Sony BRCH900 User manual

BRC-H900
BRC-H700
BRC-Z700
BRC-Z330
BRC-300
BRC Series
Color Video Cameras

2
APPLICATIONS
Corporate/Boardroom
BRC Series cameras are excellent for various business
communication applications, videoconferencing, corporate
training, and broadcasting management meetings to remote
locations. Each camera in this series offers particular features
and benefits to fit the various needs of applications.
The cameras are easy to operate and can be quickly reset
after each use by simply
touching a button on the
optional controllers which
recall pre-specified positions
for capturing speech and
switching scenes.
Auditorium/Concert Hall
With its pan/tilt/zoom (P/T/Z) capability, a single camera can
capture a wide shooting range during an entire live
performance, including audience shots. The BRC’s wide range
capability can reduce the need for additional cameras and
cameras operators resulting in substantial cost savings. These
cameras make it easy to get close-ups of performers from
locations that are usually difficult
for a camera operator to reach.
Additionally, each camera’s
compact size and quiet
movement does not distract the
audience from the performance.
City Council
Remotely controlled by the RM-BR300, BRC Series cameras
can quickly capture the actions at council meetings or trials.
With the ability to select
multiple pre-defined P/T/Z
positions, each camera
provides simple, streamlined
operation.
Sports Events
With high-speed and extremely smooth pan/tilt movement,
BRC Series cameras can follow the quick, spontaneous flow of
sports action. With cameras installed in high positions,
operators can obtain extensive views of each event, and
capture shots at unique angles, which are usually very difficult
to capture with conventional
shooting. Also, optical fiber
connection (max. 2,000 m)
achieves long-distance data
transfer and enables single-
operator broadcasting.
Studio
The BRC Series is also ideal for use in the broadcast industry.
The BRC-H900, BRC-H700, BRC-Z700, and BRC-Z330 can output
HD-SDI signals*1– a necessity for highly demanding
broadcasters who seek uncompromising picture quality. With
flexible installation, these cameras can be easily integrated
into a working studio with tripods or ceiling brackets. For the
wide angles required in studio shooting, wide conversion
lenses are available*2. And
there are numerous other
benefits, including quiet and
smooth P/T/Z movement, a
tally indicator, cost-efficiency,
and more.
Education
By deploying BRC Series cameras, teachers can offer students
new educational opportunities anytime and anywhere. With
the real-time distribution of lectures and other educational
content, academic institutions
can deliver e-learning classes,
and professors can efficiently
share their opinions and
collaborate via networked
communication.
Houses of Worship
By using large screens in combination with highly sensitive
BRC Series cameras, clear video images can be delivered
with accurate color reproduction. Attendees can become
more involved in the service and follow ongoing events better
than ever before. With a variety
of peripheral components, a
range of user-friendly systems
can be designed to suit the
size and budget of every
organization.
Weddings
Pre-installed BRC Series cameras are ideal for capturing
wedding ceremonies since their silent movement will not
disturb the ceremony. With high picture performance and
zooming capabilities, these cameras can capture natural
facial expressions and, for
example, the graceful
movements of the bride. Also,
due to their compact and
sleek design, these cameras
blend easily into the
surrounding environment.
*1 The BRC-H700, BRC-Z700,and BRC-Z330 require optional video cards. (sold separately)
*2 Wide conversion lenses are available for the BRC-Z700 and BRC-300.(sold separately)

3
The BRC Series consists of five pan/tilt/zoom (P/T/Z) cameras – the BRC-H900, BRC-H700, BRC-Z700, BRC-Z330, and
BRC-300. They offer wide and smooth P/T/Z capabilities together with exceptional picture quality from SD to Full HD
images. You can remotely control these cameras using the RM-BR300 Remote Control Unit or RM-IP10 IP Remote
Controller.*3As a flagship model, the BRC-H900 delivers superb sensitivity (F10) and horizontal resolution (more
than 1, 000 TV lines in HD-SDI output) to meet the needs of high image quality applications. The BRC Series is
perfect for a variety of remote video shooting applications, and each camera integrates easily into a wide range of
indoor and outdoor systems.
These features enable users to enjoy the benefits of BRC Series cameras, particularly in education, broadcast,
wedding, and corporate applications. These cameras also enable a reduction in manned operation with their
advanced remote capabilities.
