTER V ...........Moves the center marker vertically.
*** MARKER 2/2 ***
BOX CURSOR : OFF ...........Sets the box cursor display to ON or OFF. *1
BOX WIDTH ...........Changes the width of the box cursor.
BOX HEIGHT ...........Changes the height of the box cursor.
BOX H ...........Moves the box cursor horizontally.
BOX V ...........Moves the box cursor vertically.
** VF DISPLAY 1/2 **
DISP MODE : 3 ...........Set whether to display the items partially or to display no item. (1/2/3)
...........For details, refer to the Operation Manual.
EXTENDER : ON ........... Sets the extender display to ON or OFF.
ZOOM : ON ...........Sets the zoom position display to ON or OFF.
** VF DISPLAY 2/2 **
FILTER : ON ...........Sets the filter display to ON or OFF.
WHITE : ON ...........Sets the white balance display to ON or OFF.
GAIN : ON ...........Sets the gain selection value display to ON or OFF.
SHUTTER : ON ...........Sets the shutter speed/mode display to ON or OFF.
TAPE : ON ...........Sets the tape remaining display to ON or OFF.
AUDIO : ON ...........Sets the CH-1 audio level display to ON or OFF.
IRIS : ON ........... Sets the iris value display to ON or OFF.
*** MASTER GAIN *** Sets the gain corresponding to the LOW, MIDDLE, HIGH and TURBO positions of the
gain selector switch.
LOW : 0 dB Selects a GAIN value from -3, 0, 3, 6, 9, 12, 18, 24, or 30 dB .
MID : 9 dB Selects a TURBO value from -3, 0, 3, 6, 9, 12, 18, 24, 30, or 36 dB.
HIGH : 18 dB n
TURBO : 36 dB When the gain selection value is changed, the BLACK SET adjustment
(Section 8-13) is required.
*** SHOT ID *** Sets the shot ID of a maximum of twelve characters using alphanumeric character,
symbol, and space.
ID-1 :
ID-2 :
ID-3 :
ID-4 :
*1 : The box cursor is not functioned in the following conditions (DNW-90WS/90WSP only).
1. Set the “BOX/4:3 LIMITS” to 4:3 at WIDE SCREEN page.
2. Set the “BOX/4:3 LIMITS” to 4:3, and “VF ASPECT” to 16:9A or 16:9B at WIDE SCREEN page.

2-4 DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Viewfinder screen (Factory default setting) Description
* SHOT DATA DISP. * Sets the contents of the shot data to be recorded on tape
DATE : OFF ...........Sets whether to display/record the date. (ON/OFF only)
TIME : OFF ...........Sets whether to display/record the time. (ON/OFF only)
MODEL NAME : OFF ...........Sets whether to display/record the model name (ON/OFF only)
SERIAL NO. : OFF ...........Sets whether to display/record the serial No. (ON/OFF only)
CASSETTE NO. : OFF ...........Sets whether to display/record the cassette No.. (ON/OFF only)
SHOT NO. : OFF ...........Sets whether to display/record the shot No.. (ON/OFF only)
ID SELECT : OFF ...........Sets whether the any specific shot ID displays/records. (OFF/ID1/ID2/ID3/ID4)
*** SHUTTER SPEED *** Sets the shutter speed/mode selection range.
EVS : ON ...........Enhanced Vertical Definition mode (DNW-7 only)
Super Enhanced Vertical Definition mode (DNW-90/90WS only)
CLS : ON ...........CLS : Clear scan mode
ECS : Extended clear scan mode (DNW-90/90WS only)
1/100 (for NTSC) : ON ...........Shutter speed 1/100 (for NTSC) or 1/60 (for PAL) second in the standard mode
or 1/60 (for PAL)
1/125 : ON ...........Shutter speed 1/125 second in the standard mode
1/250 : ON ...........Shutter speed 1/250 second in the standard mode
1/500 : ON ...........Shutter speed 1/500 second in the standard mode
1/1000 : ON ...........Shutter speed 1/1000 second in the standard mode
1/2000 : ON ...........Shutter speed 1/2000 second in the standard mode
*** ! LED ***
MASTER GAIN : ON ...........Sets whether to light the ! indicator LED on the viewfinder when the gain is set
except 0 dB.
SHUTTER : ON ...........Sets whether to light the ! indicator LED on the viewfinder when the SHUTTER
selector switch is set to ON.
WHITE PRESET : OFF ...........Sets whether to light the ! indicator LED on the viewfinder when the white
balance memory is set to PRESET.
ATW RUN : OFF ...........Sets whether to light the ! indicator LED on the viewfinder when the ATW
(automatic homing white balance) is operating.
EXTENDER ON : ON ...........Sets whether to light the ! indicator LED on the viewfinder when the lens
extender is used.
FILTER 2,3,4 : OFF ...........Sets whether to light the ! indicator LED on the viewfinder when the FILTER
selector is set except 1. (Standard setting is 1.)
A. IRIS OVERRIDE : OFF ...........Sets whether to light the ! indicator LED on the viewfinder when the reference
value of the automatic iris adjustment is set to any value other than the
standard value.
*** SETUP CARD ***
READ (→CAM) ...........Reads data from the setup card.
WRITE (→CARD) ...........Writes data to the setup card.
ID EDIT ...........Sets ID of the setup card.
WRITE PROTECT ...........Sets the WRITE PROTECT function of the setup card . (ENG mode only)

