Sony CVX-V3 User manual

MICROFILM
SERVICE MANUAL
US Model
Canadian Model
CVX-V3
AEP Model
UK Model
CVX-V3P
COLOR VIDEO CAMERA
CVX-V3/ V3P
SPECIFICATIONS
NTSC model: CVX-V3
PAL model : CVX-V3P
Photo: CVX-V3

– 3 –
1. GENERAL ................................................................... 1-1
2. DISASSEMBLY
2-1. Removal of Cabinet (Lower) Assembly ........................ 2-1
2-2. Removal of VA-103 Board............................................. 2-1
2-3. Removal of Camera Head Assembly,
CS-53 Board.................................................................. 2-1
2-4. Removal of Case (B) Assembly .................................... 2-2
2-5. Removal of Lens (CD) PC Board Assembly ................. 2-2
2-6. Circuit Boards Location ................................................. 2-3
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram................................................... 3-1
3-2. Camera (1) Block Diagram ........................................... 3-5
3-3. Camera (2) Block Diagram ........................................... 3-9
3-4. Audio Block Diagram..................................................... 3-11
3-5. Power Block Diagram.................................................... 3-13
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagram............................................ 4-1
4-2. Printed Wiring Boards and Schematic Diagrams ......... 4-5
CD-184 (CCD Imager) Schematic Diagram ................. 4-6
CD-184 (Timing Generator), (Iris Drive, Mic In)
Schematic Diagrams ..................................................... 4-7
CS-53 (Camera, Y/C Process, Mic Amp,
Mode Control) Printed Wiring Board............................. 4-11
CS-53 (Camera, Y/C Process)
Schematic Diagram ....................................................... 4-15
CS-53 (Mode Control) Schematic Diagram .................. 4-21
CS-53 (Mic Amp) Schematic Diagram .......................... 4-23
VA-103 (DC-DC Converter, Video/Audio I/O, LANC I/O),
IF-69 (Interface) Printed Wiring Boards........................ 4-28
VA-103 (DC-DC Converter) Schematic Diagram ......... 4-33
VA-103 (Video/Audio I/O) Schematic Diagram............. 4-36
VA-103 (LANC I/O), IF-69 (Interface)
Schematic Diagrams ..................................................... 4-39
5. ADJUSTMENTS
5-1. Camera Section Adjustment ......................................... 5-1
1-1. Preparations Before Adjustment ................................... 5-1
1-1-1. List of Service Tools ................................................. 5-1
1-1-2. Preparations ............................................................. 5-2
1-1-3. Precaution ................................................................ 5-3
1. Setting the Switch .................................................... 5-3
2. Order of Adjustment ................................................. 5-3
3. Subjects.................................................................... 5-3
1-1-4. Adjustment Remote Commander ............................ 5-4
1. Using the Adjustment Remote Commander ............ 5-4
2. Precaution Upon Using the Adjustment
Remote Commander................................................ 5-4
1-1-5. Data Process............................................................ 5-5
1-2. Initialization of F Page Data.......................................... 5-6
1. Initializing the F Page Data...................................... 5-6
2. Modification of F Page Data .................................... 5-6
3. F Page Table............................................................. 5-6
1-3. Camera System Adjustments .................................. 5-9
1. 28 MHz Origin Oscillation Adjustment ..................... 5-9
2. HALL Adjustment ..................................................... 5-10
3. Picture Frame Setting .............................................. 5-11
4. Color Reproduction Adjustment............................... 5-12
5. IRIS IN/OUT Adjustment.......................................... 5-13
6. Auto White Balance Reference Data Input .............. 5-14
7. Auto White Balance Adjustment .............................. 5-14
8. White Balance Check............................................... 5-15
9. Battery Down Adjustment ........................................ 5-16
6. REPAIR PARTS LIST
6-1. Exploded Views ............................................................. 6-1
6-1-1. Main Section............................................................. 6-1
6-1-2. Camera Head Section.............................................. 6-2
6-2. Electrical Parts List ....................................................... 6-3
TABLE OF CONTENTS
Section Title Page Section Title Page
*The color reproduction frame is shown after the page
of ELECTRICAL PARTS LIST.

2-1
Note: Follow the disassembly procedure in the numerical order given.
2-1. REMOVAL OF CABINET (LOWER)
ASSEMBLY 2-3. REMOVAL OF CAMERA HEAD ASSEMBLY, CS-53 BOARD
2-2. REMOVAL OF VA-103 BOARD
SECTION 2
DISASSEMBLY
CVX-V3/V3P
1Two tapping
screws
3Claw
9Tapping screw
0Two earth leads
4Claw
2Two tapping screws
6Connector
(CN601)
5Cabinet (lower)
assembly
8Flexible flat cable (CN802)
7Flexible flat cable (CN801)
CS-53 Board
2Camera head assembly
1Two connectors
(CN301, 302)
(Note1, 2)
3Three tapping
screws
4CS-53 board
VA-103 Board
1Flexible board
(CN803)
2Four tapping screws
3VA-103 board
Note 1: When remove a connector, don't pull at
wire of connector.
Be in danger of the snapping of a wire.
Note 2: When installing a connector, don't press
down at wire of connector.
Be in danger of the snapping of a wire.

2-2
2-5. REMOVAL OF LENS (CD) PC BOARD ASSEMBLY
6Adjust AE dial to
position of W and
remove the case (M)
assembly in the
direction of arrow.
!º Connector
(CN251)
8Screw
(M2)
!¡ Screw
!™ Screw
1Two screws
4Two screws
(M2)
3Two screws
5Two o rings
Case (F) assembly
7Case (M) assembly
!£ Lens (CD) PC board assembly
2Tripod table assembly
9Open CD-184 board.
Note 1: When remove a connector, don't pull at
wire of connector.
Be in danger of the snapping of a wire.
Note 2: When installing a connector, don't press
down at wire of connector.
Be in danger of the snapping of a wire.
2-4. REMOVAL OF CASE (B) ASSEMBLY
6Two connectors
(CN102, 202)
(Note 1, 2)
7Screw
(M2)
3Two screws
1Two screws
2Two o rings
4Two o rings
5Case (B) assembly
8Earth lead
Note: The lens (CD) PC board assembly is a mechanical
unit which has completely been adjusted in the
factory. So never disassemble the lens (CD) PC
board assembly.

2-3 E
2-6. CIRCUIT BOARDS LOCATION
CS-53 Board
VA-103 Board
IF-69 Board
CD-184
Board
VA-103
VIDEO/AUDIO I/O,
DC-DC CONVERTER,
LANC I/O
()
CS-53
CAMERA,Y/C PROCESS,
MIC AMP, MODE CONTROL
IF-69
(INTERFACE)
()
LENS (CD) PC BOARD ASSEMBLY
(CD-184)
(CCD IMAGER, TIMING GENERATOR, IRIS DRIVE, MIC IN)

CVX-V3/V3P