PRODUCTS OVERVIEW
Superb Picture Quality
Thanks to Sony’s amazing image sensor technology, BRC
Series remote cameras deliver exceptionally high picture
quality to meet demanding live production requirements. The
BRC-H900 offers excellent performance at minimum
illumination (as low as four lux) and therefore offers visibility
even in dark environments*4.
Silent & Smooth Pan/Tilt/Zoom Mechanism
BRC Series remote cameras can be operated with slow to fast
P/T/Z motion from remote locations*5. Also the silent
mechanism enables the unit to be installed in noise-
conscious environments.
Flexible Installation
In addition to typical desktop installation, BRC Series cameras
can be ceiling mounted. With the use of a tripod and tripod
screw, these cameras are also suitable for mobile
applications, such as live events. Thanks to their compact
design, these cameras can be installed in locations typically
too small for camera operators and larger cameras.
IP Control
The BRC-H900, BRC-Z700, and BRC-Z330 can be controlled
though an IP network with the use of an RM-IP10 IP Remote
Controller and BRBK-IP10 or BRBK-IP7Z IP Control Card. This
functionality allows for flexible configurations, and enables the
installation of up to 112 units of BRC cameras and up to five
units of RM-IP10 controller depending on customer
requirements.
Advanced Color Adjustment
The BRC-H900 is equipped with a variety of picture adjustment
features, including color, gamma, black, and knee settings.
These feature-rich color adjustment functions allow fine
tuning to meet professional demands.
Tally Lamp
All BRC Series cameras are equipped with a tally lamp.
Additionally, the BRC-H900 has a second tally lamp – one on
the front and one on the rear, offering wider visibility.
BRC-H900 BRC-H700 BRC-Z700 BRC-Z330 BRC-300
Image Sensor 1/2-type Exmor
CMOS x 3 1/3-type IT CCD x 3 1/4-type CMOS x 3 1/3-type CMOS 1/4.7-type CCD x 3
Signal System
1080i/59.94,
720p/59.94,
1080i/50, 720p/50,
NTSC, PAL
1080i/59.94,
1080i/50
1080i/59.94,
1080i/50, NTSC, PAL
1080i/59.94,
720p/59.94,
1080i/50, 720p/50,
NTSC, PAL
NTSC
Sensitivity F10 NA
Minimum Illumination 4 lx
(50IRE, F1.9, +24 dB)
6 lx
(50IRE, F1.6, +24 dB)
6 lx
(50IRE, F1.6, +24 dB)
6 lx
(50IRE, F1.6, +24 dB)
7 lx
(25IRE, F1.6, +18 dB)
Advanced Color Adjustment 4
HD Video Output HD/SD-SDI 4Option Option Option
Component, RGB 4444
SD Video Output Composite,Y/C 4 4 4 4 (NTSC)
Optical Zoom (Digital Zoom) 14x 12x (4x) 20x (4x) 18x (4x) 12x (4x)
IP Control Option Option Option
KEY FEATURES
*3 The RM-IP10 is compatible with the BRC-H900, BRC-Z700,and BRC-Z330 only.
*4 At 50IRE, F1.9, +24 dB.
*5 Ranging from 0.22° to 60° per second for the BRC-H900 and BRC-Z700.

4
SYSTEM CONFIGURATION
You can congure a variety of systems to meet your application needs by choosing HD and/or SD components.
Users can choose either HD or SD system components.
RM-BR300
Video Switcher with
Audio Mixer
BRC Cameras
Presentation Material (PC)
Audio Source
Monitor (PGM)
Monitor (AUX1)
Monitor (MV)
Projector (PGM)
Projector (PGM)
PA
Video
Audio
Control (VISCA)
Presentation_01
RM-BR300 RM-BR300
Video Switcher with
Audio Mixer
BRC Cameras
Presentation Material (PC)
Audio Source
Monitor (PGM)
Monitor (MV)
Recorder
Broadcast/Streaming
PA
Video Switcher with
Audio Mixer
BRC Cameras
Optical fiber
cable*6
Optical
multiplex card Optional
video card
Presentation Material (PC)
Audio Source
Monitor (PGM)
Monitor (MV)
Recorder
Broadcast/Streaming
PA
Live Broadcast_01 Live Broadcast_02
Optical
Multiplex
Unit
*6 There are two types of optical fiber cable (Single-mode/Multi-mode). Please refer to the specifications.