2-5
DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Viewfinder screen (Factory default setting) Description
** FUNCTION 1/2 **
TEST OUT : ENC ...........Selects the ENC, R, G or B signal of the video signal output from the TEST
OUT connector.
n
When the R-G/B-G SEL item on the OP MODE page is set to ON, the R-G and
B-G items are added enabling to select R-G and B-G.
DETAIL : ON ...........Sets whether to add the detail signal for resolution improvement to the video
signal.
n
The level adjustment for this item is performed on the “LEVEL 1” page.
APERTURE : ON ........... Sets the aperture correction to ON or OFF.
SKIN TONE DTL : OFF ........... Sets whether to activate the skin tone detail circuit.
n
The level adjustment for this item is performed on the “LEVEL 2” page.
MATRIX : OFF (for NTSC) ...........Sets whether to activate the linear matrix circuit.
: ON (for PAL) The highly color saturation can be obtained when this item is set to ON.
n
The level adjustment for this item is performed on the “LEVEL 8” page.
GAMMA : ON ...........Sets whether to implement the gamma correction so that the overall character-
istic of signals from the camera to monitor display is “GAMMA = 1”.
n
The level adjustment for this item is performed on the “LEVEL 3” and “LEVEL
6” pages.
CHROMA : ON ...........Sets whether to add the chroma signal.
n
The level adjustment for this item is performed on the “LEVEL 4” page.
TEST SAW : OFF ........... Sets whether to close the lens forcibly and add the TEST SAW waveform to the
video signal circuit.
This signal is used for the video signal system adjustment.
CROSS COLOR FLT : OFF ...........Sets whether to reduce the cross color of a video signal. The cross color is
(for NTSC only) reduced when this item is set to ON.

2-6 DNV-5
DNW-7/90/90WS
2-1. Setup Menu
Viewfinder screen (Factory default setting) Description
** FUNCTION 2/2 **
GENLOCK : ON ...........Sets whether to synchronize the internal reference signal with the external input
video signal supplied to the GENLOCK IN connector.
CAM RET. : OFF ...........Sets whether to display the return video signal input to the GENLOCK IN
connector on the viewfinder screen when the RET button is pressed ON.
FILTER INH. : OFF ...........Sets whether to interlock the white balance correction value to the filter
position.
ON : The white balance correction value is not interlocked to the color
temperature conversion filters ; The memory A and the memory B store
one adjustment value respectively.
OFF : The white balance correction values for the respective color temperature
conversion filters are stored in the memories A and B.
Four for memory A and four for memory B, total eight values can be
stored.
FIELD/FRAME : FLD ...........Sets the type of the CCD data read-out system.
FLD : Field read mode. Normally set to this position.
FRM : Frame read mode. This position is selected when improved vertical
resolution is desired.
n
The frame read mode has more image lag than the field read mode.
A. IRIS OVERRIDE : OFF ...........Sets whether to activate the auto iris override function.
When this item is set to ON, the reference value of the auto iris adjustment can
be changed using the rotary encoder when menu is set to OFF.
(Five steps : Irises off –1/2, –1/4, 0, +1/4, and +1/2)
DYNALATITUDE : OFF ...........Sets whether to active the dynalatude function.
Detects a high contrast signal that white and/or black level becomes flat, and
correct to the suitable contrast. (Four steps : OFF, LOW, MID and HI)
* WIDE SCREEN * (DNW-90WS/90WSP only)
16:9/4:3 MODE : 16:9 ...........Sets the aspect ratio of the video signal output from the VIDEO OUT and TEST
OUT connectors.
VF ASPECT : AUTO ...........Sets the aspect ratio on the viewfinder.
AUTO : Sets the aspect ratio set by 16:9/4:3 MODE setting.
4:3 : Sets the aspect ratio to 4:3 regardless of 16:9/4:3 MODE setting.
16:9A : Sets the aspect ratio to 16:9 regardless of 16:9/4:3 MODE setting
(displays the erea of 4:3 mode with the marker).
16:9B : Sets the aspect ratio to 16:9 regardless of 16:9/4:3 MODE setting
(video level is cut in half out of the safety zone area on the VF
screen).
BOX/4:3 LIMITS : BOX ...........Sets the function of the box cursor.
BOX : Operates as the normal cursor function.
4:3 : Displays the erea of 4:3 mode when the 16:9/4:3 MODE set to
16:9.
“16:9” BARS ID : OFF ...........Sets whether to add the “16:9” character in the color bars signal genarated in
this unit when the 16:9/4:3 MODE set to 16:9.
“16:9” VF ID : OFF ...........Sets whether to add the “16:9” character on the VF screen when the 16:9/4:3
MODE set to 16:9.