5
BRC and BRU System
BRC-H900 BRC-H700 BRC-Z700 BRC-Z330 BRC-300
Wide
Conversion
Lens
————VCL-0737W
Optical Multiplex
Card (inserted to
the BRC Series)
BRBK-SF1 BRBK-H700 BRBK-MF1 BRBK-SF1 BRBK-303
Optical Fiber
Cable
CCFC-S200
(Single-mode)
CCFC-M100HG
(Multi-mode)
CCFC-S200
(Single-mode)
CCFC--M100
(Multi-mode)
Optical
Multiplex
Unit
BRU-SF10
(Supports
Single-mode optical ber)
BRU-H700
(Supports
Multi-mode optical ber)
BRU-SF10
(Supports
Single-mode optical ber)
BRU-300
(Supports Multi-mode optical ber)
Optional
Video Card
(inserted to
the BRC
Series)
BRBK-HSD2
HD/SD-SDI
HFBK-HD1
HD-SDI, HD Component
(Y/Pb/Pr), RGB
BRBK-HSD1
HD-SDI, SD-SDI
BRBK-HSD2
HD/SD-SDI
HFBK-SD1
SD-SDI, Composite,Y/C,
SD Component (Y/Cb/Cr), RGB
BRBK-SA1
Analog SD Output
HFBK-TS1
i.LINK (HDV) BRBK-SA1
Analog SD Output
HFBK-XG1
WXGA, XGA,VGA
IP Control
Card BRBK-IP10 —BRBK-IP7Z BRBK-IP10 —
Remote
Control Unit
(IP)
RM-IP10 —RM-IP10 RM-IP10 —
Remote
Control Unit
(VISCA)
RM-BR300
RM-IP10
(No. 1)
RM-IP10
(No. 2)
RM-IP10
(No. 3)
RM-IP10
(No. 4)
RM-IP10
(No. 5)
Switching HUB
BRC-H900, Z330, Z700
(No. 1)
PC (for System Setting)
BRBK-IP10 or IP7Z
BRC-H900, Z330, Z700
(No. 2)
BRBK-IP10 or IP7Z
BRC-H900, Z330, Z700
(No. 3)
BRBK-IP10 or IP7Z
BRC-H900, Z330, Z700
(No. 112)
BRBK-IP10 or IP7Z
BRC Control by RM-IP10 IP Remote Controller
BRBK-301
Composite,Y/C, SD Component
(Y/Cb/Cr), RGB
BRBK-302
SD-SDI
BRBK-304
i.LINK (DV)

6
DIMENSIONS
REAR PANELS
7 3/8(186)
7/32 (5)
3 3/4
(93)
9/16
(14)
5
1/4
(
131
)
3/4
(19)
1
13
/
16
(46)
5 1/8(129.5)
6 3/8
(160.8)
6 1/8(152.8)
Tripod Screw 1/4-20 UNC
ø5 Depth 5
3 1/2(88)
4 1/2(113)
7 5/8(193.4)
7/16
(11)
1/16
(1.1)
BRC-H900
BRC-300BRC-Z330
FRONT
BOTTOM
SIDE
Units: inches (mm)
BRC-H700 BRC-Z700
ø 8 1/4(207) ø 8 1/4(207)
4
1
/ 8 (103.5)
8 5/8(219)
3 1/4
(80)
1
3
/
4
(43.5)
4 1/2(112)
12 1/4(310.8)
2 5/8(66)3 (75)
7/32 (5)
4 3/8(110)
1/4 - 20 UNC
FRONT
BOTTOM
SIDE
Units: inches (mm)
9 3/4(247)
7 1/2(190)
5 7/8(149)
2 1/4
(56)
1 15/16
(48.2)
4 1/8
(102)
7/32 (5)
7 7/8
(198)
1/4 - 20 UNC
9 3/8(238)
4 (99)
3 7/8(98)
2 3/4
(68.2)
2 3/8
(58)
FRONT
BOTTOM
SIDE
Units: inches (mm)
Units: inches (mm)
7/32 (5.5)
7 1/8
(180)
1 13/16
(45)
1
5
/
8
(40.8)
5 7/8(147)
5 3/4(143)
8 3/8(210.2)
8 1/8(205)
13/32
(9.6)
3 5/8(90)
4 1/4(106)
2 3/4
(68.8)
3
(75)
5 7/8(147.6)
1/4 - 20 UNC
FRONT
BOTTOM
SIDE
FRONT
BOTTOM
SIDE
Units: inches (mm)
Tripod screw hole
10 1/4(260)
5 7/8(149)
2 1/8
(51)
4 1/8
(102)
7/32 (5)
7 7/8
(198)
4-M3
9 3/8(238)
4 (99)
3 7/8(98)
3 7/8(98)
2 3/8
(58)
BRC-H900
BRC-300/300PBRC-Z330
DC IN
12V
OFF ON
VISCA RS-422
1 2 3 4 5 6 7 8 9
EXT SYNC IN IN VISCA RS-232C OUT
VIDEO S VIDEO
75Ω IR SELECT
1 2 3
BRC-H700 BRC-Z700
DC IN 12V
OFF ON
OFF ON
IR SELECT
1 2 3
VISCA RS-422
1 2 3 4 5 6 7 8 9
75Ω
EXT SYNC IN DATA MIX
IN VISCA RS-232C OUT RGB/COMPONENT DC IN 12V
OFF
DATA MIX
ON
OFF ON
IR SELECT
1 2 3
VISCA RS-422
1 2 3 4 5 6 7 8 9
75Ω
EXT SYNC ININ VISCA
RGB/COMPONENT
VIDEO S VIDEORS-232C OUT
R
R
BRBK-302
SDI
RGB/COMPONENT
VISCA RS-422
123456789
EXT SYNC IN
IR SELECT
75Ω
1
2
3OFF ON
DATA MIX
OFF ON
IN VISCARS-232C OUT
DC IN 12V
R
VIDEOS VIDEO
BRBK-HD2
SDI OUTPUT

7
OPTIONAL ACCESSORIES
BRBK-H700
HD Optical
Multiplex Card
HFBK-HD1
HD Interface Board
HFBK-SD1
SD Interface Board
HFBK-XG1
XGA Interface
Board
HFBK-TS1
i.LINK (HDV)
Interface Board
BRBK-MF1
HD Optical
Multiplex Card
BRBK-HSD1
HD/SD-SDI Output
Card
BRBK-303
SD Optical
Multiplex Card
BRBK-301
Analog RGB
Component Card
BRBK-302
SDI Card
BRBK-304
DV Card
BRU-H700
HD Optical
Multiplex Unit
(Supports Multi-mode
optical fiber)
BRU-SF10
HD/SD Optical
Multiplex Unit
(Supports Single-mode
optical fiber)
BRBK-SF1
HD Optical
Multiplex Card
BRBK-IP10
IP Control Card
BRBK-IP7Z
IP Control Card
BRBK-SA1
Analog SD Output
Card
BRBK-HSD2
HD/SD-SDI Output
Card
BRU-300
SD Optical
Multiplex Unit
(Supports Multi-mode
optical fiber)
CCFC-M100HG
Optical Fiber Cable
2-core Multi-mode
Optical Fiber Cable
(100 m long),
Extension Plug
Included
CCFC-M100
Optical Fiber Cable
2-core Multi-mode
Optical Fiber Cable
(100 m long),
Extension Plug
Included
CCFC-S200
Optical Fiber Cable
2-core Single-mode
Optical Fiber Cable
(200 m long),
Extension Plug
Included
CCMC-9DS*7
RGB/Component,
Y/C Cable (9-pin
D-sub)
CCXC-9DBS*7
RGB/Component,
VBS Cable (9-pin
D-sub)
VCL-0737W
Wide Conversion
Lens
REMOTE CONTROL UNITS
RM-IP10*8
IP Remote Controller
•ComfortableP/T/Zoperationwiththeopticalthree-axisjoystick
•Versatilecameraadjustmentbysimplepaneloperation
•TheuseofIPtechnologyallowsflexibleinstallationandeasy
operation
•Presetfeaturesavescamerasettings(upto16positions)
RM-BR300
Remote Control Unit
BRS-200
Remote Camera
Operating Switcher
•ComfortableP/T/Zoperationwiththeopticalthree-axisjoystick
•Versatilecameraadjustmentbysimplepaneloperation
•VISCARS-232C/RS-422communicationinterfacesallowhigh-speed,
long-distance control
•Atally/contactconnectorallowsconnectionwithaswitcherand
provides a short-circuit corresponding to the camera address
•Presetfeaturesavescamerasettings(upto16positions)*9
•LiveProductionandPresentationSwitcherforHDorSDSystems
•MultiViewingFunction
•RichSelectionofInputsandOutputs
• Standard: SDI input x 4 / output x 4, DVI-I output x 1
• With option: SDI input x 8 / output x 4, DVI-I input x 1 / output x 2
•BRCSeriesCameraControlCapability
Note: BRC-H900 is NOT compatible with BRS-200.
*7 These cables are for use with the BRBK-301 or HFBK-SD1.
*8 The RM-IP10 is compatible with the BRC-H900, BRC-Z700, and BRC-Z330 only.
*9 For the BRC-300, six positions can be saved.
BRC-H700BRC-Z330 BRC-Z330
BRC-Z330BRC-Z330
BRC-Z330
BRC-Z700BRC-Z700
BRU-SF10BRU-SF10
BRC-300
BRC-H700 BRC-Z700 BRC-300BRC-Z330 BRC-300 BRC-Z700
BRC-H700 BRC-H700 BRU-H700 BRC-H700 BRU-H700 BRC-H700 BRU-H700 BRC-H700 BRU-H700 BRC-Z700 BRC-Z700
BRC-300BRC-300 BRU-300 BRC-300 BRU-300 BRC-300 BRU-300
BRC-H900 BRC-H900
BRC-H900 BRC-H900 BRC-H900
BRC-H900
VCL-HG0862K
Wide Conversion
Lens

©2012 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for weight and dimension are approximate.
Some images in this brochure are simulated.
“SONY” and “make.believe” are registered trademarks of Sony Corporation.
All other trademarks are the trademarks of their respective owners.
SPECIFICATIONS
BRU-H700 BRU-SF10 BRU-300
Interfaces
Optical fiber connector LC Duplex Fiber Connector
Optical cable type Multi-mode Single-mode Multi-mode
HD video output D-Sub 15 pin: Component (Y/Pb/Pr) or RGB, HD, VD or SYNC —
SD video output — BNC: Composite (NTSC), Mini DIN 4 pin: Y/C
External sync input BNC
External sync output BNC
Audio line output Phono jack x2 (L/R) —
Camera control Mini DIN 8 pin: RS-232C (VISCA IN), Mini DIN 8 pin: RS-232C (VISCA OUT), Connector plug 9 pin: RS-422 (VISCA IN/OUT)
Optional card slots 2 slots
2 slots (When both slots are used simultaneously, the interface cards must be of two different types.)
General
Operating temperature 32 ºF to 104 ºF (0 ºC to 40 ºC)
Storage temperature -4 ºF to +140 ºF (-20 ºC to +60 ºC)
Power requirements AC 100 V to 240 V (50/60 Hz) DC 12 V AC 100 V to 240 V (50/60 Hz)
Power consumption Max.10 W (without optional cards) Max. 15.6 W (without optional cards) Max. 9 W (without optional cards)
Dimensions (W x H x D) 8 3/8x 3 1/2x 9 1/2inches (210 x 86 x 240 mm) 8 3/8x 3 1/2x 8 3/8inches (212 x 88 x 210 mm)
Weight 5 lb 5 oz (2.4 kg) 4 lb 7 oz (2.0 kg) 4 lb 10 oz (201 kg)
Supplied accessories
AC power cord, RS-422 connector plug, RS-232C
cable (3 m, Mini DIN 8 pin), Operating instructions
AC adapter,Power cord, DC-cord secure connection
attachment, RS-232C connecting cable, RS-422
connector plug,Operationg Instructions
AC power cord, RS-422 connector plug, RS-232C cable (3 m, Mini DIN 8 pin), Operating instructions
BRBK-302 BRBK-303 BRBK-304 BRBK-SA1 BRBK-SF1 BRBK-IP10 BRBK-IP7Z
Video output BNC: SD-SDI LC Duplex Fiber Connector i.LINK 6 pin: DV OUT
(IEEE1394 S100)
BNC x1: VIDEO, Mini DIN
4pin x1: S VIDEO, D-sub
9pin x1: RGB/SYNC
LC Duplex Fiber Connector BNC x2: HD-SDI or SD-SDI* BNC x2: HD-SDI or SD-SDI
Audio line input — — — — — Phono jack x2 (L/R) RJ-45 x1: 10Base-T/100Base-TXAuto
BRC-H900 BRC-H700 BRC-Z700 BRC-Z330 BRC-300
Camera
Image Sensor 1/2-type Exmor CMOS x3 1/3-type IT CCD x3 1/4-type CMOS x3 1/3-type CMOS 1/4.7-type IT Advanced HAD CCD x3
Image Sensor (Number of
Effective Pixels)
Approx. 2.07 Megapixels Approx. 1.07 Megapixels Approx. 1.04 Megapixels Approx. 2.16 Megapixels Approx. 1.02 Megapixels
Signal System 60 Hz: 1080/59.94i, 720/59.94P, NTSC
50 Hz: 1080/50i, 720/50P, PAL
60 Hz: 1080/59.94i
50 Hz: 1080/50i
60 Hz: 1080/59.94i, NTSC
50 Hz: 1080/50i, PAL
60 Hz: 1080/59.94i, 720/59.94P, NTSC
50 Hz: 1080/50i, 720/50P, PAL
NTSC
Sensitivity F10 NA
Minimum Illumination (50IRE) 4 lx (50IRE, F1.9, +24 dB) 6 lx (50IRE, F1.6, +18 dB) 6 lx (50 IRE, F1.6, +24 dB) NA
Minimum Illumination (25IRE) NA 7 lx (25IRE, F1.6, +18dB)
Horizontal Resolution
>1,000 TV line (in HD-SDI output) (center) NA
S/N Ratio 50 dB
Gain Auto/Manual (-3 dB to +24 dB) Auto/Manual
(0 dB to +18 dB and Hyper Gain)
Auto/Manual
(0 to +24 dB and Hyper Gain)
Auto/Manual
(-3 dB to +24 dB and Hyper Gain)
Auto/Manual (-3 dB to +18 dB,3 dB steps) switchable
Shutter Speed
1/8,000 s to 1/60 s or 1/8,000 s to 1/50 s 1/10,000 s to 1/60 s or 1/10,000 s to 1/50 s NTSC: 1/10,000 s to 1/4 s
Exposure Control Auto,Manual,Priority mode (shutter
priority & iris priority), Back light, Spot
light
Auto,Manual, Priority mode (shutter priority, Gain priority & iris priority),
EV compensation
Auto,Manual, Priority mode (shutter
priority, Gain priority & iris priority),
EV compensation, Color AE
Auto,Manual, Priority mode (shutter priority & iris priority), Bright, spot AE
Color AE Function No
Off/Narrow/STD/Wide switchable in menu No
White Balance Auto/Indoor/Outdoor/One-push/Manual Auto1/Auto2/Indoor/Outdoor/One-push/Manual Auto/Indoor/Outdoor/One-push/Manual
Optical Zoom 14x 12x 20x 18x 12x
Digital Zoom – 4x 4x 4x 4x
Focusing System Auto/Manual
Horizontal Viewing Angle 59.6°(Wide-end) 60.3°(Wide-end) 55.2°(Wide-end) 55.1°(Wide-end) 4:3 mode: 37.8°, 16:9 mode: 45.4°(Wide end)
Focal Length f=5.8 mm to 81.2 mm
F1.9 (Wide), F2.8 (Tele)
f = 4.5 mm to 54 mm
F1.6 (Wide), F2.8 (Tele)
f = 3.9 mm to 78 mm
F1.6 (Wide), F2.8 (Tele)
f=4.6 mm to 82.8 mm
F1.6 (Wide), F2.2 (Tele)
f = 3.6 mm to 43.2 mm
F1.6 (Wide), F2.8 (Tele)
Minimum Object Distance 800mm 500 mm (Wide)
800mm (Tele)
10 mm (Wide,Limiter Off)
500 mm (Wide,Limiter On)
800 mm (Tele)
100 mm (Wide,Limiter Off)
500 mm (Wide,Limiter On)
1,500 mm (Tele)
300 mm (Wide)
800 mm (Tele)
Pan/Tilt Angle Pan: ±170°
Tilt: +90°/-30°
Pan: ±175°
Tilt: +90°/-30°
Pan: ±170°
Tilt: +90°/-30°
Pan/Tilt Speed Pan: 0.22° to 60°/s
Tilt: 0.22° to 60°/s
Pan: 0.25° to 60°/s
Tilt: 0.25° to 60°/s
Pan: 0.22° to 60°/s
Tilt: 0.22° to 60°/s
Pan: 0.25° to 60°/s
Tilt: 0.25° to 60°/s
Pan: 0.25° to 60°/s
Tilt: 0.25° to 60°/s
Preset Position 16 6
Image Stabilization On/Off (Optical) On/Off (Optical) On/Off (Optical) No No
Image Flip On/Off On/Off On/Off On/Off On/Off
ND Filter No Off/ND1/ND2 No Off/ 1/4 / 1/16 switchable in menu No
Gamma STD1/STD2/STD3/STD4/CINE1/CINE2/
CINE3/CINE4
Normal/Cinema Normal/Cinema Normal/Cinema No
Interface
HD Video Output HD/SD-SDI(switchable)
Component (Y/Pb/Pr) or RGB,HD,VD or
SYNC
Component (Y/Pb/Pr) or RGB,HD,VD or SYNC –
SD Video Output Composite,Y/C No Composite,Y/C VBS,Y/C
Camera Control Interface RS-232C/RS-422 (VISCA)
External Sync. Input Yes
General
Power Requirements DC 10.8 V to 13.2 V DC 12 V
Power Consumption Max 28.8 W (without optional cards) Max 24 W (without optional cards) Max 28.8 W (without optional cards) Max 18 W (without optional cards) 21.6 W (without optional cards)
Operating Temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage Temperature -4 °F to +140 °F (-20 °C to +60 °C)
Dimensions (W x H x D) 7 7/8 x 10 1/4 x 9 3/8 inch
(198 x 260 x 238 mm)
8 1/4 x 12 1/4 x 8 1/4 inches
(207 x 310.8 x 207 mm)
7 7/8 x 9 3/4 x 9 3/8 inches
(198 x 247 x 238 mm)
6 3/8 x 7 3/8 x 7 5/8 inches
(160.8 x 186 x 193.4 mm)
7 1/8 x 8 3/8 x 8 1/8 inches (180 x 210.1 x 205 mm)
Weight 11 lb 0.37 oz (5.0 kg) 9 lb 15 oz (4.5 kg) 9 lb 15 oz (4.5 kg) 4 lb 4 oz (1.9 kg) 5 lb 8 oz (2.5 kg)
Supplied Accessories IR Remote Commander Unit (1), AC power adaptor (1), AC power cord (1), RS-422 connector plug (1), Ceiling bracket (2), Wire rope (1), Screws (M3 x 8) (7),
Screws (M4 x 8) (1),Operating instructions (1)
IR Remote Commander Unit (1), AC power adaptor (1), AC power cord (1),
RS-422 connector plug (1), Ceiling bracket (2),Wire rope (1), Screws (7),
Operating instructions (1)
This RM-IP10 includes software designed for use with an MS Windows
®
operating system (OS).
U.S. export control regulations may require an export license for export/re-export of the Windows OS
(for details, contact Microsoft Corporation).
HFBK-HD1 HFBK-SD1 HFBK-XG1 HFBK-TS1 BRBK-MF1 BRBK-HSD1 BRBK-HSD2 BRBK-301
Video output D-Sub 15 pin: Component (Y/Pb/Pr) or
RGB,HD,VD or SYNC
BNC x2: HD-SDI
D-Sub 9 pin: Component (Y/Pb/Pr) or
RGB, Composite or Y/C, SYNC
BNC: Composite BNC: SD-SDI
D-Sub 15 pin: RGB, HD, VD
(WXGA/XGA/VGA)
i.LINK 6 pin: HDV OUT
(IEEE1394 S100)
LC Duplex Fiber Connector BNC x2: HD-SDI or SD-SDI BNC x3, HD-SDI or SD-SDI D-Sub 9 pin: Component (Y/Pb/Pr) or
RGB, Composite or Y/C, SYNC
Audio line input — — — Phono jack x2 (L/R) Phono jack x2 (L/R) — — —
* DATA MIX ON/OFF selectable in HD-SDI
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/professional
V-2456-D (MK10595V4) Printed in USA (12/12)
